Frigidaire FRT18B4A Factory Parts Catalog

Top-mount refrigerator
Hide thumbs Also See for FRT18B4A:

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRT18B4AQ4
FRT18B4A
FRT18B4AT4
FRT18B4A
FRT18B4AW4
FRT18B4A
FRT18B4AZ4
FRT18B4A
MARKET
North America
WIRING DIAGRAM - # 240379007
OWNER'S GUIDE - # 240400105
SERVICE DATA SHEET - # 240379007
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque (right)
R134a
bisque (left)
R134a
white (right)
R134a
white
Publication No.
5995368338
020314
-EN/SERVICE /MLR
390
FACTORY
PARTS CATALO
VOLTS
115
115
115
(left)
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18B4A
©2002 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading

Related Manuals for Frigidaire FRT18B4A

Summary of Contents for Frigidaire FRT18B4A

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18B4AQ4 FRT18B4A R134a bisque (right) FRT18B4AT4 FRT18B4A R134a bisque (left) FRT18B4AW4 FRT18B4A R134a white (right) FRT18B4AZ4 FRT18B4A R134a white (left) MARKET North America WIRING DIAGRAM - # 240379007 OWNER’S GUIDE - # 240400105 SERVICE DATA SHEET - # 240379007 TOP MOUNT REFRIGERATOR...
  • Page 2 Publication No. FRT18B4A 5995368338 DOOR 03/02...
  • Page 3 FRT18B4A Publication No. 5995368338 DOOR A = FRT18B4A (FRT18B4AQ4) B = FRT18B4A (FRT18B4AT4) C = FRT18B4A (FRT18B4AW4) D = FRT18B4A (FRT18B4AZ4) POS. NO PART NO DESCRIPTION 240514605 A B C D Gasket-frzr door,white ,magnetic 240514606 A B C D Gasket-refr door,white ,magnetic 240331401 A B C D Rack-door,20.27"...
  • Page 4 Publication No. FRT18B4A 5995368338 CABINET 03/02...
  • Page 5 FRT18B4A Publication No. 5995368338 CABINET A = FRT18B4A (FRT18B4AQ4) B = FRT18B4A (FRT18B4AT4) C = FRT18B4A (FRT18B4AW4) D = FRT18B4A (FRT18B4AZ4) POS. NO PART NO DESCRIPTION 240355401 A B C D Cover-fan 240367001 A B C D Knob-damper control 5303001028 A B C D Nut,push-on 240367401...
  • Page 6 Publication No. FRT18B4A 5995368338 SHELVES 03/02...
  • Page 7 FRT18B4A Publication No. 5995368338 SHELVES A = FRT18B4A (FRT18B4AQ4) B = FRT18B4A (FRT18B4AT4) C = FRT18B4A (FRT18B4AW4) D = FRT18B4A (FRT18B4AZ4) POS. NO PART NO DESCRIPTION 215667501 A B C D Tray-ice,plastic 5303282284 A B C D Shelf-freezer,"table type" 240362502 A B C D Diffuser-air,top 240362601...
  • Page 8 Publication No. FRT18B4A 5995368338 SYSTEM 03/02...
  • Page 9 FRT18B4A Publication No. 5995368338 SYSTEM A = FRT18B4A (FRT18B4AQ4) B = FRT18B4A (FRT18B4AT4) C = FRT18B4A (FRT18B4AW4) D = FRT18B4A (FRT18B4AZ4) POS. NO PART NO DESCRIPTION 240406404 A B C D Condenser,static 5303208866 A B C D Spacer-cond tube,black 5308000296 A B C D Bracket,condenser mtg ,(4) 5308009617...

  • Page 10: Wiring Schematic

    Publication No. FRT18B4A 5995368338 WIRING SCHEMATIC 03/02...

  • Page 11: Wiring Diagram

    FRT18B4A Publication No. 5995368338 WIRING DIAGRAM # = Fast-moving Parts 03/02 * = Non-Illustrated Parts...
