PRODUCT NO.
BASE MODEL NO.
FRT21NGJB0
FRT21NGJ
FRT21NGJB1
FRT21NGJ
FRT21NGJD0
FRT21NGJ
FRT21NGJD1
FRT21NGJ
FRT21NGJW0
FRT21NGJ
FRT21NGJW1
FRT21NGJ
MARKET
North America
WIRING DIAGRAM - #193832
OWNER'S GUIDE - # 218972200
SERVICE DATA SHEET - # 218755000
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a System
black
R134a System
black
R134a System
almond
R134a System
almond
R134a System
white
R134a System
white
Publication No.
5995332219
000126
-EN/SERVICE /DJH
357
REFRIGERATOR
VOLTS
115
115
115
115
115
115
REFRIGERATOR
Model No.
FRT21NGJ
©2000 White Consolidated Industries, Inc.
All rights reserved
Advertisement
Related Manuals for Frigidaire FRT21NGJ
Summary of Contents for Frigidaire FRT21NGJ
- Page 1 FACTORY PARTS CATALOG REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21NGJB0 FRT21NGJ R134a System black FRT21NGJB1 FRT21NGJ R134a System black FRT21NGJD0 FRT21NGJ R134a System almond FRT21NGJD1 FRT21NGJ R134a System almond FRT21NGJW0 FRT21NGJ R134a System white FRT21NGJW1 FRT21NGJ R134a System white MARKET North America...
- Page 2 Publication No. FRT21NGJ 5995332219 DOOR 01/00...
- Page 3 FRT21NGJ Publication No. 5995332219 DOOR A = FRT21NGJ (FRT21NGJW0) B = FRT21NGJ (FRT21NGJW1) C = FRT21NGJ (FRT21NGJD0) D = FRT21NGJ (FRT21NGJD1) E = FRT21NGJ (FRT21NGJB0) F = FRT21NGJ (FRT21NGJB1) POS. NO PART NO DESCRIPTION 215608913 A B C D - - Gasket-frzr door,white ,magnetic 215608923 - - - - E F...
- Page 4 Publication No. FRT21NGJ 5995332219 CABINET 01/00...
- Page 5 FRT21NGJ Publication No. 5995332219 CABINET A = FRT21NGJ (FRT21NGJW0) B = FRT21NGJ (FRT21NGJW1) C = FRT21NGJ (FRT21NGJD0) D = FRT21NGJ (FRT21NGJD1) E = FRT21NGJ (FRT21NGJB0) F = FRT21NGJ (FRT21NGJB1) POS. NO PART NO DESCRIPTION 5304402655 A B C D E F Cover-fan 5303307351 A B C D E F...
- Page 6 Publication No. FRT21NGJ 5995332219 CABINET 01/00...
- Page 7 FRT21NGJ Publication No. 5995332219 CABINET A = FRT21NGJ (FRT21NGJW0) B = FRT21NGJ (FRT21NGJW1) C = FRT21NGJ (FRT21NGJD0) D = FRT21NGJ (FRT21NGJD1) E = FRT21NGJ (FRT21NGJB0) F = FRT21NGJ (FRT21NGJB1) POS. NO PART NO DESCRIPTION 5308016566 A B C D E F Screw,hex wshr hd ,8-15A x 0.625 ,low profile 5308000107 A B C D E F...
- Page 8 Publication No. FRT21NGJ 5995332219 SHELVES 01/00...
- Page 9 FRT21NGJ Publication No. 5995332219 SHELVES A = FRT21NGJ (FRT21NGJW0) B = FRT21NGJ (FRT21NGJW1) C = FRT21NGJ (FRT21NGJD0) D = FRT21NGJ (FRT21NGJD1) E = FRT21NGJ (FRT21NGJB0) F = FRT21NGJ (FRT21NGJB1) POS. NO PART NO DESCRIPTION 218651900 A B - - - - Mullion,white 218651901 - - C D - -...
- Page 10 Publication No. FRT21NGJ 5995332219 SYSTEM 01/00...
- Page 11 FRT21NGJ Publication No. 5995332219 SYSTEM A = FRT21NGJ (FRT21NGJW0) B = FRT21NGJ (FRT21NGJW1) C = FRT21NGJ (FRT21NGJD0) D = FRT21NGJ (FRT21NGJD1) E = FRT21NGJ (FRT21NGJB0) F = FRT21NGJ (FRT21NGJB1) POS. NO PART NO DESCRIPTION 218657100 A B C D E F Condenser 5304406039 A B C D E F...
-
Page 12: Wiring Schematic
Publication No. FRT21NGJ 5995332219 WIRING SCHEMATIC 01/00... -
Page 13: Wiring Diagram
FRT21NGJ Publication No. 5995332219 WIRING DIAGRAM # = Fast-moving Parts 01/00 * = Non-Illustrated Parts...
