Frigidaire FRT21LR7D Factory Parts Catalog

Top-mount refrigerator with ice-maker
Hide thumbs Also See for FRT21LR7D:

Advertisement

Quick Links

Download this manual
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet
Installation Instructions 240568300
N05L00003.eps N05DCDBBA11.eps N05BAAAAC1.eps N05SACAFX13.eps
N05CAAAAA10.eps 115-1.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
FRT21LR7DK1 FRT21LR7DK2 FRT21LR7DK3 FRT21LR7DS1 FRT21LR7DS2 FRT21LR7DS3
R134a
R134a
R134a
stainless lh
stainless lh
stainless lh
115
115
115
240398801
240398801
240398801
240400111
240400111
240400112
North America North America North America North America North America North America
241538744
241538744
241538744
240379014
240379014
240379014
240568300
240568300
240398801.eps 240398601.eps
Publication No.
5995423976
04/12/10
(EN/SERVICE/WC)
390
R134a
R134a
R134a
stainless rh
stainless rh
stainless rh
115
115
115
240398801
240398801
240398801
240400111
240400111
240400112
241538744
241538744
241538744
240379014
240379014
240379014
240568300
240568300
240568300
TOP-MOUNT
REFRIGERATOR WITH
ICE-MAKER
Model No.
FRT21LR7D
©
Copyright
2004 Home Pr
All rights reserved.
oducts, Inc.

Advertisement

loading

Related Manuals for Frigidaire FRT21LR7D

Summary of Contents for Frigidaire FRT21LR7D

  • Page 1 Product No. FRT21LR7DK1 FRT21LR7DK2 FRT21LR7DK3 FRT21LR7DS1 FRT21LR7DS2 FRT21LR7DS3 Series R134a R134a R134a R134a R134a R134a Color stainless lh stainless lh stainless lh stainless rh stainless rh stainless rh Volts Wiring Diagram 240398801 240398801 240398801 240398801 240398801 240398801 Owner's Guide 240400111 240400111 240400112 240400111...
  • Page 2 Publication No: 5995423976 FRT21LR7D DOOR 21 14B N05DCDBBA11 12/04...
  • Page 3 FRT21LR7D Publication No: 5995423976 DOOR Model Index: A FRT21LR7D (FRT21LR7DK1) B FRT21LR7D (FRT21LR7DK2) C FRT21LR7D (FRT21LR7DK3) D FRT21LR7D (FRT21LR7DS1) E FRT21LR7D (FRT21LR7DS2) F FRT21LR7D (FRT21LR7DS3) POS. NO PART NO. DESCRIPTION 240514611 A B C D E F Gasket, seal, black, frzr door, magnetic 240514612 A B C D E F Gasket, seal, black, refr door, magnetic...
  • Page 4 Publication No: 5995423976 FRT21LR7D CABINET 12/04...
  • Page 5 FRT21LR7D Publication No: 5995423976 CABINET Model Index: A FRT21LR7D (FRT21LR7DK1) B FRT21LR7D (FRT21LR7DK2) C FRT21LR7D (FRT21LR7DK3) D FRT21LR7D (FRT21LR7DS1) E FRT21LR7D (FRT21LR7DS2) F FRT21LR7D (FRT21LR7DS3) POS. NO PART NO. DESCRIPTION 240355402 A B C D E F Cover-fan 240367001 A B C D E F Knob-damper control 5303001028 A B C D E F...
  • Page 6 Publication No: 5995423976 FRT21LR7D SHELVES N05SACAFX13 12/04...
  • Page 7 FRT21LR7D Publication No: 5995423976 SHELVES Model Index: A FRT21LR7D (FRT21LR7DK1) B FRT21LR7D (FRT21LR7DK2) C FRT21LR7D (FRT21LR7DK3) D FRT21LR7D (FRT21LR7DS1) E FRT21LR7D (FRT21LR7DS2) F FRT21LR7D (FRT21LR7DS3) POS. NO PART NO. DESCRIPTION 240358003 A B C D E F Shelf, freezer, full-width, wire 5303299664 A B C D E F Spacer, shelf...
  • Page 8 Publication No: 5995423976 FRT21LR7D SYSTEM N05CAAAAA10 12/04...
  • Page 9 FRT21LR7D Publication No: 5995423976 SYSTEM Model Index: A FRT21LR7D (FRT21LR7DK1) B FRT21LR7D (FRT21LR7DK2) C FRT21LR7D (FRT21LR7DK3) D FRT21LR7D (FRT21LR7DS1) E FRT21LR7D (FRT21LR7DS2) F FRT21LR7D (FRT21LR7DS3) POS. NO PART NO. DESCRIPTION 240444401 A B C D E F Condenser, dynamic 218944001 A B C D E F Drier-filter, R134a System 241607001...
  • Page 10 Publication No: 5995423976 FRT21LR7D SYSTEM N05CAAAAA10 12/04...
  • Page 11 FRT21LR7D Publication No: 5995423976 SYSTEM Model Index: A FRT21LR7D (FRT21LR7DK1) B FRT21LR7D (FRT21LR7DK2) C FRT21LR7D (FRT21LR7DK3) D FRT21LR7D (FRT21LR7DS1) E FRT21LR7D (FRT21LR7DS2) F FRT21LR7D (FRT21LR7DS3) POS. NO PART NO. DESCRIPTION 240553501 A - C D - F Tube-connector, suction 240346201 - B - - E - Tube-connector, suction 240409302...

  • Page 12: Ice Maker

    Publication No: 5995423976 FRT21LR7D ICE MAKER 12/04...
  • Page 13 FRT21LR7D Publication No: 5995423976 ICE MAKER Model Index: A FRT21LR7D (FRT21LR7DK1) B FRT21LR7D (FRT21LR7DK2) C FRT21LR7D (FRT21LR7DK3) D FRT21LR7D (FRT21LR7DS1) E FRT21LR7D (FRT21LR7DS2) F FRT21LR7D (FRT21LR7DS3) POS. NO PART NO. DESCRIPTION 218976901 A B C D E F Tube-water inlet, inlet valve, to ice maker 240561701 A B C D E F Seal-water inlet, inlet valve, to ice maker...

  • Page 14: Wiring Schematic

    Publication No: 5995423976 FRT21LR7D WIRING SCHEMATIC 12/04...

  • Page 15: Wiring Diagram

    FRT21LR7D Publication No: 5995423976 WIRING DIAGRAM 12/04 # Functional Parts * Non-Illustrated Parts...
