PRODUCT NO.
BASE MODEL NO.
FRT18TPHW0
FRT18TPH
MARKET
North America
WIRING DIAGRAM - # 218758400
OWNER'S GUIDE - # 218942600
SERVICE DATA SHEET - #218758400
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a System
white
Publication No.
5995328449
991001
-EN/SERVICE /DJH
390
REFRIGERATOR
VOLTS
115
REFRIGERATOR
Model No.
FRT18TPH
©1999 White Consolidated Industries, Inc.
All rights reserved
Advertisement
Related Manuals for Frigidaire FRT18TPH
Summary of Contents for Frigidaire FRT18TPH
- Page 1 FACTORY PARTS CATALOG REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18TPHW0 FRT18TPH R134a System white MARKET North America WIRING DIAGRAM - # 218758400 OWNER’S GUIDE - # 218942600 SERVICE DATA SHEET - #218758400 REFRIGERATOR Model No. FRT18TPH 101 Masters Blvd. Anderson, SC 29624 Publication No.
- Page 2 Publication No. FRT18TPHW0 5995328449 DOOR 10/99...
- Page 3 FRT18TPHW0 Publication No. 5995328449 DOOR POS. NO PART NO DESCRIPTION 215608916 Gasket-frzr door,white ,magnetic 218730605 Gasket-refr door,white ,magnetic 218360001 Panel-inner door,refr 218027022 Rack-door,23.81" x 1.62" 215267701 Support-door rack,"2-liter" ,RH/LH 215473602 Support-door rack,RH/LH 218287801 Door-dairy,10.71" wide ,white ,no graphics 218360101 Panel-inner door,frzr 5308000134 Plug-button,white ,hinge brg hole 5303917805...
- Page 4 Publication No. FRT18TPHW0 5995328449 CABINET 10/99...
- Page 5 FRT18TPHW0 Publication No. 5995328449 CABINET POS. NO PART NO DESCRIPTION 218672501 Cover-fan 5303307351 Knob-damper control 5303001028 Nut,push-on 218722200 Damper-fan cover,black 218649000 Fan Blade,black 218448301 Cover,white ,lwr hinge hole 5300157666 Bushing-motor mtg,(2) 5303205118 Bracket-motor mtg,front 3206451 Cover-evap coil 5303208309 Plug-hole,factory test 215079000 Plug-harness hole,round 215079100...
- Page 6 Publication No. FRT18TPHW0 5995328449 SHELVES 10/99...
- Page 7 FRT18TPHW0 Publication No. 5995328449 SHELVES POS. NO PART NO DESCRIPTION 218874301 Mullion,white 218781003 Heater-mullion 218845602 Tapping Plate,mullion mtg ,(2) 218814800 Panel-top,refr cavity 218872903 Divider,styrofoam ,w/foil tape 8* # 218878500 Wiring Harness,control/divider 218814700 Panel-bottom,frzr cavity 215667501 Tray-ice,plastic 5303288242 Shelf-freezer,fixed/flat ,full width ,wire 5303299664 Spacer-shelf 218730000...
- Page 8 Publication No. FRT18TPHW0 5995328449 SYSTEM 10/99...
- Page 9 FRT18TPHW0 Publication No. 5995328449 SYSTEM POS. NO PART NO DESCRIPTION 218173900 Condenser 5303208866 Spacer-cond tube,black 5308009617 Washer,ext tooth lock ,#10 ,grounding 5308000296 Bracket,condenser mtg ,(4) 218944001 Drier-filter,R134a System 218878500 Wiring Harness,control/divider 215257004 Wiring Harness,compressor 5316254901 Cord-electric power 5303001197 Cover-wiring 13 # 218429306 Heat Exchanger,suction line 14 #...
-
Page 10: Wiring Schematic
Publication No. FRT18TPHW0 5995328449 WIRING SCHEMATIC 10/99... -
Page 11: Wiring Diagram
FRT18TPHW0 Publication No. 5995328449 WIRING DIAGRAM W193832 # = Fast-moving Parts 10/99 * = Non-Illustrated Parts...
