Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet
Installation Instructions 240568303
N05L00004.eps N05DCDBCA1.eps N05BBAABA17.eps N05SAAAFI21.eps
N05CAABAD4.eps
W241582401.eps S241582801.eps
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
FRT18HS6JB0 FRT18HS6JK0 FRT18HS6JM0 FRT18HS6JQ0 FRT18HS6JS0 FRT18HS6JW0
R134a
R134a
R134a
black
stainless (LH) silver mist
115
115
115
241582401
241582401
241582401
241857201
241857201
241857201
North America North America North America North America North America North America
241868083
241868083
241868083
241588203
241588203
241588203
240568303
240568303
Publication No.
5995506713
08/02/12
(EN/SERVICE/KHB)
390
R134a
R134a
R134a
bisque
stainless (RH) white
115
115
115
241582401
241582401
241582401
241857201
241857201
241857201
241868083
241868083
241868083
241588203
241588203
241588203
240568303
240568303
240568303
TOP-MOUNT
REFRIGERATOR
Model No.
FRT18HS6J
©
Copyright
All rights reserved.
Advertisement
Related Manuals for Frigidaire FRT18HS6J
Summary of Contents for Frigidaire FRT18HS6J
- Page 1 Product No. FRT18HS6JB0 FRT18HS6JK0 FRT18HS6JM0 FRT18HS6JQ0 FRT18HS6JS0 FRT18HS6JW0 Series R134a R134a R134a R134a R134a R134a Color black stainless (LH) silver mist bisque stainless (RH) white Volts Wiring Diagram 241582401 241582401 241582401 241582401 241582401 241582401 Owner's Guide 241857201 241857201 241857201 241857201 241857201 241857201 Market...
- Page 2 Publication No: 5995506713 FRT18HS6J DOOR N05DCDBCA1 02/08...
- Page 3 FRT18HS6J Publication No: 5995506713 DOOR Model Index: A FRT18HS6J (FRT18HS6JB0) B FRT18HS6J (FRT18HS6JK0) C FRT18HS6J (FRT18HS6JM0) D FRT18HS6J (FRT18HS6JQ0) E FRT18HS6J (FRT18HS6JS0) F FRT18HS6J (FRT18HS6JW0) POS. NO PART NO. DESCRIPTION 241872509 A B C - E - Gasket-frzr door, black, magnetic 241872503 - - - D - F Gasket-frzr door, white, magnetic...
- Page 4 Publication No: 5995506713 FRT18HS6J CABINET 02/08...
- Page 5 FRT18HS6J Publication No: 5995506713 CABINET Model Index: A FRT18HS6J (FRT18HS6JB0) B FRT18HS6J (FRT18HS6JK0) C FRT18HS6J (FRT18HS6JM0) D FRT18HS6J (FRT18HS6JQ0) E FRT18HS6J (FRT18HS6JS0) F FRT18HS6J (FRT18HS6JW0) POS. NO PART NO. DESCRIPTION 241652301 A B C D E F Cover-fan 240367001 A B C D E F Knob-damper control 5303001028 A B C D E F...
- Page 6 Publication No: 5995506713 FRT18HS6J CABINET 02/08...
- Page 7 FRT18HS6J Publication No: 5995506713 CABINET Model Index: A FRT18HS6J (FRT18HS6JB0) B FRT18HS6J (FRT18HS6JK0) C FRT18HS6J (FRT18HS6JM0) D FRT18HS6J (FRT18HS6JQ0) E FRT18HS6J (FRT18HS6JS0) F FRT18HS6J (FRT18HS6JW0) POS. NO PART NO. DESCRIPTION 241839406 - - - D - - Grille/Kickplate, bisque 241839405 - - - - - F Grille/Kickplate, white 5304455650...
- Page 8 Publication No: 5995506713 FRT18HS6J SHELVES N05SAAAFI21 02/08...
- Page 9 FRT18HS6J Publication No: 5995506713 SHELVES Model Index: A FRT18HS6J (FRT18HS6JB0) B FRT18HS6J (FRT18HS6JK0) C FRT18HS6J (FRT18HS6JM0) D FRT18HS6J (FRT18HS6JQ0) E FRT18HS6J (FRT18HS6JS0) F FRT18HS6J (FRT18HS6JW0) POS. NO PART NO. DESCRIPTION 240358005 A B C D E F Shelf, freezer, full-width, wire 241542001 A B C D E F Diffuser, air, top...
- Page 10 Publication No: 5995506713 FRT18HS6J SYSTEM 24 25 N05CAABAD4 02/08...
- Page 11 FRT18HS6J Publication No: 5995506713 SYSTEM Model Index: A FRT18HS6J (FRT18HS6JB0) B FRT18HS6J (FRT18HS6JK0) C FRT18HS6J (FRT18HS6JM0) D FRT18HS6J (FRT18HS6JQ0) E FRT18HS6J (FRT18HS6JS0) F FRT18HS6J (FRT18HS6JW0) POS. NO PART NO. DESCRIPTION 241785404 A B C D E F Condenser, dynamic 218944002 A B C D E F Drier-filter, R134a System 241607001...
-
Page 12: Wiring Schematic
Publication No: 5995506713 FRT18HS6J WIRING SCHEMATIC 02/08... -
Page 13: Wiring Diagram
FRT18HS6J Publication No: 5995506713 WIRING DIAGRAM 02/08 # Functional Parts * Non-Illustrated Parts...
