Frigidaire FRT18B6C Factory Parts Catalog
Top-mount refrigerator
Hide thumbs
Also See for FRT18B6C:
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
PRODUCT NO.
BASE MODEL NO.
FRT18B6CB3
FRT18B6C
MARKET
North America
ENERGY GUIDE - 240572124
OWNER'S GUIDE - 240400109
SERVICE DATA SHEET - 240379012
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
black
Publication No.
5995398418
031105
-EN/SERVICE /DCS
357
FACTORY
PARTS CATALO
VOLTS
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18B6C
©2003 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT18B6C
Summary of Contents for Frigidaire FRT18B6C
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18B6CB3 FRT18B6C R134a black MARKET North America ENERGY GUIDE - 240572124 OWNER’S GUIDE - 240400109 SERVICE DATA SHEET - 240379012 TOP MOUNT REFRIGERATOR Model No. ELECTROLUX HOME PRODUCTS, INC. FRT18B6C P.O.
- Page 2 Publication No. FRT18B6CB3 5995398418 DOOR 11/03...
- Page 3 FRT18B6CB3 Publication No. 5995398418 DOOR POS. NO PART NO DESCRIPTION 240514609 Gasket,frzr door seal ,black ,magnetic 240514612 Gasket,seal ,black ,refr door ,magnetic 240337701 Door-dairy,w/o graphics ,white 240381303 Plug-button,black ,hinge brg hole 240476203 Panel-frzr door,black ,complete assy 240415204 Label-nameplate,black 240312405 Door Stop,black ,refr 240312406 Door Stop,black ,frzr 240494003...
- Page 4 Publication No. FRT18B6CB3 5995398418 CABINET 11/03...
- Page 5 FRT18B6CB3 Publication No. 5995398418 CABINET POS. NO PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240462010 Cover-evap coil 240568605 Seal-coil cover 10*# 240524701 Wiring Harness,freezer section 5303208309 Plug-hole,factory test 240366801...
- Page 6 Publication No. FRT18B6CB3 5995398418 SHELVES 11/03...
- Page 7 FRT18B6CB3 Publication No. 5995398418 SHELVES POS. NO PART NO DESCRIPTION 215667501 Tray,ice cube ,plastic 5303282284 Shelf-freezer,"table type" 240362502 Diffuser,air ,top 240362601 Diffuser,air ,bottom 240505801 Switch,light/lamp 240436702 Light Bulb/Lamp,A-15 ,clear ,40 W ,120 V,miniature 241500701 Socket-light/lamp 240352701 Control Box 17*# 240388701 Wiring Harness,control box 240360801 Knob,temp control...
- Page 8 Publication No. FRT18B6CB3 5995398418 SYSTEM 11/03...
- Page 9 FRT18B6CB3 Publication No. 5995398418 SYSTEM POS. NO PART NO DESCRIPTION 240444401 Condenser,dynamic 218944001 Drier-filter,R134a System 240581701 Harness-wiring,machine compt 6* # 240388701 Wiring Harness,control box 6* # 240524701 Wiring Harness,freezer section 6* # 240581801 Harness-wiring,compressor 14 # 5303918208 Defrost Heater Kit 15 # 5303918274 Evaporator Kit...
-
Page 10: Wiring Schematic
Publication No. FRT18B6CB3 5995398418 WIRING SCHEMATIC 11/03... -
Page 11: Wiring Diagram
FRT18B6CB3 Publication No. 5995398418 WIRING DIAGRAM # = Fast-moving Parts 11/03 * = Non-Illustrated Parts...
