Dymo LabelPOINT 150 User Manual

About Your New Labelmaker
With your DYMO LabelPOINT
you can create a wide variety of high-quality, self-
adhesive labels. You can choose to print your
labels in many different sizes and styles. The
labelmaker uses DYMO D1 tape cassettes in
widths of 9 mm (3/8") and 12 mm (1/2"). Tape
cassettes are also available in a wide range of
colors.
Visit www.dymo.com for information on obtaining
labels and accessories for your labelmaker.

Warranty Registration

Please complete the warranty registration card and
return it to the appropriate customer service
address within seven days. Visit www.dymo.com
for details.

Getting Started

Follow the instructions in this section to print your
first label.

Connecting the Power

The labelmaker is powered by six AAA batteries.
To save power, the labelmaker will automatically
turn off after two minutes of inactivity.
To insert the batteries
1. Remove the battery compartment cover. See
Figure 2.
Figure 2
™
150 labelmaker,
2. Insert the batteries following the
polarity markings (+ and –).
3. Replace the battery compartment cover.
Remove the batteries if the labelmaker will
not be used for a long period of time.

Inserting the Tape Cassette

Your labelmaker comes with one tape cassette.
Visit www.dymo.com for information about
purchasing additional tape cassettes.
To insert the tape cassette
1. Press and release the tape cassette cover to
open the label compartment. See Figure 3.
Figure 3
The first time you use the labelmaker,
remove the protective cardboard insert from
between the print head and pinch roller. See
Figure 3.
2. Make sure the tape and ribbon are taut across
the mouth of the cassette and that the tape
passes between the guideposts. If necessary,
turn the spool clockwise to tighten the ribbon.
3. Insert the cassette with the tape and ribbon
positioned between the print head and pinch
roller. See Figure 4.
GB
Remove
cardboard insert
3
