- Page 1 User's Guide MADI Converter 6 x Bidirectional MADI Optical to BNC Converter 6 coaxial Inputs and Outputs 6 optical Inputs and Outputs 1 to 3 MIDI Distributor...
-
Page 2: Table Of Contents
Operation with MADI Bridge ................5 Inputs and Outputs 6.1 MADI Inputs ......................6 6.2 MADI Outputs .....................6 6.3 MIDI Input and Outputs..................6 Technical Background 7.1 MADI Basics .......................7 7.2 MADI Converter Technology ................8 Block Diagram ....................9 Warranty......................10 Appendix ......................10 User's Guide MADI Converter © RME... -
Page 3: Introduction
Additionally, a MIDI distributor copies one MIDI input signal to three MIDI outputs, removing the need for an external MIDI distributor. The MADI converter is an ideal companion to RME's MADI Bridge. The Bridge's six coaxial inputs and outputs can be converted to optical, a format which is advantageous in live and in- stalled setups, and for longer cable lengths. -
Page 4: Operation
LEDs to turn on as well. • The MIDI INPUT LED shows any MIDI activity, including MIDI Clock, MTC and Active Sens- ing. The latter is sent by most keyboards every 0.3 seconds. User's Guide MADI Converter © RME... -
Page 5: Operation With Madi Bridge
Thanks to interchanged inputs and outputs, the cabling is done without crossing and cluttering, maintaining perfect overview. User's Guide MADI Converter © RME... -
Page 6: Inputs And Outputs
The rear of the MADI Converter offers one MIDI input and three MIDI outputs via 5-pin DIN jacks. All MIDI data at the MIDI input are passed on and copied to the outputs, a method known as MIDI Thru function. User's Guide MADI Converter © RME... -
Page 7: Technical Background
2 km. Single mode allows for much longer distances, but it uses a completely different fibre (8 µm). By the way, due to the wave-length of the light being used (1300 nm), the opti- cal signal is invisible to the human eye. User's Guide MADI Converter © RME... -
Page 8: Madi Converter Technology
MADI Converter travels dou- ble the distance. RME's MADI Converter uses adapted termination and a special equalizing, to reach higher cable lengths despite its simpler design. The MADI Converter can even serve as cable buffer for the limited outpus of some manufacturers (90 meter coaxial instead of 30 meter...). -
Page 9: Block Diagram
8. Block Diagram User's Guide MADI Converter © RME... -
Page 10: Warranty
RME does not accept responsibility for any misleading or incorrect information within this guide. Lending or copying any part of the guide or the RME Driver CD, or any commercial exploitation of these media without express written permission from RME Intelligent Audio Solutions is prohibited. RME reserves the right to change specifi- cations at any time without notice. - Page 11 • Use power outlets on different branch circuits, or install AC line filters • Contact your local retailer or any qualified radio and television engineer FCC compliance statement: Tested to comply with FCC standards for home or office use. User's Guide MADI Converter © RME...
