Frigidaire FRS26ZGH Factory Parts Catalog

Frigidaire FRS26ZGH Factory Parts Catalog

Side by side
Hide thumbs Also See for FRS26ZGH:

Advertisement

Table of Contents

PRODUCT NO.
BASE MODEL NO.
FRS26ZGHB0
FRS26ZGH
FRS26ZGHD0
FRS26ZGH
FRS26ZGHW0
FRS26ZGH
MARKET
North American
WIRING DIAGRAM - # 218875901
OWNER'S GUIDE - # 218908400
SERVICE DATA SHEET - # 218909400
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
GALLERY R134a
black
GALLERY R134a
almond
GALLERY R134a
white
Publication No.
5995323283
990517
-EN/SERVICE/KB
357

SIDE BY SIDE

REFRIGERATOR
VOLTS
115
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS26ZGH
©1999 White Consolidated Industries, Inc.
All rights reserved

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire FRS26ZGH

Summary of Contents for Frigidaire FRS26ZGH

  • Page 1: Side By Side

    FACTORY PARTS CATALOG SIDE BY SIDE REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRS26ZGHB0 FRS26ZGH GALLERY R134a black FRS26ZGHD0 FRS26ZGH GALLERY R134a almond FRS26ZGHW0 FRS26ZGH GALLERY R134a white MARKET North American WIRING DIAGRAM - # 218875901 OWNER’S GUIDE - # 218908400 SERVICE DATA SHEET - # 218909400 SIDE BY SIDE REFRIGERATOR...

  • Page 2: Freezer Door

    Publication No. FRS26ZGH 5995323283 FREEZER DOOR 05/99...
  • Page 3 FRS26ZGH Publication No. 5995323283 FREEZER DOOR A = FRS26ZGH (FRS26ZGHB0) B = FRS26ZGH (FRS26ZGHD0) C = FRS26ZGH (FRS26ZGHW0) POS. NO PART NO DESCRIPTION 215734323 A - - Gasket-frzr door,black ,magnetic 215734303 - B - Gasket-frzr door,almond ,magnetic 215734313 - - C Gasket-frzr door,white ,magnetic 5303288950 A B C...

  • Page 4: Refrigerator Door

    Publication No. FRS26ZGH 5995323283 REFRIGERATOR DOOR 05/99...
  • Page 5 FRS26ZGH Publication No. 5995323283 REFRIGERATOR DOOR A = FRS26ZGH (FRS26ZGHB0) B = FRS26ZGH (FRS26ZGHD0) C = FRS26ZGH (FRS26ZGHW0) POS. NO PART NO DESCRIPTION 215734324 A - - Gasket-refr door,black ,magnetic 215734304 - B - Gasket-refr door,almond ,magnetic 215734314 - - C Gasket-refr door,white ,magnetic 215403201 A B C...
  • Page 6 Publication No. FRS26ZGH 5995323283 CABINET 05/99...
  • Page 7 FRS26ZGH Publication No. 5995323283 CABINET A = FRS26ZGH (FRS26ZGHB0) B = FRS26ZGH (FRS26ZGHD0) C = FRS26ZGH (FRS26ZGHW0) POS. NO PART NO DESCRIPTION 215637602 A B C Cover-air duct 5303209814 A B C Nut,"U" type ,8-15(A) ,fan mtr mtg 215637401 A B C Cover-evap coil,lower 5303208309 A B C...
  • Page 8 Publication No. FRS26ZGH 5995323283 SHELVES 05/99...
  • Page 9 FRS26ZGH Publication No. 5995323283 SHELVES A = FRS26ZGH (FRS26ZGHB0) B = FRS26ZGH (FRS26ZGHD0) C = FRS26ZGH (FRS26ZGHW0) POS. NO PART NO DESCRIPTION 5303298147 A B C Trim-basket 218298003 A B C Shelf-freezer,sliding ,wire 218298004 A B C Shelf-freezer,sliding ,wire 218815501 A B C Shelf-pizza,24B 215029002...
  • Page 10 Publication No. FRS26ZGH 5995323283 CONTROLS 05/99...
  • Page 11 FRS26ZGH Publication No. 5995323283 CONTROLS A = FRS26ZGH (FRS26ZGHB0) B = FRS26ZGH (FRS26ZGHD0) C = FRS26ZGH (FRS26ZGHW0) POS. NO PART NO DESCRIPTION 5303307883 A B C Knob-damper control,white/teal line 5308000010 A B C Fan Blade,red 5308000124 A B C Ring-fan orifice 5300157666 A B C Bushing-motor mtg,(2)
  • Page 12 Publication No. FRS26ZGH 5995323283 SYSTEM 05/99...
  • Page 13 FRS26ZGH Publication No. 5995323283 SYSTEM A = FRS26ZGH (FRS26ZGHB0) B = FRS26ZGH (FRS26ZGHD0) C = FRS26ZGH (FRS26ZGHW0) POS. NO PART NO DESCRIPTION 218787900 A B C Condenser 5303208866 A B C Spacer-cond tube,black 5303289026 A B C Spacer-tube 5303289029 A B C Clip-cond mtg,(4) 218679603 A B C...
  • Page 14 Publication No. FRS26ZGH 5995323283 DISPENSER 05/99...
  • Page 15 FRS26ZGH Publication No. 5995323283 DISPENSER A = FRS26ZGH (FRS26ZGHB0) B = FRS26ZGH (FRS26ZGHD0) C = FRS26ZGH (FRS26ZGHW0) POS. NO PART NO DESCRIPTION 5318582501 A B C Tube-water inlet,93" ,plastic, cut-to-size 215294101 A B C Tube-water inlet,formed ,plastic, dispenser 218832301 A B C Tube-water inlet,inlet valve ,to filter 218505303 A - -...

  • Page 16: Ice Container

    Publication No. FRS26ZGH 5995323283 ICE CONTAINER 05/99...
  • Page 17 FRS26ZGH Publication No. 5995323283 ICE CONTAINER A = FRS26ZGH (FRS26ZGHB0) B = FRS26ZGH (FRS26ZGHD0) C = FRS26ZGH (FRS26ZGHW0) POS. NO PART NO DESCRIPTION 5304404344 A B C Auger-ice 5304404343 A B C Cam-drive 218815300 A B C Container-ice 5304404346 A B C Drum-ice disp 218815400 A B C...

  • Page 18: Ice Maker

    Publication No. FRS26ZGH 5995323283 ICE MAKER 05/99...
  • Page 19 FRS26ZGH Publication No. 5995323283 ICE MAKER A = FRS26ZGH (FRS26ZGHB0) B = FRS26ZGH (FRS26ZGHD0) C = FRS26ZGH (FRS26ZGHW0) POS. NO PART NO DESCRIPTION 5318582501 A B C Tube-water inlet,93" ,plastic, cut-to-size 215294101 A B C Tube-water inlet,formed ,plastic, dispenser 218832301 A B C Tube-water inlet,inlet valve ,to filter 3206348...

  • Page 20: Wiring Schematic

    Publication No. FRS26ZGH 5995323283 WIRING SCHEMATIC 05/99...

  • Page 21: Wiring Diagram

    FRS26ZGH Publication No. 5995323283 WIRING DIAGRAM # = Fast-moving Parts 05/99 * = Non-Illustrated Parts...
