Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet 240389638
N58L00003.eps F58FFDEAA0.eps N58RFDAAB4.eps E58BAAAAE0.eps
F58SKDUBK10.eps F58TEBCAE0.eps N58CAAAAC14.eps F58XFAAAA0.eps
N58YDAAAC4.eps N58I115TServo.eps W241912901.eps S241912901.eps
P.O. BOX 212378
AUGUSTA, GA 30917
FGHS2367KB1 FGHS2367KE1 FGHS2367KP1 FGHS2367KW1
Gallery
Gallery
Gallery
black
black
white
115
115
115
241912901
241912901
241912901
241979200
241979200
241979200
North America North America North America North America
241935569
241935569
241935569
240389638
240389638
Publication No.
5995538419
09/04/17
(EN/SERVICE/DCS)
137
Gallery
white
115
241912901
241979200
241935569
240389638
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FGHS2367K
©
Copyright
All rights reserved.
Advertisement
Table of Contents
Related Manuals for Frigidaire FGHS2367K
Summary of Contents for Frigidaire FGHS2367K
- Page 1 Product No. FGHS2367KB1 FGHS2367KE1 FGHS2367KP1 FGHS2367KW1 Series Gallery Gallery Gallery Gallery Color black black white white Volts Wiring Diagram 241912901 241912901 241912901 241912901 Owner's Guide 241979200 241979200 241979200 241979200 Market North America North America North America North America Energy Guide 241935569 241935569 241935569...
-
Page 2: Freezer Door
Publication No: 5995538419 FGHS2367K FREEZER DOOR F58FFDEAA0 04/09... - Page 3 FGHS2367K Publication No: 5995538419 FREEZER DOOR Model Index: A FGHS2367K (FGHS2367KB1) B FGHS2367K (FGHS2367KE1) C FGHS2367K (FGHS2367KP1) D FGHS2367K (FGHS2367KW1) POS. NO PART NO. DESCRIPTION 241786008 A B - - Gasket-frzr door, black, magnetic 241786004 - - C D Gasket-frzr door, white, magnetic 240367301 A B C D Bin-door, frzr-upper...
-
Page 4: Refrigerator Door
Publication No: 5995538419 FGHS2367K REFRIGERATOR DOOR N58RFDAAB4 04/09... - Page 5 FGHS2367K Publication No: 5995538419 REFRIGERATOR DOOR Model Index: A FGHS2367K (FGHS2367KB1) B FGHS2367K (FGHS2367KE1) C FGHS2367K (FGHS2367KP1) D FGHS2367K (FGHS2367KW1) POS. NO PART NO. DESCRIPTION 241786007 A B - - Gasket-refr door, black, magnetic 241786003 - - C D Gasket-refr door, white, magnetic 240363702 A B C D Bin-door, 2-liter...
- Page 6 Publication No: 5995538419 FGHS2367K CABINET E58BAAAAE0 04/09...
- Page 7 FGHS2367K Publication No: 5995538419 CABINET Model Index: A FGHS2367K (FGHS2367KB1) B FGHS2367K (FGHS2367KE1) C FGHS2367K (FGHS2367KP1) D FGHS2367K (FGHS2367KW1) POS. NO PART NO. DESCRIPTION 240435913 A B C D Cover-air duct 241719710 A B C D Cover-evap coil, lower 5303208309 A B C D Plug-hole, factory test 14A#...
- Page 8 Publication No: 5995538419 FGHS2367K SHELVES 108A 107B F58SKDUBK10 04/09...
- Page 9 FGHS2367K Publication No: 5995538419 SHELVES Model Index: A FGHS2367K (FGHS2367KB1) B FGHS2367K (FGHS2367KE1) C FGHS2367K (FGHS2367KP1) D FGHS2367K (FGHS2367KW1) POS. NO PART NO. DESCRIPTION 241510609 A B C D Trim-basket 241992913 A B C D Shelf-freezer, glass, upper 241992914 A B C D Shelf-freezer, glass, lower 241552801 A B C D...
- Page 10 Publication No: 5995538419 FGHS2367K CONTROLS 210A F58TEBCAE0 04/09...
- Page 11 FGHS2367K Publication No: 5995538419 CONTROLS Model Index: A FGHS2367K (FGHS2367KB1) B FGHS2367K (FGHS2367KE1) C FGHS2367K (FGHS2367KP1) D FGHS2367K (FGHS2367KW1) POS. NO PART NO. DESCRIPTION 5308000010 A B C D Fan Blade, red, evaporator fan 215474201 A B C D Washer, "slinger", nylon, evap fan shaft 241563601 A B C D Bushing-motor mtg...
- Page 12 Publication No: 5995538419 FGHS2367K SYSTEM N58CAAAAC14 04/09...
- Page 13 FGHS2367K Publication No: 5995538419 SYSTEM Model Index: A FGHS2367K (FGHS2367KB1) B FGHS2367K (FGHS2367KE1) C FGHS2367K (FGHS2367KP1) D FGHS2367K (FGHS2367KW1) POS. NO PART NO. DESCRIPTION 240333602 A B C D Condenser 218679606 A B C D Block-evap coil, styrofoam, (2) 218944001 A B C D Drier-filter, R134a System 241516901...
-
Page 14: Ice And Water Dispenser
Publication No: 5995538419 FGHS2367K ICE & WATER DISPENSER F58XFAAAA0 04/09... - Page 15 FGHS2367K Publication No: 5995538419 ICE & WATER DISPENSER Model Index: A FGHS2367K (FGHS2367KB1) B FGHS2367K (FGHS2367KE1) C FGHS2367K (FGHS2367KP1) D FGHS2367K (FGHS2367KW1) POS. NO PART NO. DESCRIPTION 218976419 A B C D Tube-water inlet, valve to door 218976429 A B C D Tube-water inlet, 97.50", brown/tan 218976915 A B C D...
-
Page 16: Ice Container
Publication No: 5995538419 FGHS2367K ICE CONTAINER 37A 34 34 33 N58YDAAAC4 04/09... - Page 17 FGHS2367K Publication No: 5995538419 ICE CONTAINER Model Index: A FGHS2367K (FGHS2367KB1) B FGHS2367K (FGHS2367KE1) C FGHS2367K (FGHS2367KP1) D FGHS2367K (FGHS2367KW1) POS. NO PART NO. DESCRIPTION 241716101 A B C D Auger-ice 241685201 A B C D Cam-drive 241561302 A B C D Container-ice, bucket only 241685101 A B C D...
-
Page 18: Ice Maker
Publication No: 5995538419 FGHS2367K ICE MAKER INSTALLATION PARTS N58I115TServo 04/09... - Page 19 FGHS2367K Publication No: 5995538419 ICE MAKER Model Index: A FGHS2367K (FGHS2367KB1) B FGHS2367K (FGHS2367KE1) C FGHS2367K (FGHS2367KP1) D FGHS2367K (FGHS2367KW1) POS. NO PART NO. DESCRIPTION 218976419 A B C D Tube-water inlet, valve to door 218976429 A B C D Tube-water inlet, 97.50", brown/tan 218976915 A B C D...
- Page 20 Publication No: 5995538419 FGHS2367K ICE MAKER INSTALLATION PARTS N58I115TServo 04/09...
- Page 21 FGHS2367K Publication No: 5995538419 ICE MAKER Model Index: A FGHS2367K (FGHS2367KB1) B FGHS2367K (FGHS2367KE1) C FGHS2367K (FGHS2367KP1) D FGHS2367K (FGHS2367KW1) POS. NO PART NO. DESCRIPTION 5304455651 A B C D Screw, hex washer head, 8-15A x 0.500 5304455846 A B C D Clamp, .31 ID, steel, water tube 5304458374 A B C D...
-
Page 22: Wiring Schematic
Publication No: 5995538419 FGHS2367K WIRING SCHEMATIC 04/09... -
Page 23: Wiring Diagram
FGHS2367K Publication No: 5995538419 WIRING DIAGRAM 04/09 # Functional Parts * Non-Illustrated Parts...
