T1- - NAC
T1- - NHP
LEGACY LINE- - RNC
NON- -PROGRAMMABLE THERMOSTAT
US patents: US20060165149 A1, USD578026 SI, US6205041 B1
Legacy Line ---RNC Non ---Programmable Thermostat
NOTE: Read the entire instruction manual before starting the
installation.
TABLE OF CONTENTS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SAFETY CONSIDERATIONS
Improper installation, adjustment, alteration, service, maintenance,
or use can cause explosion, fire, electrical shock, or other
conditions which may cause death, personal injury, or property
damage. Consult a qualified installer, service agency, or your
distributor or branch for information or assistance. The qualified
installer or agency muse use factory- -authorized kits or accessories
when modifying this product. Refer to the individual instructions
packaged with the kits or accessories when installing.
Installation Instructions
. . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . .
Follow all safety codes. Wear safety glasses, protective clothing,
and work gloves. Have a fire extinguisher available. Read these
instructions thoroughly and follow all warnings or cautions
included in literature and attached to the unit. Consult local
building codes and the current editions of the National Electrical
Code (NEC) NFPA 70.
In Canada, refer to the current editions of the Canadian Electrical
Code CSA C22.1.
Recognize safety information. This is the safety- -alert symbol
When you see this symbol on the unit and in the instructions or
manuals, be alert to the potential for personal injury.
Understand the signal words DANGER, WARNING, and
CAUTION. These words are used with the safety- -alert symbol.
DANGER identifies the most serious hazards which will result in
severe personal injury or death. WARNING signifies a hazard
which could result in personal injury or death. CAUTION is used
to identify unsafe practices which may result in minor personal
injury or product and property damage. NOTE is used to highlight
suggestions which will result in enhanced installation, reliability, or
operation.
The Legacy Line- -RNC Series thermostat is an electronic 24VAC,
non- -programmable, manual changeover wall mount thermostat.
A07110
This thermostat uses a single setpoint to maintain and control room
temperature in both the heating and air conditioning modes. The
thermostat is designed to maintain +/- - 2_F accuracy. No batteries
are required; temperature, fan, mode, and installer configuration
settings are preserved with power off.
INSTALLATION CONSIDERATIONS
PAGE
Air Conditioner Model
1
T1- -NAC, Legacy Line- -RNC Series Model air conditioner
1
thermostat, may be wired with or without connecting a common
1
wire between the indoor equipment and the thermostat. However, it
is recommended to use a common wire whenever possible.
2
Without a common wire this thermostat becomes "power stealing."
2
This means it will need to steal a small amount of power from the
2
equipment to which it is connected.
NOTE:
Not all HVAC equipment is compatible with power
2
stealing type thermostats. All Bryant equipment is directly
3
compatible with this thermostat except the Thermostat Conversion
3
Kit, Part #TSTATXXCNV10. For all non- -Bryant equipment,
consult the system equipment Installation Instructions before
4
applying this thermostat in a power stealing manner.
Heat Pump Model
T1- -NHP, Legacy Line- -RNC Series Model heat pump thermostat,
is compatible with all Bryant heat pump systems. It is NOT power
stealing and MUST have both the R and C terminals connected to
operate properly. This thermostat uses a green LED to indicate
auxiliary heat and emergency heat operation.
INTRODUCTION
.
Advertisement
Table of Contents
Related Manuals for Bryant LEGACY LINE-RNC T1-NAC
Summary of Contents for Bryant LEGACY LINE-RNC T1-NAC
-
Page 1: Table Of Contents
T1- -NHP, Legacy Line- -RNC Series Model heat pump thermostat, or use can cause explosion, fire, electrical shock, or other is compatible with all Bryant heat pump systems. It is NOT power conditions which may cause death, personal injury, or property stealing and MUST have both the R and C terminals connected to damage. -
Page 2: Installation
INSTALLATION Any excess wire left inside thermostat casing may also af- fect thermostat operation by interfering with airflow across Step 1 — Thermostat Location the temperature sensor. Thermostat should be mounted: 9. Snap thermostat together making sure terminal block con- S Approximately 5 ft (1.5m) from floor. -
Page 3: Step 4 - Thermostat Operation
Available Selection: output is turned on for 9 minutes and then satisfies, it cannot turn back on for another 6 minutes regardless of demand). However, Use UP and DOWN buttons to change between F and C. pressing UP and FAN buttons simultaneously or changing the Option 04 —... -
Page 4: Wiring Diagrams
Fig. 2 - - HP Thermostat Typical Installation Catalog No. IIT1---NAC ---05 E2012 Bryant Heating & Cooling Systems 7310 W. Morris St. Indianapolis, IN 46231 Edition Date: 05/12 Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations. -
Page 5: Designed And Assembled In The Usa
T1- - NAC T1- - NHP LEGACY LINE- - RNC NON- -PROGRAMMABLE THERMOSTAT Homeowner’s Guide 1. To Select the Mode: Designed and Assembled Use the H/C button to move between the choices. OFF, in the USA. HEAT, COOL, or EMHT will appear on the display. EMHT will only appear on heat pump models. - Page 7 Limited Warranty for Thermostats FOR WARRANTY SERVICE OR REPAIR: Contact the installer or a Bryant dealer. You may be able to find the installer’s name on the equipment or in your Owner’s Packet. You can also find a Bryant dealer online at www.bryant.com For help, contact: Bryant Heating &...
-
