Page 2
Dear customer, Before placing your new refrigerator/freezer into operation please read these operating instructions carefully. They contain important information for safe use, for installation and for care of the appliance. Please keep these operating instructions for future reference. Pass them on to possible new owners of the appliance.
Customer Care Department. Prior to Installation • Check the refrigerator/freezer for transport damage. Under no circum- stances should a damaged appliance be installed! In the event of damage, please contact your retailer.
Page 6
Important Safety Instructions Child Safety • Do not allow children to tamper with the controls or play with the pro- duct. • Keep packaging material away from children! (There is a risk of suffoca- tion!) During Use • This appliance is designed for domestic use only, specifically for the storage of edible foodstuffs only.
Environmental Information Packaging All transit packaging materials are environmentally compatible and can be reused. Wood is un-treated. The plastics can be recycled and are identified as follows: >PE< for polyethylene, e.g. the outer covering and the bags in the inte- rior.
0 In order to push the appliance into its final position, press carefully at the top of the door and tip the appliance back slightly. The weight is thus transferred to the back casters and the appliance can be easily pushed.
Remove the transport fittings from the storage shelves: 0 Slide the fittings securing the shelf forward to the thicker section on the edge of the storage shelf. 0 Slide the storage shelf far enough forward so that it can be hinged downwards and the fittings can be removed from the guides.
Installation Installation Location The appliance should be installed in a well ventilated, dry room. Energy use is affected by the ambient temperature. The appliance should therefore – not be exposed to direct sunlight; – not be installed next to radiators, cookers or other sources of heat; –...
The refrigerator/freezer needs air Air is fed under the door through the vent slots in the base and is exhausted upwards along the back wall. To ensure proper air circulation never cover or alter the vent openings. Important! If the appliance is installed...
Installation Electrical Connection Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. WARNING – THIS APPLIANCE MUST BE EARTHED The manufacturer declines any liability should these safety measures not be observed. Before switching on, make sure the electricity supply voltage is the same as that indicated on the appliance rating plate.
Reversing The Door The door hinges can be changed from right (as supplied) to left if requi- red to suit the location where the appliance is installed. Warning! Unplug from the mains, before reversing the door. 0 Open the freezer compartment door and remove the plinth to the front.
Page 14
Changing Over The Door Hinges 0 Move the bearing pivot from the right to the left hand hole. Remove the freezer compartment door carefully to the front and place on one side. 0 Unscrew the centre door bearing. 0 Remove the fridge compartment door carefully to the front and place on one side.
Page 15
0 Unscrew the top handle bracket from the handle rod (1). Unscrew the bottom handle bracket from the door (2). 0 Unscrew the top handle bracket from the door (3) and screw onto the bottom right-hand side of the door (4). Caution! Do not overtighten the screws (max.
Page 16
Changing Over The Door Hinges 0 Slide the centre door bearing into the bottom left of the fridge com- partment door and fasten to the housing. 0 Fasten the self-closing mechanism on the top left of the freezer compartment door, 0 Carefully slide the freezer com- partment door onto the centre bearing pivot and close.
Appliance Description View of Appliance Control panel and elements Butter and cheese compartment with lid Door storage compartments Variable storage box Bottle compartment/bottle rack Fruit and vegetable drawers Shelves Freezer drawer (only for storage) When defrosting the bottom drawer also serves as a water collecting vessel.
Appliance Description Freezer tray with "Cold Accumulation Block" A freezer tray with a cold accumula- tion block and two ice trays is included below the upper drawer in the freezer compartment. Refer to the section "Prior to Initial Start-Up" regarding the freezing of the cold accumulation block.
8 Temperature regulator for freezer compartment 9 FAST FREEZE indicator light (yellow) 10 FAST CHILL/-FREEZE button • FAST CHILL for intensive cooling in the refrigerator • FAST FREEZE for fast freezing in the freezer compartment 11 Warning indicator light (red) 12 WARNING OFF button (see section: "Control and Information Systems")
(ACTUAL temperature). Temperature Displays • In normal operation the refrigerator or freezer compartment tempe- rature is displayed (ACTUAL temperature). The temperature regulator must be in its recessed position. • During temperature adjustment, the temperature selected will flash in the display (SET temperature).
• When the FAST CHILL function is switched on (see also section: "Fast Chill/Fast Freeze"), "IC" is displayed in the temperature display. As long as the FAST CHILL function is switched on, no refrigerator tem- perature is indicated in the temperature display.
Once the self-test rou- tine is complete, the compressor starts and functions automatically thereafter. 0 Set the refrigerator to the desired temperature (see section: "Tempera- ture Adjustment"). Goods to be refrigerated can be loaded immediately after switching on, because the storage temperature in the refrigerator is quickly reached.
Temperature Adjustment With the individual temperature regulators the desired temperatures in the refrigerator and in the freezer compartment can be adjusted inde- pendently of one another. 0 Press desired temperature regulator, so that it pops out of its recessed position. The temperature display will flash the selected temperature.
FAST CHILL The FAST CHILL function is suited for quick cooling of large quantities of goods in the refrigerator, e.g. drinks and salads for a party. 0 To switch on the FAST CHILL function first press the temperature regu- lator for the refrigerator. The temperature regulator pops out of its recessed position.
In order to protect frozen goods, the appliance is guarded against acci- dental switching off (child-proof). Refrigerator and freezer compartments can be switched off independ- ently of one another. 0 To switch off press and hold the ON/OFF button for about 5 seconds. A so-called "count down"...
0 Turn temperature regulator anticlockwise as far as possible. Indicated temperature in the temperature display is increased in 1° increments up to +10°C. The +10°C value is followed by +15°C. The refrigerator is now in the energy saving stand-by mode.
The control and information systems consist of a temperature display, an optical warning display and an acoustic warning. The system warns if: – the temperature in the refrigerator or freezer compartment is too high; – partial or complete thawing of frozen goods;...
Partial/Complete Thaw Warning If frozen goods in the freezer compartment have been partially or com- pletely thawed (e.g. during a temporary power interruption), the red warning display flashes. In addition the temperature display alternately indicates: – the highest temperature to which the frozen goods have warmed; –...
Interior Accessories Storage Shelves 0 A storage shelf must be inserted into the lower guide track above the fruit and vegetable drawers. It must always remain in this position, so that fruits and vegetables remain fresh longer. The remaining storage shelves can be adjusted to various heights: 0 Pull the storage shelf forward until it can be tipped up or down and...
Interior Accessories 0 To do this pull the bottle rack for- ward until it can be tilted upwards, then slide the front sup- port into the next level up. Variable Inner Door The door compartments can be pulled up and removed, and inserted at other positions as needed.
Foodsense, London SE99 7TT. Tel: 0645 556000 Tip: Food stored in the refrigerator compartment should always be cov- ered or packed so that they do not dry out, lose their flavour, or trans- fer their flavour to any other refrigerated food.
Freezing Except for the bottom drawer, which serves only for storage purposes, all compartments and drawers in the freezer compartment are suitable for freezing fresh food. Warning! • Before foods are frozen, the actual temperature in the freezer com- partment must be -18°C or colder. •...
Tips: • The following are suited for the packaging of frozen goods: – freezer bags and polyethylene wraps; – plastic containers for frozen foods; – extra-thick aluminium foil • The following are suited for sealing bags and wraps: plastic clips, rubber bands or adhesive tape. •...
The water collects in the discharge trough at the back wall of the refrigerator, and is fed through the discharge opening in the catch tray at the compressor where it is evaporated. Freezer Compartment Defrosting...
Page 35
0 Remove frozen goods, pack them in several layers of newspaper, cover them and store them in a cool place, e.g. in a refrigerator. 0 Switch off refrigerator and freezer and remove plug from the mains, or disconnect from the electricity supply.
• A thermostat controls the compressor and you will hear a faint click when the thermostat cuts in and out. Food Storage To obtain the best performance from your refrigerator/freezer: • Do not store warm food or evaporating liquids. • Do not store food uncovered.
ELECTRICITY supply. Internal Cleaning 0 If the refrigerator only is to be cleaned, press the FAST CHILL/-FREEZE button several hours in advance, in order to build up sufficient chill reserve in the freezer compartment for the interruption in service. Do not open the freezer compartment door.
Maintenance and Cleaning Replace light bulb For safety reasons the interior lighting switches off after 10 minutes when the door is open. It switches on again the next time the door is opened. Warning! Danger of electrical shock! Before replacing the light bulb switch off the appliance and remove the mains plug.
Before contacting your local service force centre, check the following points. Sympton No power to the appliance. The temperature in the refrigerator/free- zer is too high. Red warning display flashes, audible warning sounds, temperature display indicates an error (F1, F2, etc.).
Page 40
Something not Working Sympton Excessive build up of frost. Noise The compressor does not start immedia- tely after changing the temperature set- ting. If after the above checks there is still a fault, call your local AEG Service Force Centre. In-guarantee customers should ensure that the above checks have been made as the engineer will make a charge if the fault is not a mechani- cal or electrical breakdown.
Technical Terminology • Refrigerant Liquids that can be used to a generate a cooling effect are known as refrigerants. They have a relatively low boiling-point, indeed so low, that the warmth from the food stored in the fridge or freezer can cause the refrigerant to boil and vaporise.
Guarantee Conditions AEG offer the following guarantee to the first purchaser of this appliance. 1. The guarantee is valid for 12 months commencing when the appliance is handed over to the first retail purchaser, which must be verified by purchase invoice or similar docu- mentation.
Service & Spare Parts If after carrying out the necessary checks there is still a fault with your appliance please contact your local AEG Service Force Centre. In guarantee customers should ensure that the suggested checks have been made as the engineer will make a charge if the fault is not a mechanical or electrical breakdown.
