LASER PRINTER

PARTS REFERENCE LIST
HL-1660e

Advertisement

Table of Contents
loading

Related Manuals for Brother HL-1660e

Summary of Contents for Brother HL-1660e

  • Page 1: Laser Printer

    LASER PRINTER PARTS REFERENCE LIST HL-1660e...
  • Page 2 NOTE FOR USING THIS PARTS REFERENCE LIST 1. In the case of ordering parts, it needs mentioning the following items: (1) Code (2) Q'ty (3) Description (4) Symbol ( PCB No., Revision , and Parts location mounted on the PCB.) Note : No orders without Parts Code or Tool No.

  • Page 3: Table Of Contents

    CONTENTS POWER CORDS & HARNESSES ............1 PAPER FEEDER PCB ................1 CONTROL PANEL ................3 PCB ATTACHMENTS ................3 MAIN PCB..................... 5 HIGH-VOLTAGE POWER SUPPLY ............. 7 LOW-VOLTAGE POWER SUPPLY ............7 COVERS ....................9 CHASSIS ....................9 10. TRANSFER ..................11 11.

  • Page 4: Power Cords & Harnesses

    1 . POWER CORDS & HARNESSES MODEL HL-1660e 54T-U03-050/070 2 . PAPER FEEDER PCB JW18 (MP SOL) P5 (ENGINE) JW13 JW19 JW20 JW17 JW21 JW26 B48K139-2 JW14 B48K140-2 MODEL HL-1660e 54T-U03-090...
  • Page 5 1. POWER CORDS & HARNESSES REF.NO. CODE Q'TY DESCRIPTION REMARK UH1052001 1 AC CORD, VDE UH1053001 1 AC CORD, SEV UH1055001 1 AC CORD, SAA UH1054001 1 AC CORD, BS UH1051001 1 AC CORD, UL/CSA U34320001 1 AC CORD #4, BS WO/PLUG UK4094001 1 AC CORD #5, DEMKO U34322001...

  • Page 6: Control Panel

    3 . CONTROL PANEL I F T L I N T IO IE N MODEL HL-1660e 54T-U03-150 4 PCB ATTACHMENTS 54T-U03-450 MODEL HL-1660e T/I NO. PR98309...
  • Page 7 3. CONTROL PANEL REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK UK3024001 1 CONTROL PANEL UNIT (SP) (B48K143-200B) UK2500000 1 SWITCH FLAT CABLE 21P UH2011001 1 PANEL STOPPER, GRAY1227 UH1451001 1 PANEL SHEET, HL-1660e MODEL HL-1660e 54T-U03-150 4. PCB ATTACHMENTS REF.NO. CODE Q'TY DESCRIPTION REMARK...

  • Page 8: Main Pcb

    5 . MAIN PCB MODEL HL-1660e 54T-U03-103...
  • Page 9 5. MAIN PCB REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK UK3799001 1 MAIN PCB ASSY (SP), HL1660e B48K294-100E UK4280000 1 MROM23C32000-01 UK4281000 1 MROM23C32000-02 UK3785001 1 MIO CONNECTOR PCB ASSY B48K295-100 087320616 7 TAPTITE, CUP S M3X6 087320616 1 TAPTITE, CUP S M3X6 UK2466000 1 EPROM:27C8000DZ(BLANK EPROM)(SP) (#1) MODEL HL-1660e 54T-U03-103...

  • Page 10: High-Voltage Power Supply

    6 . HIGH-VOLTAGE POWER SUPPLY MODEL HL-1660e 54T-U03-200 7 . LOW-VOLTAGE POWER SUPPLY MODEL HL-1660e 54T-U03-300...
  • Page 11 6. HIGH-VOLTAGE POWER SUPPLY REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK UK2702001 1 HIGH-VOLTAGE PS PCB ASSY (SP) B48K186-300E 087320616 2 TAPTITE, CUP S M3X6 MODEL HL-1660e 54T-U03-200 7. LOW-VOLTAGE POWER SUPPLY REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK UK2753001 1 LOW-VOLT PS PCB ASSY, 115VM(SP) UK2754001 1 LOW-VOLT PS PCB ASSY, 230VM(SP) UK2756001...

  • Page 12: Covers

    8 . COVERS 54T-U03-400 MODEL HL-1660e 9 . CHASSIS 54T-U03-500 MODEL HL-1660e...
  • Page 13 8. COVERS REF.NO. CODE Q'TY DESCRIPTION REMARK UH2065001 1 UPPER COVER ASSY, GRAY1227 UH2071001 1 TONER CARTRIDGE LID, GRAY1227 UH2072001 1 FONT COVER ASSY, GRAY1227 UH2076001 1 CLEANER BRUSH UH2077001 1 SIDE COVER L, GRAY1227 UH2027001 1 SIDE COVER R2 ASSY, GRAY1227 UH2082001 1 REAR COVER ASSY, GRAY1227 UH2104001...

  • Page 14: Transfer

    10 . TRANSFER MODEL HL-1660e 54T-U03-600 11 . PAPER TRAY 1-10 54T-U03-650/651 MODEL HL-1660e...
  • Page 15 10. TRANSFER REF.NO. CODE Q'TY DESCRIPTION REMARK UH2787001 1 TRANSFER BASE ASSY (SP) UH1834001 1 TRANFER ROLLER A ASSY (SP) 087321016 1 TAPTITE, CUP S M3X10 MODEL HL-1660e 54T-U03-600 T/I NO. PR98174 11. PAPER TRAY REF.NO. CODE Q'TY DESCRIPTION REMARK 1-10 UH2806001 1 PAPER TRAY UNIT SO, USA (SP) GRAY1227...

  • Page 16: Paper Feeder

    12 . PAPER FEEDER 1-35 54T-U03-630 MODEL HL-1660e T/I No. PR98202...
  • Page 17 12. PAPER FEEDER REF.NO. CODE Q'TY DESCRIPTION REMARK 1-35 UH2824001 1 PAPER FEED CHASSIS UNIT 2 (SP) (WITH PCB/SW SPRING/SCREW) UH2357001 1 PAPER FEED MOTOR ASSY 087320616 2 TAPTITE, CUP S M3X6 UH2359000 1 MP PAPER DETECTION ACTUATOR 085310815 2 TAPTITE, BIND B M3X8 UH2362001 1 PAPER PICK-UP ROLLER ASSY UH2364001...

  • Page 18: Scanner

    13 . SCANNER 54T-U03-700 MODEL HL-1660e 14 . FIXING UNIT, 120V/230V 54T-U03-770/771 MODEL HL-1660e T/I NO. PR98054, PR98061...
  • Page 19 13. SCANNER REF.NO. CODE Q'TY DESCRIPTION REMARK UH2815001 1 SCANNER UNIT ASSY C (SP) UK2503000 1 SCN FLAT CABLE 6P 087321616 4 TAPTITE, CUP S M3X16 UK3254001 1 POLYGON HARNESS 5P MODEL HL-1660e 54T-U03-700 14. FIXING UNIT, 120V/230V REF.NO. CODE Q'TY DESCRIPTION SYMBOL...

  • Page 20: Documents

    15 . DOCUMENTS MODEL HL-1660e 54T-U03-920 T/I NO. PR98209 / PR98263 / PR98280 / PR98310...
  • Page 21 15. DOCUMENTS REF.NO. CODE Q'TY DESCRIPTION REMARK UK3811001 PR DRIVER DISK #1, HL-1660e(FIRST PART 1/2) UK4335001 1 PR DRIVER DISK #3, HL-1660e SPA (1/2) UK3813001 PR DRIVER DISK #2, HL-1660e (LATTER PART 2/2) UK4337001 1 PR DRIVER DISK #4, HL-1660e SPA (2/2) UK4329001 1 CD-ROM ASSY (HL-1070/1660E/2060) VER.

  • Page 22: Packing Materials

    16 . PACKING MATERIALS 54T-U03-930 MODEL HL-1660e 17 . OPTIONAL PARTS SET 54T-U03-940 MODEL HL-1660e...
  • Page 23 16. PACKING MATERIALS REF.NO. CODE Q'TY DESCRIPTION REMARK UE0367000 1 CARTON, C-NO BRAND UE0637001 1 CARTON, C-USA H UE0638001 1 CARTON, C-EUR H UE0370000 1 STYROFOAM PAD ASSY UE0373000 1 PAD UE0374000 1 CARTON, TNR CARTRIDGE (W/EP-ED) UE0476000 1 CARTON, TNR CARTRIDGE (WO/EP-ED) UE0376000 1 STYROFOAM PAD (PLATE HOLDER) UH2735001...

  • Page 24: Adjusting Tool Kit

    18 . ADJUSTING TOOL KIT 11,12 13,14 43-D,N,O 78-A 54T-U03-99A MODEL HL-1660e T/I NO. PR98047...
  • Page 25 18. ADJUSTING TOOL KIT TOOL NO. TOOL NAME REMARK ZX-1 PLIERS (150MM) ZX-9 SCREWDRIVER (75MM) ZX-10 SCREWDRIVER (70MM) ZX-11 SCREWDRIVER (4.7X270MM) ZX-12 SCREWDRIVER, (6.2X200MM) ZX-13 SCREWDRIVER, PHILLIPS (NO-1) ZX-14 SCREWDRIVER, PHILLIPS (NO-2) ZX-29 HOOK FOR SPRING ZX-31 TWEEZERS (150MM) ZX-43D LUBRICATING GREASE(SILICON G,KS64F 0.1KG) ZX-43N LUBRICATING GREASE(MOLYKOTE EM-30L TKC-0) 1KG...
