Blueant S4 User Manual

True handsfree voice controlled car speakerphone
Hide thumbs Also See for S4:
Table of Contents

Advertisement

Quick Links

TRUE H ANDSFREE
VOICE CONTROLLED
CAR SPEAKERPHONE
User Guide

Advertisement

Table of Contents
loading

Related Manuals for Blueant S4

Summary of Contents for Blueant S4

  • Page 1 TRUE H ANDSFREE VOICE CONTROLLED CAR SPEAKERPHONE User Guide...

  • Page 3: Table Of Contents

    Contents Introduction  Remove the Protective Cover  Charge Your S4  Pair the S4 with your Phone  Install the S4 in your Car  Using the Handsfree Trigger  Handsfree Trigger Battery Saving Mode  Reconnecting to the S4  Use Your Voice to Make Phone Calls  Use Your Voice to Answer Calls ...
  • Page 4 Transferring your Phonebook Contacts to the S4  Automatically Transferring your Phonebook Contacts to the S4  Manually Transferring your Phonebook Contacts to the S4  Updating your Phonebook Contacts on the S4  Listening to Audio  Adjusting the Volume  Using 2 Phones with the S4 (Multipoint)  Which Phone is Used for Calls? ...
  • Page 5 Android  Apple iPhone   ® ® BlackBerry  Other Models  Troubleshooting  Resetting the S4  Specifi cations  Help and Support  Terms and Conditions ...

  • Page 6: Introduction

    S4. Simply say the trigger phrase BlueAnt BlueAnt Speak To Me™ and the S4 will be ready for your voice commands. You can make outgoing calls and answer incoming calls using just your voice, and you will always know who is calling you without looking at your phone because the S4 will read out the caller’s name or number when the phone rings.

  • Page 7: Remove The Protective Cover

    Remove the Protective Cover The plastic cover on your S4 is intended to protect it during transit. Please remove it before using your S4. Charge Your S4 Battery Your S4 has been given an initial partial charge to get you started, Indicator but for best results we recommend you charge it using the supplied USB cable and adaptor:...

  • Page 8: Pair The S4 With Your Phone

    2. If this is the fi rst time you have used the S4 it will go straight to pairing mode. The voice prompts will start to talk you through the pairing process and the light will fl ash blue. For subsequent pairings, say BlueAnt Speak To Me, wait for the S4 to ask you to Say A Command...
  • Page 9 BlackBerry ® Accept connection request from BlueAnt S4? If you are using a BlackBerry smartphone you may see a message like this one. Select “Don’t ask this again” so that a tick appears in the box, and then choose “YES”.

  • Page 10: Install The S4 In Your Car

    Please refer to the relevant national or local legislation regarding the usage of mobile devices while driving. Remember that driving is your fi rst priority: please read the enclosed safety information booklet for tips on the safe use of your BlueAnt device.

  • Page 11: Using The Handsfree Trigger

    Using the Handsfree Trigger Your S4 is designed to be a true handsfree device. Simply say the trigger phrase BlueAnt Speak To Me and the S4 will be ready to receive your voice commands. Handsfree BlueAnt Trigger Speak To Me...

  • Page 12: Handsfree Trigger Battery Saving Mode

    In this mode the S4 only listens for 2 minutes after the last action. Once the 2 minutes are up, the green indicator light goes out and the S4 stops listening. To re-activate the S4, tap the symbol instead of saying BlueAnt Speak To Say A Command BlueAnt...

  • Page 13: Reconnecting To The S4

    Alternatively, use the power switch to turn the S4 off when you get out of the car and then turn it back on again when you come back. The S4 will then automatically reconnect to your phone. BlueAnt...

  • Page 14: Use Your Voice To Make Phone Calls

    Use Your Voice to Make Phone Calls BlueAnt Speak To Me and wait for the S4 to ask you to Say A Command, then: > Phone Commands to activate the voice dial feature on your phone (if your phone supports voice dialing).

  • Page 15: Use Your Voice To Access The World

    Your S4 provides you with voice access to the world by giving you stock quotes, news, sports updates, traffi c information, weather, and more. To access this function: 1. Say BlueAnt Speak To Me and wait for the S4 to ask you to Say A Command.

  • Page 16: List Of Voice Commands

    List of Voice Commands When you want to do something, just say BlueAnt Speak To Me, wait for the S4 to ask you to Say A Command, and then say one of the following commands: > Am I Connected? — The S4 will check if your phone is connected, and attempt to connect if it is not.
  • Page 17 > Redial — Redials the last outgoing call made on the connected phone. > Sensitivity Level — Confi gures the sensitivity of the S4’s voice recognition. > LED Light — Turns the LEDs on or off. When the LEDs are set to off, they still light up when you turn the S4 on or off, but will not fl...

  • Page 18: Transferring Your Phonebook Contacts To The S4

    Transferring your Phonebook Contacts to the S4 Your S4 uses Text To Speech technology (TTS) to read out the name of the person who is calling you. To do this, the S4 needs to store a copy of your phonebook contacts. Automatically Transferring your Phonebook Contacts to the S4 When you pair your phone with the S4 it will attempt to transfer the phonebook contacts automatically.

  • Page 19: Updating Your Phonebook Contacts On The S4

    If you add or change entries in your phonebook then you need to update the contacts on your S4 by doing the following. 1. Say BlueAnt Speak To Me, and wait for the S4 to ask you to Say A Command.

  • Page 20: Listening To Audio

    If you want to exit A2DP streaming mode to do something else, tap the symbol. The S4 will ask you to Say A Command. If you do not say a command within a few seconds the music will resume playing. BlueAnt BlueAnt...

  • Page 21: Adjusting The Volume

    - or + symbols. You can adjust the volume during calls, during music playback and you can also adjust the volume of the audio prompts. Please note that each of these modes has its own independent BlueAnt BlueAnt volume setting.

  • Page 22: Using 2 Phones With The S4 (Multipoint)

    Using 2 Phones with the S4 (Multipoint) Up to 2 devices can connect to the S4 at the same time. If either phone rings, you can answer it with the S4. Use the Pair Me command to put your S4 back into pairing mode to pair another phone. Any currently connected phone will be disconnected during pairing, so you will need to reconnect afterwards.

  • Page 23: Multiple Calls (Call Waiting)

    Multiple Calls (Call Waiting)* If you receive an incoming call while you are already on a call the S4 will play a tone to alert you. > Press the + symbol on the S4 for about 1 second to put your current call on hold and answer the incoming call. >...

  • Page 24: Switching The S4 On And Off

    From time to time we will make upgrades available on our website for you to download and apply to your S4. Go www.blueantwireless.com for full details on the latest upgrades available for your S4. You must register your product online at register.blueantwireless.com for access to fi rmware upgrades. BlueAnt...

  • Page 25: Function Reference

    Function Reference > Standby Mode means connected to a device but not on a call. > Idle Mode means the S4 is on but not connected to any devices. S4 Function Do This When Volume Up Swipe from - to + Idle/Standby/Active call/Music Or: press and hold + Streaming...
  • Page 26 Press the - symbol for 1 second Active call with ringing incoming a new incoming call call Reset the S4 Press the + and - symbols together for Idle (not connected to any phones) BlueAnt about 6 seconds BlueAnt BlueAnt...

  • Page 27: Phone Specifi C Tips And Tricks

    Phone Specifi c Tips and Tricks Android > Please note that voice dialing over Bluetooth was added to the Android Operating System in version 2.2. It will not be possible to use Phone Commands unless your Android device is running Android OS 2.2 or higher. >...

  • Page 28: Blackberry

    to the “Mail, Contacts, Calendars” section in the “Settings” menu on your phone and change both the “Sort Order” and “Display Order” to “First, Last”. Once you have changed this setting, you must use the Update Phonebook command to copy the phonebook to the S4 again. BlackBerry >...

  • Page 29: Troubleshooting

    Troubleshooting I Cannot Transfer my Phonebook to the S4 In order to transfer your phonebook to the S4, your phone must support either the Phonebook Access Profi le (PBAP), AT commands, or the Object Push Profi le (OPP). If your phone does not support any of these Bluetooth profi...
  • Page 30 If this is happening, you can resolve it by changing the setting on your phone that controls the display and sort order of your contacts.* The exact setting to change depends on your phone. For example, Apple iPhone users should go to the “Mail, Contacts, Calendars”...
  • Page 31 3 separate entries. The S4 Does Not Respond to “BlueAnt Speak To Me” If you are having trouble getting the S4 to respond to your voice, it may be that there is too much noise around you for the S4 to hear you.
  • Page 32 My Phone Prompts me for a Code when I Pair the S4 Enter the code 0000 (four zeros). My Phone Prompts me to Confi rm the Connection to the S4 If your phone always prompts you to confi rm whether you want to accept the connection from the S4, then you should confi...
  • Page 33 The S4 Does Not Respond to my Voice Commands If you are having trouble getting the S4 to respond to your voice commands, try the following tips: > Say your command as soon as possible after the S4 asks you to Say A Command.

  • Page 34: Resetting The S4

    > If you take the S4 out of range of your phone, then it will play a tone to indicate that it is no longer connected. > The S4 plays a tone when you end a call. > The S4 plays a call waiting tone if you receive an incoming call while you are on a call. The S4 Light is Distracting By default the Bluetooth indicator will fl...

  • Page 35: Specifi Cations

    To reset the S4: 1. Delete any existing pairing information from your phone and turn it off and back on again to refresh the phone memory. 2. Make sure the S4 is switched on but not connected to any phones. 3.

  • Page 36: Help And Support

    > Talk Time: Up to 20 hours > Standby Time: Up to 700 hours with handsfree trigger in battery saving mode > Charging Time: 3 - 4 hours > Battery Type: Rechargeable Lithium Ion Help and Support If you are having trouble getting the S4 to work, please visit www.blueantwireless.com for online help, support, and troubleshooting tips.

  • Page 37: Terms And Conditions

    Please protect your ears. All BlueAnt devices are designed to reach volumes of up to 100 decibels. Prolonged use at high volumes may affect your hearing capacity and may result in noise induced hearing loss (NIHL).
  • Page 40 BlueAnt w w w. b l u e a n t w i re le s s . co m North America Australia New Zealand Email Enquiries 1866 891 3032 1300 669 049 0800 443 122 customercare blueantwireless.com...
