TOYOTA
FJ CRUISER
Preparation
Part Number: TMS-SA-FJ
Code:
Kit Contents
Item #
Quantity Reqd.
1
2
2
2
Hardware Bag Contents
Item #
Quantity Reqd.
1
8
Additional Items Required For Installation
Item #
Quantity Reqd.
Conflicts
Conflicts with factory installed rear speakers
Recommended Tools
Personal & Vehicle
Protection
Vehicle Protection
Part Protection
Special Tools
Dremel Tool
Dremel Cable Tool
FJ Cable Tool Guide
Installation Tools
Panel Removal Tool
Pliers
Screwdriver
Screwdriver
Panel Cutout Template
Torque Wrench 36"lbs
Special Chemicals
Cleaner
Southeast Toyota Distributors LLC
Description
Rear Speaker Assembly
Replacement Grilles
Description
Push nuts for Grilles
Description
Notes
Seat/Floor Covers
Blankets
Notes
Notes
Nylon Removal Tool (NRT)
1. Diagonal Cutters
2. Long Nose (optional)
Magnetized Philips # 2
Magnetized Philips # 1
Spiral Bit
3/32" Drill Bit
Notes
Page 1 of 5 pages
2007 -
REAR SPEAKER UPGRADE
General Applicability
Conflicts with factory installed rear speakers
Recommended Sequence of Application
Item #
Accessory
1
Install Security/Audio
2
Install Bazooka Tube
3
Install Door Sills
4
Install Molded Dash
Vehicle Service Parts
Item #
Quantity Reqd.
1
Legend
STOP: Damage to the vehicle may occur. Do not
proceed until process has been complied with.
OPERATOR SAFETY: Use caution to avoid risk of
injury.
CAUTION: A process that must be carefully observed
in order to reduce the risk of damage to the
accessory/vehicle and to ensure a quality installation.
TOOLS & EQUIPMENT: Used in Figures calls out the
specific tools and equipment recommended for this
process.
REVISION MARK: This mark highlights a change in
installation with respect to previous issue.
Speaker Specifications / Replacement Parts
Size
Frequency Response
Magnet Size
Efficiency
Power Handling
Weight
Impedance
SPECIAL NOTE: Installation Sequences
After TMS and Safety mandated preparatory steps have been
taken, the installation sequence is the suggested method for
completing the accessory installation. In some instances the
suggested sequence is written for one associate to install and in
others the sequence is given as part of a team accessory
installation. Unless otherwise stated in the document, the
associates may perform the installation steps in any order to
make the installation as efficient as possible while maintaining
consistent quality.
*Mandatory
(may be required for reassembly)
Description
3.5 inch (nominal)
125 Hz – 20kHz
8 oz.
90 dB
45 watts each
2 lbs.
4 ohms
