Owner's Manual
GENERATOR
EU2000i
See page 78 for
Initial Use Instructions
o2008 Honda Motor Co., Ltd. -All Rights Reserved

Advertisement

Table of Contents
loading

Summary of Contents for Honda EU2000i Companion

  • Page 1 Owner’s Manual GENERATOR EU2000i See page 78 for Initial Use Instructions o2008 Honda Motor Co., Ltd. -All Rights Reserved...
  • Page 2 The information and specifications included in this publication were in effect at the time of approval for printing. Honda Motor Co., Ltd. reserves the right, however, to discontinue or change specifications or design at any time without notice and without incurring any obligation whatever.
  • Page 3 When your generator needs scheduled maintenance, keep in mind that your Honda servicing dealer is specially trained in servicing Honda generators and is supported by the parts and service divisions of American Honda. Your Honda servicing dealer is dedicated to your satisfaction and will be pleased to answer your questions and concerns.
  • Page 4 A FEW WORDS ABOUT SAFETY Your safety and the safety of others are very important. And using this generator safely is an important responsibility. To help you make informed decisions about safety, we have provided operating procedures and other information on labels and in this manual.
  • Page 5: Table Of Contents

    CONTENTS GENERATOR SAFETY ................IMPORTANT SAFETY INFORMATION ..........Operator Responsibility ..............Carbon Monoxide Hazards ..............Electric Shock Hazards ............... Fire and Burn Hazards ................ Refuel With Care ................. SAFETY LABEL LOCATIONS ..............CONTROLS & FEATURES ................ COMPONENT & CONTROL LOCATIONS ...........
  • Page 6 CONTENTS OPERATION ....................SAFE OPERATING PRECAUTIONS ............. STARTING THE ENGINE ..............STOPPING THE ENGINE ..............AC OPERATION ..................AC Applications ................. AC PARALLEL OPERATION ..............AC Parallel Operation Applications ..........ECO-THROTTLE SYSTEM ..............STANDBY POWER ................Connections to a Building’s Electrical System .......
  • Page 7 Emission Control System Information ..........Air Index ..................... Specifications ..................Wiring Diagram ................. CONSUMER INFORMATION ............... Dealer Locator Information .............. Honda Publications ................Customer Service Information ............Distributor’s Limited Warranty ............Emission Control System Warranty ..........INITIAL USE INSTRUCTIONS ..............ENGINE OIL ...................
  • Page 8: Generator Safety

    GENERATOR SAFETY IMPORTANT SAFETY INFORMATION Honda generators are designed for use with electrical equipment that has suitable power requirements. Other uses can result in injury to the operator or damage to the generator and other property. Most injuries or property damage can be prevented if you follow all instructions in this manual and on the generator.
  • Page 9: Electric Shock Hazards

    Do not connect to a building’s electrical system unless an isolation switch has been installed by a qualified electrician. For parallel operation, use only a Honda approved parallel operation cable kit (optional equipment) when connecting one EU2000i Companion to either an EU2000i or another EU2000i Companion generator.
  • Page 10: Refuel With Care

    GENERATOR SAFETY Refuel With Care Gasoline is extremely flammable, and gasoline vapor can explode. Allow the engine to cool if the generator has been in operation. Refuel only outdoors in a well-ventilated area with the engine OFF. Do not overfill the fuel tank. Never smoke near gasoline, and keep other flames and sparks away.
  • Page 11: Safety Label Locations

    GENERATOR SAFETY SAFETY LABEL LOCATIONS These labels warn you of potential hazards that can cause serious injury. Read them carefully. If a label comes off or becomes hard to read, contact your Honda servicing dealer for a replacement.
  • Page 12 GENERATOR SAFETY...
  • Page 13: Controls & Features

    CONTROLS & FEATURES COMPONENT & CONTROL LOCATIONS Use the two illustrations on these pages to locate and identify the most frequently used controls. PARALLEL OPERATION OUTLETS ECO-THROTTLE SWITCH 20A RECEPTACLE 30A twist lock receptacle OIL ALERT INDICATOR OVERLOAD INDICATOR AC CIRCUIT PROTECTOR OUTPUT INDICATOR GROUND TERMINAL FUEL TANK CAP VENT LEVER...
  • Page 14 CONTROLS & FEATURES SPARK PLUG MAINTENANCE COVER SPARK PLUG MUFFLER AIR CLEANER...
  • Page 15: Controls

    CONTROLS & FEATURES CONTROLS Engine Switch ENGINE SWITCH The engine switch controls the ignition system and the fuel valve. Stops the engine and closes the fuel valve. Running position; opens the fuel valve and allows the engine to be started. Starter Grip Pulling the starter grip operates the recoil starter to crank the...
  • Page 16: Fuel Tank Cap Vent Lever

    CONTROLS & FEATURES Fuel Tank Cap Vent Lever The fuel tank cap is provided with a vent lever to seal the fuel tank. The vent lever must be in the ON position for the engine to run. When the engine is not in use, leave the vent lever in the OFF position to reduce the possibility of fuel leakage.
  • Page 17: Eco-Throttle Switch

    EU2000i or another EU2000i Companion generator for parallel operation (see page ). A Honda approved parallel operation cable kit (optional equipment) is required for parallel operation. This kit can be purchased from an authorized Honda generator dealer. PARALLEL OPERATION OUTLETS...
  • Page 18: Ac Circuit Protector

    CONTROLS & FEATURES AC Circuit Protector The AC circuit protector will automatically switch OFF if there is a short circuit or a significant overload of the generator at the 20A receptacle. If the circuit protector switches OFF automatically, check that the appliance is working properly and does not exceed the rated load capacity of the circuit before resetting the circuit protector ON.
  • Page 19: Features

    CONTROLS & FEATURES FEATURES Ground Terminal The generator ground terminal is connected to the frame of the generator, the metal non-current-carrying parts of the generator, and the ground terminals of each receptacle. Before using the ground terminal, consult a qualified electrician, electrical inspector, or local agency having jurisdiction for local codes or ordinances that apply to the intended use of the generator.
  • Page 20: Output Indicator

    CONTROLS & FEATURES Output Indicator The output indicator (green) is illuminated when the generator is operating normally. It indicates that the generator is producing electrical power at the receptacles. OUTPUT INDICATOR (GREEN) Overload Indicator If the generator is overloaded (in excess of 2.0 kVA), or if there is a short circuit in a connected appliance, the overload indicator (red) will come ON.
  • Page 21: Oil Alert Indicator

    CONTROLS & FEATURES Oil Alert Indicator The Oil Alert system is designed to prevent engine damage caused by an insufficient amount of oil in the crankcase. Before the oil level in the crankcase can fall below a safe limit, the Oil Alert indicator (red) comes on and the Oil Alert system automatically will stop the engine (the engine switch will remain in the ON position).
  • Page 22: Before Operation

    BEFORE OPERATION ARE YOU READY TO GET STARTED? Your safety is your responsibility. A little time spent in preparation will significantly reduce your risk of injury. Knowledge Read and understand this manual. Know what the controls do and how to operate them. Familiarize yourself with the generator and its operation before you begin using it.
  • Page 23: Check The Engine

    BEFORE OPERATION To prevent a possible fire, keep the generator at least 3 feet (1 meter) away from building walls and other equipment during operation. Do not place flammable objects close to the engine. Before beginning your pre-operation checks, be sure the generator is on a level surface and the engine switch is in the OFF position.
  • Page 24: Operation

    OPERATION SAFE OPERATING PRECAUTIONS Before operating the generator for the first time, review chapters GENERATOR SAFETY (see page ) and BEFORE OPERATION (see page For your safety, do not operate the generator in an enclosed area such as a garage. Your generator’s exhaust contains poisonous carbon monoxide gas that can collect rapidly in an enclosed area and cause illness or death.
  • Page 25: Starting The Engine

    OPERATION STARTING THE ENGINE To prevent a possible fire, keep the generator at least 3 feet (1 meter) away from building walls and other equipment during operation. Do not place flammable objects close to the engine. Operating this generator less than 3 feet (1 meter) from a building or other obstruction can cause overheating and damage the generator.
  • Page 26 OPERATION Make sure the Eco-Throttle ECO-THROTTLE SWITCH switch is in the OFF position, or more time will be required for warm-up. To start a cold engine, move the CHOKE LEVER choke lever to the CLOSED position. To restart a warm engine, leave the choke lever in the OPEN position.
  • Page 27 OPERATION Pull the starter grip lightly until you feel resistance, then pull briskly in the direction of the arrow as shown. Do not allow the starter grip to snap back against the generator. Return it gently to prevent damage to the starter. STARTER GRIP If the choke lever was moved to CHOKE LEVER...
  • Page 28: Stopping The Engine

    OPERATION STOPPING THE ENGINE To stop the engine in an emergency, simply turn the engine switch to the OFF position. Under normal conditions, use the following procedure. Turn off or disconnect all appliances connected to the generator. Turn the engine switch to the OFF position. ENGINE SWITCH Allow the engine to cool, and then turn the fuel tank cap vent lever to the OFF position.
  • Page 29 OPERATION If two generators were connected for parallel operation, disconnect the parallel operation cable after stopping the engines if you do not wish to resume parallel operation. PARALLEL OPERATION CABLE (optional equipment)
  • Page 30: Ac Operation

    OPERATION AC OPERATION Before connecting an appliance to either generator, make sure that it is in good working order and that its electrical rating does not exceed that of the receptacle. Most motorized appliances require more than their electrical rating for startup.
  • Page 31: Ac Applications

    OPERATION AC Applications Before connecting an appliance or power cord to the generator: Make sure that it is in good working order. A faulty appliance or power cord can create a potential for electrical shock. If an appliance begins to operate abnormally, becomes sluggish, or stops suddenly, turn it off immediately.
  • Page 32: Ac Parallel Operation

    OPERATION AC PARALLEL OPERATION Before connecting an appliance to either generator, make sure that it is in good working order and that its electrical rating does not exceed that of the receptacle. Most motorized appliances require more than their electrical rating for startup.
  • Page 33 OPERATION Plug an appliance into the 30A twist lock receptacle. L5-30P PLUG Turn on the appliance. If the generators are overloaded (see page ), or if there is a short circuit in a connected appliance, the overload indicator (red) will go ON.
  • Page 34: Ac Parallel Operation Applications

    Power levels between rated and maximum may be used for no more than 30 minutes. Never connect different generator models. For parallel operation, use only a Honda approved parallel operation cable kit (optional equipment, see page ) when connecting one EU2000i Companion to either an EU2000i or another EU2000i Companion generator.
  • Page 35 OPERATION Limit operation requiring maximum power to 30 minutes. Maximum power in parallel operation is: 4.0 kVA For continuous operation, do not exceed the rated power. Rated power in parallel operation is: 3.2 kVA The total power requirements (VA) of all appliances connected must be considered.
  • Page 36: Eco-Throttle System

    OPERATION ECO-THROTTLE SYSTEM With the switch in the ON position, engine speed is automatically lowered when loads are reduced, turned OFF, or disconnected. When appliances are turned ON or reconnected, the engine returns to the proper speed to power the electrical load. In the OFF position, the Eco-Throttle system does not operate.
  • Page 37: Standby Power

    Check local regulations for proper registration and use procedures. System Ground Honda portable generators have a system ground that connects the generator frame components to the ground terminals in the AC output receptacles. The system ground is not connected to the AC neutral wire.
  • Page 38: Special Requirements

    OPERATION Special Requirements Keep all cooling holes open and clear of debris, mud, water, etc. Cooling holes are located on the side panel, the control panel, and the bottom of the generator. If the cooling holes are blocked, the generator may overheat and damage the engine, inverter, or windings. Do not lay the generator on its side when moving, storing, or operating it.
  • Page 39: Servicing Your Generator

    Other service tasks that are more difficult or require special tools are best handled by professionals and are normally performed by a Honda technician or other qualified mechanic. The maintenance schedule applies to normal operating conditions. If...
  • Page 40: Maintenance Safety

    SERVICING YOUR GENERATOR MAINTENANCE SAFETY Some of the most important safety precautions follow. However, we cannot warn you of every conceivable hazard that can arise in performing maintenance. Only you can decide whether or not you should perform a given task. Failure to properly follow maintenance instructions and precautions can cause you to be...
  • Page 41: Maintenance Schedule

    Every 2 years (Replace if necessary) (2) Service more frequently when used in dusty areas. These items should be serviced by your Honda servicing dealer, unless you have the proper tools and are mechanically proficient. Refer to the Honda shop manual for service procedures.
  • Page 42: Refueling

    SERVICING YOUR GENERATOR REFUELING With the engine stopped, remove the fuel tank cap and check the fuel level. Refill the fuel tank if the fuel level is low. Gasoline is highly flammable and explosive. You can be burned or seriously injured when handling fuel.
  • Page 43 SERVICING YOUR GENERATOR NON-CALIFORNIA TYPE FUEL TANK CAP UPPER LEVEL MARK (RED) After refueling, reinstall the fuel tank cap securely. CALIFORNIA TYPE FUEL TANK CAP UPPER LEVEL MARK (RED) TETHER After refueling, tighten the fuel tank cap until it clicks.
  • Page 44: Fuel Recommendations

    SERVICING YOUR GENERATOR FUEL RECOMMENDATIONS This engine is certified to operate on regular unleaded gasoline with a pump octane rating of 86 or higher. Never use stale or contaminated gasoline or an oil/gasoline mixture. Avoid getting dirt or water in the fuel tank. You may use regular unleaded gasoline containing no more than 10% ethanol (E10) or 5% methanol by volume.
  • Page 45: Engine Oil Level Check

    SERVICING YOUR GENERATOR ENGINE OIL LEVEL CHECK Check the engine oil level with the generator on a level surface and the engine stopped. Place the generator on a level surface. Loosen the cover screw and remove the maintenance cover. COVER SCREW MAINTENANCE COVER...
  • Page 46 SERVICING YOUR GENERATOR Remove the oil filler cap and wipe the dipstick clean. Check the oil level by inserting the dipstick into the oil filler neck without screwing it in. If the level is low, fill to the upper limit of the oil filler neck with the recommended oil.
  • Page 47: Engine Oil Change

    SERVICING YOUR GENERATOR ENGINE OIL CHANGE Drain the oil while the engine is warm to assure rapid and complete draining. Turn the engine switch and fuel tank cap vent lever to the OFF position (see page ) to reduce the possibility of fuel leakage. Loosen the cover screw and remove the maintenance cover (see page 43 ).
  • Page 48: Engine Oil Recommendations

    AMBIENT TEMPERATURE The SAE oil viscosity and service category are in the API label on the oil container. Honda recommends that you use API service category SJ or later (or equivalent) oil.
  • Page 49: Air Cleaner Service

    SERVICING YOUR GENERATOR AIR CLEANER SERVICE COVER SCREW Loosen the cover screw and remove the maintenance cover. MAINTENANCE COVER Loosen the air cleaner cover screw, and remove the air MAIN FILTER cleaner cover. AIR CLEANER COVER SCREW OUTER FILTER Remove the main and outer AIR CLEANER COVER filters from the air cleaner cover.
  • Page 50 SERVICING YOUR GENERATOR Reinstall the air filters. AIR CLEANER COVER Make sure that the rubber seal is set in the groove of the air cleaner cover. Reinstall the air cleaner cover, and tighten the air cleaner cover screw. RUBBER SEAL Reinstall the maintenance cover, and tighten the cover screw securely.
  • Page 51: Main And Outer Filter Cleaning

    SERVICING YOUR GENERATOR MAIN AND OUTER FILTER CLEANING A dirty main and outer filters will restrict air flow to the carburetor, reducing engine performance. If you operate the generator in very dusty areas, clean the main and outer filters more frequently than specified in the Maintenance Schedule.
  • Page 52: Spark Plug Service

    SERVICING YOUR GENERATOR SPARK PLUG SERVICE In order to service the spark plug, you will need a spark plug wrench (commercially available). Recommended spark plug: CR5HSB (NGK) To ensure proper engine operation, the spark plug must be properly gapped and free of deposits. An incorrect spark plug can cause engine damage.
  • Page 53 SERVICING YOUR GENERATOR Inspect the spark plug. Replace it if the electrodes are worn or if the insulator is cracked, SEALING WASHER chipped, or fouled. 0.024 0.028 in (0.6 0.7 mm) Measure the spark plug electrode gap with a wire-type feeler gauge.
  • Page 54: Spark Arrester Service

    SERVICING YOUR GENERATOR SPARK ARRESTER SERVICE The spark arrester must be serviced every 100 hours to keep it functioning as designed. If the engine has been running, the muffler will be very hot. Allow the muffler to cool before servicing the spark arrester. Clean the spark arrester as follows: Remove the four 6 mm screws, and remove the muffler protector.
  • Page 55 SERVICING YOUR GENERATOR Use a brush to remove carbon deposits from the spark arrester screen. Be careful to avoid damaging the screen. The spark arrester must be free of breaks and tears. Replace the spark arrester if it is damaged. Check the muffler gasket;...
  • Page 56: Storage

    STORAGE STORAGE PREPARATION Proper storage preparation is essential for keeping your generator trouble-free and looking good. The following steps will help to keep rust and corrosion from impairing your generator’s function and appearance, and will make the engine easier to start when you use the generator again.
  • Page 57 STORAGE Adding a Gasoline Stabilizer to Extend Fuel Storage Life When adding a gasoline stabilizer, fill the fuel tank with fresh gasoline. If only partially filled, air in the tank will promote fuel deterioration during storage. If you keep a container of gasoline for refueling, be sure that it contains only fresh gasoline.
  • Page 58 STORAGE Draining the Fuel Tank and Carburetor Gasoline is highly flammable and explosive. You can be burned or seriously injured when handling fuel. Stop the engine and keep heat, sparks, and flame away. Handle fuel only outdoors. Wipe up spills immediately. Unscrew the fuel tank cap (see page 41), remove the debris screen, and empty the fuel tank into an approved gasoline container.
  • Page 59: Engine Oil

    STORAGE Engine Oil Change the engine oil (see page 45). Remove the spark plug (see page 50), and pour approximately one teaspoon (5-10 cc) of clean engine oil into the cylinder. Crank the engine several revolutions to distribute the oil, then reinstall the spark plug.
  • Page 60: Storage Precautions

    STORAGE STORAGE PRECAUTIONS If your generator will be stored with gasoline in the fuel tank and carburetor, it is important to reduce the hazard of gasoline vapor ignition. Select a well ventilated storage area away from any appliance that operates with a flame, such as a furnace, water heater, or clothes dryer. Also avoid any area with a spark-producing electric motor, or where power tools are operated.
  • Page 61: Transporting

    TRANSPORTING Do not lay the generator on its side when moving, storing, or operating it. Oil may leak and damage the engine or your property. If the generator has been used, allow it cool for at least 15 minutes before loading the generator on the transport vehicle. A hot engine and exhaust system can burn you and can ignite some material.
  • Page 62: Taking Care Of Unexpected Problems

    (p. 50). Spark plug wet with fuel Dry and reinstall spark plug. (flooded engine). Fuel filter restricted, Take the generator to an carburetor malfunction, authorized Honda servicing ignition malfunction, valves dealer, or refer to the shop stuck, etc. manual.
  • Page 63: Engine Lacks Power

    (p. 56). gasoline, or refueled with bad Refuel with fresh gasoline gasoline. (p. 40). Fuel filter restricted, Take the generator to an carburetor malfunction, authorized Honda servicing ignition malfunction, valves dealer, or refer to the shop stuck, etc. manual.
  • Page 64: No Power At The Receptacles

    Check AC load and reset circuit protector (p. 16). Faulty power tool or Replace or repair power tool or appliance. appliance. Stop and restart the engine. Faulty generator. Take the generator to an authorized Honda servicing dealer, or refer to the shop manual.
  • Page 65: Technical & Consumer Information

    TECHNICAL & CONSUMER INFORMATION TECHNICAL INFORMATION Serial Number Location FRAME SERIAL NUMBER Record the frame serial number and date purchased in the spaces below. You will need this information when ordering parts, and when making technical or warranty inquiries. Frame serial number: Date purchased:...
  • Page 66: Carburetor Modification For High Altitude Operation

    High altitude performance can be improved by specific modifications to the carburetor. If you always operate your generator at altitudes above 5,000 feet (1,500 meters), have your authorized Honda servicing dealer perform this carburetor modification. This engine, when operated at high altitude with the carburetor modifications for high altitude use, will meet each emission standard throughout its useful life.
  • Page 67: Emission Control System Information

    The following instructions and procedures must be followed in order to keep the Honda engine emissions within the emission standards. Tampering and Altering Tampering with or altering the emission control system may increase emissions beyond the legal limit.
  • Page 68 Afterburning (backfiring). Black exhaust smoke or high fuel consumption. Replacement Parts The emission control systems on your new Honda engine were designed, built, and certified to conform with applicable emission regulations. We recommend the use of Honda Genuine parts whenever you have maintenance done. These original-design replacement parts are manufactured to the same standards as the original parts, so you can be confident of their performance.
  • Page 69: Air Index

    TECHNICAL & CONSUMER INFORMATION Air Index (Models certified for sale in California) An Air Index Information label is applied to engines certified to an emission durability time period in accordance with the requirements of the California Air Resources Board. The bar graph is intended to provide you, our customer, the ability to compare the emissions performance of available engines.
  • Page 70: Specifications

    Refer to page 50 (0.6 0.7 mm) Valve clearance (cold) IN: 0.15 0.04 mm See your authorized EX: 0.20 0.04 mm Honda dealer. Other specifications No other adjustments needed. Specifications may vary according to the types, and are subject to change without notice.
  • Page 71: Wiring Diagram

    TECHNICAL & CONSUMER INFORMATION Wiring Diagram...
  • Page 72: Consumer Information

    TECHNICAL & CONSUMER INFORMATION CONSUMER INFORMATION Dealer Locator Information To find an authorized Honda Servicing Dealer anywhere in the United States: Visit our website: www.hondapowerequipment.com Honda Publications Shop Manual This manual covers complete maintenance and overhaul procedures. It is intended to be used by a skilled technician.
  • Page 73: Customer Service Information

    TECHNICAL & CONSUMER INFORMATION Customer Service Information Honda Power Equipment dealership personnel are trained professionals. They should be able to answer any question you may have. If you encounter a problem that your dealer does not solve to your satisfaction, please discuss it with the dealership’s management.
  • Page 74: Distributor's Limited Warranty

    What American Honda will Repair or Replace Under Warranty: American Honda will repair or replace, at its option, any part that is proven to be defective in material or workmanship under normal use during the applicable warranty time period. Warranty repairs and replacements will be made without charge for parts or labor.
  • Page 75: Emission Control System Warranty

    Disclaimer of Consequential Damage and Limitation of Implied Warranties: American Honda disclaims any responsibility for loss of time or use of the product, transportation, commercial loss, or any other incidental or consequential damage. Any implied warranties are limited to the duration of this written limited warranty.
  • Page 76 U.S. EPA and Environment Canada emission standards for spark-ignited engines at or below 19 kilowatts. Specific Honda products that do not meet the California emissions regulations can be identified by a ‘‘Not for Sale in California’’...
  • Page 77 United States, and Canadian certified engines manufactured on or after January 1, 2005 are covered by this warranty for a period of two years or the length of the Honda Distributor’s Limited Warranty , whichever is longer from the date of delivery to the original retail purchaser.
  • Page 78 You must take your Honda Power Equipment engine or the product on which it is installed, along with your sales registration card or other proof of original purchase date, at your expense, to any Honda Power Equipment dealer who is authorized by Honda to sell and service that Honda product during his normal business hours.
  • Page 79 Tubing, fittings, seals, gaskets, and clamps associated with these listed systems. Note: This list applies to parts supplied by Honda and does not cover parts supplied by the equipment manufacturer. Please see the original equipment manufacturer’s emissions warranty for non-Honda parts.
  • Page 80: Initial Use Instructions

    INITIAL USE INSTRUCTIONS ENGINE OIL The generator is shipped WITHOUT OIL in the engine. Place the generator on a level surface. Loosen the cover screw and remove the maintenance cover. COVER SCREW MAINTENANCE COVER With the generator in a level position, remove the oil filler cap/ dipstick.
  • Page 81: Fuel

    INITIAL USE INSTRUCTIONS FUEL Add fuel to the generator in a well-ventilated area. Never refuel the engine inside a building where gasoline fumes may reach flames or sparks. Keep gasoline away from appliance pilot lights, barbecues, electric appliances, power tools, etc. Spilled fuel is not only a fire hazard, it causes environmental damage.
  • Page 82 INITIAL USE INSTRUCTIONS Fuel carefully to avoid spilling fuel. Do not fill the fuel tank above the upper level mark (red) on the fuel strainer. NON-CALIFORNIA TYPE CALIFORNIA TYPE UPPER LEVEL MARK (RED) UPPER LEVEL MARK (RED) TETHER Fuel can damage paint and plastic. Be careful not to spill fuel when filling your fuel tank.
  • Page 83 INITIAL USE INSTRUCTIONS After refueling, tighten the fuel tank cap securely (for Non-California types) or until it clicks (for California types). Keep the fuel tank cap vent lever OFF for storage or transport, and ON to run the generator. NON-CALIFORNIA TYPE CALIFORNIA TYPE FUEL TANK CAP VENT LEVER Move the generator at least 10 feet (3 meters) away from the fueling...
  • Page 84: Before Operation

    Please Register Your Generator If your dealer did not collect registration information from you, please take a few minutes and register your purchase with Honda. This allows us to contact you with any important updates regarding your generator. Please note registration is not required to obtain warranty service.
  • Page 85: Index

    INDEX AC Applications ..................29 AC Circuit Protector ................16 AC OPERATION ..................28 AC PARALLEL OPERATION ..............30 AC Parallel Operation Applications ........... . 32 AIR CLEANER SERVICE ............... 47 Air Index ....................67 ARE YOU READY TO GET STARTED? ..........
  • Page 86 . 42 Fuel Tank Cap Vent Lever ..............14 GENERATOR SAFETY ................Ground Terminal ................. . 17 Honda Publications ................70 IMPORTANT SAFETY INFORMATION ..........INITIAL USE INSTRUCTIONS ............. 78 IS YOUR GENERATOR READY TO GO? ..........
  • Page 87 INDEX MAIN AND OUTER FILTER CLEANING ..........49 MAINTENANCE SAFETY ..............38 MAINTENANCE SCHEDULE .............. . 39 NO POWER AT THE RECEPTACLES ........... 62 Oil Alert Indicator ................19 OPERATION ..................22 Operator Responsibility ............... Output Indicator ..................
  • Page 88 INDEX SAFE OPERATING PRECAUTIONS ........... . 22 SAFETY LABEL LOCATIONS ..............Safety Precautions ................38 Serial Number Location ..............63 SERVICING YOUR GENERATOR ............37 SPARK ARRESTER SERVICE .............. . 52 SPARK PLUG SERVICE ............... . 50 Special Requirements ................
  • Page 89 MEMO...
  • Page 90 MEMO...
  • Page 91: Quick Reference Information

    QUICK REFERENCE INFORMATION Fuel Type Regular unleaded gasoline with a pump octane rating of 86 or higher Engine Oil Type SAE 10W-30, API SJ or later (or equivalent), for general use (page 46) Spark Plug Type NGK: CR5HSB Electrode Gap 0.024 0.028 in (0.6 0.7 mm) Maintenance Before each use...
  • Page 92 2eY16000.2008.07 31Z07700 00X31-Z07-7000 Printed in Japan...
