Dual Diaphragm Condenser Microphone; Specifications - Behringer B-2 PRO User Manual

4
DUAL DIAPHRAGM CONDENSER MICROPHONE B-2 PRO User Manual
330°
300°
270°
240°
250 Hz
210°
500 Hz
1000 Hz
2000 Hz
Polar pattern (omnidirectional)
dB
20.0
10.0
0.0
-10.0
Low cut
-20.0
50.0 100.0
Frequency response (omnidirectional)
330°
300°
270°
240°
250 Hz
210°
500 Hz
1000 Hz
2000 Hz
Polar pattern (figure eight)
dB
20.0
10.0
0.0
-10.0
Low cut
-20.0
50.0 100.0
Frequency response (figure eight)
0°
0 dB
30°
-5 dB
-10 dB
-15 dB
60°
-20 dB
-25dB
-30 dB
90°
120°
150°
4000 Hz
180°
8000 Hz
16000 Hz
1000.0 10k 15k 20k Hz
0 dB
30°
-5 dB
-10 dB
-15 dB
60°
-20 dB
-25dB
-30 dB
90°
120°
150°
4000 Hz
180°
8000 Hz
16000 Hz
1000.0 10k 15k 20k Hz
7.

Specifications

Transducer type
Operating principle
Polar pattern
Connection
Open Circuit Sensitivity (at 1 kHz)
cardioid
omnidirectional
figure eight
Frequency response
Level attenuation
Low-Cut filter
Max. SPL (1% THD @ 1 kHz)
cardioid
omnidirectional
figure eight
Equivalent SPL (IEC 651)
cardioid
omnidirectional
figure eight
Signal-to-Noise Ratio
cardioid
omnidirectional
figure eight
Nominal impedance
Load impedance
Mains Voltage/Fuse
Supply voltage
Supply current
Physical/Weight
Dimensions
Weight
condenser, 1" dual-diaphragm
pressure gradient
cardioid, omnidirectional
or figure eight
gold-plated balanced XLR connector
-36 dBV (0 dBV = 1 V/Pa), 16 mV/Pa
-37 dBV (0 dBV = 1 V/Pa), 14 mV/Pa
-35 dBV (0 dBV = 1 V/Pa), 18 mV/Pa
20 Hz - 20 kHz
-10 dB (switchable)
6 dB/oct. at 150 Hz (switchable)
138 dB (0 dB), 148 dB (-10 dB)
139 dB (0 dB), 149 dB (-10 dB)
137 dB (0 dB), 147 dB (-10 dB)
17 dB-A
18 dB-A
16 dB-A
77 dB, A-weighted
76 dB, A-weighted
78 dB, A-weighted
<100 Ω
>1 kΩ
+48 V
3 mA
Ø head: 56 mm, Ø shaft: 50 mm,
length: 210 mm
approx. 0.55 kg
