STAGE DIMMER 6 TFX-6D User Guide Please read these instructions carefully before use World-wide Headquarters: 3000 North 29th Ct., Hollywood, Florida, USA, FL 33020 Tel: +1-954-929-1115 Fax: +1-954-929-5560 www.ChauvetLighting.com...
Page 2
Introduction Congratulations on the purchase of your new Chauvet dimmer pack. We are confident that you will enjoy many trouble free hours with this unit. To assist with the use and care of this unit, we have pre- pared this short guide.
Page 3
Drawing A NOTE: ALL ELECTRICAL WORK MUST BE DONE BY A QUALIFIED ELECTRICIAN Single phase hookup 1. 6 single tap terminals for positive (do not jump terminals) 2. Ground wires go here (terminals are already jumped together) 3. All neutral wires should be attached here (terminals are already jumped together) 4.
CHAUVET. Troubleshooting • If the unit is not functional - check that unit is fully plugged in and then check circuit breaker. No user serviceable parts inside, please refer to CHAUVET for service. Technical Assistance: 1-800-762-1084 (954) 929-1115 E-Mail tech@chauvetlighting.com...
