- Page 1 Read all instructions BEFORE assembly and USE of product. KEEP INSTRUCTIONS FOR FUTURE USE. Model #9178TW US PATENT # 6196571, DES.430826 Expedition Double Jogging Stroller ® Instruction Manual Convenience through Innovation and thoughtful design 12.05...
- Page 2 8:00 a.m. and 4:30 p.m. Pacific Coast Time. Please do not return the product to the store as once it is returned it cannot be re-sold and the materials and energy used to make it are wasted. To contact us: BABY TREND, INC. Parts Hotline: 1567 S. Campus Ave.
- Page 3 PARTS Front Wheel Fender Fender Screws Stroller Rear Wheels Parent Tray Parent Tray Screws TO ENSURE SAFE OPERATION OF YOUR STROLLER, PLEASE FOLLOW THESE INSTRUCTIONS CAREFULLY. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE. TO ASSEMBLE JOGGING STROLLER • Remove stroller from box. The front wheel, rear wheels, fender, and parent tray need to be installed prior to use.
- Page 4 • The front fender is secured to the frame by the 5 screws provided. Close Examine the bottom of the front fender. You will notice four inch diameter plastic tubes protruding from the bottom. See figure 7a. These tubes must be lined up with the holes in the front frame assembly. See Open figure 7b.
- Page 5 Open Close Figure 10. Figure 11. Figure 11a. TO SECURE THE CHILD Shoulder Strap • The shoulder straps of the 5-point harness have 2 attachment positions. Select the position that places the shoulder strap level with, or below the top of the child's shoulder. Figure 12a.
-
Page 6: To Fold Stroller
BRAKES WARNING: Always set brakes when the stroller is not being pushed so that the stroller will not roll away. Never leave stroller unattended on a hill or incline as the stroller may slide down the hill. • To engage brakes, apply light downward pressure to the brake lever located on each rear wheel. -
Page 7: To Unfold Stroller
TO UNFOLD STROLLER WARNING: Care must be taken when folding and unfolding the stroller to prevent finger entrapment. Un-Lock • Stand the stroller on the ground with all three wheels touching the ground. Release the folding latch, which is located on the right side. See figure •... -
Page 8: Troubleshooting
TROUBLE SHOOTING Stroller pulls to one side: The jogging stroller is unusual in that it has no swiveling front wheels. Therefore, the stroller may at times feel like it is pulling to one side. This problem can have two different causes, either individually or in combination. Please perform the following steps in their numbered order. - Page 9 Flat tire: The jogging stroller features bicycle tires to allow for extended wear and ease of pushing. Just like a bicycle tire, the jogging stroller can suffer from flat tires. If you have a flat tire, you can use a standard bicycle tire repair kit to repair the tire or you can take the tire to a bicycle shop for repair.
