Important Safety Instructions
Please read the following instructions carefully. This manual should be retained for future use.
1. To clean LCD Monitor screen;
-- Power off LCD Monitor and unplug the AC Cord.
-- Spray a non-solvent cleaning solution onto a rag.
-- Gently clean the screen with dampened rag.
2. Do not place the LCD Monitor near a window. Exposing the monitor to rain water, moisture or sunlight can severely
damage it.
3. Do not apply pressure to the LCD screen. Excess pressure may cause permanent damage to the display.
4. Do not remove the cover or attempt to service this unit by yourself. Servicing of any nature should be performed by an
authorized technician.
5. Store LCD Monitor in a room with a room temperature of -20° ~ 60°C (or -4° ~ 140°F). Storing the LCD Monitor outside
this range could result in permanent damage.
6. If any of the following occurs, immediately unplug your monitor and call an authorized technician.
* Monitor to PC signal cable is frayed or damaged.
* Liquid spilled into LCD Monitor or the monitor has been exposed to rain.
* LCD Monitor or the case is damaged.
7. A certified line is required to connect this device to a power outlet. For a nominal current up to 6A and a device weight
above 3 kg, a line not lighter than H05VV-F, 3G, 0.75 mm
8. For use only with power supply LINEARITY LAD6019AB5 and Li-shin, LSE9901B1260.

Chapter 1 Installation

Unpacking

Before unpacking the LCD Monitor, prepare a suitable workspace for your Monitor and computer. You need a stable and clean
surface near a wall power outlet. Make sure that LCD Monitor has enough space around it for sufficient airflow. Though the
LCD Monitor uses very little power, some ventilation is needed to ensure that the Monitor does not become too hot.
After you unpack the LCD Monitor, make sure that the following items were included in the box:
* LCD Monitor
* 1.8M Monitor-to-PC VGA Cable
* 1.8M Monitor-to-PC DVI-D Cable
* 1.5M Stereo Jack Audio Cable
If you find that any of these items is missing or appears damaged, contact your dealer immediately.

Viewing Angle Adjustment

The LCD Monitor is designed to allow users to have a comfortable
viewing angle. The viewing angle can be adjusted from -5°to +25°.(See
fig. 1-1)& Left / Right -45° to +45°
Warning: Do not force the LCD Monitor over its maximum viewing angle settings as stated above. Attempting this will
result in damaging the Monitor and Monitor stand.

Detaching LCD Monitor from Its Stand

Unscrew screws the swivel base support column and pull down
must be used.
2
* User's Manual
* AC Adapter
* 1.8M Power Cord
the second.
2
Figure 1-1
Figure 1-2
