Available Drives:
Port 2 - QUANTUM FIREBALLP LM30
*Port 3 - QUANTUM FIREBALLP LM30
Disk Arrays:
*Array Unit 1 - 2 drive Mirror
Port 1 - QUANTUM FIREBALLP LM30
Create Array
Alt-F1 Help
Restore Initial Values
F6

Figure 20. Select Available Drive to Replace Faulted Drive,

RAID 1 Example
8 Navigate to the Rebuild Array button and press Enter (see
Figure 21). A status screen will be displayed with your
requested array and member drives.
9 Select OK to continue.
