Wireless sender/receiver (front panel)
# Feature
Standby indicator Turns red when the wireless sender/receiver is in standby mode.
1
Power/Join
2
button
Power/Join
indicator
3
Sender mode
4
indicator
Description
Press to turn the wireless sender/receiver on. Press and hold to initiate joining.
Press again to go to standby mode. When you connect the AC power adapter,
the device turns on automatically.
Lights blue when the HUB STATUS switch is set to DISABLE.
Lights green when the HUB STATUS switch is set to ENABLE.
The indicator will turn solid when it is joined in a network, if the device is not in
a network, the indicator blinks slowly. When the device is put in joining mode,
the indicator blinks rapidly. See "Establishing communication" on page 21 for
more information.
Turns blue when sending audio.
Note: This indicator will light automatically when a 3.5 mm connector or a USB
cable is attached to the device (the device senses the cable connection).
RF-RBUSB 9
