- Page 1 PT-F300 P ro d u c t N u m b e r : LCD Projector P ro d u c t N a m e : As of May 2009. Appearance and specifications are subject to change without notice. <...
-
Page 2: Specifications
PT-F300 LCD Projector Specifications Power supply 100–240 V AC, 50/60 Hz Power consumption 350 W (Approx. 4 W in standby mode with fan stopped. Approx. 25 W when standby mode is turned on by a Web browser, and approx. 35 W when audio is output during standby mode.) Optical system Dichroic mirror separation/prism synthesis system... -
Page 3: Lcd Projector
PT-F300 LCD Projector VIDEO IN RCA pin x 1, 1.0 Vp-p, 75 ohms S-VIDEO IN Mini DIN 4-pin x 1, Y: 1.0 Vp-p, C: 0.286 Vp-p, 75 ohms COMPUTER AUDIO IN 1 M3 (stereo) x 1, 0.5 Vrms, for COMPUTER 1 COMPUTER AUDIO IN 2 M3 (stereo) x 1, 0.5 Vrms, for DVI-D and COMPUTER 2 AUDIO IN... - Page 4 PT-F300 LCD Projector Dimensions unit : mm (inch) NOTE: This illustration is not drawn to scale. (3-11/32˝) (12-1/4˝) (8-3/8˝) (2-3/32˝) (17˝) Terminals DVI-D input 5 6 7 Computer 1 input Computer 2 input/computer 1 output S-Video input Video input Audio input for S-Video and video Serial input Remote input Audio input for computer 1...
-
Page 5: Standard Setting-Up Positions
PT-F300 LCD Projector Standard setting-up positions unit : mm (inch) Ø49 Upper edge of projected image (1-15/16˝) Ø42 (1-21/32˝) Projected image (7-27/32˝) Lower edge of projected image L: Distance to screen H: Height from the edge of screen to center of lens 70 (2-3/4˝) NOTE: Illustrations show the projector installed... - Page 6 PT-F300 LCD Projector Shift range Optical axis shift function allows to shift the position of a projected image as shown below. (Width of projected image) 0.27H 0.27H Standard postition of projected image Installable angle Install the projector at an angle within the range shown below.. •...
- Page 7 PT-F300 LCD Projector Computer data compatibility This projector accepts up to 91 kHz horizontal scanning frequency and 162 MHz dot clock. NOTE: Pixel thinning is applied to signals that exceed a dot clock frequency of 150 MHz. The display resolution of this projector is 1,024 x 768 pixels.
- Page 8 PT-F300 LCD Projector Serial connector The serial connector complies with RS-232C. To control the projector from a personal computer, com- mands must be input through communication software, based on the format and satisfying the commu- nication conditions shown below. Pin assignments and signal names Signal name Signal name Description...
-
Page 9: Control Commands
PT-F300 LCD Projector Control commands Command: <Parameter> Function Callback: <Parameter> Parameter value Power on (standby mode on) PO N – – Power off (standby mode off) PO F – – Volume control AV L: < pl > AVL:<pl > Input signal selection II S: <... -
Page 10: Parameter Format
PT-F300 LCD Projector Parameter format Parameter format Size (Byte) Definition <pl> 3 (1 or 2 bytes also Decimal without signs: 0-999 (000, 001, 002...999) possible when Decimal with signs: -99 to +99 (-99...-01, +00, +01, +02...+99) under control) Callback from the projector is 3 Byte. <off on>... -
Page 11: Notes On Projector Placement And Operation
PT-F300 LCD Projector Notes on Projector Placement and Operation The projector uses a high-wattage lamp that becomes very hot during operation. Please observe the following precautions. Never place objects on top of the projector while it is operating. Make sure there is an unobstructed space of 500 mm (19-11/16˝) or more around the projector's exhaust open- ings.
