Information Files

This monitor includes a diskette with two information files that should
be installed onto your computer—an INF file and an ICM file. The INF
file defines monitor resources, and provides specifications used by
Windows 95 to install support software for certain hardware devices.
The INF file ensures monitor compatibility with your computer's
graphics adapter. The ICM file provides color matching consistency
from monitor screen to printer and is activated from within the graphics
programs that have this feature. To install these files onto your
computer, follow the instructions on the "Configuring Your Compaq
CRT Monitor" card located in the Program License Agreement packet
along with the diskette.

Installing the Monitor

To install the monitor, ensure that the power to the monitor, computer
system, and other attached devices is turned off; then follow these steps:
1. Place the monitor in a convenient, well-ventilated location near
your computer.
2. Connect the monitor signal cable to the 15-pin connector
the rear panel of the computer. Tighten the screws on the end of
the connector.
IMPORTANT: Be sure the signal cable aligns with the 15-pin connector.
Do not force the cable onto the connector or you may damage the signal
cable.
3. Connect the monitor power cord
beneath the back panel of the monitor, then plug the other end of
the cord into an electrical outlet that is easily accessible and close
to the monitor.
to the connector that is
on
English 1-3
