Summary of Contents for Asus B75M-A

  • Page 1 B75M-A...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Table Of Contents

    Package contents ..................xi Chapter 1: Product introduction Special features ................1-1 1.1.1 Product highlights ............1-1 1.1.2 ASUS Exclusive features ..........1-1 Before you proceed ..............1-4 Motherboard overview ..............1-4 1.3.1 Placement direction ............1-4 1.3.2 Screw holes ..............1-5 1.3.3...
  • Page 4 2.1.1 ASUS Update utility ............2-1 2.1.2 ASUS EZ Flash 2 ............2-2 2.1.3 ASUS CrashFree BIOS 3 utility ........2-3 2.1.4 ASUS BIOS Updater ............2-4 BIOS setup program ..............2-6 BIOS menu screen ................. 2-7 Main menu .................. 2-10 2.3.1...
  • Page 5 2.7.11 Boot Option Priorities ............ 2-34 2.7.12 Boot Override ..............2-34 Tools menu ................. 2-35 2.8.1 ASUS EZ Flash 2 Utility ..........2-35 2.8.2 ASUS O.C. Profile ............2-35 2.8.3 ASUS SPD Information ..........2-35 Exit menu ..................2-36 Appendices Notices .......................A-1...

  • Page 6: Safety Information

    Safety information Electrical safety • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.

  • Page 7: Conventions Used In This Guide

    Refer to the following sources for additional information and for product and software updates. ASUS websites The ASUS website provides updated information on ASUS hardware and software products. Refer to the ASUS contact information. Optional documentation Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer.

  • Page 8: B75M-A Specifications Summary

    2 x DIMM, max. 16GB, DDR3 2200(O.C.) / 2000(O.C.) /1800 (O.C.) / 1600 / 1333 / 1066 MHz, non-ECC, un-buffered memory Dual-channel memory architecture * Refer to www.asus.com for the latest Memory QVL (Qualified Vendors List). ** When you install a total memory of 4GB capacity or more, Windows 32-bit ®...
  • Page 9 B75M-A specifications summary ASUS Exclusive Features: ASUS unique features - ASUS USB 3.0 Boost - ASUS Network iControl - ASUS AI Suite II - ASUS AI Charger - ASUS Anti-Surge Protection - ASUS UEFI BIOS ASUS Quiet Thermal Solution: - ASUS Fan Xpert...
  • Page 10 B75M-A specifications summary BIOS features 128 Mb Flash ROM, AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.5, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3 Manageability WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE...

  • Page 11: Package Contents

    SATA3G_1 EATXPWR SATA6G_1 SATA3G_4 SATA3G_2 1 x Serial ATA 3.0Gb/s cable ASUS B75M-A motherboard 1 x Serial ATA 6.0Gb/s cable 1 x I/O-Shield User Guide Support DVD • If any of the above items are damaged or missing, contact your retailer.

  • Page 13: Chapter 1: Product Introduction

    * Intel 3rd generation processors support DDR3 1600 MHz and higher frequency. ® 1.1.2 ASUS Exclusive features Native SATA 6.0 Gb/s support With Intel B75 Express Chipset native support for the next-generation Serial ATA (SATA) ® storage interface, this motherboard delivers up to 6.0 Gb/s data transfer rates. It also provides enhanced scalability, faster data retrieval, and double the bandwidth of current bus systems.

  • Page 14: Pci Express

    AI Suite II With its user interface, ASUS AI Suite II integrates several ASUS utilities and allows you to launch and operate these utilities simultaneously. It allows you to configure the overclocking settings, adjust the frequencies and related voltages, remotely control the system via a mobile device, and other easy-to-use helpful utilities.

  • Page 15: Asus Mylogo 2

    ASUS CrashFree BIOS 3 ASUS CrashFree BIOS 3 is an auto-recovery tool that allows you to restore a corrupted BIOS file using the bundled support DVD or USB flash disk that contains the latest BIOS file.

  • Page 16: Before You Proceed

    Before you proceed Take note of the following precautions before you install motherboard components or change any motherboard settings. • Unplug the power cord from the wall socket before touching any component. • Before handling components, use a grounded wrist strap or touch a safely grounded object or a metal object, such as the power supply case, to avoid damaging them due to static electricity.

  • Page 17: Screw Holes

    Screw holes Place six screws into the holes indicated by circles to secure the motherboard to the chassis. Do not overtighten the screws! Doing so can damage the motherboard. B75M-A Place this side towards the rear of the chassis ASUS B75M-A...

  • Page 18: Motherboard Layout

    1.3.3 Motherboard layout 17.8cm(7.0in) KBMS CPU_FAN DIGI +VRM USB34 ATX12V HDMI USB3_12 LAN1_USB12 BATTERY AUDIO B75M-A CHA_FAN PCIEX16 8111F PCIEX1_1 Intel ® Super PCIEX1_2 128Mb BIOS PCI1 SB_PWR USB78 USB56 USB3_34 SPEAKER AAFP F_PANEL Chapter 1: Product introduction...

  • Page 19: Layout Contents

    10. System panel connector (10-1 pin F_PANEL) 1-28 11. Speaker connector (4-pin SPEAKER) 1-29 12. USB 2.0 connectors (10-1 pin USB56, USB78) 1-31 13. Onboard LED (SB_PWR) 1-32 14. Clear RTC RAM (3-pin CLRTC) 1-20 15. Front panel audio connector (10-1 pin AAFP) 1-25 ASUS B75M-A...

  • Page 20: Central Processing Unit (Cpu)

    Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket contacts/motherboard components. ASUS will shoulder the cost of repair only if the damage is shipment/ transit-related.

  • Page 21: Installing The Cpu

    1.4.1 Installing the CPU The LGA1156 CPU is incompatible with the LGA1155 socket. DO NOT install a LGA1156 CPU on the LGA1155 socket. ASUS B75M-A...
  • Page 22 Chapter 1: Product introduction 1-10...

  • Page 23: Cpu Heatsink And Fan Assembly Installation

    1.4.2 CPU heatsink and fan assembly installation Apply the Thermal Interface Material to the CPU heatsink and CPU before you install the heatsink and fan if necessary. To install the CPU heatsink and fan assembly ASUS B75M-A 1-11...
  • Page 24 To uninstall the CPU heatsink and fan assembly Chapter 1: Product introduction 1-12...

  • Page 25: System Memory

    DDR2 DIMM socket. DDR3 modules are developed for better performance with less power consumption. The figure illustrates the location of the DDR3 DIMM sockets: Channel Sockets Channel A DIMM_A1 Channel B DIMM_B1 B75M-A B75M-A 240-pin DDR3 DIMM sockets ASUS B75M-A 1-13...

  • Page 26: Memory Configurations

    • The maximum 16GB memory capacity can be supported with 8GB or above DIMMs. ASUS will update the memory QVL once the DIMMs are available in the market. • The default memory operation frequency is dependent on its Serial Presence Detect (SPD), which is the standard way of accessing information from a memory module.
  • Page 27 3rd generation processors' behavior, DDR3 2250 (and above)/2133/1866 ® MHz memory module will run at DDR3 2200/2000/1800 MHz frequency as default. • Visit the ASUS website at www.asus.com for the latest QVL. DDR3-2400 MHz capability DIMM socket support (optional) Chip Vendors Part No.
  • Page 28 DDR3-1066 MHz capability DIMM socket Chip support (optional) Vendors Part No. Size SS/DS Chip No. Timing Voltage Brand 1DIMM 2DIMMs Crucial CT25664BA1067.16FF Micron 9HF22D9KPT • • J1108BFSE- KINGSTON KVR1066D3N7/2G ELPIDA 1.5V • • DJ-F DDR3-1866 MHz capability DIMM socket SS/DS Chip support (optional) Vendors Part No.
  • Page 29 KVR1333 Hynix H5TQ2G • • D3N9/4G 83AFR Micron MT16JTF512 Micron OLD22D • • 64AZ-1G4D1 9LGK NANYA NT4GC64B8 NANYA NT5CB256 • • HG0NF-CG M8GN-CG SAMSUNG M378B5273 SAMSUNG K4B2G0846C • • CH0-CH9 Transcend 8G DDR3 • • 1333 DIMM ASUS B75M-A 1-17...

  • Page 30: Installing A Dimm

    1.5.3 Installing a DIMM Unplug the power supply before adding or removing DIMMs or other system components. Failure to do so can cause severe damage to both the motherboard and the components. Press the retaining clips outward to unlock a DIMM socket. DIMM notch Align a DIMM on the socket such that the notch on the DIMM...

  • Page 31: Expansion Slots

    The PCI slots support LAN cards, SCSI cards, USB cards, and other cards that comply with PCI specifications. 1.6.4 PCI Express 2.0 x1 slots This motherboard supports PCI Express x1 network cards, SCSI cards, and other cards that comply with the PCI Express specifications. ASUS B75M-A 1-19...

  • Page 32: Jumpers

    1.6.5 PCI Express 3.0/2.0 x16 slot This motherboard supports PCI Express x1 network cards, SCSI cards, and other cards that comply with the PCI Express specifications. IRQ assignments for this motherboard Intel PCH SATA controller #0 – – – shared –...
  • Page 33 P/S 2 keyboard or by clicking on the P/S 2 mouse. This feature requires an ATX power supply that can supply at least 1A on the +5VSB lead, and a corresponding setting in the BIOS. PS2_USBPW34 +5VSB (Default) B75M-A B75M-A Keyboard Power Setting ASUS B75M-A 1-21...
  • Page 34 USB device wake-up (USBPW12, USBPW5-8) Set this jumper to +5V to wake up the computer from S1 sleep mode (CPU stopped, DRAM refreshed, system running in low power mode) using the connected USB devices. Set to +5VSB to wake up from S3 and S4 sleep modes (no power to CPU, DRAM in slow refresh, power supply in reduced power mode).

  • Page 35: Connectors

    8-channel configurations, the function of this port becomes Front Speaker Out. Microphone port (pink). This port connects to a microphone. Refer to the audio configuration table for the function of the audio ports in 2, 4, 6, or 8- channel configuration. ASUS B75M-A 1-23...
  • Page 36 Audio 2, 4, 6, or 8-channel configuration Headset Port 4-channel 6-channel 8-channel 2-channel Light Blue (Rear Line In Rear Speaker Out Rear Speaker Out Rear Speaker Out panel) Lime (Rear panel) Line Out Front Speaker Out Front Speaker Out Front Speaker Out Pink (Rear panel) Mic In Mic In...

  • Page 37: Internal Connectors

    Front Panel Type item in the BIOS setup to [HD]. If you want to connect an AC’97 front panel audio module to this connector, set the item to [AC97]. By default, this connector is set to [HD]. See section 2.5.7 Onboard Devices Configuration for details. ASUS B75M-A 1-25...
  • Page 38 The system may become unstable or may not boot up if the power is inadequate. • If you are uncertain about the minimum power supply requirement for your system, refer to the Recommended Power Supply Wattage Calculator at http://support.asus. com/PowerSupplyCalculator/PSCalculator.aspx?SLanguage=en-us for details. Chapter 1: Product introduction 1-26...
  • Page 39 These are not jumpers! Do not place jumper caps on the fan connectors! The CPU_FAN connector supports a CPU fan of maximum 2A (24 W) fan power. Only the 4-pin CPU fan supports the ASUS Fan Xpert feature. ASUS B75M-A 1-27...

  • Page 40: System Panel Connector

    System panel connector (10-1 pin PANEL) This connector supports several chassis-mounted functions. F_PANEL PWR LED PWR BTN PIN 1 B75M-A +HD_LED RESET B75M-A System panel connector • System power LED (2-pin PLED) This 2-pin connector is for the system power LED. Connect the chassis power LED cable to this connector.
  • Page 41 Service Pack 3 or later version before using Serial ATA ® hard disk drives. • When using hot-plug and NCQ, set the SATA Mode Selection item in the BIOS to [AHCI]. See section 2.5.3 SATA Configuration for details. ASUS B75M-A 1-29...
  • Page 42 This connector is for additional USB 3.0 ports. Connect the USB 3.0 bracket cable to this connector, then install the USB 3.0 bracket to the rear side of the chassis. If your chassis supports front panel ports, you can use the ASUS USB 3.0 header to install additional front panel USB 3.0 ports.

  • Page 43: Usb 2.0 Connectors

    These USB connectors comply with USB 2.0 specifications and supports up to 480Mbps connection speed. USB56 USB78 B75M-A PIN 1 PIN 1 B75M-A USB2.0 connectors Never connect a 1394 cable to the USB connectors. Doing so will damage the motherboard! The USB 2.0 module is purchased separately. ASUS B75M-A 1-31...

  • Page 44: Onboard Leds

    The contents of the Support DVD are subject to change at any time without notice. Visit the ASUS website at www.asus.com for updates. Chapter 1: Product introduction 1-32...
  • Page 45 Place the Support DVD into the optical drive. If Autorun is enabled in your computer, the DVD automatically displays the Specials screen which lists the unique features of your ASUS motherboard. Click Drivers, Utilities, Make Disk, Manual, and Contact tabs to display their respective menus.

  • Page 46: Intel ® Sba Support

    • Local Administrator rights on the target machine The Intel SBA does not support the 800 x 600 screen resolution. ® Visit the ASUS website at www.asus.com for the latest CPU QVL (Qualified Vendors List). Chapter 1: Product introduction 1-34...

  • Page 47: Chapter 2: Bios Information

    BIOS in the future. Copy the original motherboard BIOS using the ASUS Update utility. 2.1.1 ASUS Update utility The ASUS Update is a utility that allows you to manage, save, and update the motherboard BIOS in Windows environment. ®...

  • Page 48: Asus Ez Flash 2

    Follow the onscreen instructions to complete the updating process. 2.1.2 ASUS EZ Flash 2 The ASUS EZ Flash 2 feature allows you to update the BIOS without using an OS-based utility. Before you start using this utility, download the latest BIOS file from the ASUS website at www.asus.com.

  • Page 49: Asus Crashfree Bios 3 Utility

    2.1.3 ASUS CrashFree BIOS 3 utility The ASUS CrashFree BIOS 3 is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can restore a corrupted BIOS file using the motherboard support DVD or a USB flash drive that contains the updated BIOS file.

  • Page 50: Asus Bios Updater

    2.1.4 ASUS BIOS Updater The ASUS BIOS Updater allows you to update BIOS in a DOS environment. This utility also allows you to copy the current BIOS file that you can use as a backup when the BIOS fails or gets corrupted during the updating process.

  • Page 51: Updating The Bios File

    Ensure to load the BIOS default settings to ensure system compatibility and stability. Select the Load Optimized Defaults item under the Exit menu. Refer to section 2.9 Exit menu for details. • Ensure to connect all SATA hard disk drives after updating the BIOS file if you have disconnected them. ASUS B75M-A...

  • Page 52: Bios Setup Program

    The BIOS setup screens shown in this section are for reference purposes only, and may not exactly match what you see on your screen. • Visit the ASUS website at www.asus.com to download the latest BIOS file for this motherboard. •...

  • Page 53: Bios Menu Screen

    Selects the boot ASUS Optimal Selects the device priority mode Advanced mode functions • The boot device options vary depending on the devices you installed to the system.

  • Page 54: Advanced Mode

    The Advanced Mode provides advanced options for experienced end-users to configure the BIOS settings. The figure below shows an example of the Advanced Mode. Refer to the following sections for the detailed configurations. To access the EZ Mode, click Exit, then select ASUS EZ Mode. Back button Menu items...

  • Page 55: Menu Items

    You cannot select an item that is not user-configurable. A configurable field is highlighted when selected. To change the value of a field, select it and press <Enter> to display a list of options. ASUS B75M-A...

  • Page 56: Main Menu

    Main menu The Main menu screen appears when you enter the Advanced Mode of the BIOS Setup program. The Main menu provides you an overview of the basic system information, and allows you to set the system date, time, language, and security settings. 2.3.1 System Language [English] Allows you to choose the BIOS language version from the options.

  • Page 57: Administrator Password

    To clear the user password, follow the same steps as in changing a user password, but press <Enter> when prompted to create/confirm the password. After you clear the password, the User Password item on top of the screen shows Not Installed. ASUS B75M-A 2-11...

  • Page 58: Ai Tweaker Menu

    Ai Tweaker menu The Ai Tweaker menu items allow you to configure overclocking-related items. Be cautious when changing the settings of the Ai Tweaker menu items. Incorrect field values can cause the system to malfunction. The configuration options for this section vary depending on the CPU and DIMM model you installed on the motherboard.

  • Page 59: Dram Timing Control

    Configuration options: [Auto] [1 DRAM Clock] – [15 DRAM Clock] DRAM FOUR ACT WIN Time [Auto] Configuration options: [Auto] [1 DRAM Clock] – [63 DRAM Clock] DRAM WRITE to READ Delay [Auto] Configuration options: [Auto] [1 DRAM Clock] – [15 DRAM Clock] ASUS B75M-A 2-13...
  • Page 60 DRAM CKE Minimum pulse width [Auto] Configuration options: [Auto] [1 DRAM Clock] – [15 DRAM Clock] DRAM CAS# Write to Latency [Auto] Configuration options: [Auto] [1 DRAM Clock] – [15 DRAM Clock] DRAM RTL (CHA) [Auto] Configuration options: [Auto] [1 DRAM Clock] – [63 DRAM Clock] DRAM RTL (CHB) [Auto] Configuration options: [Auto] [1 DRAM Clock] –...

  • Page 61: Cpu Power Management

    Turbo Mode [Enabled] Allows you to enable your core processor’s speed to run faster than the marked frequency in a specific condition. Configuration options: [Disabled] [Enabled] ASUS B75M-A 2-15...

  • Page 62: Digi+ Vrm

    • Turbo Mode is only available on selected CPU models only. The following items appear only when you set the Turbo Mode to [Enabled]. • Turbo Mode Parameters Long Duration Power Limit [Auto] Allows you to limit the turbo ratio’s long duration power. Use the <+>...
  • Page 63 Current Capability [100%] Allows you to set the iGPU Current Capability. Configuration options: [100%] [110%] [120%] Do not remove the thermal module while changing the DIGI+ VRM related parrameters . The thermal conditions should be monitored. ASUS B75M-A 2-17...

  • Page 64: Advanced Menu

    Advanced menu The Advanced menu items allow you to change the settings for the CPU and other system devices. Be cautious when changing the settings of the Advanced menu items. Incorrect field values can cause the system to malfunction. 2.5.1 CPU Configuration The items in this menu show the CPU-related information that the BIOS automatically detects.
  • Page 65 Turbo Mode is only available on selected CPU models only. CPU C1E [Auto] [Auto] Automatically enables the C1E support function. [Enabled] Enables the C1E support function. This function must be enabled to enable or disable the Intel Turbo Mode Technology. ® [Disabled] Disables the function. ASUS B75M-A 2-19...

  • Page 66: Pch Configuration

    CPU C3 Report [Auto] Allows you to disable or enable the CPU C3 report to OS. Configuration options: [Auto] [Disabled] [Enabled] CPU C6 Report [Auto] Allows you to disable or enable the CPU C6(ACPI C3) report to OS. Configuration options: [Auto] [Disabled] [Enabled] Package C State Support [Auto] Allows you to disable or enable the Package C State support.

  • Page 67: Sata Configuration

    These items appear only when you set the SATA Mode Selection item to [AHCI] and allow you to enable/disable SATA Hot Plug Support. Configuration options: [Disabled] [Enabled] 2.5.4 System Agent Configuration Memory Remap Feature [Enabled] Allows you to enable remapping the memory above 4GB. [Enabled] Enables the function. [Disabled] Disables this function. ASUS B75M-A 2-21...

  • Page 68: Amt Configuration

    Graphics Configuration Allows you to select a primary display from iGPU, and PCIe graphical devices. Primary Display [Auto] Allows you to select which of the iGPU/PCIE Graphics device should be the Primary Display. Configuration options: [Auto] [iGPU] [PCIE] [PCI] iGPU Memory [Auto] Allows you to select the amount of system memory allocated to DVMT 5.0 used by the iGPU.

  • Page 69: Usb Configuration

    Disables the function. Intel xHCI Mode [Smart Auto] ® [Auto] Keeps the last operation of xHCI controller in OS during bootup. [Smart Auto] Enables the operation of xHCI controller. [Enabled] Enables the function. [Disabled] Disables the function. ASUS B75M-A 2-23...

  • Page 70: Onboard Devices Configuration

    EHCI Hand-off [Disabled] [Enabled] Enables the support for operating systems without an EHCI hand-off feature. [Disabled] Disables the function. USB Single Port Control USB3_1~USB3_4 [Enabled] Allows you to enable or disable an individual USB port. Refer to the section 1.3.3 Motherboard layout in this user manual for the locations of the USB ports.

  • Page 71: Network Stack

    This item allows user to disable or enable the Ipv4 PXE Boot support. Configuration options: [Disabled] [Enabled] Ipv6 PXE Support [Enabled] This item allows user to disable or enable the Ipv6 PXE Boot support. Configuration options: [Disabled] [Enabled] ASUS B75M-A 2-25...

  • Page 72: Monitor Menu

    Monitor menu The Monitor menu displays the system temperature/power status, and allows you to change the fan settings. 2.6.1 CPU Temperature / MB Temperature [xxxºC/xxxºF] The onboard hardware monitor automatically detects and displays the CPU and motherboard temperatures. Select Ignore if you do not wish to display the detected temperatures. 2.6.2 CPU / Chassis Fan Speed [xxxx RPM] or [Ignore] / [N/A]...

  • Page 73: Chassis Q-Fan Control [Enabled]

    Chassis Fan Speed Low Limit [600 RPM] This item appears only when you enable the Chassis Q-Fan Control feature and allows you to disable or set the chassis fan warning speed. Configuration options: [Ignore] [200RPM] [300 RPM] [400 RPM] [500 RPM] [600 RPM] ASUS B75M-A 2-27...

  • Page 74: Cpu Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage

    Chassis Fan Profile [Standard] This item appears only when you enable the Chassis Q-Fan Control feature and allows you to set the appropriate performance level of the chassis fan. [Standard] Sets to [Standard] to make the chassis fan automatically adjust depending on the chassis temperature.

  • Page 75: Boot Menu

    POST time. [Full Initialization] All USB devices will be available during POST. This process will extend the POST time. [Partial Initialization] For a faster POST time, only the USB ports with keyboard and mouse connections will be detected. ASUS B75M-A 2-29...

  • Page 76: Boot Logo Display [Enabled]

    PS/2 Keyboard and Mouse Support [Auto] Select any of these settings when PS/2 keyboard and mouse are installed. These settings only apply when Fast Boot is enabled. [Auto] For a faster POST time, PS/2 devices will only be available when the system boots up or rebooted when the PS/2 devices have not been reconnected or changed.

  • Page 77: Option Rom Messages [Force Bios]

    Boot from Storage Devices [Legacy OpROM first] Allows you to select the type of storage devices that you want to launch. Configuration options: [Both, Legacy OpROM first] [Both, UEFI first] [Legacy OpROM first] [UEFI driver first] [Ignore] ASUS B75M-A 2-31...

  • Page 78: Security Boot

    Boot from PCIe/PCI Expansion Devices [Legacy OpROM first] Allows you to select the type of PCIe/PCI expansion devices that you want to launch. Configuration options: [Legacy OpROM first] [UEFI driver first] 2.7.10 Security Boot Allows you to configure the Windows Secure Boot settings and manage its keys to protect ®...
  • Page 79 Append DB from file Allows you to load the additional DB from a storage device so that more images can be loaded securely. The DB file must be formatted as a UEFI variable structure with time-based authenticated variable. ASUS B75M-A 2-33...

  • Page 80: Boot Option Priorities

    • To select the boot device during system startup, press <F8> when ASUS Logo appears. • To access Windows OS in Safe Mode, do any of the following: •...

  • Page 81: Tools Menu

    <Enter> to display the submenu. 2.8.1 ASUS EZ Flash 2 Utility Allows you to run ASUS EZ Flash 2. Press [Enter] to launch the ASUS EZ Flash 2 screen. For more details, see section 2.1.2 ASUS EZ Flash 2. 2.8.2 ASUS O.C.

  • Page 82: Exit Menu

    This option allows you to exit the Setup program without saving your changes. When you select this option or if you press <Esc>, a confirmation window appears. Select Yes to discard changes and exit. ASUS EZ Mode This option allows you to enter the EZ Mode screen. Launch EFI Shell from filesystem device This option allows you to attempt to launch the EFI Shell application (shellx64.efi) from one of...

  • Page 83: Appendices

    Appendices Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference. • This device must accept any interference received including interference that may cause undesired operation.

  • Page 84: Canadian Department Of Communications Statement

    ASUS Recycling/Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components as well as the packaging materials.

  • Page 85: Asus Contact Information

    +1-812-282-3777 +1-510-608-4555 Web site usa.asus.com Technical Support Telephone +1-812-282-2787 Support fax +1-812-284-0883 Online support support.asus.com ASUS COMPUTER GmbH (Germany and Austria) Address Harkort Str. 21-23, D-40880 Ratingen, Germany +49-2102-959911 Web site www.asus.de Online contact www.asus.de/sales Technical Support Telephone +49-1805-010923* Support Fax...
  • Page 86 Appendices...
