- Page 1 ViewSonic ® DSM3210 Digital Signage Multimedia - User Guide - Guide de l’utilisateur - Guía del usuario ViewSonic Model No. : VS11770-1M ®...
-
Page 2: Table Of Contents
Cleaning the Digital Signage Multimedia ............5 Getting Started Package Contents ................... 6 Mounting ViewSonic Digital Signage Multimedia to the wall ......6 Front View of the Product ................7 Rear View of the Product ................8 Remote Control ....................9 Installation ....................... -
Page 3: Compliance Information
The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment Directive 2002/96/EC (WEEE). The mark indicates the requirement NOT to dispose the equipment as unsorted municipal waste, but use the return and collection systems according to local law. ViewSonic DSM3210... -
Page 4: Declaration Of Rohs Compliance
3. Lead in high temperature type solders (i.e. lead-based alloys containing 85% by weight or more lead). 4. Lead as an allotting element in steel containing up to 0.35% lead by weight, aluminium containing up to 0.4% lead by weight and as a cooper alloy containing up to 4% lead by weight. ViewSonic DSM3210... -
Page 5: Important Safety Instructions
15. This product is only to perform the useful function of entertainment and visual display tasks are excluded. ViewSonic DSM3210... -
Page 6: Copyright Information
Purchase Date: Product disposal at end of product life ViewSonic is concerned about the preservation of our environment. Please dispose of this product properly at the end of its useful life. Your local waste disposal company may provide information about proper disposal. -
Page 7: Antenna Installation Instructions
Digital Signage ® Multimedia screen or case. Some chemical cleaners have been reported to damage the screen and/or case of the Digital Signage Multimedia. ViewSonic will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners. ViewSonic... -
Page 8: Getting Started
• Install the wall mount plate to the Digital Signage Multimedia using screws NO LONGER than 10mm, as longer screws found in universal (non-ViewSonic) wall mount kits may damage the power supply causing the unit to fail. The wall-mount screw type is M6 x L10. -
Page 9: Front View Of The Product
1. Press VOL+ and MENU buttons at the same time to lock power button, and press VOL+ and MENU buttons again to unlock it. 2. Press VOL- and VOL+ buttons at the same time to lock OSD menu, and press VOL- and VOL+ buttons again to unlock it. ViewSonic DSM3210... -
Page 10: Rear View Of The Product
Connect this port to the VGA output of your PC. Headphone Jack Connect this port to your headphone. HDMI Input Terminal Connect this port to the HDMI output of A/V device. Power (AC input) Using power cord provided, connect to a power source. ViewSonic DSM3210... -
Page 11: Remote Control
Remote Control ViewSonic DSM3210... - Page 12 Volume mute ON/OFF TV/CATV Swap between TV/CATV PICTURE Select picture modes WIDE Change the image size RETURN Return to previous channel CH▲ and CH▼ Adjust Channel UP/DOWN FAV.CH Select from preset Favorite Channels MENU On Screen Display (OSD) menu ON/OFF ViewSonic DSM3210...
-
Page 13: Installation
See page 22. Note: Users can select either Air or Cable TV cable to be connected to the TV/DTV IN jack. To watch both of them, use an adapter to connect both Air and Cable cables to the jack. ViewSonic DSM3210... - Page 14 Connect Video/ Audio cables from compatible devices into the back panel of Digital Signage Multimedia. 1) With AV cable: RCA A/V Cable (not supplied) VCR or DVD Player 2) With S-Video cable: S-Video Cable (not supplied) Audio Cable (not supplied) VCR or DVD Player ViewSonic DSM3210...
- Page 15 4) With HDMI/ HDMI-DVI cable: (DVD Player should have the HDMI output terminal) VCR or DVD Player HDMI Cable (not supplied) Audio Cable (not supplied) (DVD Player should have the HDMI-DVI output terminal) VCR or DVD Player HDMI-DVI Cable (not supplied) ViewSonic DSM3210...
- Page 16 Connect the VGA cable from VGA output of computer to the VGA terminal input of your Digital Signage Multimedia. Also, Connect the Audio cable (green) from audio output of your Computer to the audio input terminal (green) of your Digital Signage Multimedia. PC Audio Connection (not supplied) VGA 15 Pin Cable (not supplied) ViewSonic DSM3210...
- Page 17 Connect the power cord to the AC inlet on the back of your Digital Signage Multimedia, after all connections have been completed, and plug the other end of the power cord into a correctly grounded electrical outlet. AC wall socket ViewSonic DSM3210...
-
Page 18: Basic Operation
To display the current information of the Digital Signage Multimedia: Press INFO, and the current state will be displayed on the screen. (It shows all or some of the information about Input, Channel, Resolution, Audio Type, etc., depending on what input source it is in.) ViewSonic DSM3210... - Page 19 There are several times for choice – Off, 10min, 20min, 30min, 40min, 50min, 60min, 90min, or 120min. Zoom Press ZOOM button repeatedly to select the screen size. You can select from Zoom x 1, Zoom x 2, Zoom x 4, Zoom x 1/4, and Zoom x 1/2 sizes. ViewSonic DSM3210...
- Page 20 • Use ▲▼ to select the control you want to adjust. • When selecting the control with II►, press ENTER to enable the function. • Press ◄► to adjust or select the settings. • Press MENU to exit from the OSD menu. ViewSonic DSM3210...
-
Page 21: Osd Functions
Contrast: To adjust contrast of video. (right: Max, left: Min.) • Color: To adjust color. (right: brilliant color, left: pale color.) • Tint: To adjust tint level. (right: greenish tone, left: reddish tone.) • Sharpness: To adjust picture sharpness. (right: sharper, left: softer.) ViewSonic DSM3210... -
Page 22: Audio Menu
＊ Phase: To adjust delay time of phase in order to reduce the noise of picture. ＊ Clock: To adjust delay time of clock in order to reduce the noise of picture. Audio Menu — To set the audio quality and status In TV source: ViewSonic DSM3210... -
Page 23: Tv Menu
TV Menu — To set up for TV It is only active in TV source. • Tuner Mode: To select Cable or Air as the TV source. Select “Cable” if you want to watch Cable TV channels, and select Air to watch Air TV channels. ViewSonic DSM3210... -
Page 24: Setup Menu
Audio Language: To select audio language from English, Spanish, or French. Setup Menu — To set up OSD window In TV, AV, S-Video, YPbPr, HDMI source: Note: When in AV, S-Video, YPbPr or HDMI source,the TV option on the left does not appear. ViewSonic DSM3210... - Page 25 Timer: To set power-on and power-off time. ＊ Sleep Timer: To set the off timer from 10~120 minutes. ＊ Auto Sleep: To set the off timer for longer intervals -- 1 hour, 2 hours, or 5 hours. ViewSonic DSM3210...
- Page 26 Font Opacity: To select font opacity from Solid, Translucent, or Transparent. Background Color: To select background color. Background Opacity: To select background opacity. Window Color: To select window color. Window Opacity: To select window opacity. • Memory Recall: To restore the factory default settings. ViewSonic DSM3210...
-
Page 27: Parental Menu
Enter password and the screen below will show. (The default password is 0000.) • Channel Block: To block channels. Use ▲▼ to select the channel you want to block, and then press ENTER to block or unblock it. ViewSonic DSM3210... - Page 28 TV-MA Mature audience only Use ENTER button to block or unblock the ratings, and use MENU to exit. ＊ U.S. Movie Ratings: To adjust movie blocking level in the US. You can select between G, PG, PG-13, R, NC-17, or X. ViewSonic DSM3210...
- Page 29 18 ans + Reserved to adults 13 ans + Not appropriate for children of less than 13 years Use ENTER button to block or unblock the ratings, and use MENU to exit. ＊ Block Unrated: To block unrated movie or TV programs. ViewSonic DSM3210...
- Page 30 Note: Please make sure you remember your new password after changing, because you cannot recall the default setting of the password by any selection. • Clear All: To clear all the locks set before, press ENTER, and then select “OK” to confirm. ViewSonic DSM3210...
-
Page 31: Other Information
Preset Timing Mode (Pre-adjusted to GTF® 1360 x 768 @ 60 Hz) Warning: Do not set the graphics card in your computer to exceed these refresh rates; doing so may result in permanent damage to the Digital Signage Multimedia. Note: Product Specifications are subject to change without notice. ViewSonic DSM3210... -
Page 32: Troubleshooting
• CATV is connected improperly or not connected; please check all the CATV connections. • The cable TV service is interrupted; please contact your cable operator. Picture is cut off/with sidebar screen • Is the image positioned correctly? • Are screen mode adjustments such as picture size set correctly? ViewSonic DSM3210... -
Page 33: Customer Support
Note: You will need the product serial number. Country/ T= Telephone Web Site Email Region F= Fax T (Toll-Free) = 1-800-688-6688 United States www.viewsonic.com T (Toll) = 1-424-233-2530 service.us@viewsonic.com F = 1-909-468-1202 T (Toll-Free) = 1-866-463-4775 Canada www.viewsonic.com T (Toll) = 1-424-233-2533 service.ca@viewsonic.com... -
Page 34: Limited Warranty
ViewSonic warrants its products to be free from defects in material and workmanship, under normal use, during the warranty period. If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will at its sole option repair or replace the product with a like product. -
Page 35: Mexico Limited Warranty
& accessories. How long the warranty is effective: ViewSonic Digital Signage Multimedia is warranted for 1 year for all parts excluding the light source and 1 year for labor from the date of the first customer purchase. Who the warranty protects: This warranty is valid only for the first consumer purchaser. - Page 36 Tel: 01(52)95-15-15-22-22 E-Mail: rrrb@sureste.com Fax: 01(52)95-15-13-67-00 E-Mail. gpotai2001@hotmail.com Tijuana: FOR USA SUPPORT: ViewSonic Corporation Av Ferrocarril Sonora #3780 L-C 381 Brea Canyon Road, Walnut, CA. 91789 USA Col 20 de Noviembre Tel: 800-688-6688 (English); 866-323-8056 (Spanish); Tijuana, Mexico Fax: 1-800-685-7276 E-Mail: http://www.viewsonic.com...
- Page 37 ViewSonic ®...
