2.4

Ai Tweaker menu

The Ai Tweaker menu items allow you to configure overclocking-related items.
Be cautious when changing the settings of the Ai Tweaker menu items. Incorrect field
values can cause the system to malfunction.
The configuration options for this section vary depending on the CPU and DIMM model you
installed on the motherboard.
EFI BIOS Utility - Advanced Mode
Main Ai Tweaker

Ai Overclock Tuner

Memory Frequency
OC Tuner
EPU Power Saving MODE
> DRAM Timing Control
> CPU Power Management
Offset Mode Sign
CPU Offset Voltage
DRAM Voltage
VCCIO Voltage
PCH Voltage
Load-Line Calibration
CPU Spread Spectrum
2.4.1 Ai Overclock Tuner [Auto]
Allows you to select the CPU overclocking options to achieve the desired CPU internal
frequency. Select any of these preset overclocking configuration options:
[Auto] Loads the optimal settings for the system.
[Manual] Allows you to individually set overclocking parameters.
BCLK/PEG Frequency [XXX]
This item appears only when you set the AI Overclock Tuner item to [Manual] and allows
you to adjust the CPU and VGA frequency to enhance the system performance. Use the <+>
and <-> keys to adjust the value. You can also key in the desired value using the numeric
keypad. The values range from 80.0MHz to 300.0MHz.
Chapter 2: BIOS information
Advanced
Auto
1.500V Auto
1.050V Auto
1.050V Auto
Version 2.00.1201. Copyright (C) 2010 American Megatrends, Inc.
Monitor Boot
[X.M.P.] When XMP is enabled BCLK
Auto frequency, CPU ratio and memory
parameters will be auto optimized.
Auto
Disabled
Disabled
+
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
Auto
F5: Optimized Defaults
F10: Save
Auto
Exit
Tool
ESC: Exit
2-13
