Before connecting, operating or adjusting this product,
For USA and Puerto Rico assistance, please call: 1-800-211-PANA(7262) or,
contact us via the web at: http://www.panasonic.com/contactinfo
P
Basic Owner's Manual
please read the instructions completely.
More detailed instructions on the
operation of this camera are
contained in "Owner's Manual for
advanced features (PDF format)" in the supplied
CD-ROM. Install it on your PC to read it.
Digital Camera
DMC-TS3
Model No.
VQT3L22
Advertisement
Table of Contents
Related Manuals for Panasonic DMC-TS3D
Summary of Contents for Panasonic DMC-TS3D
-
Page 1: Digital Camera
“Owner’s Manual for advanced features (PDF format)” in the supplied CD-ROM. Install it on your PC to read it. For USA and Puerto Rico assistance, please call: 1-800-211-PANA(7262) or, contact us via the web at: http://www.panasonic.com/contactinfo VQT3L22... - Page 2 Dear Customer, Thank you for choosing Panasonic! You have purchased one of the most sophisticated and reliable products on the market today. Used properly, we’re sure it will bring you and your family years of enjoyment. Please take time to fill in the information on the below.
-
Page 3: Information For Your Safety
Information for Your Safety WARNING: To reduce the risk of fire, electric shock or product damage, • Do not let water or other liquids drip or splash inside the unit. • Do not expose accessories (battery pack, battery charger, AC adaptor, SD memory card and etc.) to rain, moisture, dripping or splashing. - Page 4 Declaration of Conformity Trade Name: Panasonic Model No.: DMC-TS3 Responsible party: Panasonic Corporation of North America One Panasonic Way, Secaucus, NJ 07094 Support Contact: Panasonic Consumer Electronics Company 1-800-211-PANA (7262) This device complies with Part 15 of the FCC Rules. Operation is...
- Page 5 ∫ About the battery pack CAUTION Battery pack (Lithium ion battery pack) • Use the specified unit to recharge the battery pack. • Do not use the battery pack with equipment other than the specified unit. • Do not get dirt, sand, liquids, or other foreign matter on the terminals. •...
-
Page 6: Cautions For Use
∫ Cautions for Use • Do not use any other AV cables except the supplied one. • Always use a genuine Panasonic HDMI micro cable (RP-CHEU15; optional). Part numbers: RP-CHEU15 (1.5 m) (5 feet) • Do not use any other USB connection cables except the supplied one. - Page 7 -If you see this symbol- Information on Disposal in other Countries outside the European Union This symbol is only valid in the European Union. If you wish to discard this product, please contact your local authorities or dealer and ask for the correct method of disposal.
-
Page 8: Table Of Contents
Contents Information for Your Safety ................3 Standard Accessories ................... 9 When inner side of the lens is fogged (condensation) ........ 10 (Important) About the Waterproof/ Dustproof and Anti-shock Performance of the Camera ......11 Names of the Components ................. 16 Charging the Battery ................... -
Page 9: Standard Accessories
• “ For information about optional accessories, refer to the Digital Camera ” Accessory System • If any accessories are lost, customers should contact Panasonic’s parts department at 1 800 833-9626 for further information about obtaining replacement parts. (ENG) VQT3L22... -
Page 10: When Inner Side Of The Lens Is Fogged (Condensation)
• Contact Panasonic’s Service Center if the fogging does not disappear. Conditions in which inner side of the lens may be fogged Condensation may occur and the inner side of the lens may be fogged when the... -
Page 11: (Important) About The Waterproof/Dustproof And Anti-Shock Performance Of The Camera
5 devices) Panasonic’s test method is based on the above “MIL-STD 810F Method 516.5-Shock”. However, the drop height was changed from 122 cm (4.0 feet) to 200 cm (6.6 feet) dropping onto 3 cm (0.10 feet) thick plyboard. - Page 12 Waterproofing is not guaranteed if the unit is subject to an impact as a result of being hit or dropped etc. If an impact to the camera occurs, it should be inspected (subject to a fee) by a Panasonic’s Service Center to verify that the waterproofing is still effective.
- Page 13 The integrity of the rubber seals may decrease after about 1 year, with use and age. To avoid permanently damaging the camera the seals should be replaced once each year. Please contact Panasonic’s Service Center for related costs and other information.
- Page 14 Using the camera underwater • Use the camera underwater at a depth of up to 12 m (40 feet) with the water temperature between 0 oC and 40 oC (32 oF to 104 °F). • Do not use for scuba diving (Aqualung). •...
- Page 15 Drain water by holding the camera upside down and shaking it lightly a few times. • After using the camera at the seaside or under water, or after washing it, water will remain at the speaker site of the camera for a while and it may cause lower sound or sound distortion.
-
Page 16: Names Of The Components
Names of the Components Flash Self-timer indicator/ AF Assist Lamp/LED light Lens LCD monitor Speaker Zoom button Playback button [MODE] button [MENU/SET] button 10 [Q.MENU]/Delete/Cancel button [DISP.] button 11 10 12 Cursor buttons A: 3/Exposure compensation Auto Bracket B: 4/Macro Mode MENU /SET AF Tracking... - Page 17 When using an AC adaptor, ensure that the Panasonic DC coupler (DMW-DCC4; optional) and AC adaptor (DMW-AC5PP; optional) are used. • Always use a genuine Panasonic AC adaptor (DMW-AC5PP; optional). • It is recommended to use a fully charged battery or AC adaptor (DMW-AC5PP;...
-
Page 18: Charging The Battery
Please be advised that we are not liable for any accident or failure occurring as a result of use of a counterfeit battery pack. To ensure that safe products are used we would recommend that a genuine Panasonic battery pack is used. • Use the dedicated charger and battery. -
Page 19: Approximate Operating Time And Number Of Recordable Pictures
Normal Picture Mode Temperature: 23 oC (73.4 oF)/Humidity: 50%RH when LCD monitor is on. • • Using a Panasonic SD Memory Card (32 MB). • Using the supplied battery. • Starting recording 30 seconds after the camera is turned on. (When the Optical Image Stabilizer function is set to [ON].) -
Page 20: About The Built-In Memory/The Card
Memory Card compatible equipment. • Check that the PC and other equipment are compatible when using the SDXC Memory Cards. http://panasonic.net/avc/sdcard/information/ SDXC.html • Only the cards with capacity listed left can be used. ¢ SD Speed Class is the speed standard regarding continuous writing. Check via the label on the card, etc. -
Page 21: Inserting And Removing The Card (Optional)/The Battery
Check that this unit is turned off. • Confirm that there is no foreign object. • We recommend using a Panasonic card. 1:Slide the [LOCK] switch B, and release the lock. 2:Slide the release lever A and open the side door. -
Page 22: Setting Date/Time (Clock Set)
Setting Date/Time (Clock Set) • The clock is not set when the camera is shipped. Press the [OFF/ON] button. • [Precautions] is displayed. Be sure to check this so that you can maintain the waterproof performance. [Please set the clock] is displayed by selecting [No] before it starts or by pressing [MENU/SET] after viewing the last screen (12/12). -
Page 23: Changing The Clock Setting
Press [MENU/SET] to set. • A setting screen for automatic clock correction is displayed. Select [Yes] to automatically correct the clock, and then press [MENU/SET]. • [GPS Setting] will be set to [ON], and the clock is automatically corrected to the current time. Press [MENU/SET] in the message display screen. -
Page 24: Selecting The [Rec] Mode
Selecting the [Rec] Mode Press [MODE]. Press 3/4/2/1 to select the mode. Press [MENU/SET]. ∫ List of [Rec] Modes Normal Picture Mode The subjects are recorded using your own settings. ¦ Intelligent Auto Mode The subjects are recorded using settings automatically selected by the camera. Sports Mode Use this mode to take pictures of sporting events, etc. -
Page 25: Taking Pictures Using The Automatic Function ( Ñ : Intelligent Auto Mode)
ñ [Rec] Mode: Taking Pictures Using the Automatic Function ñ : Intelligent Auto Mode) The camera will set the most appropriate settings to match the subject and the recording conditions so we recommend this mode for beginners or those who want to leave the settings to the camera and take pictures easily. -
Page 26: Scene Detection
Scene Detection When the camera identifies the optimum scene, the icon of the scene concerned is displayed in blue for 2 seconds, after which its color changes to the usual red. ¦ > [i-Portrait] [i-Scenery] [i-Macro] • [i-Night Portrait] Only when [ ] is selected [i-Night Scenery] [i-Sunset]... -
Page 27: Recording Motion Pictures
ñ· ¿ [Rec] Mode: Recording Motion Pictures This can record full high definition motion pictures that are compatible with the AVCHD format or motion pictures recorded in Motion JPEG. Audio will be recorded in monaural. Start recording by pressing the motion picture button. -
Page 28: Playing Back Pictures ([Normal Play])
¸ [Playback] Mode: Playing Back Pictures ([Normal Play]) Press [(]. • Normal Playback is displayed automatically when the power is turned on by pressing and holding the [ ( ] button. Press 2 or 1. After selecting the motion picture, press 3 to •... -
Page 29: Setting The Menu
Setting the Menu Press [MENU/SET]. Press 3/4/2/1 to select menu and then press [MENU/SET]. Press 3/4 to select the menu item and then press [MENU/SET]. • It will switch to next page when you reach the bottom. (It will also switch by pressing the zoom button) •... -
Page 30: Reading The Owner's Manual (Pdf Format)
Reading the Owner’s Manual (PDF format) More detailed instructions on the operation of this camera are contained in “Owner’s Manual for advanced features (PDF format)” in the supplied CD-ROM. Install it to your PC to read it. ∫ For Windows Turn the PC on and insert the CD-ROM containing the Owner’s Manual (supplied). -
Page 31: For Macintosh
OS from the following website. http://get.adobe.com/reader/otherversions ∫ To uninstall the Owner’s Manual (PDF format) Delete the PDF file from the “Program Files\Panasonic\Lumix\” folder. • When the contents in the Program Files folder cannot be displayed, click the [Show the contents of this folder] to display them. -
Page 32: Specifications
Specifications Digital Camera: Information for your safety Power Source: DC 5.1 V Power Consumption: 1.4 W (When recording) 0.7 W (When playing back) Camera effective 12,100,000 pixels pixels Image sensor 1/2.33q CCD, total pixel number 12,500,000 pixels, Primary color filter Lens Optical 4.6kzoom, fl4.9 mm to 22.8 mm (35 mm film camera equivalent: 28 mm to 128 mm)/F3.3 (Wide) to... - Page 33 Hi-speed burst Burst speed Approx. 10 pictures/second (Speed priority) Approx. 7 pictures/second (Image priority) 3M (4:3), 2.5M (3:2), 2M (16:9), 2.5M (1:1) is selected as the picture size. Number of When using the built-in memory: recordable Approx. 15 pictures (immediately after formatting) pictures When using a Card: Max.
- Page 34 Interface Digital “USB 2.0” (High Speed) Analog video NTSC, audio Audio line output (monaural) Terminal [AV OUT/ Dedicated jack (8 pin) DIGITAL] [HDMI] MicroHDMI TypeD Dimensions Approx. 103.5 mm (W)k64 mm (H)k26.5 mm (D) (excluding the [4.07q(W)k2.52q(H)k1.04q(D)] projecting parts) Mass (weight) Approx.
- Page 35 5 devices) • Panasonic’s test method is based on the above “MIL-STD 810F Method 516.5-Shock”. However, the drop height was changed from 122 cm (4.0 feet) to 200 cm (6.6 feet) dropping onto 3 cm (0.10 feet) thick plyboard.
-
Page 36: Digital Camera Accessory System
Class 4 2 GB SD Memory Card Product numbers correct as of January 2011. These may be subject to change. ¢ The AC Adaptor (optional) can only be used with the designated Panasonic DC Coupler (optional). The AC adaptor (optional) cannot be used by itself. -
Page 37: Digital Camera Accessory Order Form
THE FOLLOWING: VISIT YOUR LOCAL PANASONIC DEALER CALL PANASONIC’S ACCESSORY ORDER LINE AT 1-800-332-5368 [6 AM-6 PM M-F, PACIFIC TIME] MAIL THIS ORDER TO: PANASONIC SERVICE AND TECHNOLOGY COMPANY ACCESSORY ORDER OFFICE 20421 84th Avenue South Kent, WA. 98032 (ENG) VQT3L22... -
Page 38: Limited Warranty (Only For U.s.a. And Puerto Rico)
Limited Warranty Coverage (For USA and Puerto Rico Only) If your product does not work properly because of a defect in materials or workmanship, Panasonic Consumer Electronics Company (referred to as “the warrantor”) will, for the length of the period indicated on the chart below, which starts with the date of original purchase (“warranty period”), at its option either (a) - Page 39 When shipping Lithium Ion batteries please visit our Web Site at www.panasonic.com/BatteryHandling as Panasonic is committed to providing the most up to date information. Include a letter detailing the complaint, a return address and provide a daytime phone number where you can be reached.
- Page 40 THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER “LIMITED WARRANTY COVERAGE”. THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY. (As examples, this excludes damages for lost time, travel to and from the servicer, loss of or damage to media or images, data or other memory or recorded content.
- Page 41 Monday-Friday 9am-9pm, Saturday-Sunday 10am-7pm EST For hearing or speech impaired TTY users, TTY: 1-877-833-8855 Accessory Purchases (United States and Puerto Rico) Purchase Parts, Accessories and Instruction Books online for all Panasonic Products by visiting our Web Site at: http://www.pstc.panasonic.com Or, send your request by E-mail to: npcparts@us.panasonic.com...
- Page 42 • SDXC Logo is a trademark of SD-3C, LLC. • The “AVCHD” and the “AVCHD” logo are trademarks of Panasonic Corporation and Sony Corporation. • Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.
