- Page 1 Use and Care manual Condensing Dryer TD-C70210E TD-C70215E TD-C70212E TD-C70216E Please read this manual carefully prior to use. Keep it for future reference. Write down model name and serial number of your product. Have all these details ready when you call for service.
-
Page 2: Table Of Contents
Ultra big Capacity Drum LG Dryer has 7.0kg capacity which is the ultra big capacity. Lower Energy Consumption Energy Energy Energy is saved by cutting-edge engineering design of drying system and by optimized heating control. It’s a real money saving. -
Page 3: Safety Instructions
afety instructions To help reduce any risk of electric shock, fire, or other personal or property injury when using your dryer, please follow basic safety instructions. WARNING Serious injury or death may occur when not observing the following rules. Not allowed actions. •... - Page 4 afety instructions • Do not use damaged power • Prevent pets biting the dryer. cord, plug and socket. Pets may die from an It may cause a fire or an electric shock or electric shock. appearance may be damaged. • Do not install or store the •...
- Page 5 afety instructions • Young children should be supervised to ensure that they do not play with the appliance. Children may fall off. Pets or children may be wounded by rotating parts or suffocated inside drum. • If this appliance is supplied from a cord extension set or an electrical connector, portable outlet device must be positioned so that it is not subject to splashing or ingress of moisture.
-
Page 6: Installation Instructions
Closet installation instructions The LG Dryer can be placed on the top of a front loading washing machine. They are sure to be fixed with stacking kit (See the next page). This installation must be conducted by an experienced installer in order to secure robust installation of both washer and dryer. -
Page 7: Grounding Instruction
Instructions GROUNDING INSTRUCTION Stacking Kit In order to stack this dryer on a LG washing This appliance must be grounded. In the event of machine, LG stacking kit is needed. malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for the electric current. -
Page 8: Level The Dryer
nstallation Instructions Level the dryer 1. Leveling the dryer is to prevent undesirable noise and vibration. When placing your dryer in an solid and level area where water is not dripping and freezing, flammable materials are not stored. 2. If the dryer is not properly level, adjust the front leveling legs up and down as necessary. -
Page 9: Appearance & Design
• Buzzer Off • Anti-Crease • Time Delay • More Time • Less Time Program selector Start/Pause LED Display • Time Display TD-C70212E/216E • Indicator lamps Additional function buttons • Gentle • Buzzer Off • Anti-Crease • Time Delay • More Time •... -
Page 10: Operating Your Dryer
perating your dryer Cycle Selection Table Standard Electronic Auto Dry Cycles Program Mixed-Fabric cycles (Note) press the "Gentle" button for heat-sensitive items Bed linen and table linen, tracksuits, For thick and quilted fabrics which do not need to be ironed. Very Dry anorak, blankets shirts, blouses and sportswear... - Page 11 perating your dryer Before first use of the dryer Before you use the dryer for the first time, there are some points that you have to check. After removing package, you will check the product has no problem and is properly installed. 1.
- Page 12 perating your dryer 5. Close the Door. Select the desired Before you close the door, make sure fabrics are Cycle. well placed inside and that foreign objects, especially flammable ones, are not caught around door. CAUTION - Be careful not to trap laundry in between the loading door and rubbber seal.
-
Page 13: Rack Dry
perating your dryer Rack Dry Apply models : TD-C70210E/215E The dryer Rack is placed inside the dryer like the picture. Note Remove and discard packing material before use, Check the lint filter and remove any lint The Rack Dry is designed for use with items that accumulated from items dried on the Rack. -
Page 14: Additional Functions
Functions TD-C70210E/215E TD-C70212E/216E Gentle Time Delay This is used to lengthen the cycle time by You can use the Time Delay function to delay the finishing time of drying cycle. decreasing temperature. Maximum Time Delay is 19 hours. Minimum Time Delay is 3 hours. -
Page 15: Caring For Your Dryer
aring for your dryer How important Care and cleaning is~ Clean lint filter during a cycle It’s not very difficult to care for your dryer. All you If “Clean Filter” indicator lamp flashes during have to do is to follow the information below. operation, clean the filter promptly. - Page 16 aring for your dryer Condenser Condenser is also a very important part for efficient drying performance result so it needs a special care from you. It is recommended that condenser be cleaned three or four times a year. 1. Open condensing cover by using a coin or flat 4.
-
Page 17: Moisture Sensor
aring for your dryer Front Ventilation Grille Moisture Sensor? Vacuum the front ventilation grill 3~4 time a year to This device functions to sense the moisture make sure there must be no build-up of lints or dirts remaining contents of the laundry during operation which cause improper intake air flow. -
Page 18: Reverse The Door
aring for your dryer Reverse the door 4. Detach both hinge point The door can be reversed to fit to your own covers. installation conditions. From the factory, the door hinge is located on the right side. CAUTION 1. This work may cause the injury of your hands so you must be careful to handle some sharp devices like tork screwdriver or 5. - Page 19 aring for your dryer Change the Bulb CAUTION The bulb itself could be very hot when the dryer just finishes its operation. So before changing the bulb, Power cord must be unplugged before this be sure that the inside of the drum is cool down. work to avoid danger of electric shock.
-
Page 20: Additional Tips For Smart Use
dditional Tips for smart use Drying Guide Energy consumption Capacity for laundry type Cottons Light dry 3,92 kWh Cotton 7 kg (Applied EN 61121, 2005 test program) Mixed 3.5 kg Wool 1.5 kg Delicate 1.5 kg Below are fabric care labels. Woolen Article Symbols Instructions... -
Page 21: Spare Parts
- fig : Washer top plate size 550 - fig : Washer top plate size 600 If stacking is needed, you must stack the dryer upon LG washing machine. In order to do this, stacking kit must be purchased separately. -
Page 22: Troubleshooting Guidelines
roubleshooting Guidelines Troubleshooting Tips To save you time and money, the following page will help answer your questions before service call. Questions What to do Dryer doesn't work 1. Check dryer is plugged in. 2. Check "Start" button is pressed. 3. -
Page 23: Error Mode
roubleshooting Guidelines Error Mode • : LED displays “ ” in case of the door open. The door must be closed and start Button must be pressed for re-operation. High temperature and high humidity of air continues to remain at the contained dryer by drying object during drying if the dryer suddenly stops due to power failure or other different causes while drying is in progress. -
Page 24: Technical Data
echnical Data Weight : 50 kg Electrical Requirements Ventilation Requirement Volts Hertz Watts Alcove or Closet under counter U.K. Singapore Ensure air flow of Closet door must have Jordan Israel 112 cu.ft./min 2(louvered) openings, 220 V~240 V 50 Hz 2600 Syria through dryer each having a minimum... -
Page 25: Warranty
arranty Disposal of your old appliance 1. When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the European Directive 2002/96/EC. 2. All electrical and electronic products should be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities. - Page 28 For U.K. Customer CUSTOMER SERVICES Tel. : +44- (0) 844 847 5454 Fax. : +44- (0) 844 847 1413 LGEUK SERVICE WEB-SITE : http://uk.lge.com P/No.: MFL32312501...
