Eizo FP-2100W User Manual

Note Note
•
Please be careful not to scratch the LCD panel or the cabinet with the panel protector during installation. Also please do
not remove the panel protector often. It may scratch or result in damage to the LCD panel.
•
The panel protector has a non-glare treatment side and a glossy side. Use preferable side.
•
When using LCD monitor with optional panel protector, it is preferable to avoid using downwards. In this condition, the
panel protector might become bend or slip out from the monitor.
Installation
Before installation, please remove dust and stains from the LCD panel.
1.
(2)
(1)
1. Set the panel protector into the grooves of the panel frame; the lower fi rst (1), then the upper (2).
2. With the enclosed tool (Lever) set the tabs of the panel protector into the side grooves (4 tabs).
Put the lever on the tabs of the panel protector and move it toward the LCD panel to install. Position the protector into the
LCD panel tightly without leaving an opening.
Removing
Put the lever on the tabs of panel protector and move it toward the cabinet to remove.
Cleaning
Note Note
•
Please be sure to keep the panel protector immobilized while cleaning it. Otherwise it may scratch the surface of the LCD
panel. To hold the panel protector by hand, use a soft cloth to avoid dust or fi nger prints.
•
Never use thinner, benzene, alcohol (ethanol, methanol, or isopropyl alcohol), abrasive cleaners, or other strong solvents,
as these may cause damage to the cabinet or panel.
The panel surface can be cleaned with a soft cloth such as cotton or lens paper.
If necessary stubborn stains can be removed by moistening part of the cloth with water to enhance its
cleaning power.
Tips
•
It is recommended to use EIZO cleaning kit "ScreenCleaner" (option) to clean the panel.
Specifi cation
Surface treatment Non-glare side: non glare hard coating / Glossy side: hard coating
Coating strength 2H
Refl ectivity Less than 6.8 %
Light transmission More than 90 %
Dimension/ Weight 476.8 mm (W) × 299.4 mm (H) × 1.0 mm (D) / approx. 175 g
Accessories Lever (for Panel Protector), User's Manual
Copyright© 2007 EIZO NANAO CORPORATION All rights reserved.
2.
Lever
00N0L357B1
(U.M-FP2201W)
