HP Compaq 6520s Notebook PC
Maintenance and Service Guide

Advertisement

Table of Contents
loading

Related Manuals for HP 6520s - Notebook PC

Summary of Contents for HP 6520s - Notebook PC

  • Page 1 HP Compaq 6520s Notebook PC Maintenance and Service Guide...
  • Page 2 © Copyright 2007 Hewlett-Packard Development Company, L.P. AMD, the AMD Arrow logo, and combinations thereof, are trademarks of Advanced Micro Devices, Inc. Bluetooth is a trademark owned by its proprietor and used by Hewlett-Packard Company under license. Intel, Core, Pentium, Celeron are trademarks of Intel Corporation in the United States and other countries.
  • Page 3 Safety warning notice WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not place the computer directly on your lap or obstruct the computer air vents. Use the computer only on a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or rugs or clothing, to block airflow.
  • Page 4 Safety warning notice...

  • Page 5: Table Of Contents

    Table of contents 1 Product description 2 External component identification Top components ........................7 TouchPad ......................... 7 Buttons, lights, and speaker ..................8 Keys ........................9 Front components ........................10 Right-side components ......................10 Left-side components ....................... 11 Bottom components ........................ 12 3 Illustrated parts catalog Serial number location ......................
  • Page 6 Unknown user password ..................34 Component replacement procedures ..................35 Serial number ......................35 Computer feet ......................36 Battery ........................37 Hard drive ......................38 WLAN module ......................40 Memory module ...................... 43 Optical drive ......................45 Switch cover and keyboard ..................47 Speaker .........................
  • Page 7 System memory map specifications ..................95 7 Screw listing Phillips PM2.0×5.0 captive screw .................... 97 Phillips PM2.5×12.0 captive screw ..................98 Phillips PM3.0×4.0 screw ....................... 99 Phillips PM2.5×4.0 screw ..................... 100 Torx T8M2.5×7.0 screw ....................... 101 Phillips PM2.0×4.0 screw ..................... 104 Torx T8M2.5×3.0 broad-head screw ..................
  • Page 8 Performing a recovery from the hard drive ............... 127 Initiating a recovery in Windows .............. 128 Initiating a recovery from the hard drive recovery partition ......129 9 Connector pin assignments Audio-out (headphone) ......................130 Audio-in (microphone) ......................130 External monitor ........................131 RJ-11 (modem) ........................

  • Page 9: Product Description

    GLE960 system GME965 PM965 system board system board board Product Name HP Compaq 6520s Notebook PC √ √ √ Processors Intel® Core™ 2 Duo processors T9300 2.50-GHz processor, 6-MB L2 √ √ ● cache, 800-MHz front side bus (FSB) T8300 2.40-GHz processor, 3-MB L2...
  • Page 10 Category Description Computer Computer Computer models models models equipped with equipped with equipped with GLE960 system GME965 PM965 system board system board board 530 1.73-GHz processor, 1-MB L2 √ ● cache, 533-MHz FSB Chipset Northbridge: Intel PM965 with up to 800- √...
  • Page 11 Category Description Computer Computer Computer models models models equipped with equipped with equipped with GLE960 system GME965 PM965 system board system board board 1024-MB total system memory (1024 ● × 1) 512-MB total system memory (512 × ● Supports the following configurations only in √...
  • Page 12 Category Description Computer Computer Computer models models models equipped with equipped with equipped with GLE960 system GME965 PM965 system board system board board Supports boot from external USB diskette √ √ √ drive Supports 3-mode diskette drive √ √ √ Audio HD audio - ADI1981 √...
  • Page 13 Category Description Computer Computer Computer models models models equipped with equipped with equipped with GLE960 system GME965 PM965 system board system board board RJ-45 (Ethernet, includes link and activity √ √ √ lights) USB (3) √ √ √ VGA (Dsub 15-pin) supporting 1600 × √...
  • Page 14 Category Description Computer Computer Computer models models models equipped with equipped with equipped with GLE960 system GME965 PM965 system board system board board Windows Vista Home Premium √ √ √ Windows Vista Business 32 √ √ √ Windows XP Professional √...

  • Page 15: External Component Identification

    External component identification Top components TouchPad Item Component Function TouchPad* Moves the pointer and selects or activates items on the screen. Left TouchPad button* Functions like the left button on an external mouse. Right TouchPad button* Functions like the right button on an external mouse. TouchPad scroll zone Scrolls up or down.

  • Page 16: Buttons, Lights, And Speaker

    Buttons, lights, and speaker Item Component Function Caps lock light On: Caps lock is on. Wireless button Turns the wireless feature on or off, but does not establish a wireless connection. NOTE: A wireless network must be set up in order to establish a wireless connection.

  • Page 17: Keys

    Item Component Function Power light On: The computer is on. ● Blinking: The computer is in the Sleep state (Windows ● Vista) or Standby (Windows XP). Off: The computer is off or in Hibernation. ● Speaker Produces sound. Keys Item Component Function Displays system information when pressed in combination...

  • Page 18: Front Components

    Front components Item Component Function Audio-out (headphone) jack Produces sound when connected to optional powered stereo speakers, headphones, ear buds, a headset, or television audio. Audio-in (microphone) jack Connects an optional computer headset microphone, stereo array microphone, or monaural microphone. SD/MMC Card Reader Supports the following optional digital card formats: SD Memory Card and MMC.

  • Page 19: Left-Side Components

    Left-side components Item Component Function Battery light Amber: A battery is charging. ● ● Blue: A battery is close to full charge capacity. Blinking amber: A battery that is the only available ● power source has reached a low battery level. When the battery reaches a critical battery level, the battery light begins blinking rapidly.

  • Page 20: Bottom Components

    Bottom components Item Component Function Battery bay Holds the battery. Battery release latches (2) Release the battery from the battery bay. Memory module compartment Contains 2 memory module slots. Vents (4) Enable airflow to cool internal components. NOTE: The computer fan starts up automatically to cool internal components and prevent overheating.

  • Page 21: Illustrated Parts Catalog

    Illustrated parts catalog Serial number location When ordering parts or requesting information, provide the computer serial number and model number located on the bottom of the computer. Serial number location...

  • Page 22: Computer Major Components

    Computer major components Chapter 3 Illustrated parts catalog...
  • Page 23 Item Description Spare part number Display assemblies (include 2 WLAN antenna transceivers and cables) 14.1-inch, WXGA BrightView display assembly for use only with computer models equipped 456598-001 with discrete graphics subsystem memory 14.1-inch, WXGA display assembly for use only with computer models equipped with discrete 456597-001 graphics subsystem memory 14.1-inch, WXGA BrightView display assembly for use only with computer models equipped...
  • Page 24 Item Description Spare part number For use only with computer models equipped with Intel Core 2 Duo processors and discrete 456613-001 graphics subsystem (includes 128-MB DDR2 discrete graphics system memory) For use only with computer models equipped with Intel Core 2 Duo processors and discrete 456612-001 graphics subsystem (includes 64-MB DDR2 discrete graphics system memory) For use only with computer models equipped with Intel Core 2 Duo processors and discrete...
  • Page 25 Item Description Spare part number T5270 1.40-GHz (2-MB L2 cache, 800-MHz FSB) 462345-001 ● Intel Celeron M processors: ● 550 2.00-GHz (1-MB L2 cache, 533-MHz FSB) 446889-001 540 1.86-GHz (1-MB L2 cache, 533-MHz FSB) 446888-001 ● 530 1.73-GHz (1-MB L2 cache, 533-MHz FSB) 459462-001 ●...
  • Page 26 Item Description Spare part number Hong Kong, Hungary, Iceland, India, Ireland, Israel, Italy, the Ivory Coast, Jamaica, Jordan, Kazakhstan, Kenya, Kiribati, Kyrgyzstan, Laos, Latvia, Lebanon, Lesotho, Liberia, Liechtenstein, Lithuania, Luxembourg, Macedonia, Madagascar, Malawi, Malaysia, the Maldives, Mali, Malta, the Marshall Islands, Martinique, Mauritania, Mauritius, Mexico, Micronesia, Monaco, Mongolia, Montenegro, Morocco, Mozambique, Namibia, Nauru, Nepal, the Nether Antilles, the Netherlands, New Zealand, Nicaragua, Niger, Nigeria, Norway, Oman, Pakistan, Palau, Panama, Papua New Guinea, Paraguay, Peru, the...
  • Page 27 Item Description Spare part number DVD±RW and CD-RW Double-Layer Combo Drive 456798-001 DVD/CD-RW Combo Drive 456797-001 Cable Kit (not illustrated; see Cable Kit on page 21 for more Cable Kit spare part number 457400-001 information) Computer major components...

  • Page 28: Plastics Kit

    Plastics Kit Item Description Spare part number Plastics Kit: 456614-001 Hard drive bay cover (includes 2 captive screws, secured by C-clips) WLAN module compartment cover (includes one captive screw, secured by a C-clip) ExpressCard slot bezel Memory module compartment cover (includes one captive screw, secured by a C-clip) Chapter 3 Illustrated parts catalog...

  • Page 29: Cable Kit

    Cable Kit Item Description Spare part number Cable Kit: 457400-001 RJ-11 jack cable Display lid switch module and cable Bluetooth module cable Cable Kit...

  • Page 30: Mass Storage Devices

    Mass storage devices Item Description Spare part number Optical drives (include bezel and bracket) DVD±RW and CD-RW Super Multi Double-Layer Combo Drive with LightScribe 456799-001 DVD±RW and CD-RW Super Multi Double-Layer Combo Drive 456798-001 DVD/CD-RW Combo Drive 456797-001 Hard drives (include bracket) 160-GB, 5400-rpm 457014-001 120-GB, 5400-rpm...

  • Page 31: Miscellaneous Parts

    Miscellaneous parts Description Spare part number AC adapters 90-W slimline AC adapter (for use only with computer models with discrete graphics system memory) 458220-001 65-W AC adapter (for use only with computer models with UMA graphics system memory) 417220-001 Logo Kit 456617-001 Nylon carrying case 325814-001...

  • Page 32: Sequential Part Number Listing

    Sequential part number listing Spare part Description number 246959-001 Power cord for use in the United States 246959-011 Power cord for use in Australia and New Zealand 398393-002 Bluetooth module for use in North America NOTE: The Bluetooth module spare part kits do not include a Bluetooth module cable. The Bluetooth module cable is included in the Cable Kit, spare part number 457400-001.
  • Page 33 Spare part Description number Iceland, Ireland, Israel, Italy, Latvia, Lebanon, Liechtenstein, Lithuania, Luxembourg, Malta, Monaco, the Netherlands, Norway, Oman, the Philippines, Poland, Portugal, Qatar, Romania, Russia, Serbia and Montenegro, Singapore, Slovakia, Slovenia, South Africa, Spain, Sri Lanka, Sweden, Switzerland, Turkey, Ukraine, the United Kingdom, and Uzbekistan 441082-003 Intel 802.11a/b/g WLAN module for use in Australia, New Zealand, Pakistan, the People's Republic of China,...
  • Page 34 Spare part Description number 446893-001 Intel Core 2 Duo T7500 2.20-GHz processor (4-MB L2 cache, 800-MHz FSB, includes replacement thermal material) 446894-001 Intel Core 2 Duo T7700 2.40-GHz processor (4-MB L2 cache, 800-MHz FSB, includes replacement thermal material) 448674-001 Intel 802.11a/b/g WLAN module for use in Antigua & Barbuda, Argentina, Aruba, the Bahamas, Barbados, Bermuda, Brunei, Canada, the Cayman Islands, Chile, Colombia, Costa Rica, the Dominican Republic, Ecuador, El Salvador, Guam, Guatemala, Haiti, Honduras, Hong Kong, India, Indonesia, Malaysia, Mexico, Panama, Paraguay, Peru, Saudi Arabia, Taiwan, the United States, Uruguay, Venezuela, and Vietnam...
  • Page 35 Spare part Description number 456603-001 Base enclosure (includes rubber feet) 456605-001 Heat sink for use only with computer models equipped with UMA graphics subsystem (includes replacement thermal material) 456606-001 Heat sink for use only with computer models equipped with discrete graphics subsystem (includes replacement thermal material) 456608-001 System board for use only with computer models equipped with Intel Core 2 Duo processors and UMA graphics...
  • Page 36 Spare part Description number 457013-001 120-GB, 5400-rpm hard drive (includes bracket) 457014-001 160-GB, 5400-rpm hard drive (includes bracket) 457400-001 Cable Kit (see Cable Kit on page 21 for more Cable Kit spare part information) 458220-001 90-W slimline AC adapter (for use only with computer models with discrete graphics system memory) 459462-001 Intel Celeron M 530 1.73-GHz processor (1-MB L2 cache, 533-MHz FSB, includes replacement thermal material)

  • Page 37: Removal And Replacement Procedures

    Removal and replacement procedures Preliminary replacement requirements Tools required You will need the following tools to complete the removal and replacement procedures: Flat-bladed screwdriver ● Magnetic screwdriver ● Phillips P0 and P1 screwdrivers ● Torx T8 screwdriver ● Service considerations The following sections include some of the considerations that you must keep in mind during disassembly and assembly procedures.

  • Page 38: Cables And Connectors

    Cables and connectors CAUTION: When servicing the computer, be sure that cables are placed in their proper locations during the reassembly process. Improper cable placement can damage the computer. Cables must be handled with extreme care to avoid damage. Apply only the tension required to unseat or seat the cables during removal and insertion.

  • Page 39: Grounding Guidelines

    Grounding guidelines Electrostatic discharge damage Electronic components are sensitive to electrostatic discharge (ESD). Circuitry design and structure determine the degree of sensitivity. Networks built into many integrated circuits provide some protection, but in many cases, ESD contains enough power to alter device parameters or melt silicon junctions. A discharge of static electricity from a finger or other conductor can destroy static-sensitive devices or microcircuitry.

  • Page 40: Packaging And Transporting Guidelines

    Packaging and transporting guidelines Follow these grounding guidelines when packaging and transporting equipment: To avoid hand contact, transport products in static-safe tubes, bags, or boxes. ● Protect ESD-sensitive parts and assemblies with conductive or approved containers or packaging. ● Keep ESD-sensitive parts in their containers until the parts arrive at static-free workstations. ●...

  • Page 41: Equipment Guidelines

    Equipment guidelines Grounding equipment must include either a wrist strap or a foot strap at a grounded workstation. When seated, wear a wrist strap connected to a grounded system. Wrist straps are flexible straps ● with a minimum of one megohm ±10% resistance in the ground cords. To provide proper ground, wear a strap snugly against the skin at all times.

  • Page 42: Unknown User Password

    Unknown user password If the computer you are servicing has an unknown user password, follow these steps to clear the password: NOTE: These steps also clear CMOS. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.

  • Page 43: Component Replacement Procedures

    Component replacement procedures This chapter provides removal and replacement procedures. There are as many as 76 screws, in 16 different sizes, that must be removed, replaced, or loosened when servicing the computer. Make special note of each screw size and location during removal and replacement.

  • Page 44: Computer Feet

    Computer feet The computer feet are adhesive-backed rubber pads. The feet are included in the Rubber Kit, spare part number 456616-001. There are 6 rubber feet that attach to the base enclosure in the locations illustrated below. Chapter 4 Removal and replacement procedures...

  • Page 45: Battery

    Battery Description Spare part number 6-cell, 47-Wh Li-ion battery 456623-001 Before disassembling the computer, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer.

  • Page 46: Hard Drive

    Hard drive NOTE: All hard drive spare part kits include a hard drive bracket. Description Spare part number 160-GB, 5400-rpm hard drive 457014-001 120-GB, 5400-rpm hard drive 457013-001 80-GB, 5400-rpm hard drive 457012-001 Before disassembling the computer, follow these steps: Shut down the computer.
  • Page 47 Remove the hard drive (4) from the hard drive bay. If it is necessary to replace the hard drive bracket, remove the two Phillips PM3.0×4.0 hard drive bracket screws (1) from each side of the hard drive. Lift the bracket (2) straight up to remove it from the hard drive. Reverse this procedure to reassemble and install the hard drive.

  • Page 48: Wlan Module

    WLAN module Description Spare part number Intel 802.11a/b/g/n WLAN modules: ● For use in Antigua and Barbuda, Argentina, Aruba, the Bahamas, Barbados, Bermuda, Brunei, 441086-001 Canada, the Cayman Islands, Chile, Colombia, Costa Rica, the Dominican Republic, Ecuador, El Salvador, Guam, Guatemala, Haiti, Honduras, Hong Kong, India, Indonesia, Malaysia, Mexico, Panama, Paraguay, Peru, Saudi Arabia, Taiwan, Uruguay, the United States, Venezuela, and Vietnam ●...
  • Page 49 Description Spare part number For use in Australia, New Zealand, Pakistan, the People's Republic of China, and South Korea 441082-003 and ● 448674-003 For use in Japan 441082-291 and ● 448674-291 For use in South Korea: 456576-AD1 ● Broadcom 802.11b/g WLAN modules: For use in Afghanistan, Albania, Algeria, Andorra, Angola, Antigua &...
  • Page 50 Lift the right side of the WLAN module compartment cover (2), swing it to left, and remove the cover. The WLAN module compartment cover is included in the Plastics Kit, spare part number 456614-001. Disconnect the WLAN antenna cables (1) from the terminals on the WLAN module. NOTE: The black WLAN antenna cable is connected to the WLAN module “Main”...

  • Page 51: Memory Module

    Memory module Description Spare part number 2048-MB (PC2-5300, 667-MHz, DDR2) 417506-001 1024-MB (PC2-5300, 667-MHz, DDR2) 414046-001 512-MB (PC2-5300, 667-MHz, DDR2) 414045-001 Before removing the memory module, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.
  • Page 52 Remove the memory module (2) by pulling the module away from the slot at an angle. NOTE: Memory modules are designed with a notch (3) to prevent incorrect installation into the memory module slot. Reverse this procedure to install a memory module. Chapter 4 Removal and replacement procedures...

  • Page 53: Optical Drive

    Optical drive NOTE: All optical drive spare part kits include an optical drive bezel. Description Spare part number DVD±RW and CD-RW Super Multi Double-Layer Combo Drive with LightScribe 456799-001 DVD±RW and CD-RW Super Multi Double-Layer Combo Drive 456798-001 DVD/CD-RW Combo Drive 456797-001 Before removing the optical drive, follow these steps: Shut down the computer.
  • Page 54 Remove the optical drive bracket (2). Reverse this procedure to reassemble and install an optical drive. Chapter 4 Removal and replacement procedures...

  • Page 55: Switch Cover And Keyboard

    Switch cover and keyboard Description Spare part number Switch cover (includes button board and cable) 456581-001 Keyboards for use in the following countries or regions: Belgium 456587-181 Norway 456587-091 The Czech Republic 456587-221 Portugal 456587-131 Denmark 456587-081 Russia 456587-251 France 456587-051 Saudi Arabia 456587-171...
  • Page 56 Remove the switch cover and keyboard: Remove the following screws: (1) Two Torx T8M2.5×7.0 screws (2) Three Torx T8M2.5×3.0 broad-head screws Remove the two Torx T8M2.5×7.0 screws that secure the keyboard to the computer. Turn the computer display-side up, with the front toward you. Open the computer as far as possible.
  • Page 57 Lift the switch cover (1) straight up until it disengages from the computer, and slide it back (2) until it rests on the display assembly. Lift the rear edge of the keyboard (1) until it rests at an angle, and slide it back (2) until it rests on the display assembly and switch cover.
  • Page 58 Release the zero insertion force (ZIF) connector (1) to which the keyboard cable is attached, and disconnect the keyboard cable (2) from the system board. Remove the keyboard. Release the ZIF connector (1) to which the button board cable is attached, and disconnect the button board cable (2) from the system board.

  • Page 59: Speaker

    Speaker Description Spare part number Speaker 456593-001 Before removing the speaker, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer.

  • Page 60: Display Lid Switch Module

    Display lid switch module NOTE: The display lid switch module is included in the Cable Kit, spare part number Cable Kit, spare part number 457400-001. Before removing the display lid switch module, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.

  • Page 61: Display Assembly

    Display assembly NOTE: All display assembly spare part kits include 2 WLAN antenna transceivers and cables. Description Spare part number 14.1-inch, WXGA BrightView display assembly for use only with computer models equipped with 456598-001 discrete graphics subsystem memory 14.1-inch, WXGA display assembly for use only with computer models equipped with discrete 456597-001 graphics subsystem memory 14.1-inch, WXGA BrightView display assembly for use only with computer models equipped with...
  • Page 62 Remove the two Torx T8M2.5×7.0 screws that secure the display assembly to the computer. Turn the computer right-side up, with the front toward you. Open the computer as far as possible. Disconnect the display panel cables (1) and (2) from the system board. Remove the wireless antenna cables (3) from the clips and routing channels built into the top cover.
  • Page 63 Lift the display assembly (2) straight up and remove it. If it is necessary to replace the display bezel, display inverter, or display hinges, remove the eight rubber screw covers (1) and the eight Torx T8M2.5×6.0 screws (2) that secure the display bezel to the display assembly.
  • Page 64 Remove the display bezel (3). The display bezel is available using spare part number 456620-001. If it is necessary to replace the display inverter, remove the inverter (1) from the display enclosure as far as the display panel cable and the backlight cable will allow. Disconnect the display panel cable (2) and the backlight cable (3) from the display inverter.
  • Page 65 Remove the display panel (2). Remove the four Phillips PM2.0×4.0 screws (1) that secure each display hinge to the display panel. Remove the display hinges (2). The left and right display hinges are available using spare part number 456619-001. Reverse this procedure to reassemble and install the display assembly. Component replacement procedures...

  • Page 66: Top Cover

    Top cover Description Spare part number Top cover 456599-001 Before removing the top cover, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer.
  • Page 67 Remove the followng screws: (1) Three Phillips PM2.0×2.0 broad-head screws (2) Seven Torx T8M2.5×7.0 screws (3) One Torx T8m2.5×4.0 screw Turn the computer right-side up, with the left side toward you. Press in on the ExpressCard slot eject button (1) two times. The first press releases the ExpressCard slot eject button.
  • Page 68 Release the ZIF connector (4) to which the TouchPad cable is connected and disconnect the TouchPad cable from the system board. Remove the top cover. Reverse this procedure to install the top cover. Chapter 4 Removal and replacement procedures...

  • Page 69: Touchpad Board And Touchpad Button Board

    TouchPad board and TouchPad button board Description Spare part number TouchPad board (includes cable) 456600-001 TouchPad button board (includes cable) 456601-001 TouchPad Miscellaneous Kit (includes TouchPad bracket and TouchPad button board actuators) 456602-001 Before removing the TouchPad board and TouchPad button board, follow these steps: Shut down the computer.
  • Page 70 Remove the two Phillips PM2.0×4.0 screws (4) that secure the TouchPad bracket to the computer. Release the TouchPad bracket (1) by sliding it back. Remove the TouchPad bracket (2) by lifting it straight up. Remove the TouchPad button board (3). Remove the TouchPad button board cable (4) from the opening in the TouchPad bracket.
  • Page 71 Remove the TouchPad board (1) from the top cover. NOTE: When replacing the TouchPad board and TouchPad button board, be sure the TouchPad button actuators (2) are installed in the top cover. Reverse this procedure to install the TouchPad board and TouchPad button board. Component replacement procedures...

  • Page 72: Bluetooth Module

    Bluetooth module NOTE: The Bluetooth module spare part kits do not include a Bluetooth module cable. The Bluetooth module cable is included in the Cable Kit, spare part number 457400-001. See Cable Kit on page 21 for more Cable Kit spare part number information. Description Spare part number For use in all countries and regions except Japan and Asia Pacific countries and regions...
  • Page 73 Remove the Bluetooth module (3) from the base enclosure. Reverse this procedure to install the Bluetooth module. Component replacement procedures...

  • Page 74: System Board

    System board NOTE: All system board spare part kits include the ExpressCard assembly. NOTE: All system board spare part kits include replacement thermal material. Replacement thermal material is also available in the Thermal Material Kit, spare part numbers 413706-001 (for use only in the United States) and 445853-001 (for use only in Japan and Asia Pacific countries and regions).
  • Page 75 When replacing the system board, be sure that the following components are removed from the defective system board and installed on the replacement system board: Memory module (see Memory module on page ● WLAN module (see WLAN module on page ●...
  • Page 76 Remove the system board (4) from the base enclosure by sliding it back. Reverse the preceding procedure to install the system board. Chapter 4 Removal and replacement procedures...

  • Page 77: Fan

    Description Spare part number 431312-001 Before removing the fan, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer.
  • Page 78 Remove the fan (3) from the base enclosure. Reverse this procedure to install the fan. NOTE: To properly ventilate the computer, allow at least a 7.6-cm (3-inch) clearance on the left side of the computer. The computer uses an electric fan for ventilation. The fan is controlled by a temperature sensor and is designed to turn on automatically when high temperature conditions exist.

  • Page 79: Heat Sink

    Heat sink NOTE: The heat sink spare part kits include replacement thermal material. Replacement thermal material is also available in the Thermal Material Kit, spare part numbers 413706-001 (for use only in the United States) and 445853-001 (for use only in Japan and Asia Pacific countries and regions). Description Spare part number For use only with computer models equipped with discrete graphics subsystem...
  • Page 80 Remove the heat sink (2). NOTE: The thermal material must be thoroughly cleaned from the surfaces of the heat sink (1), (2), and (3), and the system board components (4), (5), and (6) each time the heat sink is removed. Replacement thermal material is included with all heat sink, system board, and processor spare part kits.
  • Page 81 Remove the heat sink (2). NOTE: The thermal material must be thoroughly cleaned from the surfaces of the heat sink (1) and (2), and the system board (3) and (4) each time the heat sink is removed. Replacement thermal material is included with all heat sink, system board, and processor spare part kits. Reverse this procedure to install the heat sink.

  • Page 82: Processor

    Processor NOTE: All processor spare part kits include replacement thermal material. Replacement thermal material is also available in the Thermal Material Kit, spare part numbers 413706-001 (for use only in the United States) and 445853-001 (for use only in Japan and Asia Pacific countries and regions). Description Spare part number Intel Core 2 Duo processors...
  • Page 83 Speaker (see Speaker on page Display lid switch module (see Display lid switch module on page Display assembly (see Display assembly on page Top cover (see Top cover on page System board (see System board on page Remove the processor: Turn the system board upside down, with the USB connectors toward you.

  • Page 84: Modem Module

    Modem module NOTE: The modem module spare part kits do not include a modem module cable. The modem module cable is included in the Cable Kit, spare part number 457400-001. See Cable Kit on page 21 for more Cable Kit spare part number information. Description Spare part number For use only in the United States...
  • Page 85 Lift the modem module (2) straight up to disconnect it from the system board. Remove the modem module. Reverse this procedure to install the modem module. Component replacement procedures...

  • Page 86: Rtc Battery

    RTC battery NOTE: Removing the RTC battery and leaving it uninstalled for 5 or more minutes causes all passwords and CMOS settings to be cleared. Description Spare part number RTC battery 449137-001 Before removing the RTC battery, follow these steps: Shut down the computer.
  • Page 87 Remove the RTC battery from the socket on the system board. Reverse this procedure to install the RTC battery. Component replacement procedures...

  • Page 88: Computer Setup

    Computer Setup Starting Computer Setup Computer Setup is a preinstalled, ROM-based utility that can be used even when the operating system is not working or will not load. NOTE: Some of the Computer Setup menu items listed in this guide may not be supported by your computer.

  • Page 89: Using Computer Setup

    Using Computer Setup Navigating and selecting in Computer Setup The information and settings in Computer Setup are accessed from the File, Security, Diagnostics, and System Configuration menus. Open Computer Setup by turning on or restarting the computer, and then pressing while the "F10 = ROM Based Setup"...

  • Page 90: Computer Setup Menus

    Computer Setup menus The menu tables in this section provide an overview of Computer Setup options. NOTE: Some of the Computer Setup menu items listed in this chapter may not be supported by your computer. File menu Select To do this System information View identification information for the computer and the batteries in the system.

  • Page 91: Security Menu

    Security menu Select To do this Setup password Enter, change, or delete a setup password. Power-On password Enter, change, or delete a power-on password. Password options Enable/disable stringent security. ● ● Enable/disable password requirement on computer restart. DriveLock passwords Enable/disable DriveLock on any computer hard drive. ●...

  • Page 92: System Configuration Menu

    System Configuration menu NOTE: Some of the listed System Configuration options may not be supported by your computer. Select To do this Language (or press f2) Change the Computer Setup language. Boot options ● Set f9, f10, and delay when starting up. Enable/disable CD-ROM boot.
  • Page 93 Select To do this Built-In Device Options Enable/disable embedded WWAN Device Radio. ● Enable/disable embedded WLAN Device Radio. ● Enable/disable embedded Bluetooth® Device Radio. ● Enable/disable LAN/WLAN Switching. When enabled, switches to a WLAN ● when a LAN is either unavailable or disconnected. Enable/disable Wake on LAN from Off.

  • Page 94: Specifications

    Specifications Computer specifications Metric U.S. Dimensions Depth 24.64 cm 9.70 in Width 33.80 cm 13.31 in Height (front to rear) 3.08 to 3.43 cm 1.21 to 1.35 in Weight (equipped with optical drive, hard drive, and battery) 2.20 kg 4.85 lbs Input power Operating voltage 19.0 V dc @ 4.74 A –...

  • Page 95: 14.1-Inch, Wxga Display Specifications

    Metric U.S. Nonoperating 1.50 g zero-to-peak, 10 Hz to 500 Hz, 0.5 oct/min sweep rate NOTE: Applicable product safety standards specify thermal limits for plastic surfaces. The computer operates well within this range of temperatures. 14.1-inch, WXGA display specifications Metric U.S.

  • Page 96: Hard Drive Specifications

    Hard drive specifications 160-GB* 120-GB* 80-GB* Dimensions Height 9.5 mm 9.5 mm 9.5 mm Width 70 mm 70 mm 70 mm Weight 101 g 101 g 101 g Interface type SATA SATA SATA Transfer rate 100 MB/sec 100 MB/sec 100 MB/sec Security ATA security ATA security...

  • Page 97: Dvd±Rw And Cd-Rw Double-Layer Combo Drive Specifications

    DVD±RW and CD-RW Double-Layer Combo Drive specifications Applicable disc Read: Write: CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-R and CD-RW CD-ROM XA, MIXED MODE CD, CD-I, CD-I DVD+R, DVD+RW, DVD-R, DVD- Bridge (Photo-CD, Video CD), Multisession CD RW, DVD-RAM (Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW, DVD-RAM...

  • Page 98: Dvd/Cd-Rw Combo Drive Specifications

    DVD/CD-RW Combo Drive specifications Applicable disc Read: Write: CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-R and CD-RW CD-ROM XA, MIXED MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW, DVD-RAM Center hole diameter 1.5 cm (0.59 in)

  • Page 99: System Dma Specifications

    System DMA specifications Hardware DMA System function DMA0 Not applicable DMA1* Not applicable DMA2* Not applicable DMA3 Not applicable DMA4 Direct memory access controller DMA5* Available for ExpressCard DMA6 Not assigned DMA7 Not assigned *ExpressCard controller can use DMA 1, 2, or 5. System DMA specifications...

  • Page 100: System Interrupt Specifications

    System interrupt specifications Hardware IRQ System function IRQ0 System timer IRQ1 Standard 101-/102-Key or Microsoft® Natural Keyboard IRQ2 Cascaded IRQ3 Intel 82801DB/DBM USB2 Enhanced Host Controller—24CD IRQ4 COM1 IRQ5* Conexant AC—Link Audio Intel 82801DB/DBM SMBus Controller—24C3 Data Fax Modem with SmartCP IRQ6 Diskette drive IRQ7*...

  • Page 101: System I/O Address Specifications

    System I/O address specifications I/O address (hex) System function (shipping configuration) 000 - 00F DMA controller no. 1 010 - 01F Unused 020 - 021 Interrupt controller no. 1 022 - 024 Opti chipset configuration registers 025 - 03F Unused 02E - 02F 87334 “Super I/O”...
  • Page 102 I/O address (hex) System function (shipping configuration) 220 - 22F Entertainment audio 230 - 26D Unused 26E - 26 Unused 278 - 27F Unused 280 - 2AB Unused 2A0 - 2A7 Unused 2A8 - 2E7 Unused 2E8 - 2EF Reserved serial port 2F0 - 2F7 Unused 2F8 - 2FF...

  • Page 103: System Memory Map Specifications

    System memory map specifications Size Memory address System function 640 KB 00000000-0009FFFF Base memory 128 KB 000A0000-000BFFFF Video memory 48 KB 000C0000-000CBFFF Video BIOS 160 KB 000C8000-000E7FFF Unused 64 KB 000E8000-000FFFFF System BIOS 15 MB 00100000-00FFFFFF Extended memory 58 MB 04800000-07FFFFFF Super extended memory 58 MB...

  • Page 104: Screw Listing

    Screw listing This section provides specification and reference information for the screws and screw locks used in the computer. All screws listed in this section are available in the Screw Kit, spare part number 456615-001. Chapter 7 Screw listing...

  • Page 105: Phillips Pm2.0×5.0 Captive Screw

    Phillips PM2.0×5.0 captive screw Color Quantity Length Thread Head diameter Black 5.0 mm 2.0 mm 5.0 mm Where used: (1) Two captive screws that secure the hard drive bay cover to the computer (screws are captured on the cover by C-clips) (2) One captive screw that secures the WLAN module compartment cover to the computer (screw is captured on the cover by a C-clip) (3) One captive screw that secures the memory module compartment cover to the computer (screw is...

  • Page 106: Phillips Pm2.5×12.0 Captive Screw

    Phillips PM2.5×12.0 captive screw Color Quantity Length Thread Head diameter Silver 12.0 mm 2.5 mm 5.0 mm Where used: One captive screw that secures the hard drive to the computer (screw is secured to the hard drive bracket) Chapter 7 Screw listing...

  • Page 107: Phillips Pm3.0×4.0 Screw

    Phillips PM3.0×4.0 screw Color Quantity Length Thread Head diameter Silver 4.0 mm 3.0 mm 5.0 mm Where used: 4 screws that secure the hard drive bracket to the hard drive Phillips PM3.0×4.0 screw...

  • Page 108: Phillips Pm2.5×4.0 Screw

    Phillips PM2.5×4.0 screw Color Quantity Length Thread Head diameter Black 4.0 mm 2.5 mm 5.0 mm Where used: 2 screws that secure the WLAN module to the system board 100 Chapter 7 Screw listing...

  • Page 109: Torx T8M2.5×7.0 Screw

    Where used: 2 screws that secure the modem module to the system board Torx T8M2.5×7.0 screw Color Quantity Length Thread Head diameter Black 7.0 mm 2.5 mm 5.0 mm Where used: (1) One screw that secures the optical drive to the computer (2) Two screws that secure the keyboard to the computer (3) Two screws that secure the switch cover to the computer Torx T8M2.5×7.0 screw 101...
  • Page 110 Where used: 2 screws that secure the display assembly to the computer Where used: 2 screws that secure the display assembly to the computer 102 Chapter 7 Screw listing...
  • Page 111 Where used: 7 screws that secure the top cover to the base enclosure Where used: 2 screws that secure the top cover to the base enclosure Torx T8M2.5×7.0 screw 103...

  • Page 112: Phillips Pm2.0×4.0 Screw

    Phillips PM2.0×4.0 screw Color Quantity Length Thread Head diameter Silver 4.0 mm 2.0 mm 4.5 mm Where used: 2 screws that secure the optical drive bracket to the optical drive 104 Chapter 7 Screw listing...
  • Page 113 Where used: 8 screws that secure the display hinges to the display assembly Where used: 2 screws that secure the TouchPad bracket and TouchPad button board to the top cover Phillips PM2.0×4.0 screw 105...
  • Page 114 Where used: 2 screws that secure the Blueotooth module to the base enclosure Where used: 2 screws that secure the ExpressCard assembly to the system board 106 Chapter 7 Screw listing...

  • Page 115: Torx T8M2.5×3.0 Broad-Head Screw

    Torx T8M2.5×3.0 broad-head screw Color Quantity Length Thread Head diameter Black 3.0 mm 2.5 mm 8.0 mm Where used: 2 screws that secure the switch cover to the computer Torx T8M2.5×3.0 broad-head screw 107...

  • Page 116: Torx T8M2.5×4.0 Screw

    Torx T8M2.5×4.0 screw Color Quantity Length Thread Head diameter Black 4.0 mm 2.5 mm 5.0 mm Where used: 2 screws that secure the speaker to the computer 108 Chapter 7 Screw listing...

  • Page 117: Torx T8M2.5×6.0 Screw

    Where used: One screw that secures the top cover to the base enclosure Torx T8M2.5×6.0 screw Color Quantity Length Thread Heat width Black 6.0 mm 2.5 mm 5.0 mm Where used: 8 screws that secure the display bezel to the display assembly Torx T8M2.5×6.0 screw 109...

  • Page 118: Phillips Pm2.0×2.0 Broad-Head Screw

    Where used: One screw that secures the system board to the base enclosure Phillips PM2.0×2.0 broad-head screw Color Quantity Length Thread Head diameter Black 2.0 mm 2.0 mm 7.0 mm Where used: 3 screws that secure the top cover to the display enclosure 110 Chapter 7 Screw listing...

  • Page 119: Phillips Pm2.0×6.0 Screw

    Phillips PM2.0×6.0 screw Color Quantity Length Thread Head diameter Black 6.0 mm 2.0 mm 4.5 mm Where used: One screw that secures the system board to the base enclosure Phillips PM2.0×6.0 screw 111...

  • Page 120: Phillips Pm2.5×7.0 Screw

    Phillips PM2.5×7.0 screw Color Quantity Length Thread Head diameter Black 7.0 mm 2.5 mm 5.0 mm Where used: One screw that secures the fan to the base enclosure 112 Chapter 7 Screw listing...

  • Page 121: Phillips Pm2.5×7.0 Captive Screw

    Phillips PM2.5×7.0 captive screw Color Quantity Length Thread Head diameter Silver 7.0 mm 2.5 mm 5.0 mm Where used: One captive screw that secures the fan to the base enclosure (screw is secured to the fan by a C-clip) Phillips PM2.5×7.0 captive screw 113...

  • Page 122: Phillips Pm2.5×10.0 Captive Screw

    Phillips PM2.5×10.0 captive screw Color Quantity Length Thread Head diameter Silver 10.0 mm 2.5 mm 5.0 mm Where used: 6 captive screws that secure the heat sink to the system board on computer models equipped with discrete graphics subsystem memory (screws are secured to the heat sink by C-clips) 114 Chapter 7 Screw listing...
  • Page 123 Where used: 4 captive screws that secure the heat sink to the system board on computer models equipped with UMA graphics subsystem memory (screws are secured to the heat sink by C-clips) Phillips PM2.5×10.0 captive screw 115...

  • Page 124: Phillips Pm2.0×8.0 Screw

    Phillips PM2.0×8.0 screw Color Quantity Length Thread Head diameter Black 8.0 mm 2.0 mm 4.5 mm Where used: 2 screws that secure the ExpressCard assembly to the system board 116 Chapter 7 Screw listing...

  • Page 125: Backup And Recovery

    Backup and recovery Creating recovery discs in Windows VIsta After setting up the computer for the first time, be sure to create a set of recovery discs of the full factory image. The recovery discs are used to start up (boot) the computer and recover the operating system and software to factory settings in case of system instability or failure.

  • Page 126: Backing Up Your Information In Windows Vista

    Backing up your information in Windows Vista NOTE: You can only recover files that you have previously backed up. HP recommends that you use HP Backup & Recovery Manager to create an entire drive backup as soon as you set up your computer. With HP Backup &...

  • Page 127: Backing Up Specific Files Or Folders

    Backing up specific files or folders You can back up specific files or folders to the recovery partition on the hard drive, to an optional external hard drive, or to optical discs (CDs or DVDs). NOTE: This process will take several minutes, depending on the file size and the speed of the computer. To back up specific files or folders: Select Start >...

  • Page 128: Creating Recovery Points

    Creating recovery points When you back up modifications since your last backup, you are creating system recovery points. This allows you to save a snapshot of your hard drive at a specific point in time. You can then recover back to that point if you want to reverse subsequent changes made to your system.

  • Page 129: Performing A Recovery In Windows Vista

    Performing a recovery in Windows Vista NOTE: You can only recover files that you have previously backed up. HP recommends that you use HP Backup & Recovery Manager to create an entire drive backup as soon as you set up your computer. HP Backup &...

  • Page 130: Initiating A Recovery In Windows

    Initiating a recovery in Windows To initiate a recovery in Windows, follow these steps: Back up all personal files. Select Start > All Programs > HP Backup & Recovery > Backup & Recovery Manager. Click Next. Click Perform a recovery, and then click Next. Follow the on-screen instructions.

  • Page 131: Creating Recovery Discs In Windows Xp

    Creating recovery discs in Windows XP After setting up the computer for the first time, be sure to create a set of recovery discs of the full factory image. The recovery discs are used to start up (boot) the computer and recover the operating system and software to factory settings in case of system instability or failure.

  • Page 132: Backing Up Your Information In Windows Xp

    Backing up your information in Windows XP NOTE: You can only recover files that you have previously backed up. HP recommends that you use HP Backup and Recovery Manager to create an entire drive backup as soon as you set up your computer. With HP Backup and Recovery Manager, you can perform the following tasks: ●...

  • Page 133: Backing Up Specific Files Or Folders

    Backing up specific files or folders You can back up specific files or folders to the recovery partition on the hard drive, to an optional external hard drive, or to optical discs (CDs or DVDs). NOTE: This process will take several minutes, depending on the file size and the speed of the computer. To back up specific files or folders: Select Start >...

  • Page 134: Creating Recovery Points

    Creating recovery points When you back up modifications since your last backup, you are creating system recovery points. This allows you to save a snapshot of your hard drive at a specific point in time. You can then recover back to that point if you want to reverse subsequent changes made to your system.

  • Page 135: Performing A Recovery In Windows Xp

    Performing a recovery in Windows XP NOTE: You can only recover files that you have previously backed up. HP recommends that you use HP Backup and Recovery Manager to create an entire drive backup as soon as you set up your computer. HP Backup and Recovery Manager helps you with the following tasks for safeguarding your information and restoring it in case of a system failure: Recovering important files—This feature helps you reinstall important files without performing a full...

  • Page 136: Initiating A Recovery In Windows

    Initiating a recovery in Windows To initiate a recovery in Windows, follow these steps: Back up all personal files. Select Start > All Programs > HP Backup & Recovery > HP Backup and Recovery Manager. Click Next. Click Recover important files or the entire system, and then click Next. Follow the on-screen instructions.

  • Page 137: Initiating A Recovery From The Hard Drive Recovery Partition

    Initiating a recovery from the hard drive recovery partition To initiate a recovery from the hard drive recovery partition, follow these steps: Back up all personal files. Restart the computer, and then press before the Windows operating system loads. Click a recovery option, and then click Next. Follow the on-screen instructions.

  • Page 138: Connector Pin Assignments

    Connector pin assignments Audio-out (headphone) Signal Audio out, left channel Audio out, right channel Ground Audio-in (microphone) Signal Audio signal in Audio signal in Ground 130 Chapter 9 Connector pin assignments...

  • Page 139: External Monitor

    External monitor Signal Red analog Green analog Blue analog Not connected Ground Ground analog Ground analog Ground analog +5 VDC Ground Monitor detect DDC 2B data Horizontal sync Vertical sync DDC 2B clock External monitor 131...

  • Page 140: Modem)

    RJ-11 (modem) Signal Unused Ring Unused Unused Unused 132 Chapter 9 Connector pin assignments...

  • Page 141: Network)

    RJ-45 (network) Signal Transmit + Transmit - Receive + Unused Unused Receive - Unused Unused Universal Serial Bus Signal +5 VDC Data - Data + Ground RJ-45 (network) 133...

  • Page 142: 10 Power Cord Set Requirements

    10 Power cord set requirements The wide range input feature of the computer permits it to operate from any line voltage from 100 to 120 volts AC or from 220 to 240 volts AC. The 3-conductor power cord set included with the computer meets the requirements for use in the country or region where the equipment is purchased.

  • Page 143: Requirements For Specific Countries And Regions

    Requirements for specific countries and regions Country/region Accredited agency Applicable note number Australia EANSW Austria Belgium CEBC Canada Denmark DEMKO Finland FIMKO France Germany Italy Japan METI Korea The Netherlands KEMA Norway NEMKO The People's Republic of China Sweden SEMKO Switzerland Taiwan BSMI...

  • Page 144: 11 Recycling

    11 Recycling Battery When a battery has reached the end of its useful life, do not dispose of the battery in general household waste. Follow the local laws and regulations in your area for computer battery disposal. Display WARNING! The backlight contains mercury. Exercise caution when removing and handling the backlight to avoid damaging this component and causing exposure to the mercury.
  • Page 145 Perform the following steps to disassemble the display assembly: Remove all screw covers (1) and screws (2) that secure the display bezel to the display assembly. Lift up and out on the left and right inside edges (1) and the top and bottom inside edges (2) of the display bezel until the bezel disengages from the display assembly.
  • Page 146 Disconnect all display panel cables (1) from the display inverter and remove the inverter (2). Remove all screws (1) that secure the display panel assembly to the display enclosure. Remove the display panel assembly (2) from the display enclosure. Turn the display panel assembly upside down. Remove all screws that secure the display panel frame to the display panel.
  • Page 147 Remove the display panel frame (2) from the display panel. Remove the screws (1) that secure the backlight cover to the display panel. Lift the top edge of the backlight cover (2) and swing it outward. Remove the backlight cover. Turn the display panel right-side up.
  • Page 148 Remove the backlight cables (1) from the clip (2) in the display panel. Turn the display panel upside down. WARNING! The backlight contains mercury. Exercise caution when removing and handling the backlight to avoid damaging this component and causing exposure to the mercury. Remove the backlight frame from the display panel.
  • Page 149 Remove the backlight from the backlight frame. Disconnect the display panel cable (1) from the LCD panel. Remove the screws (2) that secure the LCD panel to the display rear panel. Release the LCD panel (3) from the display rear panel. Release the tape (4) that secures the LCD panel to the display rear panel.

  • Page 150: Index

    Index bottom components 12 System Configuration menu 84 AC adapter, spare part button components 8 using 81 numbers 23, 24, 28 buttons computer specifications 86 antenna, disconnecting 42 power 8 connectors audio, product description 4 TouchPad 7 power 11 audio-in jack wireless 8 service considerations 30 location 10...
  • Page 151 removal 52 keyboard spare part number 52 graphics, product description 2 product description 5 display panel, removal 56 grounding equipment and removal 47 display specifications 87 methods 33 spare part numbers 15, 27, DriveLock password 83 drives keypad keys 9 hard drive boot order 84 keys...
  • Page 152 modem jack Plastics Kit product name 1 location 11 contents 20 security 5 pin assignments 132 spare part number 15, 20, serviceability 6 modem module wireless 4 product description 4 pointing device product name 1 removal 76 components 7 spare part numbers 17, 24, illustrated 7 recovery discs 26, 76...
  • Page 153 speaker TouchPad board location 9 removal 61 removal 51 spare part number 15, 26, spare part number 15, 26, TouchPad button board specifications removal 61 computer 86 spare part number 15, 26, display 87 DVD/CD-RW Combo Drive 90 TouchPad buttons 7 DVD±RW and CD-RW Combo TouchPad components 7 Drive 89...

This manual is also suitable for:

Compaq 6520s

Table of Contents
