Wii Remote Induction Charge Kit
Package contents
• Wii remote induction charge base
• Rechargeable induction batteries (2)
• AC adapter
• Quick Setup Guide
Features
Remote induction charge base (front)
#
Description
#
1
Charge indicator
3
2
DC IN connector
4
Remote induction charge base (top)
RF-GWII052
RF-GWII052_09-0479_QSG_V1_ENG.in1 1
RF-GWII052_09-0479_QSG_V1_ENG.in1 1
Battery packs and AC adapter
Installing the battery pack
1 Remove the Wii remote jacket, if applicable, then remove the
battery compartment cover.
2 Install the battery pack into the remote.
Description
On/Off switch
Charge indicator
3 Put the Wii remote jacket, if applicable, back on the remote.
QUICK SETUP GUIDE
Using the charger
1 Insert the plug into the DC IN connector, then plug the AC
adapter into a power outlet.
2 Turn on the charger, then place the remote with the battery
pack installed on the charger. Your battery can be recharged
without removing the silicone sleeve and without removing
the Wii MotionPlus™ module.
Note: You should place the remote parallel with the center bar and the
battery pack should be near the center position.
Charging starts if the charger detects the battery pack and the
glow bar lights red. There may be a brief delay before you see the
light. When the battery pack is fully charged, the glow bar changes
to green.
Notes:
•
The supplied rechargeable battery packs must be fully charged before
being used for the fi rst time. It may take up to 4 hours to fully charge a
new battery.
