PRODUCT NO.
BASE MODEL NO.
FEF352AUA
FEF352A
FEF352AWA
FEF352A
SERVICE DATA SHEET - # 316259142
WIRING DIAGRAM - #316255104
OWNER'S GUIDE - # 316257104
INSTALLATION INSTRUCTIONS -# 316259200
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
COLOR
MARKET
black/bisque
North America
black/white
North America
Publication No.
5995357745
010816
-EN/SERVICE /ECL
369
FACTORY
PARTS CATALO
ELECTRIC
RANGE
Model No.
FEF352A
©2001 White Consolidated Industries, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FEF352A
Summary of Contents for Frigidaire FEF352A
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. COLOR MARKET FEF352AUA FEF352A black/bisque North America FEF352AWA FEF352A black/white North America SERVICE DATA SHEET - # 316259142 WIRING DIAGRAM - #316255104 ELECTRIC OWNER’S GUIDE - # 316257104 INSTALLATION INSTRUCTIONS -# 316259200 RANGE Model No.
- Page 2 Publication No. FEF352A 5995357745 BACKGUARD 08/01...
- Page 3 FEF352A Publication No. 5995357745 BACKGUARD A = FEF352A (FEF352AWA) B = FEF352A (FEF352AUA) POS. NO PART NO DESCRIPTION 316239900 Shield,backguard ,rear wall 316241000 Shield,end cap ,RH 316241001 Shield,end cap ,LH 316022503 Light/Lamp,indicator ,surface ,250 V 316220204 Support,backguard ,black ,RH 316220205 Support,backguard ,black ,LH 316240905 End Cap,black ,RH...
- Page 4 Publication No. FEF352A 5995357745 BODY 08/01...
- Page 5 FEF352A Publication No. 5995357745 BODY A = FEF352A (FEF352AWA) B = FEF352A (FEF352AUA) POS. NO PART NO DESCRIPTION 316201300 Back,main 316230102 Panel,bodyside ,white ,RH 316230103 Panel,bodyside ,white ,LH 316230108 Panel,bodyside ,bisque ,RH 316230109 Panel,bodyside ,bisque ,LH 316201401 Burner Box 316129200 Screw,leveling ,plastic ,with stop 316067902 Rack,oven...
- Page 6 Publication No. FEF352A 5995357745 TOP/DRAWER 08/01...
- Page 7 FEF352A Publication No. 5995357745 TOP/DRAWER A = FEF352A (FEF352AWA) B = FEF352A (FEF352AUA) POS. NO PART NO DESCRIPTION 316011503 Drawer 316231500 Liner,drawer 316231305 Panel,drawer ,white 316231309 Panel,drawer ,bisque 3051163 Glide,drawer ,rear 15 # 5303012223 Element,surface ,8" ,large 15A# 08067762 Element,surface ,6" ,small 316202307 Main Top,white 316202309...
- Page 8 Publication No. FEF352A 5995357745 DOOR 08/01...
- Page 9 FEF352A Publication No. 5995357745 DOOR A = FEF352A (FEF352AWA) B = FEF352A (FEF352AUA) POS. NO PART NO DESCRIPTION 5303935191 Trim kit-door,3 sided ,black ,w/tape and foil 5303935203 Glass,door kit ,black ,outer ,w/ foil tape 316088700 Glass,oven door ,airwash 316222706 Shield,wool ,oven door 316236800 Insulation,oven door 316088600...
-
Page 10: Wiring Diagram
Publication No. FEF352A 5995357745 WIRING DIAGRAM 08/01...
