D-Link WDA-1320 User Manual

Wireless g desktop adapter
Hide thumbs Also See for WDA-1320:
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading

Related Manuals for D-Link WDA-1320

Summary of Contents for D-Link WDA-1320

  • Page 2: Table Of Contents

    Windows Vista ..............5 What is WPA? ..............50 Wireless Networks ............ 5 Configure WPA/WPA Passphrase ........51 Wi-Fi Protected Setup ..........6 Using the D-Link Utility ..........51 Personal Identification Number (PIN) ....... 7 Using the Windows XP Utility ......... 53 ®...
  • Page 3 Table of Contents Configure 80.1x ............. 56 Using the D-Link Utility ..........56 Troubleshooting ........... 57 Wireless Basics ........... 62 Networking Basics ..........67 Check your IP address ............. 67 Windows XP/000 User .......... 68 ® Windows Vista Users ..........68 ™...

  • Page 4: Product Overview

    Section 1 - Product Overview Product Overview Package Contents • D-Link WDA-130 Wireless G Desktop Adapter • Manual, Software, and Warranty on CD System Requirements • A desktop computer with an available PCI slot • Windows Vista , XP (Service Pack ) or 000 (Service Pack 4) ®...

  • Page 5: Introduction

    Introduction The D-Link Wireless G WDA-130 Desktop adapter features the very latest in advanced wireless silicon chip technology to deliver a maximum wireless signal rate of up to 54Mbps* in the .4GHz frequency. The WDA-130 also works with 80.11b standard wireless devices and when used with other D-Link Wireless G products delivers throughput speeds capable of handling heavy data payloads.

  • Page 6: Features

    • 3-bit PCI Performance/Plug & Play Connectivity - The WDA-130 is a powerful 3-bit PCI adapter that installs quickly and easily into desktop PCs, and when used with other D-Link Wireless G products will automatically connect to the network out of the box.

  • Page 7: Hardware Overview

    Section 1 - Product Overview Hardware Overview LEDs Link A steady light indicates a connection to a wireless network. A blinking light indicates activity on the network. D-Link WDA-130 User Manual...

  • Page 8: Installation

    Remove Existing Installations If you’ve installed a different manufacture’s adapter or a different model D-Link adapter, make sure the software is uninstalled before installing the new software. Some utilities may cause a conflict with the new software. If you plan to use multiple adapters at different times, make sure the utilities are not set to load when your computer boots up.

  • Page 9: Disable Other Wireless Adapters

    Section  - Installation Disable Other Wireless Adapters Most newer laptops may include a built-in wireless adapter. To prevent any conflicts or confusion with the D-Link wireless adapter, it is recommended to disable the wireless adapter (as well as any unused Ethernet adapters).
  • Page 10 Click Yes to disable the adapter. The adapter is now disabled. When disabled, a red X will be displayed. Disabling the adapter will not remove the drivers. If you would like to use the adapter, simply right-click it and select Enable. D-Link WDA-130 User Manual...

  • Page 11: Wireless Installation Considerations

    RF (radio frequency) noise in your home or business. The key to maximizing wireless range is to follow these basic guidelines: 1. Keep the number of walls and ceilings between the D-Link adapter and other network devices to a minimum - each wall or ceiling can reduce your adapter’s range from 3-90 feet (1-30 meters.) Position your devices so that the number...

  • Page 12: Adapter Installation

    Section  - Installation Adapter Installation Note: Please install the WDA-1320 Desktop Adapter into your computer before installing the driver software from the D-Link CD. Refer to the insert included with this adapter for installation instructions. Turn on the computer and Insert the D-Link WDA-130 Driver CD in the CD-ROM drive. The step-by-step instructions that follow are shown in Windows XP.

  • Page 13: Windows Vista ™ Installation

    Click Next to continue. By default setup will install to the default location: C:\Program Files\D-Link\WDA-1320, where C: represents the drive letter of your hard drive. To install to a different location click Browse and specify the location. Click Next to continue.
  • Page 14 Select the Program Files folder location. Click Next to continue. WDA-130 will start configuring your new software installation. This may take few minutes. Once the installation is complete, the InstallShield Wizard screen displays. Click Finish to close the window. D-Link WDA-130 User Manual...
  • Page 15 The Wireless Connection Wizard will now appear. If you want to manually connect to a wireless network, refer to page 17. The following instructions will connect you to a wireless network using Wi-Fi Protected Setup (WPS). D-Link WDA-130 User Manual...

  • Page 16: Push Button Configuration (Pbc)

    Press the WPS button on your access point or wireless router within  minutes to establish connectivity. When this screen appears, you have successfully connected to your wireless network. Click Next to complete your setup. D-Link WDA-130 User Manual...
  • Page 17 Click Scan to display the site survey page. Click the Scan button to display a list of wireless networks (site survey). Click on the network name (SSID) and click Next. D-Link WDA-130 User Manual...
  • Page 18 When this screen appears, you are successfully connected to your wireless network. Click Next to complete your setup. Click Finish to continue. If you are prompted to reboot your computer, select Yes, I want to restart my computer now. D-Link WDA-130 User Manual...

  • Page 19: Windows ® Xp Installation

    The InstallShield Wizard window will appear. Click Next to continue. By default setup will install to the default location: C:\Program Files\D-Link\WDA-1320, where C: represents the drive letter of your hard drive. To install to a different location click Browse and specify the location.
  • Page 20 The D-Link configuration wizard will now appear. If you are using Windows XP (SP), you will have the option to use ® either the D-Link utility or the built-in Windows Wireless utility. ® Click Next to continue. The Wireless Connection Wizard will now appear.

  • Page 21: Push Button Configuration (Pbc)

    Press the WPS button on your access point or wireless router within  minutes to establish connectivity. When this screen appears, you have successfully connected to your wireless network. Click Next to complete your setup. D-Link WDA-130 User Manual...
  • Page 22 Click Next to continue or click Scan to display the site survey page. Click the Scan button to display a list of wireless networks (site survey). Click on the network name (SSID) and click Connect. D-Link WDA-130 User Manual...
  • Page 23 If the wireless network you are trying to connect to is using WPA- PSK, enter the WPA-PSK passphrase. Click Next to continue. Click Finish to continue. If you are prompted to reboot your computer, select Yes, I want to restart my computer now. D-Link WDA-130 User Manual...

  • Page 24: Configuration

    Section 3 - Configuration Configuration This section will show you how to configure your new D-Link wireless adapter using the D-Link Utility as well as the Windows ® Zero Configuration Utility. D-Link Configuration Utility The D-Link WDA-130 uses the Configuration Utility as the management software. The utility provides the user an easy interface to change any settings related to the wireless adapter.

  • Page 25: Windows Vista

    Enter the security information to connect (refer to the Wireless Security section for more information). Activate Button: Select a wireless network profile from the drop-down menu and click Activate to connect. Allow up to 30 seconds to connect. D-Link WDA-130 User Manual...

  • Page 26: Wi-Fi Protected Setup

    Entering this number in the utility of the WPS-enabled wireless router or access point connects you with the intended wireless network. Refer to the next page for more information. D-Link WDA-130 User Manual...

  • Page 27: Personal Identification Number (Pin)

    Enter this number in your access point or wireless router. Please refer to the manufacture’s manual for instructions. Once you click Next, you will have  minutes to enter this number in your access point or wireless router. D-Link WDA-130 User Manual...
  • Page 28 Section 3 - Configuration The adapter will try to establish connectivity to your access point or wireless router. When this screen appears, you have successfully established connectivity. Click Finish to complete your setup. D-Link WDA-130 User Manual...

  • Page 29: My Wireless Networks

    Click Activate to use a profile. Allow up to 30 seconds to connect to the wireless network. Profile Details: The Profile Details section will display information about the wireless network such as the network name (SSID), and if the network is secured. D-Link WDA-130 User Manual...

  • Page 30: Add Profile

    Select the network type. If you are connecting to a wireless router or access point, select Infrastructure. Set Security: Select the type of security used. Please refer to the Wireless Security section for more information. OK Button: Click OK to save your settings. D-Link WDA-130 User Manual...

  • Page 31: Modify Profile

    Displays the SSID of the network. Network Type: Displays the network type. Set Security: Select the type of security used. Please refer to the Wireless Security section for more information. OK Button: Click OK to save your settings. D-Link WDA-130 User Manual...

  • Page 32: Support

    Section 3 - Configuration Support If you need help, click the Support button. A pane will appear to the right of the utility which will display information about the utility. D-Link WDA-130 User Manual...

  • Page 33: About

    Section 3 - Configuration About The About screen gives you information about the Firmware and Utility Versions of the WDA-130. D-Link WDA-130 User Manual...

  • Page 34: Windows ® Xp Configuration Utility

    XP users may use the built-in wireless utility. The following instructions are for Service Pack  users. ® If you are using Windows 000, you must use the D-Link utility. Please refer to page 4. ® If you receive the Wireless Networks Detected bubble, click on the center of the bubble to access the utility.

  • Page 35: Windows ® Xp

    Highlight a wireless network and click the Connect button. If the network is secure, a pop-up window will appear. Enter the security information to connect (refer to the Wireless Security section for more information). Active Button: Select a wireless network profile from the drop-down menu and click Active to connect. Allow up to 30 seconds to connect. D-Link WDA-130 User Manual...

  • Page 36: Wi-Fi Protected Setup (Wps)

    Entering this number in the utility of the WPS-enabled wireless router or access point connects you with the intended wireless network. Refer to the next page for more information. D-Link WDA-130 User Manual...

  • Page 37: Personal Identification Number (Pin)

    Enter this number in your access point or wireless router. Please refer to the manufacture’s manual for instructions. Once you click Next, you will have  minutes to enter this number in your access point or wireless router. D-Link WDA-130 User Manual...
  • Page 38 Section 3 - Configuration The adapter will try to establish connectivity to your access point or wireless router. When this screen appears, you have successfully established connectivity. Click Finish to complete your setup. D-Link WDA-130 User Manual...

  • Page 39: My Wireless Networks

    Click Active to activate a profile. Allow up to 30 seconds to connect to the wireless network. Profile Details: The Profile Details section will display information about the wireless network such as the network name (SSID), network type (Infrastructure), and if the network is secured. D-Link WDA-130 User Manual...

  • Page 40: Add Profile

    Select the network type. If you are connecting to a wireless router or access point, select Infrastructure. Set Security: Select the type of security used. Please refer to the Wireless Security section for more information. OK Button: Click OK to save your settings. D-Link WDA-130 User Manual...

  • Page 41: Modify Profile

    Displays the SSID of the network. Network Type: Displays the network type. Set Security: Select the type of security used. Please refer to the Wireless Security section for more information. OK Button: Click OK to save your settings. D-Link WDA-130 User Manual...

  • Page 42: Support

    Section 3 - Configuration Support If you need help, click the Support button. A pane will appear to the right of the utility which will display information about the utility. D-Link WDA-130 User Manual...

  • Page 43: About

    Section 3 - Configuration About The About screen gives you information about the Firmware and Utility Versions of the WDA-130. D-Link WDA-130 User Manual...

  • Page 44: Disabling The Windows ® Xp Utility

    Section 3 - Configuration Disabling The Windows XP Utility ® If you want to use the D-Link wireless utility you must disable the Windows XP wireless utility. ® Right-click on the wireless computer icon in your system tray (lower- right corner next to the time). Select View Available Wireless Networks.
  • Page 45 Section 3 - Configuration In the Wireless Network Connection Properties window, uncheck Use Windows to configure my wireless network settings ® and then click OK. D-Link WDA-130 User Manual...

  • Page 46: Connect To A Wireless Network

    Click on a network (displayed using the SSID) and click the Connect button. If you get a good signal but cannot access the Internet, check you TCP/ IP settings for your wireless adapter. Refer to the Networking Basics section in this manual for more information. D-Link WDA-130 User Manual...
  • Page 47 It may take 0-30 seconds to connect to the wireless network. If the connection fails, please verify that the security settings are correct. The key or passphrase must be exactly the same as on the wireless router. D-Link WDA-130 User Manual...

  • Page 48: Connect To A Wireless Network

    Click on a network (displayed using the SSID) and click the Connect button. If you get a good signal but cannot access the Internet, check you TCP/ IP settings for your wireless adapter. Refer to the Networking Basics section in this manual for more information. D-Link WDA-130 User Manual...

  • Page 49: Wireless Security

    This section will show you the different levels of security you can use to protect your data from intruders. The WDA-130 offers the following types of security: • WPA (Wi-Fi Protected Access ) • WPA-PSK (Pre-Shared Key) • WPA (Wi-Fi Protected Access) • WPA-PSK (Pre-Shared Key) • 80.1x (RADIUS) D-Link WDA-130 User Manual...

  • Page 50: What Is Wpa

    WPA/WPA incorporates user authentication through the Extensible Authentication Protocol (EAP). EAP is built on a more secure public key encryption system to ensure that only authorized network users can access the network. D-Link WDA-130 User Manual...

  • Page 51: Configure Wpa/Wpa Passphrase

    It is recommended to enable WPA-PSK on your wireless router or access point before configuring your wireless adapter. If you are joining an existing network, you will need to know the WPA-PSK passphrase being used. 1. Open the Wireless Utility by double-clicking on the D-Link icon in your system tray (lower-right corner of screen).
  • Page 52 1. Open the Wireless Utility by double-clicking on the D-Link icon in your system tray (lower-right corner of screen). Click on New to create a new profile or highlight an existing profile and click Modify.

  • Page 53: Using The Windows ® Xp Utility

    XP Wireless Utility by right-clicking ® on the wireless computer icon in your system tray (lower-right corner of screen). Select View Available Wireless Networks. 2. Highlight the wireless network (SSID) you would like to connect to and click Connect. D-Link WDA-130 User Manual...
  • Page 54 It may take 0-30 seconds to connect to the wireless network. If the connection fails, please verify that the WPA-PSK settings are correct. The WPA-PSK passphrase must be exactly the same as on the wireless router or access point. D-Link WDA-130 User Manual...

  • Page 55: Configure Wpa/Wpa

    WPA and WPA are for advanced users who are familiar with using a RADIUS server and setting up certificates. 1. Open the Wireless Utility by double-clicking on the D-Link icon in your system tray (lower-right corner of screen). Click on New to create a new profile or highlight an existing profile and click Modify.

  • Page 56: Configure 80.1X

    80.1x is for advanced users who are familiar with using a RADIUS server and setting up certificates. 1. Open the Wireless Utility by double-clicking on the D-Link icon in your system tray (lower-right corner of screen). Click on New to create a new profile or highlight an existing profile and click Modify.

  • Page 57: Troubleshooting

    1. How do I know if my adapter is installed properly? Go to Start > My Computer > Properties. Select the Hardware Tab. D-Link WDA-130 User Manual...
  • Page 58 Section 5 - Troubleshooting Click the + sign next to Network Adapters. Right-click on D-Link WDA-1320 Desktop Adapter. Select Properties to check that the drivers are installed properly. D-Link WDA-130 Desktop Adapter D-Link WDA-130 Desktop Adapter Look under Device Status to check that the device is working properly.
  • Page 59 WDA-130. • Refresh the WDA-130 Utility. 3. Why aren’t the Power and Link lights on? • Check to see if the WDA-130 Wireless Desktop Adapter is firmly inserted into the PCI slot of your laptop computer. D-Link WDA-130 User Manual...
  • Page 60 Section 5 - Troubleshooting 4. What should I do when the computer with the WDA-1320 installed is unable to connect to the wireless network and/or the internet? • Check that the LED indicators for the broadband modem are indicating normal activity. If not, there may be a problem with the broadband connection.
  • Page 61 Double-click on the WLAN icon in the taskbar > click Encryption. Check to see that the key selected is set to the same key as other devices on the network. 5. How can I troubleshoot distance issues using the WDA-1320? • Move the WDA-130 and the access point or wireless router into the same room and then test the wireless connection.

  • Page 62: Wireless Basics

    D-Link wireless products are based on industry standards to provide easy-to-use and compatible high-speed wireless connectivity within your home, business or public access wireless networks. Strictly adhering to the IEEE standard, the D-Link wireless family of products will allow you to securely access the data you want, when and where you want it. You will be able to enjoy the freedom that wireless networking delivers.
  • Page 63 D-Link is the worldwide leader and award winning designer, developer, and manufacturer of networking products. D-Link delivers the performance you need at a price you can afford. D-Link has all the products you need to build your network. How does wireless work? Wireless works similar to how cordless phone work, through radio signals to transmit data from one point A to point B.
  • Page 64 Who uses wireless? Wireless technology as become so popular in recent years that almost everyone is using it, whether it’s for home, office, business, D-Link has a wireless solution for it. Home • Gives everyone at home broadband access •...
  • Page 65 The wireless connection in public places is usually called “hotspots”. Using a D-Link Desktop Adapter with your laptop, you can access the hotspot to connect to Internet from remote locations like: Airports, Hotels, Coffee Shops, Libraries, Restaurants, and Convention Centers.

  • Page 66: Wireless Modes

    • Infrastructure – All wireless clients will connect to an access point or wireless router. An Infrastructure network contains an Access Point or wireless router. All the wireless devices, or clients, will connect to the wireless router or access point. D-Link WDA-130 User Manual...

  • Page 67: Networking Basics

    Check your IP address After you install your new D-Link adapter, by default, the TCP/IP settings should be set to obtain an IP address from a DHCP server (i.e. wireless router) automatically. To verify your IP address, please follow the steps below.

  • Page 68: Windows ® Xp/000 User

    • This will display the IP address, subnet mask, and default gateway of your adapter. If the address is 0.0.0.0, check your adapter installation, security settings, and the settings on your router. Some firewall software programs may block a DHCP request on newly installed adapters. D-Link WDA-130 User Manual...

  • Page 69: Statically Assign An Ip Address

    000 - From the desktop, right-click My Network Places > Properties. ® Step 2 Right-click on the Local Area Connection which represents your D-Link network adapter and select Properties. Step 3 Highlight Internet Protocol (TCP/IP) and click Properties. Step 4 Click Use the following IP address and enter an IP address that is on the same subnet as your network or the LAN IP address on your router.

  • Page 70: Windows ® Xp/000 Users

    2000 – From the desktop, right-click My Network Places > Properties. ® • Right-click on the Local Area Connection which represents your D-Link wireless network adapter (or other adapter) which will be connected to your router. • Highlight Internet Protocol (TCP/IP) and click Properties.

  • Page 71: Windows Vista ™ Users

    • Click on Start > Control Panel. Make sure you are in Classic View. Double-click on the Network and Sharing Center icon. Along the left panel in the window, click on Manage network connections. • Right-click on the Local Area Connection which represents your D-Link wireless network adapter which will be connected to your network. • Highlight Internet Protocol Version 4 (TCP /IPv4) and click Properties.

  • Page 72: Technical Specifications

    Frequency Range Transmitter Output Power .4GHz to .46GHz 15dBm ± dB Wireless Signal Range* Internal Antenna Type • Indoors: Up to 38 feet (100 meters) Dual Antenna Diversity Switching • Outdoors: Up to 1,31 feet (400 meters) D-Link WDA-130 User Manual...
  • Page 73 * Maximum wireless signal rate derived from IEEE Standard 80.11g specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental factors will adversely affect wireless signal range. D-Link WDA-130 User Manual...

  • Page 74: Contacting Technical Support

    • Hardware Revision (located on the label on the adapter (e.g. rev A1)) • Serial Number (s/n number located on the label on the adapter). You can find software updates and user documentation on the D-Link website as well as frequently asked questions and answers to technical issues.

  • Page 75: Warranty

    Warranty Period or ninety (90) days, whichever is longer, and is subject to the same limitations and exclusions. If a material defect is incapable of correction, or if D-Link determines that it is not practical to repair or replace the defective Hardware, the actual price paid by the original purchaser for the defective Hardware will be refunded by D-Link upon return to D-Link of the defective Hardware.
  • Page 76 Software Warranty Period, the magnetic media on which D-Link delivers the Software will be free of physical defects. The customer’s sole and exclusive remedy and the entire liability of D-Link and its suppliers under this Limited Warranty will be, at D-Link’s option, to replace the non-conforming Software (or defective media) with software that substantially conforms to D-Link’s functional specifications for the Software or to refund...
  • Page 77 • The customer is responsible for all in-bound shipping charges to D-Link. No Cash on Delivery (“COD”) is allowed. Products sent COD will either be rejected by D-Link or become the property of D-Link. Products shall be fully insured by the customer and shipped to D- Link Systems, Inc., 17595 Mt.

  • Page 78: Limitation Of Liability

    FOR WARRANTY SERVICE) RESULTING FROM THE USE OF THE PRODUCT, RELATING TO WARRANTY SERVICE, OR ARISING OUT OF ANY BREACH OF THIS LIMITED WARRANTY, EVEN IF D-LINK HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. THE SOLE REMEDY FOR A BREACH OF THE FOREGOING LIMITED WARRANTY IS REPAIR, REPLACEMENT OR REFUND OF THE DEFECTIVE OR NONCONFORMING PRODUCT.
  • Page 79 (1) This device may not cause harmful interference, and () this device must accept any interference received, including interference that may cause undesired operation. For detailed warranty information applicable to products purchased outside the United States, please contact the corresponding local D-Link office. D-Link WDA-130 User Manual...

  • Page 80: Registration

    Appendix F - Registration Registration Product registration is entirely voluntary and failure to complete or return this form will not diminish your warranty rights. Version 1.10(B) 04/08/008 D-Link WDA-130 User Manual...
