Insignia NS-32LB451A11 Quick Setup Manual

32" LCD TV/Blu-ray Combo, 1080p
QUICK SETUP
GUIDE
NS-32LB451A11
Thank You
for purchasing this ne Insignia television.
We hope you enjoy the quality and reliability
of this product for years to come.
_______________________________
EJECT/CLOSE
Remote
control
DISK and 2 AA
BLU-RAY
batteries
POPUP MENU HOME/SETUP
LIST
SEARCH
CLEAR
REPEAT
ANGLE SUBTITLE
DYN
VOL
NS-RC07A-11
AC Component L/R Audio
cable
power cable
cord
Remote
control holder
Stand Column, TV stand, Cover, and 4 screws
Cleaning
cloth
8 stand column screws 2 stand cover screws
Quick Setup Guide
Front features
PREV
NEXT
STOP
PLAY/
PAUSE
DISC IN
OPEN/
CLOSE
Power Remote
indicator
control sensor
Installing the stand
1 Carefully place your TV screen face-down on a cushioned, clean surface to
protect the screen from damages and scratches.
2 Secure the stand to the stand column with the provided four screws and
washers.
3 Slide the stand column into the slot in the bottom of the TV/Blu-ray
combo, then secure the stand column with the eight provided screws.
4 Secure the stand cover (included) to the TV/Blu-ray combo with the two
screws provided.
Installing a wall-mount bracket
1 Carefully place your TV face-down on a cushioned, clean surface to
protect the screen from damages and scratches.
2 Remove the two screws securing the stand cover to the TV, then remove
the stand cover.
3 Remove the eight screws holding the TV/Blu-ray DVD combo to its stand,
then remove the stand.
4 Secure the wall-mount bracket to the back of your TV using the screws
provided with the wall mount. Wall-mount bracket and screws are not
provided.
Setting up your remote control
1 Press down on the battery compartment cover lock, then remove the
battery compartment cover.
2 Insert two AA batteries into the battery compartment. Make sure that the
+ and – symbols on the batteries align with the + and – symbols in the
battery compartment.
3 Replace the cover.
Programming your remote control
To program your existing universal remote control to work with your new
Insignia TV, see the table below for common codes. If you have problems
programming your remote or need a di erent remote control code, visit
www.insigniaproducts.com for the latest remote control code information.
Universal remote control TV codes
(for all Insignia TVs manufactured after Jan. 1, 2007)
Universal remote control makers and models Set-top box makers and models
Philips
RCA One for All Sony Comcast Dish Network Motorola TIVO
PHDVD5, PH5DSS,
RCU807 URC-6690 RM-VL600 M1057 VIP508, VIP622 DRC800 Series 3, HD
PMDVR8, PDVR8
115 135 0464 8043 0463 720 0463 0091
To program your universal Insignia remote control to work with other devices
in the home, see your User Guide or visit www.insigniaproducts.com.
Connecting a Home
Connecting a DVD or Blu-ray
Theater System
DVD player, cable box, satellite
receiver, or game console Using digital audio
Using HDMI (best)
Turning on your TV for the rst time
To set up your TV:
1 Make sure that you have:
• Installed the remote control batteries.
• Connected an antenna, cable TV, or satellite TV.
• Connected the power cord.
2 Press
(power) on the remote control to turn on your TV. The Choose Your
Menu language screen opens.
3 Press ▲ or ▼ to highlight the language you want, then press ENTER. The
Choose your Time Setting screen opens.
4 Press ▲ or ▼ to highlight Mode, then press ◄ or ► to select Manual (to set
the date and time manually) or Auto (to set the date and time automatically
from a TV signal source based on the time zone your select).
5 Press ▲ or ▼ to highlight an option, then press ◄ or ► to adjust the option.
You can select:
Mode—Select Auto or Manual. If you select Auto, the date and time are set
based on a time signal received from a digital TV channel. If you select Manual,
you can adjust the date and time.
Time Zone—Select the time zone.
Daylight Savings—Select On or O .
Year—Select the current year.
Month—Select the current month.
Day—Select the current day.
Time—When Time is highlighted, press ◄ or ► to move the cursor from eld to
eld, then press ▲ or ▼ to change the value in the eld.
6 Press ENTER. The Choose Your Picture Mode screen opens.
7 Press▲ or ▼ to highlight Home Mode or Retail Mode, then press ENTER. If
you selected Retail Mode, a message appears "If you select Retail Mode, then
DirectTV
RC23
Energy Savings is not realized. " If you select No, press ENTER.
10463
Connecting to a wired router
Connect an Ethernet cable (CAT5
or better with an RJ45 connector) to the ETHERNET jack on theback of your
TV/Blu-ray combo and to an Ethernet jack on a router.
Note: When plugging or unplugging the
cable, hold the connector on the end of
HDMI3
INPUT
the cable. When unplugging, do not pull
on the cable. Press down the lock tab and
pull the connector out of the jack.
Connecting power
Plug the power cord into the AC INPUT jack on the back
of your TV/Blu-ray combo and into a power outlet.
The Choose Your Picture Mode screen reopens. Go back to step 6. If you select Yes,
press ENTER. The Choose Your TV Source screen opens.
8 Press▲ or ▼ to highlight Antenna, Cable, or Cable/Satellite Box (if your cable
TV uses a box, select Cable/Satellite Box), then press ENTER. If you chose
Antenna or Cable, your TV/Blu-ray combo automatically starts scanning for
channels available in your viewing area. If you chose Cable/Satellite box, your
TV/Blu-ray combo does not need to scan for channels. During auto channel
search, your TV/Blu-ray combo searches for digital channels rst. When the
digital channel search is complete, a message appears asking if you want to
search for analog channels. Select Yes to continue searching for analog
channels, or select No to stop searching for channels.
9 To watch TV, press INPUT, then press INPUT repeatedly or press ▲
to highlight TV in the input source list, then press ENTER.
Selecting the video input source
• Press INPUT, then press INPUT repeatedly or press ▲ or ▼ to
highlight the video source, then press ENTER. SEARCH
CLEAR
REPEAT
or ▼
