WASHING MACHINE
Please read this manual before using and note
how to use in the proper manner.
Please be careful of keeping tile manual.
Otherwise, it should be bought separately.
The User's Manual is for common use.
Make use of the User's Manual depending upon your washing machine model.
SPECIFICATIONS
1
2
3
4
5
5
5
5
5
5
5
5
6
7
7
7
7
8
8
8
8
9
9
10
Advertisement
Table of Contents
Related Manuals for Samsung WA71
Summary of Contents for Samsung WA71
-
Page 1: Table Of Contents
WASHING MACHINE FEATURES SAFETY INSTRUCTIONS DESCRIPTION OF PARTS CONTROL PANEL WASHING PROCEDURE Fuzzy course Baby course Speedy course Blanket course Wool course Soak function Delay start course MANUAL FUNCTIONS INSTALLATION & MAINTENANCE Environment Levelling Connecting the water supply hose Assembling the rat protection panel How to put the detergent in Water supply connector filter Cleaning the filter net... -
Page 2: Features
FEATURES FUZZY CONTROL Fuzzy control operates with best washing course by sensing the washload like artificial intelligence. SOAK COURSE The detergent can be dissolved and contact the laundry completely, in this course, the dirt can be wiped off. SPEEDY COURSE Because washing is speedy, it is good for light or less stained laundry. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS WARNING CAUTIONS There might be serious injury or fatal accident when There might be a slight injury or damage when you violate this instruction. you violate this instruction. If the power supply cord or plug is damaged or Don't install it in the area with moisture or outdoor loosened, do not use. -
Page 4: Description Of Parts
DESCRIPTION OF PARTS DESCRIPTION OF PARTS Tile User's Manual is for common use. Make use of the User's Manual depending upon your washing machine model. -
Page 5: Control Panel
CONTROL PANEL For more details, see control panel of your washing machine. POWER BUTTON Press this button once to operate. Press once again to turn the power off. START/HOLD BUTTON Use to pause and restart the operation. To change the washing procedure during operation, press this button to stop, and once again to restart after changing the procedure. -
Page 6: Washing Procedure
WASHING PROCEDURE WASHING PROCEDURE Before starting washing, check the following; Put the laundry into the washer and add detergent, too. Be careful not to overload. Use right detergent Connect the water supply hose to the water tap. Leave a tap for the fabrics you are washing. -
Page 7: Manual Functions
MANUAL FUNCTIONS Each washing course changes manually. Ex) If you want to wash in the speedy course: Power - Select speedy course - Wash - Start/Hold button SOAK AND WASH AND RINSE AND SPIN Press the POWER button. Press the FUNCTION SELECT button once. Press the START/HOLD button once. -
Page 8: Installation & Maintenance
INSTALLATION & MAINTENANCE INSTALLATION & MAINTENANCE The User's Manual is for common use. Make use of the Uer's Manual depending upon your washing machine model. ENVIRONMENT Never install the washer near water. Do not place the washer in steamy rooms or where the Leave some space washer is directly exposed to rain. -
Page 9: Assembling The Rat Protection Panel
ASSEMBLING THE RAT PROTECTION PANEL Tilt the washer a little and lift up the panel until it clicks, 1.Insert the sound finally fix the panel with screw to the base as shown absorbing panel in the figure. to the assembling hole on back side to the end. -
Page 10: Connecting The Drain Hose
CONNECTING THE DRAIN HOSE The drain hose is normally connected on the right side of the machine. Consumers can refit it on the bit if necessary. NOTICE: Before refit, the power supply must be cut of (For the danger of getting an electric shock) 2. -
Page 11: Troubleshooting
TROUBLESHOOTING Washing machine won't work Water dose not drain Is the water tap opened? Is the drain hose down?(No pump) Is the washer plugged in? Is the drain hose frozen? Is the power cut off? Is the drain hose clogged? Is there enough water? If the water dose not drain in 15 Is the fuse broken? - Page 12 330W W530 D535 H880 MAXIMUM MUSS OF DRY CLOTH WA71: 5.0 kg / WA71S: 5.2 kg WA71: 30 kg / WA71S: 31 kg HIGH 50 l 43 l 35 l EXTRA LOW 28 l 150 l 0.05~0.78 MPa (0.5 ~ 8.0 kg f/cm ) Stirring Type CODE NO.: DC68-01950A...
