Owner's Manual
Video Cassette Recorder
SV-C15P
Video Cassette Player
SV-C15P

Advertisement

Table of Contents
loading

Related Manuals for Samsung SV-C15P

Summary of Contents for Samsung SV-C15P

  • Page 1 Owner’s Manual Video Cassette Recorder SV-C15P Video Cassette Player SV-C15P...

  • Page 2: Safety Instructions

    Safety Instructions This symbol indicates high voltage is present inside. It is dangerous to RISK OF ELECTRIC SHOCK make any kind of contact with any inside part of this product. DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, This symbol alerts you that important literature concerning operation DO NOT REMOVE COVER (OR BACK).
  • Page 3 Safety Instructions 9. Cart Usage-A product and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn. 10. Ventilation-Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from overheating.

  • Page 4: Table Of Contents

    Table of Contents Safety Instructions VCR Operation Your New VCR Playing a cassette ....5 Tracking ......5 Accessories .

  • Page 5: Your New Vcr

    Your New VCR Accessories Check to make sure the following items have been included with your VCR. Owner’s Manual ELECTRONICS Warranty Owner’s Manual Remote RF-Cable Batteries for Card Control remote(2AA) Front Panel and Display POWER Press to turn the VCR on and off. SV-C15P, SP-C15P EJECT Press to eject a tape or press.

  • Page 6: Vcr Remote Control

    Your New VCR VCR Remote Control TV/VCR Switch between TV or VCR source (See page 3). SLOW POWER Press to slow-motion playback during Press to turn your VCR on and off. playback. Press to start VCR recording. Press to adjust cassette tracking. DISPLAY Press for on-screen information displays.

  • Page 7: Vcr Setup

    VCR Setup Rear Panel Use the jacks on the rear panel to connect the VCR to other components and signals, including: VCRs, TVs, stereo equipment, digital video components, antenna and cable signals. IN FROM ANT AUDIO OUT Use to input cable Use to output audio signals or antenna signal.
  • Page 8 VCR Setup Premium Cable TV Connection 1 This set-up will enable you to: - Watch an unscrambled or scrambled channel while recording it. - Record any channels through the cable box. You will need to: • Set TV to channel 3 or 4 to receive video signals. •...

  • Page 9: Vcr Operation

    VCR operation Playing a cassette Load a recorded cassette. Power is automatically turned on. Press PLAY to start playback. When playback starts, the VCR automatically adjusts the tracking for clear pictures and sound. To stop playback, press STOP. Tracking For the best picture quality when playing a cassette, the video heads must be aligned with the recorded track. This alignment is called tracking.

  • Page 10: Tape Controls

    VCR Operation Tape Controls Play and Pause/Still • Press the PLAY button on t has oe remote control or on the front of the VCR to play a video. (If Auto play is selected and the video tape has no safety tab, it will begin playing automatically when you insert it in the VCR.) •...

  • Page 11: Recording

    VCR Operation Recording Recording while you watch Insert a video cassette with the record protect safety tab intact. Check the tape speed. Select a channel to record by pressing CH Press the REC button on the remote control. The REC indicator will light. If you want to edit out unwanted material during recording, you can press the P/STILL button while recording and the VCR will pause.

  • Page 12: Care And Maintenance

    Care and Maintenance • Unplug your VCR from the wall outlet before cleaning. • Use a dry cloth when dusting your VCR. • Proper ventilation ensures that overheating will not damage electronic circuits. Don’t block ventilation holes. • Take care of your remote control. Keep the remote with your VCR, where it is unlikely to be lost or damaged. •...

  • Page 13: Troubleshooting

    Troubleshooting Before calling for service, check this list of possible problems and solutions to see if the problem can be solved with a simple adjustment. Problem Possible Solution No power • Make sure the VCR is on and plugged into an operating wall outlet. A cassette cannot be •...

  • Page 14: Specifications

    Specifications UHF/VHF: 75 Ω F type connector Antenna input/output terminals: Signal system: Standard NTSC Recording/Playback system: Recording: VHS format(SP, SLP) Playback: VHS format(SP, LP, SLP)* Video cassette with mark Record/Play Time: 6 hours with T-120 in SLP mode Power Source: 120V AC, 60Hz Power Output: VR8459(C), VR8409(C) App.
  • Page 15 SAMSUNG ELECTRONICS AMERICA, INC. HEADQUARTERS 105 Challenger Road, Ridgefield Park, N.J. 07660-0511 TEL: 1-800-SAMSUNG SERVICE DIVISION 1 Samsung Place Ledgewood, N.J. 07852 1-800-SAMSUNG (1-800-726-7864) SAMSUNG ELECTRONICS CANADA, INC. HEADQUARTERS 7037 Financial Drive, Mississauga, Ontario, Canada L5N 6R3 TEL: 1-905-542-3535 SERVICE DIVISION...
