- Page 1 MONTE(BN68-00625A-01)_UK 4/20/04 08:23 PM Page 1 WIRELESS LCD TV LW15B13C Owner’s Instructions Before operating the unit, please read this manual thoroughly, and retain it for future reference. WIRELESS LAN POWER SAVING TELETEXT...
- Page 2 MONTE(BN68-00625A-01)_UK 4/20/04 08:23 PM Page 2...
-
Page 3: Table Of Contents
MONTE(BN68-00625A-01)_UK 4/20/04 08:23 PM Page 3 Contents ONNECTING AND REPARING ELEVISION View of Your Television ................Notes on Base Station Installation..............How to Install the Base Station..............Adjusting the Client Angle ................Infrared Remote Control ................Inserting the Batteries in the Remote Control..........Connecting to an Aerial or Cable Television Network ........ - Page 4 MONTE(BN68-00625A-01)_UK 4/20/04 08:23 PM Page 4 Contents (continued) SING ELEVISION (continued) Selecting the Power Saving................Displaying Information ................... Setting the Wireless LAN................SING THE ELETEXT EATURE Teletext Feature .................... Displaying the Teletext Information ............... Selecting a Page by Number................. Using FLOF to Select a Page................ Storing Teletext Pages ..................
-
Page 5: View Of Your Television
MONTE(BN68-00625A-01)_UK 4/20/04 08:23 PM Page 5 View of Your Television Control Panels Using the Buttons on the Panel 1) Power On/Off 5) Input Source Selection 2) Channel Selection 6) Remote Control Sensor 3) Volume Adjustment 7) Standby Indicator 4) Menu Display 8) Wireless Signal Indicator ➢... - Page 6 MONTE(BN68-00625A-01)_UK 4/20/04 08:23 PM Page 6 View of Your Television (continued) Connection Panels Side of the Client Rear of the Base Station DC Input Headphone connector 75Ω Coaxial Connector for Aerial/Cable/Satellte Network Rear of the Client SCART Audio/ Video Input/Output S-Video Input IR RELAY Audio/Video Input...
-
Page 7: Notes On Base Station Installation
MONTE(BN68-00625A-01)_UK 4/20/04 08:23 PM Page 7 Notes on Base Station Installation N The wireless signal is transmitted/received from the front and back of the Base Station using an internal antenna. N Depending on the installation location of the Base Station and the Client, the Video signal may be unstable if the communication conditions are unstable. -
Page 8: How To Install The Base Station
MONTE(BN68-00625A-01)_UK 4/20/04 08:23 PM Page 8 How to Install the Base Station N The Base Station can be installed vertically or horizontally to best fit the installation location. Attach or detach the Stand to/from the Base Station using the screws on the bottom of the Base Station. -
Page 9: Infrared Remote Control
MONTE(BN68-00625A-01)_UK 4/20/04 08:23 PM Page 9 Infrared Remote Control TELEVISION STAND-BY DIRECT CHANNEL SELECTION SWITCH REPEATEDLY ONE/TWO-DIGIT CHANNEL BETWEEN THE LAST TWO SELECTION/TELETEXT PAGE HOLD CHANNELS DISPLAYED NEXT CHANNEL/ VOLUME INCREASE TELETEXT NEXT PAGE EXTERNAL INPUT SELECTION/ TEMPORARY SOUND SWITCH-OFF TELETEXT MODE SELECTION (LIST/FLOF) PREVIOUS CHANNEL/... -
Page 10: Inserting The Batteries In The Remote Control
MONTE(BN68-00625A-01)_UK 4/20/04 08:23 PM Page 10 Inserting the Batteries in the Remote Control You must insert or replace the batteries in the remote control when you: N Purchase the LCD TV N Find that the remote control is no longer operating correctly Remove the cover on the rear of the remote control by pressing the symbol ( ) downwards and then pulling firmly to remove it. -
Page 11: Switching Your Television On And Off
MONTE(BN68-00625A-01)_UK 4/20/04 08:23 PM Page 11 Switching Your Television On and Off The mains lead is attached to the rear of your Base Station. Plug the mains lead into an appropriate socket. ➢ The main voltage is indicated on the rear of the Client/ Base Station and the frequency is 50 or 60Hz. -
Page 12: Placing Your Television In Standby Mode
MONTE(BN68-00625A-01)_UK 4/20/04 08:23 PM Page 12 Placing Your Television in Standby Mode Your television can be placed in Standby mode, in order to reduce: N Power consumption The Standby mode can be useful when you wish to interrupt viewing temporarily (during a meal, for example). Press the POWER ( ) button on the remote control. -
Page 13: Becoming Familiar With The Remote Control
MONTE(BN68-00625A-01)_UK 4/20/04 08:23 PM Page 13 Becoming Familiar with the Remote Control The remote control is used mainly to: N Change channels and adjust the volume N Set up the client using the on-screen menu system The following table presents the most frequently used buttons and their functions. -
Page 14: Plug & Play Feature
MONTE(BN68-00625A-01)_UK 4/20/04 08:23 PM Page 14 Plug & Play Feature When the television is initially powered on, three basic customer settings proceed automatically and subsequently: setting the language, channel and clock. Plug & Play If the client is in Standby mode, press the POWER( ) button on Language the remote control. -
Page 15: Choosing Your Language
MONTE(BN68-00625A-01)_UK 4/20/04 08:23 PM Page 15 Choosing Your Language When you start using your television for the first time, you must select the language which will be used for displaying menus and indications. Press the MENU ( ) button. Result: The main menu is displayed. -
Page 16: Storing Channels Automatically
MONTE(BN68-00625A-01)_UK 4/20/04 08:23 PM Page 16 Storing Channels Automatically You can scan for the frequency ranges available to you (and availability depends on your country). Automatically allocated Channel programme numbers may not correspond to actual or desired √ √ … …... -
Page 17: Sorting The Stored Channels
MONTE(BN68-00625A-01)_UK 4/20/04 08:23 PM Page 17 Sorting the Stored Channels This operation allows you to change the programme numbers of stored channels. This operation may be necessary after using auto Channel store. You can delete the channels you do not want to keep. √... -
Page 18: Storing Channels Manually
MONTE(BN68-00625A-01)_UK 4/20/04 08:23 PM Page 18 Storing Channels Manually You can store up to 100 television channels, including those received via cable networks. Channel √ √ Country When storing channels manually, you can choose: √ √ Auto Store √ √ N Whether or not to store each of the channels found Manual Store √... - Page 19 MONTE(BN68-00625A-01)_UK 4/20/04 08:23 PM Page 19 Storing Channels Manually (continued) Manual Store If you know the number of the channel to be stored, see the Programme : P17 ----- following steps. √ √ Colour System : AUTO √ √ Sound System : BG N Press the M or L button to select Channel.
-
Page 20: Skipping Unwanted Channels
MONTE(BN68-00625A-01)_UK 4/20/04 08:23 PM Page 20 Skipping Unwanted Channels You can exclude the channels you chosen from the channels you scanned. When you scan through the stored channels, those you Channel have chosen to skip are not displayed. √ √ Country √... -
Page 21: Assigning Names To Channels
MONTE(BN68-00625A-01)_UK 4/20/04 08:26 PM Page 21 Assigning Names to Channels Channel names will be assigned automatically when channel information is broadcast. These names can be changed, allowing Channel you to assign new names. √ √ Country √ √ Auto Store √... -
Page 22: Fine Tuning Channel Reception
MONTE(BN68-00625A-01)_UK 4/20/04 08:26 PM Page 22 Fine Tuning Channel Reception If the reception is clear, you do not have to fine tune the channel, as this is done automatically during the search and store operation. Channel If the signal is weak or distorted, you may have to fine tune the √... -
Page 23: Changing The Picture Standard
MONTE(BN68-00625A-01)_UK 4/20/04 08:26 PM Page 23 Changing the Picture Standard You can select the type of picture which best corresponds to your viewing requirements. Picture √ √ Dynamic Mode : Auto √ √ Standard Custom Press the MENU ( ) button. √... -
Page 24: Adjusting The Picture Settings
MONTE(BN68-00625A-01)_UK 4/20/04 08:27 PM Page 24 Adjusting the Picture Settings Your television has several settings which allow you to control picture quality. Picture √ √ Mode : Auto √ √ Custom Press the MENU ( ) button. √ √ Colour Tone : Normal √... -
Page 25: Selecting The Picture Size
MONTE(BN68-00625A-01)_UK 4/20/04 08:27 PM Page 25 Selecting the Picture Size You can select the picture size which best corresponds to your viewing requirements. Picture √ √ Mode : Auto √ √ Custom Press the MENU ( ) button. √ √ Colour Tone : Normal √... -
Page 26: Freezing The Current Picture
MONTE(BN68-00625A-01)_UK 4/20/04 08:27 PM Page 26 Freezing the Current Picture You can freeze the picture when watching a television programme simply by pressing the “STILL” button. ➢ To return to normal viewing, press this button again. Changing the Sound Standard You can select the type of special sound effect to be used when watching a given broadcast. -
Page 27: Selecting The Auto Volume
MONTE(BN68-00625A-01)_UK 4/20/04 08:27 PM Page 27 Selecting the Auto Volume Each broadcasting station has its own signal conditions, and so it is not easy for you to adjust the volume every time the channel is Sound changed. This feature lets you automatically adjust the volume of √... -
Page 28: Selecting The Sound Mode
MONTE(BN68-00625A-01)_UK 4/20/04 08:27 PM Page 28 Selecting the Sound Mode The “DUAL I-II” button displays/controls the processing and output of the audio signal. When power is switched on, the mode is automatically preset to either “Dual-I ” or “Stereo”, depending on the current transmission. -
Page 29: Setting And Displaying The Current Time
MONTE(BN68-00625A-01)_UK 4/20/04 08:27 PM Page 29 Setting and Displaying the Current Time You can set the television’s clock so that the current time is displayed by pressing the “INFO ( )” button. You must also set Setup the time if you wish to use the automatic on or off timers. √... -
Page 30: Setting The Sleep Timer
MONTE(BN68-00625A-01)_UK 4/20/04 08:27 PM Page 30 Setting the Sleep Timer You can select a time period of between 30 and 180 minutes after the Wireless LCD TV automatically switches to Standby mode. Setup √ √ Time √ √ Plug & Play Press the MENU ( ) button. -
Page 31: Switching The Television On And Off Automatically
MONTE(BN68-00625A-01)_UK 4/20/04 08:27 PM Page 31 Switching the Television On and Off Automatically You can set the On/Off timers so that the television will: N Switch on automatically and tune to the channel of your Setup choice at the time you select √... -
Page 32: Selecting The Power Saving
MONTE(BN68-00625A-01)_UK 4/20/04 08:27 PM Page 32 Selecting the Power Saving The Power Saving mode reduces power consumption during use. While in Power Saving mode, the screen is slightly darker. Setup If Power Saving has been turned On, the setting will remain until the √... -
Page 33: Setting The Wireless Lan
MONTE(BN68-00625A-01)_UK 4/20/04 08:27 PM Page 33 Setting the Wireless LAN Adjust the Bit Rate for Signal Types and the Distance from the Base Station to the Client settings. If the video or the audio signal is Setup intermittent or you experience interference, choose another channel. √... -
Page 34: Teletext Feature
MONTE(BN68-00625A-01)_UK 4/20/04 08:27 PM Page 34 Teletext Feature Most television channels provide written information services via teletext. Information provided includes: N Television programme times N News bulletins and weather forecasts N Sports results N Travel information This information is divided into numbered pages (see diagram). Part Contents Selected page number. -
Page 35: Selecting A Page By Number
MONTE(BN68-00625A-01)_UK 4/20/04 08:27 PM Page 35 Selecting a Page by Number You can enter the page number directly by pressing the numeric buttons on the remote control. Enter the three-digit page number given in the content by pressing the corresponding numeric buttons. Result: The current page counter is incremented and the page is then displayed. -
Page 36: Using Flof To Select A Page
MONTE(BN68-00625A-01)_UK 4/20/04 08:27 PM Page 36 Using FLOF to Select a Page The various topics included in the teletext pages are color-coded, and can be selected by pressing the colored buttons on the remote control. Display the teletext contents page by pressing the TTX/MIX ) button. -
Page 37: Viewing An External Signal Source
MONTE(BN68-00625A-01)_UK 4/20/04 08:27 PM Page 37 Viewing an External Signal Source Use the remote control to switch between viewing signal from connected equipment, such as VCR, DVD, Set-Top-boxs and the TV Input source (broadcast or cable). √ √ Source List : TV √... -
Page 38: Connecting To The External Input/Outputs
MONTE(BN68-00625A-01)_UK 4/20/04 08:27 PM Page 38 Connecting to the External Input/Outputs ➢ “ ” is used for the equipment with an RGB output, such as video game devices or video disc players. Rear of the Base Station Decoder / Video game device Video disc player This end can be fitted with: N A SCART connector... -
Page 39: Connecting To The Rca Input
MONTE(BN68-00625A-01)_UK 4/20/04 08:27 PM Page 39 Connecting to the RCA Input ➢ The RCA (VIDEO and AUDIO-L+R) connectors are used for equipment, Camcorder such as camcorders, video disc players, and some video game devices. Rear of the Client/ Base Station Video game device Video disc player Connecting to the S-Video Input... -
Page 40: Connecting Headphones
Connecting to the IR Relay ➢ You may control your DVD, VCR and other electronic devices through the IR Relay Controller. (Works only with Samsung products) Rear of the Base Station IR Receiver Setup the IR Relay Controller so that its IR transmitter is placed right on top of the IR receiver on the VCR, DVD or other device. -
Page 41: Connecting The Power Adapter And Recharging The Battery Pack
MONTE(BN68-00625A-01)_UK 4/20/04 08:27 PM Page 41 Connecting the Power Adapter and Recharging the Battery Pack The Battery Pack is recharged using the adapter. Properly mount the Battery Pack before recharging. When the Power Adapter is connected, the Battery Pack is not required for playback. Battery Pack Rear of the Client Plug the AC power cord into a wall outlet. -
Page 42: Using The Battery Pack
MONTE(BN68-00625A-01)_UK 4/20/04 08:27 PM Page 42 Using the Battery Pack N Fully discharge the Battery Pack before recharging to prolong the lifetime of the Battery Pack. N The Battery Pack might be hot during use or recharging. This is normal, not a defect of the Battery Pack. -
Page 43: Scart Connector Wiring (Ext1, Ext2 Or Ext3)
MONTE(BN68-00625A-01)_UK 4/20/04 08:27 PM Page 43 SCART Connector Wiring (EXT1, EXT2 or EXT3) If you wish to connect other equipment via the SCART connectors on your television, contact your dealer or a qualified technician to wire the A/V cable as illustrated below. Signal Signal Audio output R... -
Page 44: Troubleshooting: Before Contacting Service Personnel
Page 44 Troubleshooting: Before Contacting Service Personnel Before contacting Samsung after-sales service, perform the following simple checks. If you cannot solve the problem using the instructions below, note the model and serial number of the television and contact your local dealer. -
Page 45: Technical And Environmental Specifications
MONTE(BN68-00625A-01)_UK 4/20/04 08:27 PM Page 45 Technical and Environmental Specifications Model LW15B13C Panel Size 15” Diagonal Display Size 304.1(H) x 228.1(V) mm Type a-si TFT active matrix Pixel Pitch 0.297 (H) x 0.297 (V) mm Viewing Angle 140/115 (H/V) Power Supply Input AC 100 ~ 250V, (50Hz / 60Hz) Output... - Page 46 MONTE(BN68-00625A-01)_UK 4/20/04 08:27 PM Page 46 Memo English-46...
- Page 47 MONTE(BN68-00625A-01)_UK 4/20/04 08:27 PM Page 47 Memo English-47...
- Page 48 MONTE(BN68-00625A-01)_UK 4/20/04 08:27 PM Page 48 - AFTER SALES SERVICE - Do not hesitate to contact your retailer or service agent if a change in the performance of your product indicates that a faulty condition may be present. ELECTRONICS BN68-00625A-01...
