Samsung LE17D11B Owner's Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
01-BN68-00664B-00Eng
5/12/04
4:56 PM
Page 1
LCD TV
LE17D11B
Owner's Instructions
Before operating the unit,
please read this manual thoroughly,
and retain it for future reference.
ON-SCREEN MENUS
PC DISPLAY
PICTURE IN PICTURE (PIP)
DVD/VCD/CD/MP3 PLAYER
TELETEXT

Advertisement

Table of Contents
loading

Related Manuals for Samsung LE17D11B

Summary of Contents for Samsung LE17D11B

  • Page 1 01-BN68-00664B-00Eng 5/12/04 4:56 PM Page 1 LCD TV LE17D11B Owner’s Instructions Before operating the unit, please read this manual thoroughly, and retain it for future reference. ON-SCREEN MENUS PC DISPLAY PICTURE IN PICTURE (PIP) DVD/VCD/CD/MP3 PLAYER TELETEXT...

  • Page 2: Table Of Contents

    01-BN68-00664B-00Eng 5/12/04 4:56 PM Page 2 Contents ◆ C ONNECTING AND REPARING ■ Viewing the Control Panel ................■ Viewing the Connection Panel ..............- Connecting an Aerial or Cable Television Network (depending on the model)..- Connecting a Set-Top Box, VCR, or DVD ..........- Connecting a Computer ................
  • Page 3 01-BN68-00664B-00Eng 5/12/04 4:56 PM Page 3 Contents ◆ U SING THE ARIOUS UNCTIONS ■ Setting the Blue Screen Mode ..............■ Displaying Information................... ◆ U PC F SING THE UNCTIONS ■ Setting Up Your PC Software (Based on Windows 2000) ......■...

  • Page 4: Viewing The Control Panel

    01-BN68-00664B-00Eng 5/12/04 4:56 PM Page 4 Viewing the Control Panel Œ DISC TRAY ” SOURCE Load the disc here. Press the display all of the available input sources. TV - Ext. - AV - S-Video - DVD - PC ´ OPEN/CLOSE (DVD) ’...

  • Page 5: Viewing The Connection Panel

    01-BN68-00664B-00Eng 5/12/04 4:56 PM Page 5 Viewing the Connection Panel POWER IN Option ☛ Whenever you connect an audio or video system to your set, ensure that all elements are switched off. Refer to the documentation supplied with your equipment for detailed connection instructions and associated safety precautions.

  • Page 6: Connecting An Aerial Or Cable Television Network (Depending On The Model)

    01-BN68-00664B-00Eng 5/12/04 4:56 PM Page 6 Viewing the Connection Panel ΠΠConnecting an Aerial or Cable Television Network (depending on the model) To view television channels correctly, a signal must be received by the set from one of the following sources: - An outdoor aerial - A cable television network...

  • Page 7: Connecting Headphones

    01-BN68-00664B-00Eng 5/12/04 4:56 PM Page 7 Viewing the Connection Panel ¨ ¨ Connecting Headphones - Plug a set of headphones into the 3.5mm mini-jack socket on the Left of the set. ˆ ˆ Connecting External A/V Devices - Connect RCA or S-VIDEO cables to an appropriate external A/V device such as a VCR, DVD, or Camcorder.

  • Page 8: Viewing Pictures From External Sources

    01-BN68-00664B-00Eng 5/12/04 4:56 PM Page 8 Viewing Pictures From External Sources Once you have connected up your various audio and video systems, you can view the different sources by selecting the appropriate input. Check that all the necessary connections have been made (refer to pages 8 and 9 for further details).

  • Page 9: Viewing The Remote Control (Television Functions)

    01-BN68-00664B-00Eng 5/12/04 4:56 PM Page 9 Viewing the Remote Control (Television Functions) SWITCH BETWEEN THE POWER TV/DVD MODE DIRECT CHANNEL SELECTION SWITCH REPEATEDLY ONE/TWO-DIGIT CHANNEL BETWEEN THE LAST TWO SELECTION CHANNELS DISPLAYED SOUND MODE SELECTION EXTERNAL INPUT SELECTION TEMPORARY SOUND SWITCH- CHANNEL SELECTION VOLUME ADJUSTMENT PIP CHANNEL SELECTION...

  • Page 10: Viewing The Remote Control (Dvd Functions)

    01-BN68-00664B-00Eng 5/12/04 4:56 PM Page 10 Viewing the Remote Control (DVD Functions) SEARCH BACKWARD SEARCH FORWARD PLAY/PAUSE STOP BACK SKIP THE TITLE, CHAPTER, NEXT SKIP THE TITLE, OR TRACK CHAPTER, OR TRACK DVD INFORMATION DISPLAY DVD MENU DISPLAY EXIT THE DVD MENU OSD OPEN/CLOSE THE DISC TRAY ADVANCES PLAY ON FRAME AT TO CANCEL OR CLEAR EACH...

  • Page 11: Viewing The Remote Control (Teletext Functions)

    01-BN68-00664B-00Eng 5/12/04 4:56 PM Page 11 Viewing the Remote Control (Teletext Functions) TELETEXT DISPLAY/MIX BOTH TELETEXT INFORMATION AND THE NORMAL BROADCAST : TELETEXT NEXT PAGE : TELETEXT PREVIOUS PAGE TELETEXT INDEX TELETEXT REVEAL EXIT FROM THE TELETEXT FASTEXT TOPIC SELECTION TELETEXT MODE SELECTION TELETEXT SUB-PAGE (LIST/FLOF)

  • Page 12: Switching On And Off

    01-BN68-00664B-00Eng 5/12/04 4:56 PM Page 12 Switching On and Off The mains lead is attached to the rear of your set. Plug the mains lead into an appropriate socket. Result: The power indicator on the front of the LCD TV lights up. Press the POWER button to switch on.

  • Page 13: Becoming Familiar With The Remote Control

    01-BN68-00664B-00Eng 5/12/04 4:56 PM Page 13 Becoming Familiar with the Remote Control The remote control is used mainly to: ◆ Change channels and adjust the volume ◆ Set up your set using the on-screen menu system The following table presents the most frequently used buttons and their functions.

  • Page 14: Plug & Play

    02-BN68-00664B-00Eng 5/12/04 4:57 PM Page 14 Plug & Play When the set is initially powered ON, you are automatically presented with a series of basic customer settings. The following settings are available. If the set is in standby mode, press the POWER button on the remote control.
  • Page 15 02-BN68-00664B-00Eng 5/12/04 4:57 PM Page 15 Plug & Play If you want to reset this feature... Setup Press the MENU button. √ Time √ Plug & Play Result: The main menu is displayed. √ Language : English Blue Screen : On √...

  • Page 16: Selecting Tv Mode Or An Input Source

    02-BN68-00664B-00Eng 5/12/04 4:57 PM Page 16 Selecting TV Mode or an Input Source You can choose TV mode or change to an input source connected to Input the TV set. Use this button to choose an input source that you would √...

  • Page 17: Editing An Input Source Name

    02-BN68-00664B-00Eng 5/12/04 4:57 PM Page 17 Editing an Input Source Name Entering the names of the input source devices connected to the input Input ports on the TV set allows you to find and choose an input source that √ Source List : TV √...

  • Page 18: Choosing Your Language

    02-BN68-00664B-00Eng 5/12/04 4:57 PM Page 18 Choosing Your Language When you start using your set for the first time, you must select the language which will be used for displaying menus and indicators. Press the MENU button. Result: The main menu is displayed. Press the …...

  • Page 19: Storing Channels Automatically

    02-BN68-00664B-00Eng 5/12/04 4:57 PM Page 19 Storing Channels Automatically You can scan for the frequency ranges available to you (and availability Channel depends on your country). Automatically allocated programme numbers √ Country : UK √ Auto Store may not correspond to actual or desired programme numbers. √...

  • Page 20: Storing Channels Manually

    02-BN68-00664B-00Eng 5/12/04 4:57 PM Page 20 Storing Channels Manually You can store up to 100 channels, including those received via Channel cable networks. √ Country : UK √ Auto Store When storing channels manually, you can choose: √ Manual Store ◆...
  • Page 21 02-BN68-00664B-00Eng 5/12/04 4:57 PM Page 21 Storing Channels Manually Manual Store If you know the channel number to be stored, Prog. No : P 1 ---- Colour System : AUTO ◆ Press the … or † button to select the Channel. Sound System : BG Channel...

  • Page 22: Editing The Channels

    02-BN68-00664B-00Eng 5/12/04 4:57 PM Page 22 Editing the Channels You can exclude any channels of your choice from the channels you Channel have scanned. When you scan through the stored channels, those you √ Country : UK √ Auto Store have chosen to skip are not displayed.

  • Page 23: Sorting The Stored Channels

    02-BN68-00664B-00Eng 5/12/04 4:57 PM Page 23 Sorting the Stored Channels You can exchange the numbers of two channels, in order to: Channel √ Country : UK √ Auto Store ◆ Modify the numeric order in which the channels have been √...

  • Page 24: Giving Channels Names

    02-BN68-00664B-00Eng 5/12/04 4:57 PM Page 24 Giving Channels Names If channel name information is broadcast when you store the channels Channel either manually or automatically, the names are assigned to the √ Country : UK √ Auto Store channels directly. You can however change these names or assign √...

  • Page 25: Fine Tuning Channel Reception

    02-BN68-00664B-00Eng 5/12/04 4:57 PM Page 25 Fine Tuning Channel Reception If the reception is clear, you do not have to fine-tune the channel, Channel as this is done automatically during the search and store operation. √ Country : UK √ Auto Store If however the signal is weak or distorted, you may have to fine-tune √...

  • Page 26: Picture

    02-BN68-00664B-00Eng 5/12/04 4:57 PM Page 26 Changing the Picture Standard You can select the type of picture which best corresponds to your Picture viewing requirements. √ Mode : Dynamic √ Custom √ Colour Tone : Normal √ Size : Wide Press the MENU button.

  • Page 27: Adjusting The Custom Picture

    02-BN68-00664B-00Eng 5/12/04 4:57 PM Page 27 Adjusting the Custom Picture Your set has several settings which allow you to control picture quality. Picture √ Mode : Dynamic √ Custom √ Colour Tone : Normal √ Press the MENU button. Size : Wide √...

  • Page 28: Adjusting The Screen Background Colour

    02-BN68-00664B-00Eng 5/12/04 4:57 PM Page 28 Adjusting the Screen Background Colour You can change the screen background colour according to your Picture preference. √ Mode : Dynamic √ Custom √ Colour Tone : Normal √ Size : Wide Press the MENU button. √...

  • Page 29: Selecting The Picture Format

    02-BN68-00664B-00Eng 5/12/04 4:57 PM Page 29 Selecting the Picture Format You can select the picture format which best corresponds to Picture your viewing requirements. √ Mode : Dynamic √ Custom √ Colour Tone : Normal √ Press the MENU button. Size : Wide √...

  • Page 30: Viewing The Picture In Picture (Pip)

    03-BN68-00664B-00Eng 5/12/04 4:57 PM Page 30 Viewing the Picture In Picture (PIP) You can display a sub picture within the main picture of a set Picture programme or video input. In this way you can watch or monitor the set √...
  • Page 31 03-BN68-00664B-00Eng 5/12/04 4:57 PM Page 31 Viewing the Picture In Picture (PIP) : On Source : TV Swap Size Position Prog. No Press the … or † button to select the Position. Press the ENTER button. Select the position of the sub picture by Move Enter Return...

  • Page 32: Sound

    03-BN68-00664B-00Eng 5/12/04 4:57 PM Page 32 Changing the Sound Standard You can select the type of special sound effect to be used when Sound watching a given broadcast. √ Mode : Standard √ Equalizer √ : Off √ Auto Volume : Off Press the MENU button.

  • Page 33: Adjusting The Custom Sound

    03-BN68-00664B-00Eng 5/12/04 4:57 PM Page 33 Adjusting the Custom Sound The sound settings can be adjusted to suit your personal preferences. Sound √ Mode : Standard √ Equalizer Press the MENU button. √ : Off √ Auto Volume : Off Result: The main menu is displayed.

  • Page 34: Selecting Wow Surround

    03-BN68-00664B-00Eng 5/12/04 4:57 PM Page 34 Selecting WOW Surround Select the Wow Surround feature to amplify the mid- to low-range Sound sounds or create a surround sound effect. √ Mode : Standard √ Equalizer √ : Off √ Auto Volume : Off Press the MENU button.

  • Page 35: Selecting Auto Volume Control

    03-BN68-00664B-00Eng 5/12/04 4:57 PM Page 35 Selecting Auto Volume Control Reduces the differences in volume level between broadcasters. Sound √ Mode : Standard √ Equalizer √ : Off Press the MENU button. √ Auto Volume : Off √ Headphone Result: The main menu is displayed.

  • Page 36: Adjusting Your Headphone Preferences

    03-BN68-00664B-00Eng 5/12/04 4:57 PM Page 36 Adjusting Your Headphone Preferences You can adjust the headphone settings to suit your preferences. Sound The following headphones settings are available: √ Mode : Standard √ Equalizer √ : Off ◆ Volume, Balance, Bass, Treble. √...

  • Page 37: Selecting A Sound Mode For The Sub-Screen

    03-BN68-00664B-00Eng 5/12/04 4:57 PM Page 37 Selecting a Sound Mode for the Sub-Screen Sound √ Mode : Standard √ Equalizer √ : Off √ Press the MENU button. Auto Volume : Off √ Headphone √ Sound Select : Main Result: The main menu is displayed.

  • Page 38: Time

    03-BN68-00664B-00Eng 5/12/04 4:57 PM Page 38 Setting the Clock Setup √ Time √ Plug & Play √ Language : English √ Blue Screen : Off Press the MENU button. √ PC Setup √ Result: The main menu is displayed. Press the … or † button to select Setup. Move Enter Return...

  • Page 39: Switching Off Automatically

    03-BN68-00664B-00Eng 5/12/04 4:57 PM Page 39 Switching Off Automatically You can select a time period of between -- and 180 minutes after which Setup your set automatically switches off. √ Time √ Plug & Play √ Language : English √ Press the MENU button.

  • Page 40: Switching The Television On And Off Automatically

    03-BN68-00664B-00Eng 5/12/04 4:58 PM Page 40 Switching the Television On and Off Automatically You can set the On/Off timers so that the set will: Setup √ Time ◆ √ Plug & Play Switch on automatically and tune to the channel of your choice √...

  • Page 41: Setting The Blue Screen Mode

    03-BN68-00664B-00Eng 5/12/04 4:58 PM Page 41 Setting the Blue Screen Mode If no signal is being received or the signal is very weak, a blue screen Setup automatically replaces the noisy picture background. √ Time √ Plug & Play If you wish to continue viewing the poor picture, you must set the √...

  • Page 42: Setting Up Your Pc Software (Based On Windows 2000)

    Windows and your particular video card. However, even if your actual screens look different, the same basic set-up information will apply in almost all cases. (If not, contact your computer manufacturer or Samsung Dealer.) First, click on “Settings” on the Windows start menu.

  • Page 43: Coarse And Fine Tuning Of The Image

    03-BN68-00664B-00Eng 5/12/04 4:58 PM Page 43 Coarse and Fine Tuning of the Image Setup Press the MENU button. √ Time √ Plug & Play Result: The main menu is displayed. √ Language : English √ Blue Screen : On √ PC Setup Press the …...

  • Page 44: Changing The Image Position

    03-BN68-00664B-00Eng 5/12/04 4:58 PM Page 44 Changing the Image Position Setup √ Time √ Plug & Play √ Language : English Press the MENU button. √ Blue Screen : On √ PC Setup Result: The main menu is displayed. √ Press the …...

  • Page 45: Initializing The Image Settings

    03-BN68-00664B-00Eng 5/12/04 4:58 PM Page 45 Initializing the Image Settings You can replace all image settings with the factory default values. Setup √ Time √ Plug & Play √ Language : English Press the MENU button. √ Blue Screen : On √...

  • Page 46: Adjusting The Pc Screen Automatically

    03-BN68-00664B-00Eng 5/12/04 4:58 PM Page 46 Adjusting the PC Screen Automatically Setup Press the MENU button. √ Time √ Plug & Play Result: The main menu is displayed. √ Language : English √ Blue Screen : On √ PC Setup Press the …...

  • Page 47: Playing A Disc

    03-BN68-00664B-00Eng 5/12/04 4:58 PM Page 47 Playing a Disc Play Press the button to switch the DVD mode. Press the OPEN/CLOSE ( ) button. Press the PLAY/PAUSE ( ) or OPEN/CLOSE ( ) button to close the disc tray. ☛ RESUME function When you stop disc play, the player remembers where you stopped, so when you press the PLAY/PAUSE (...
  • Page 48 04-BN68-00664B-00Eng 5/12/04 4:59 PM Page 48 Playing a Disc (MP3/WMA) MP3/JPG/MPG/WMA Press the OPEN/CLOSE ( ) button. Place a disc gently into the tray 00:00 00:00 001/007 with the disc’s label facing up. Press the PLAY/PAUSE ( ) or OPEN/CLOSE ( ) button to close the disc tray.
  • Page 49 04-BN68-00664B-00Eng 5/12/04 4:59 PM Page 49 Playing a Disc (MPG) MP3/JPG/MPG/WMA Press the OPEN/CLOSE ( ) button. Place a disc gently into the tray 00:00 00:00 001/007 with the disc’s label facing up. Press the PLAY/PAUSE ( ) or OPEN/CLOSE ( ) button to close the disc tray.

  • Page 50: Playing A Disc

    04-BN68-00664B-00Eng 5/12/04 4:59 PM Page 50 Playing a Disc (Picture CD) MP3/JPG/MPG/WMA Press the OPEN/CLOSE ( ) button. Place a disc gently into the tray with 00:00 00:00 003/007 the disc’s label facing up. Press the PLAY/PAUSE ( ) or OPEN/CLOSE \ picture folder1\ ) button to close the disc tray.

  • Page 51: Using The Search And Skip Functions

    04-BN68-00664B-00Eng 5/12/04 4:59 PM Page 51 Using the Search and Skip Functions Searching through a Chapter or Track Press the FF ( ) or REW ( ) button during play. - Press the FF ( ) or REW ( ) button for move than 1 second and press again or press continuously to search at a faster speed on the DVD (2X/4X/8X/16X/ 32X), VCD (2X/4X/8X/16X/ 32X), or CD (2X/4X/8X/16X/ 32X).

  • Page 52: Using The Disc Menu

    04-BN68-00664B-00Eng 5/12/04 4:59 PM Page 52 Using the Disc Menu Press the DVD MENU button during the play of a DVD. Result: The DVD menu is displayed with the Disc Menu is selected. Press the ENTER button. ➢ Depending on the disc, the Disc Menu may not work. Press ENTER key for DiscMenu Using the Title Menu...

  • Page 53: Displaying The Disc Information

    04-BN68-00664B-00Eng 5/12/04 4:59 PM Page 53 Displaying the Disc Information Press the DVD MENU button during play. Info Result: The DVD menu is displayed. Zoom Bookmark Press the … or † button to select Function. Repeat EZ View Result: The options available in the Function group are Program displayed.

  • Page 54: Using The Zoom Function (Dvd/Vcd)

    04-BN68-00664B-00Eng 5/12/04 4:59 PM Page 54 Using the Zoom Function (DVD/VCD) Press the DVD MENU button during play or pause mode. Info Zoom Result: The DVD menu is displayed. Bookmark Repeat Press the … or † button to select Function. EZ View Program Result:...

  • Page 55: Using The Bookmark Function (Dvd/Vcd)

    04-BN68-00664B-00Eng 5/12/04 4:59 PM Page 55 Using the Bookmark Function (DVD/VCD) This feature lets you bookmark sections of a DVD or VCR so you can quickly find them at a later time. Info Zoom Bookmark Repeat Press the DVD MENU button during play. EZ View Program Result:...

  • Page 56: Repeat Play

    04-BN68-00664B-00Eng 5/12/04 4:59 PM Page 56 Repeat Play Repeat the current track, chapter, title, a chosen section (A-B), or all of the disc. Info Zoom Bookmark Repeat Press the DVD MENU button during play. EZ View Program Result: The DVD menu is displayed. Press the …...

  • Page 57: Using The Ez View (Depending On The Disk)

    04-BN68-00664B-00Eng 5/12/04 4:59 PM Page 57 Using the EZ View (depending on the Disc) You can adjust the screen setting (aspect ratio) which best corresponds to your viewing requirements. Info Zoom Bookmark Repeat Press the DVD MENU button during play. EZ View Program Result:...

  • Page 58: Program Play (Cd)

    04-BN68-00664B-00Eng 5/12/04 4:59 PM Page 58 Program Play (CD) Press the DVD MENU button during play. Info Zoom Result: The DVD menu is displayed. Bookmark Repeat Press the … or † button to select Function. EZ View Program Result: The options available in the Function group are displayed.

  • Page 59: Setting Up The Language Features

    04-BN68-00664B-00Eng 5/12/04 4:59 PM Page 59 Setting up the Language Features If you set the player menu, disc menu, audio and subtitle language in advance, they will come up automatically every time √ √ Language Setup you watch a movie. √...

  • Page 60: Setting Up The Audio Options

    04-BN68-00664B-00Eng 5/12/04 4:59 PM Page 60 Setting up the Audio Options If you set the player menu, disc menu, audio and subtitle language in advance, they will come up automatically every time √ √ Language Setup you watch a movie. √...

  • Page 61: Setting Up The Display Options

    04-BN68-00664B-00Eng 5/12/04 4:59 PM Page 61 Setting up the Display Options Press the DVD MENU button. √ √ Language Setup Result: The DVD menu is displayed. √ √ Audio Setup √ √ Display Setup √ √ Parental Setup : Press the … or † button to select Setup. Result: The options available in the Setup group are displayed.

  • Page 62: Setting Up The Parental Control

    04-BN68-00664B-00Eng 5/12/04 4:59 PM Page 62 Setting up the Parental Control Press the DVD MENU button. √ √ Language Setup √ √ Result: The DVD menu is displayed. Audio Setup √ √ Display Setup √ √ Parental Setup : Press the … or † button to select Setup. Result: The options available in the Setup group are displayed.

  • Page 63: Teletext Feature

    04-BN68-00664B-00Eng 5/12/04 4:59 PM Page 63 Teletext Feature Most television channels provide written information services via teletext. Information provided includes: ◆ Television programme times ◆ News bulletins and weather forecasts ◆ Sports results ◆ Travel information This information is divided into numbered pages (see diagram). Part Contents Selected page number.

  • Page 64: Displaying The Teletext Information

    05-BN68-00664B-00Eng 5/12/04 5:00 PM Page 64 Displaying the Teletext Information You can display Teletext information at any time on your set. ☛ For Teletext information to be displayed correctly, channel reception must be stable; otherwise: ◆ Information may be missing ◆...

  • Page 65: Selecting A Page By Number

    05-BN68-00664B-00Eng 5/12/04 5:00 PM Page 65 Selecting a Page by Number You can enter the page number directly by pressing the numeric buttons on the remote control. Enter the three-digit page number given in the content by pressing the corresponding numeric buttons. Result: The current page counter is incremented and the page is then displayed.

  • Page 66: Using Flof To Select A Page

    05-BN68-00664B-00Eng 5/12/04 5:00 PM Page 66 Using FLOF to Select a Page The various topics included in the teletext pages are colour-coded, and can be selected by pressing the coloured buttons on the remote control. Display the teletext contents page by pressing the TTX/MIX button.

  • Page 67: Storing Teletext Pages

    05-BN68-00664B-00Eng 5/12/04 5:00 PM Page 67 Storing Teletext Pages You can store up to four teletext pages to display them later at leisure. Select the LIST mode using the (LIST/FLOF) button. Result: Four 3-digit numbers are displayed in different colours. ➢...

  • Page 68: Connecting To The External Input/Output

    05-BN68-00664B-00Eng 5/12/04 5:00 PM Page 68 Connecting to the External Input/Output “ ” is used for the equipment with an RGB output, such as video game devices or video disc players. Rear of the TV ① Decoder / Video game device Video disc player ①...

  • Page 69: Connecting To The Audio/Video Input

    05-BN68-00664B-00Eng 5/12/04 5:00 PM Page 69 Connecting to the Audio/Video Input The RCA (AUDIO-R/L + VIDEO) connectors are used for equipment such as VCRs, camcorders, video disc players and some video game devices. Camcorder Rear of the TV Video disc player Video game device Connecting Headphones You can connect a set of headphones to your...

  • Page 70: Scart Connector Wiring

    05-BN68-00664B-00Eng 5/12/04 5:00 PM Page 70 SCART Connector Wiring If you wish to connect other equipment via the SCART connectors on your television, contact your dealer or a qualified technician to wire the A/V cable as illustrated below. Signal Signal Audio output R Audio input R Video chassis return (RGB red)

  • Page 71: Disc Type And Characteristics

    05-BN68-00664B-00Eng 5/12/04 5:00 PM Page 71 Disc Type and Characteristics The DVD player is capable of playing the following types of discs with the corresponding logos: Disc Types Recording Disc Max. Playing Time Characteristics (Logos) Types Size Single-sided: 240 min. - DVD contains excellent sound 5”...

  • Page 72: Technical And Environmental Specifications

    05-BN68-00664B-00Eng 5/12/04 5:00 PM Page 72 Technical and Environmental Specifications Model LE17D11B Panel Size 17” Diagonal Display Size 370.56 (H) x 222.36 (V) mm Type a-si TFT active matrix Pixel Pitch 0.2895 (H) x 0.2895 (V) mm Viewing Angle 170/170 (Horizontal/Vertical) Frequency Horizontal 30 ~ 68 kHz...

  • Page 73: Display Modes

    05-BN68-00664B-00Eng 5/12/04 5:00 PM Page 73 Display Modes If the signal from the system equals the standard signal mode, the screen is adjusted automatically. If the signal from the system does not equal the standard signal mode, adjust the mode with reference to the Video card user guide, as the screen may not display or only the power LED may be on.

  • Page 74: Maintenance Of Your Television

    05-BN68-00664B-00Eng 5/12/04 5:00 PM Page 74 Maintenance of Your Television To avoid risk of electric shock, do not disassemble the TV cabinet. Users must not service the TV. User maintenance is restricted to cleaning, as explained below: Unplug the television from the power outlet before cleaning. ◆...

  • Page 75: Troubleshooting: Before Contacting Service Personnel

    Page 75 Troubleshooting: Before Contacting Service Personnel Before contacting Samsung after-sales service, perform the following simple checks. If you cannot solve the problem using the instructions below, note the model and serial number of your set and contact your local dealer.
  • Page 76 05-BN68-00664B-00Eng 5/12/04 5:00 PM Page 76 Troubleshooting: Before Contacting Service Personnel (continued) ◆ Check that the display resolution and frequency from your In PC mode, the image is not stable and computer or video board is an available mode for your set. may appear to vibrate.
  • Page 77 05-BN68-00664B-00Eng 5/12/04 5:00 PM Page 77 Troubleshooting: Before Contacting Service Personnel (continued) ◆ Check the batteries in the remote. May need replacing. No operations can be performed with ◆ Operate the remote control at a distance of no more than 20 feet. remote.

  • Page 78: Powersaver

    05-BN68-00664B-00Eng 5/12/04 5:00 PM Page 78 PowerSaver This set has a built-in power management system called PowerSaver. This system saves energy by switching your set into a low-power mode when it has not been used for a certain period of time. The available modes are “On”, “Standby”, “Sleep”, and “Deep Sleep”.
  • Page 79 05-BN68-00664B-00Eng 5/12/04 5:00 PM Page 79 Memo English-79...
  • Page 80 05-BN68-00664B-00Eng 5/12/04 5:00 PM Page 80 - AFTER SALES SERVICE - Do not hesitate to contact your retailer or service agent if a change in the performance of your product indicates that a faulty condition may be present. ELECTRONICS BN68-00664B-00...
