Wireless PC Link Micro

Custom Installation

Manual installation of the driver

for the wireless USB adapter, the

Philips Media Manager software

and the network setup ___________ 2

Installation of an additional audio

system or recovery if audio system

PC link settings are lost ________ 3–4

Installation of an additional PC server

or recovery of PC link settings

on your PC __________________ 4–5

Integration of MC W770 into an

existing (home) network _______ 6–9

Network utilities _______________ 10–13

Check connection ______________10

Change of USB port using the

MC W770 _________________ 10–11

Change of the wireless channel ___12–13

Using a different wireless network

adapter ______________________ 14–19

MCW770

Contents

Table of Contents

Summary of Contents for Philips MCW770/21

Page 1 Custom Installation Contents Manual installation of the driver for the wireless USB adapter, the Philips Media Manager software and the network setup ___________ 2 Installation of an additional audio system or recovery if audio system PC link settings are lost ________ 3–4...
Page 2: And The Network Setup
– Add an additional PC server Manual installation of the driver for the wireless USB adapter, the Philips Media Manager software and the network setup These 3 installation steps perform the same functionality and have the same behaviour as the quick installation (see “Quick installation”) in a...
Page 3: Pc Link Settings Are Lost
Wireless PC link Custom Installation Installation of an additional audio system or recovery if audio system PC link settings are lost If you want to add an additional MC W770 or an equivalent audio system into your existing MC W770 network, you can connect them to the same PC server without changing the settings of the current PC link installation.This procedure can also be used when the PC link settings have been lost on the audio set.
Page 4 If you want to use your MC W770(s) together with more than one PC, you have to install the Philips Media Manager Software and the PC link setting on your PC. A wireless USB adapter is required. If you want to use a different network adapter as bypacked with the MC W770 proceed according to chapter “Using a different wireless network adapter”...
Page 5 Wireless PC link Custom Installation If you have clicked on No or the driver installation is ﬁnished, the Philips Media Manager Software will be installed.Then the PC is rebooted and PC conﬁgurations are checked. Finally the following window will appear: Press PC LINK A on the audio system for at least 5 seconds until INSTALLING is scrolled on the set.
Page 6: Existing (Home) Network
Both modes are supported. Before starting this installation process: – There should be a PC in the network having the dedicated Philips Media Manager Software installed.Therefore install the Philips Media Manager software from the installation CD only. – The wireless USB adapter has to be already installed and connected on the PC you use for installation.
Page 7 Wireless PC link Custom Installation The PC checks the PC link conﬁguration and, depending on the PC conﬁguration, the following window will appear: Following the procedure will not change your PC link settings. Click on Next. The following window appears: Tick the option Do not perform automatic setup and then click on...
Page 8 Custom Installation Wireless PC link The installation procedure conﬁgures your network settings. Afterwards the following window appears: Press PC LINK A on your MC W770 for at least 5 seconds until INSTALLING is scrolled on the set. The set searches for a connection to the PC.This can require up to about a minute.When the connection is established, Next is activated.Click on Next.
Page 9 ﬁnished, click on Exit to leave the installation programme. Your MC W770 is now able to connect to your network. Please note that music can only be played from PCs in the same network having the dedicated Philips Media Manager Software installed.
Page 10: Network Utilities
Wireless PC link Network utilities Check connection Perform a quick check of your wireless PC link connection. Change of USB port using the MC W770 The installation of the MC W770 is optimised for the USB port used during installation. Therefore the supplied wireless USB adapter should be connected only to this speciﬁc USB port.
Page 11 Wireless PC link The network settings are reconﬁgured and the following window will appear: Press PC LINK A on your MC W770 for at least 5 seconds until INSTALLING is scrolled on the set. The set searches for a connection to the PC.This can require up to about a minute.When the connection is established, Next is activated.Click on Next.
Page 12: Change Of The Wireless Channel
Wireless PC link Change of the wireless channel The wireless PC link uses the worldwide standardised so-called 2.4GHz ISM band.The wireless PC link can use different transmission channels and it might be necessary to change to another channel in order to optimise link quality. Enter Network Utilities, select Change transmission channel and click on Start.
Page 13 Wireless PC link Press PC LINK A on your MC W770 for at least 5 seconds until INSTALLING is scrolled on the set. The set searches for a connection to the PC.This can require up to about a minute.When the connection is established, Next is activated. Click on Next. The following window for selecting a channel will appear:...
Page 14: Adapter
Wireless PC link Using a different wireless network adapter The following steps describe how you can use a wireless network adapter different to the one bypacked with the MC W770 to set up the MC W770 with that adapter.Your network adapter should be installed already, connected to the PC and ready for wireless function.
Page 15 Wireless PC link The network setup programme starts. This will ﬁrst look for the installed wireless USB adapter which was delivered with the set. If this adapter is not found, the following window appears: You have to set up the installation network for the MC W770 with your network adapter.The installation network has the following parameter: SSID:W770-INST-PHAS Channel: 5...
Page 16 Wireless PC link Set in the Properties window of your network adapter the option Obtain an IP address automatically. Click on OK. In Windows XP: under Properties select the Wireless Networks tab and deselect the option Use Windows to conﬁgure my wireless network settings.
Page 17 Wireless PC link Press PC LINK A on your MC W770 for at least 5 seconds until INSTALLING is scrolled on the set. Press HOME on your MC W770 for at least 2 seconds until EXPERT INSTALL is scrolled on the set.
Page 18 Wireless PC link The following window appears. Enter the network parameter of your network and click on OK.Then click on Save in the previous window. It is recommended to use WEP keys encryption for network security reasons. The following window appears: The network parameter will be transferred now to the MC W770 and...
Page 19: Adapter
On PC installation software press Next/Next/Finish to exit the PC installation. Please do not forget that for successful operation the Philips Media Manager Software has to be set up too and operate on a PC which is part of the network you have just set up.
Page 20 MCW770 Wireless PC Link Micro User manual Manuel d'utilisation Manual del usuario Manual do usuário...
Page 21 LEA CUIDADOSAMENTE ESTE INSTRUCTIVO ANTES DE USAR SU APARATO. AVISO IMPORTANTE Philips Mexicana, S.A. de C.V. no se hace responsable por daños o desperfectos causados por: – Maltrato, descuido o mal uso, presencia de insectos o roedores (cucarachas, ratones etc.).
Page 22 Index English ___________________________________ 6 Français ________________________________ 38 Español _________________________________ 70 ∑ ____________________________________ 102 Português ______________________________ 135 Guarantees _____________________________ 168...
Page 23: Table Of Contents
Contents Volume control ___________________ 20 Technical data __________________ 8 Volume adjustment _____________ 20 MUTE _______________________ 20 Sound control ____________________ 20 General information Supplied accessories ________________ 8 DSC ________________________ 20 Environmental information ___________ 9 VEC ________________________ 20 Maintenance ______________________ 9 Disc handling _____________________ 9 Playback Setup ___________________________ 9 Playable discs ____________________ 21...
Page 24 Contents Tuner Tuning to radio stations ____________ 26 Storing radio stations ____________ 26–27 Storing by using “Plug and Play” ___ 26 Storing by automatic programming _ 27 Storing by manual programming ___ 27 Tuning to preset radio stations _______ 27 Deleting a preset radio station _______ 27 Switchable tuning grid (not on all versions) ________________________ 27...
Page 25 CAUTION Changes or modiﬁcations not expressly approved by Philips could void your authority to operate this transmitter. See page 16 / Voir page 47 / Véase la página 78 /...
Page 26 The set complies with the FCC- – Increase the separation between the Rules, Part 15 and with 21 CFR equipment and the receiver. 1040.10. Operation is subject to the – Connect the equipment into an following two conditions: outlet on a circuit different from that 1.This device may not cause to which the receiver is connected.
Page 27: Technical Data
Technical data / General information Technical data Tuner Subject to modiﬁcation without notice. Wave range FM ________________ 87.5–108 MHz General MW, Grid 9 __________ 531–1602 kHz AC Power ______ 110–127 V / 220–240 V, MW, Grid 10 _________ 530–1700 kHz 50 Hz–60 Hz Number of presets _______________ 40 Power consumption...
Page 28: Environmental Information
General information Environmental information Disc handling All redundant packing material has been To take a disc out of omitted.We have done our utmost to its box easily, press the make the packaging easily separable into centre spindle while lifting three mono materials: cardboard (box), it.
Page 29: Remote Control
Remote control Remote control usage Remote control keys TUNER PC LINK CD 1 CD 3 CD 2 CD 4 CD 5 Open the battery compartment of the ALBUM BROWSE remote control and insert 2 alkaline batteries, type AA (R06, UM-3). Close the battery compartment.
Page 30 Remote control DISPLAY switches the set to (Eco Power) standby CD: displays the album and track name on an MP3-CD Source buttons PC LINK: switches between displaying the elapsed playing time, the track name and selects the CD changer the ﬁle name TUNER selects the tuner and toggles between the SHUFFLE...
Page 31: Controls And Connections
Controls and connections & ∞≤£ ™ ¡ On the back VOLTAGE SELECTOR 110V–127V, 220V–240V SPEAKERS 6 Ω L/R (Not on all versions.) Set this selector to connect to the supplied speakers the local mains voltage. Disconnect the AC MAINS ~ mains lead before resetting this selector.
Page 32 Controls and connections ¢ STANDBY-ON switches the set to (Eco Power) standby – selects the next track – searches forwards (press and hold the sensor for the infrared remote control button) within the current track Note: Always point the remote control TUNER: tunes to a higher radio frequency towards this sensor.
Page 33: Installation
Installation Warning: Fit the plug of the loop antenna to Never make or change connections AM ANTENNA as shown below. with the mains supply switched on. Speaker connections Use the supplied speakers only. Using other speakers can damage the set or F M A N T E N A M A N T E N the sound quality will be negatively...
Page 34: Installing A Pc Server
Installation Installing a PC server Mains “Wireless PC Link Quick Installation”. The type plate is located on the rear of the set. Connecting an additional If your set is equipped with a VOLTAGE appliance SELECTOR set this selector to your local It is possible to use an additional appliance, mains voltage if necessary.
Page 35: Wireless Pc Link Playback
Make sure the wireless To switch between further installed USB adapter is connected or another PC servers (see network connection is working properly. www.philips.com/support) press PC LINK A. SERVER is displayed and the next server TUNER PC LINK name is scrolled.
Page 36: Track Navigation And Playback
Wireless PC link playback Track navigation and playback During playback To switch between display of elapsed (See illustration on page 6, User playing time, track name and ﬁle name press manual) DISPLAY on the remote control repeatedly. For easier ﬁnding of a desired track you can navigate as follows: To ﬁnd a particular passage in backwards or BROWSE -: goes down one level...
Page 37: Basic Functions
Basic functions Switching on, switching to Demonstration mode standby The demonstration mode displays various features of the set. TUNER PC LINK CD 1 CD 2 CD 3 CD 4 CD 5 ALBUM BROWSE To switch the set to an active mode press one of the source keys on the remote To activate the demonstration mode Ç...
Page 38: Setting The Clock
Basic functions Setting the clock Displaying the clock This function shows the set time. In any mode (except in clock or timer ALBUM setting) press CLOCK on the remote BROWSE control repeatedly to switch between the clock display and the normal display. Note: If you press a button during the clock display that changes the display, the information related to the pressed button will...
Page 39: Volume Control
Basic functions Volume control Sound control In order to reach an optimal sound, you can Volume adjustment adjust only one of the following sound controls at a time: DSC or VEC. TUNER PC LINK Digital Sound Control enables you to CD 1 CD 2 CD 3...
Page 40: Playback
Playback Playable discs Loading discs For playback on this set you can use the following discs (logos shown below): – All pre-recorded audio CDs – All ﬁnalised audio CDR and Press OPEN/CLOSE on the set. CDRW discs CD and SELECT DISC are displayed. Press one of the disc keys (DISC 1, DISC 2, DISC 3, DISC 4, or DISC 5) on the set to select the desired disc tray to be opened.
Page 41: Playing Discs
Playback Press É Å to start playback. Playing discs Playback starts from the ﬁrst track of the Direct selection and playback of one current disc. All loaded discs will be particular disc played. If one of the trays is empty, the next available disc will be selected.
Page 42: Playback Features
Playback features Selecting and searching Additional selecting and searching (on MP3-CDs only) Selecting a track when playback is stopped Selecting an album when playback is stopped ALBUM BROWSE ALBUM BROWSE Press 4 or ¢ repeatedly to skip to the Press ALBUM 5 or ALBUM ∞ repeatedly to desired track number.
Page 43: Album And Track Name Display (On Mp3-Cds Only)
Playback features Playback starts in the chosen mode. Album and track name display (on MP3-CDs only) To return to normal playback, press REPEAT on the remote control repeatedly until OFF is displayed. Notes: Not all REPEAT modes are possible during SHUFFLE or while playing a programme.
Page 44: Programming Track Numbers
Playback features Press 4 or ¢ repeatedly to select the Programming track numbers desired track. Programming tracks is possible when playback is stopped.You can select up to 99 MP3-CD only: Press ALBUM 5 or ALBUM ∞ to ﬁnd the tracks (also MP3 tracks) and store them in the memory.
Page 45: Tuner
Tuner Tuning to radio stations Storing radio stations You can store up to 40 radio stations in the memory, starting from FM and followed by MW TUNER PC LINK wavebands. Stations can be stored automatically or manually, or by using the “Plug and Play” CD 1 CD 2 CD 3...
Page 46: Storing By Automatic Programming
Tuner To store further radio stations repeat the Storing by automatic programming steps 1–3. You can start the automatic programming Ç from a selected preset number. If no preset To exit manual programming press STOP number is selected, automatic programming Tuning to preset radio stations will start at preset number 1 and all your In tuner mode, press PRESET 5 or...
Page 47: Timer
Timer You can select different timer functions Press SOURCE on the set repeatedly or press CD,TUNER or PC LINK A on the which will be activated at a chosen time. Make sure the clock is set before remote control to select the source you using one of these features.
Page 48: Activating Or Deactivating The Timer
Timer Sleep timer Activating or deactivating the timer You can set a certain period of time after which the set will switch to standby. REPEAT PROGRAM SHUFFLE DISPLAY REPEAT PROGRAM SHUFFLE DISPLAY SLEEP CLOCK TIMER TIMER ON/OFF SLEEP CLOCK TIMER TIMER ON/OFF RDS/NEWS Press TIMER ON/OFF on the remote...
Page 49: Troubleshooting
Troubleshooting WARNING Under no circumstances should you try to repair the set yourself as this will invalidate the guarantee. Do not open the set as there is a risk of electric shock. If a fault occurs, ﬁrst check the points listed before taking the set for repair.
Page 50 Troubleshooting Problem Solution Poor radio reception – Direct the antenna for optimum reception. – Make sure the antenna is not positioned near a radiation source such as a TV,VCR, etc. NO DISC indication or – Make sure the disc is not scratched or dirty. Replace or clean disc cannot be played the disc.
Page 51: Frequently Asked Questions
MC W770 Philips audio system and placing the wireless USB adapter as close as possible to the front side of the MC W770. Start the installation again.
Page 52 Philips Media Manager software. Please see the chapter ‘Preparation for wireless PC Link playback function, ’ this describes how you can add MP3 music ﬁles to the Philips Media Manager. How can I organise my tracks in Edit the Album,Title and other ID3 Tag the music library and in the information of your MP3 ﬁles with the...
Page 53: Universal Plug And Play
CD. For more information please refer to the IFU chapter “Integration of MC W770 into an existing (home) network”, (www.philips.com/support) When installed, browse through the installed networks using the 4, ¢ keys while the display shows NETWORK in the ﬁrst line.The network’s name is scrolled in the second...
Page 54 Philips audio system MC W770? Can I have more than one Philips Yes, you can connect more than one Philips audio system MC W770 to connect audio system MC W770 to your PC. to my PC?
Page 55 There is an easy way to change the network channel be changed? transmission channel, by using the Change transmission channel network utility from the installation CD-ROM. For more information please refer to the IFU chapter “Change of the wireless channel”, (www.philips.com/support)
Page 56 When I press the PC LINK A button, If you receive this message you might need to the display shows NO CONNECTION. restart your Philips Media Manager.To do this, What can I do? click on on the taskbar and select ‘Shutdown Philips Media Manager’.
Page 57 Consumer Electronics products if used in Model number:............ commercial applications. Serial number:............ 6. Philips may, at its discretion choose to replace rather Date of purchase:............ than repair any product covered by this warranty. Retailer:............ 7. This Manufacturers Warranty is neither transferable We recommend you retain your purchase nor valid in countries other than Australia.
Page 58 12 months prior to the date of your claim. 5. In the event of a failure, Philips shall be under no liability for any injury, or any loss or damage caused to property or products other than the product under guarantee.
Page 59 PHILIPS MEXICANA S.A. de C.V. a través de sus centros de servicio autorizados reparará y devolverá a usted su aparato en un plazo no mayor a 20 días hábiles, contados a partir de la fecha de ingreso, impresa en la orden de servicio de cualquiera de nuestros centros de servicio autorizados.
Page 60 Philips Mexicana, S.A. de C.V. Producto importado por: CENTRAL DE SERVICIO Philips Mexicana, S.A. de C.V. Tel. 52 69 90 86 Av. La Palma No. 6 Lada 01 800 506 92 00 Col. San Fernando La Herradura Huixquilucan, Edo. de México C. P. 52784 Tel.
Page 61 é disponível em todos os países onde este produto é oﬁcialmente distribuído pela Philips. Nos países onde a Philips não distribui este produto, o serviço técnico da Philips local poderá prestar tal serviço, contudo poderá ocorrer algum atraso no prazo de atendimento se a devida peça de reposição e...
Page 63 Meet Philips at the Internet http://www. philips.com Need more help or information on installation? Visit: Ayez besoin de plus d'aide ou d'information sur l'installation? Merci de visiter notre site internet: Problemas de Instalación? Para más información, por favor visite nuestra ¿...
