Edelbrock 5737 Installation Instructions

Please study these instructions carefully before installing your new Cat-back Exhaust System. If you have any questions,
contact our Technical Hotline at: 1-800-416-8628 , 7am - 5pm, Monday-Friday, Pacific Standard Time or e-mail us at
Edelbrock@Edelbrock.com.
Suggested Tools for Installation:
❑ 3/8" ratchet set with SAE and metric sockets
❑ 9/16" & 15mm wrench
❑ Jackstands and jack
❑ Liquid penetrant and rubber lubricant
Proper installation is the responsibility of the installer. Improper installation will void warranty and may
DISASSEMBLY
1. Raise vehicle and support with proper jackstands for
the weight, leaving the suspension hanging.
2. Use caution around hot exhaust systems to avoid
burns.
3. Use penetrating oil on all nuts and bolts.
4. Remove the bolts and clamps from the system and
lubricate the rubber isolators.
5. Use a long pry bar to pull the rubber isolators off of the
pipe hangers.
6. Remove the old system. In some cases, you will find it
easier to cut the overaxle pipe to remove it.
Note: Carefully check all rubber isolators that the exhaust
system attaches to for wear, cracks, and fatigue.
Replace as necessary.
Exhaust gas contains carbon monoxide, a deadly invisible gas. Correct any leaks before driving!
©2006 Edelbrock Corporation
Catalog #5737
IMPORTANT NOTE:
result in poor performance and engine or vehicle damage.
INSTALLATION INSTRUCTION
Edelbrock Cat-Back Exhaust System
For 2003-2006 Hummer H2 6.0L V8 4WD
ASSEMBLY
1. Install I-Pipe to factory outlet flange (behind catalytic
converters). Use supplied 2-1/2" clamp for slip fit end.
Note: Do not tighten flange bolts or clamp at this time,
(snug only).
2. Slip the muffler onto the intermediate pipe with a
3" clamp on the front. Note: Inlet end of muffler is
marked. Snug the clamp so you can adjust the system
later.
3. Install a 3" band clamp on the front of the overaxle pipe
and engage it into the stock rubber isolators as you slip
it into the muffler. Snug the clamp.
4. Install hanger clamp assembly onto I-pipe and engage
into stock rubber hanger. Snug clamp to pipe. Hanger
bar should be level.
5. Working from the front of the system, align and tighten
each pipe from the cat-back.
6. Check for clearance to body, frame, and driveline as
you tighten the system from front to rear.
7. Check for leaks and correct, if necessary.
WARNING!!!
Page 1 of 2
Catalog #5737

INSTALLATION INSTRUCTIONS

Brochure #63-0369
Rev. 11/06 - DA/mc
