Edelbrock 5419 Installation Instructions

PLEASE study these instructions carefully before beginning this installation. Most installations can be accomplished with common
tools and procedures. However, you should be familiar with and comfortable working on your vehicle. If you do not feel comfortable
performing this installation, it is recommended to have the installation completed by a mechanic. If you have any questions or
problems, please call our Technical Hotline at: 1-800-416-8628, 7:00 am - 5:00 pm, Pacific Standard Time, Monday through
Friday or e-mail us at edelbrock@edelbrock.com.. PLEASE complete and mail your warranty card. Be sure to write the model
number of this product in the "Part #____" space. THANK YOU.
DESCRIPTION: Because of the current high demand for multiple carburetion, Edelbrock has reintroduced the C-357-B three
•
two-barrel manifold #5419 for small-block Chevrolets. This manifold is primarily designed for street rod applications. Please
note "Brackets" section below for your particular installation. NOTE: HEI distributors will not fit. Stock point-type distributors
may require re-phasing to provide adequate clearance for ignition timing adjustment.
EGR SYSTEMS: Intake manifold will not accept stock EGR (Exhaust Gas Recirculation) equipment. EGR systems are used on
•
most 1972 and later model vehicles. Check local laws for requirements.
ACCESSORIES & INSTALLATION ITEMS: Major recommendations are listed below. See our catalog for details. To order a
•
catalog, call (800) FUN-TEAM, or visit www.edelbrock.com.
CARBURETOR RECOMMENDATIONS:
•
CAUTION: Use only small 2 GC Rochester carburetors. For carburetors, linkage and fuel lines, we recommend that you contact
Automotion Rochester Carburetor Service, 837- 36th Avenue Northeast, Great Falls, MT, 59404- (406) 453-5395 (phone and fax).
CARBURETOR (Qty. 3)
Rochester 2GC Type (2bbl)
A - Carburetor will work with non-EGR or pre-emission control systems.
I - Carburetor has no provisions for evaporative canister.
THROTTLE & ACCESSORY BRACKETS: The throttle and kickdown bracket on some vehicles may require modification to fit.
•
This manifold will not accept any alternator bracket assembly which mounted to the OEM manifold (check with aftermarket
suppliers of alternator brackets such as B&M, Mr. Gasket, TD Performance Products, etc.). It has no provision for ignition coil,
and will accept front (early style) oil filler tube. Valve covers with adequate ventilation provisions are required (PCV valve and
breather recommended).
GASKETS: Do not use competition style intake gaskets for this street manifold. Due to material deterioration over time, internal
•
leakage of vacuum, oil, and coolant may occur.
INTAKE MANIFOLD
5419
NOTE: To ensure maximum performance and a proper seal, Edelbrock gaskets which are
specifically designed and manufactured for use with Edelbrock parts must be used.
Catalog #5419
Rev. 5/05 - RS/mc
For Pre-1986 262-400 c.i.d. Small Block Chevrolet V8
REFERENCE PARTS REQUIRED FOR INSTALLATION
A, I Custom throttle linkage required, refer to CAUTION above for details.
REFERENCE RECOMMENDED GASKET
(None) Edelbrock #7201 Port: 1.28" x 2.09", .060" Thickness
Page 1 of 2
357
C- -B THREE-DEUCE INTAKE MANIFOLD

INSTALLATION INSTRUCTIONS

Catalog #5419
©2005 Edelbrock Corporation
Brochure #63-0402
