C O N T E N T S Preface Audience Organization Conventions Statement 1071—Warning Definition viii Related Documentation xiii Catalyst 6500 Series Switch Chassis Overview C H A P T E R Catalyst 6503 Switch Catalyst 6503-E Switch Catalyst 6504-E Switch 1-11 Catalyst 6506 Switch 1-15...
Page 4 Contents WS-X6348-RJ21V Ethernet Module 2-38 WS-X6348-RJ45 and WS-X6348-RJ45V Ethernet Modules 2-40 WS-X6516-GE-TX Ethernet Module 2-44 WS-X6548-GE-TX, WS-X6548-GE-45AF, and WS-X6548V-GE-TX Ethernet Modules 2-47 WS-X6548-RJ-21 Ethernet Module 2-51 WS-X6548-RJ-45 Ethernet Module 2-54 WS-X6748-GE-TX Ethernet Module 2-58 1-Gigabit Ethernet Modules 2-63 WS-X6408A-GBIC 2-63 WS-X6416-GBIC 2-66 WS-X6516-GBIC and WS-X6516A-GBIC...
Page 5: Esd Precautions C
Contents Ethernet Module Daughter Cards A P P E N D I X PoE Daughter Cards Centralized and Distributed Forwarding Daughter Cards Pluggable Transceiver Modules A P P E N D I X 100-MB Transceivers 1-GB Transceivers 1-GB GBIC Transceivers 1-GB SFP Transceivers 10-GB Transceivers XENPAK Transceivers...
Page 6 Contents Catalyst 6500 Series Ethernet Modules Installation Guide OL-6265-03...
Page 7: Preface
Preface This preface describes who should read the Catalyst 6500 Series Ethernet Modules Installation Guide, how it is organized, and its document conventions. Audience Only trained and qualified service personnel (as defined in IEC 60950 and AS/NZS3260) should install, replace, or service the equipment described in this publication. Organization This publication is organized as follows: Chapter...
Page 8: Conventions
Preface Conventions Chapter Title Description Appendix B Pluggable Transceiver Gives brief descriptions of the copper and optical Modules transceiver modules, physical connectors, and the cables used with the Ethernet modules. Appendix C ESD Precautions Provides a brief description of the hazards of electrostatic staic discharge (ESD) and procedures for correctly attaching an ESD wrist strap to the chassis.
Page 9 Preface Conventions Convention Description font Terminal sessions and information the system displays screen are in font. screen Information you must enter is in font. boldface screen boldface screen font italic screen font Arguments for which you supply values are in italic screen font.
Page 10: Statement 1071-Warning Definition
Preface Conventions Warnings use the following conventions: Statement 1071—Warning Definition IMPORTANT SAFETY INSTRUCTIONS Warning This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing accidents.
Page 11 Preface Conventions Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
Page 12 Preface Conventions Varning! VIKTIGA SÄKERHETSANVISNINGAR Denna varningssignal signalerar fara. Du befinner dig i en situation som kan leda till personskada. Innan du utför arbete på någon utrustning måste du vara medveten om farorna med elkretsar och känna till vanliga förfaranden för att förebygga olyckor. Använd det nummer som finns i slutet av varje varning för att hitta dess översättning i de översatta säkerhetsvarningar som medföljer denna anordning.
Page 13 Preface Conventions Aviso INSTRUÇÕES IMPORTANTES DE SEGURANÇA Este símbolo de aviso significa perigo. Você se encontra em uma situação em que há risco de lesões corporais. Antes de trabalhar com qualquer equipamento, esteja ciente dos riscos que envolvem os circuitos elétricos e familiarize-se com as práticas padrão de prevenção de acidentes. Use o número da declaração fornecido ao final de cada aviso para localizar sua tradução nos avisos de segurança traduzidos que acompanham o dispositivo.
Page 14 Preface Conventions Catalyst 6500 Series Ethernet Modules Installation Guide OL-6265-03...
Page 15: Related Documentation
• Catalyst 6500 Series Switch Software Configuration Guide • Catalyst 6500 Series Switch Command Reference • Catalyst 6500 Series Switch Cisco IOS Software Configuration Guide • • Catalyst 6500 Series Switch Cisco IOS Command Reference • ATM Software Configuration and Command Reference—Catalyst 5000 Family and Catalyst 6000...
Page 16: Obtaining Documentation And Submitting A Service Request
Obtaining Documentation and Submitting a Service Request For information on obtaining documentation, submitting a service request, and gathering additional information, see the monthly What’s New in Cisco Product Documentation, which also lists all new and revised Cisco technical documentation, at: http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html...
Page 17 C H A P T E R Catalyst 6500 Series Switch Chassis Overview This chapter describes the Catalyst 6500 series switches and contains these sections: Catalyst 6503 Switch, page 1-2 • Catalyst 6503-E Switch, page 1-7 • • Catalyst 6504-E Switch, page 1-11 •...
Page 18: Catalyst 6503 Switch
Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6503 Switch Catalyst 6503 Switch The Catalyst 6503 switch is a 3-slot horizontal chassis. Figure 1-1 shows the front view of the chassis Figure 1-2 shows the rear view of the chassis. Table 1-1 provides a description of the major switch features.
Page 19: C H A P T E R 1 Catalyst 6500 Series Switch Chassis Overview
Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6503 Switch Table 1-1 Catalyst 6503 Switch Features Feature Description Chassis Three horizontal slots. Slots are numbered from 1 (top) to 3 (bottom). Power supplies • Supports one or two power supplies. The following power supplies are supported: –...
Page 20 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6503 Switch Table 1-1 Catalyst 6503 Switch Features (continued) Feature Description Supervisor engines Supports Supervisor Engine 2, Supervisor Engine 32, Supervisor • Engine 32 PISA, and Supervisor Engine 720. Supervisor engines are installed in slot 1 and slot 2. –...
Page 21 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6503 Switch Table 1-1 Catalyst 6503 Switch Features (continued) Feature Description Modules Supports up to two Catalyst 6500 series modules. • Does not support the WS-C6500-SFM and WS-X6500-SFM2 Switch • Fabric Modules. Does not support the WS-X67xx modules.
Page 22 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6503 Switch Table 1-2 Catalyst 6503 Switch Specifications Item Specification Environmental Temperature, operating Certified for operation: 32° to 104°F (0° to 40°C) Designed and tested for operation: 32° to 130°F (0° to 55°C) The Catalyst 6500 series switches are equipped with internal air Note temperature sensors that are triggered at 104°F (40°C) generating a...
Page 23: Catalyst 6503-E Switch
Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6503-E Switch Catalyst 6503-E Switch The Catalyst 6503-E switch is a 3-slot horizontal chassis. Figure 1-3 shows the front view of the chassis Figure 1-4 shows the rear view of the chassis. Table 1-3 provides a description of the major switch features.
Page 24 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6503-E Switch Table 1-3 Catalyst 6503-E Switch Features Feature Description Chassis Three horizontal slots. Slots are numbered from 1 (top) to 3 (bottom). Power supplies • Supports one or two power supplies. The following power supplies are supported: –...
Page 25 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6503-E Switch Table 1-3 Catalyst 6503-E Switch Features (continued) Feature Description Modules Chassis supports up to two Catalyst 6500 series modules. • Chassis does not support the WS-C6500-SFM and WS-X6500-SFM2 • Switch Fabric Modules.
Page 26 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6503-E Switch Table 1-4 Catalyst 6503-E Switch Specifications Item Specification Environmental Temperature, operating Certified for operation: 32° to 104°F (0° to 40°C) Designed and tested for operation: 32° to 130°F (0° to 55°C) The Catalyst 6500 series switches are equipped with internal air Note temperature sensors that are triggered at 104°F (40°C) generating a...
Page 27: Catalyst 6504-E Switch
Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6504-E Switch Catalyst 6504-E Switch The Catalyst 6504-E switch is a 4-slot horizontal chassis. Figure 1-5 shows the front view of the chassis Figure 1-6 shows the rear view of the chassis. Table 1-5 provides a description of major switch features.
Page 28 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6504-E Switch Table 1-5 Catalyst 6504-E Switch Features Feature Description Chassis Four horizontal slots. Slots are numbered from 1 (top) to 4 (bottom). Power supplies • Supports one or two power supplies. The following power supplies are supported: –...
Page 29 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6504-E Switch Table 1-5 Catalyst 6504-E Switch Features (continued) Feature Description Modules Chassis supports up to three Catalyst 6500 series modules. • Chassis does not support the WS-C6500-SFM and WS-X6500-SFM2 • Switch Fabric Modules.
Page 30 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6504-E Switch Table 1-6 Catalyst 6504-E Switch Specifications Item Specification Environmental Temperature, operating Certified for operation: 32° to 104°F (0° to 40°C) Designed and tested for operation: 32° to 130°F (0° to 55°C) The Catalyst 6500 series switches are equipped with internal air Note temperature sensors that are triggered at 104°F (40°C) generating a...
Page 31: Catalyst 6506 Switch
Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6506 Switch Catalyst 6506 Switch The Catalyst 6506 switch is a 6-slot horizontal chassis. Figure 1-7 shows a front view of the chassis. Table 1-7 provides a description of the major switch features. Table 1-8 lists the specifications of the Catalyst 6506 switch chassis.
Page 32 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6506 Switch Table 1-7 Catalyst 6506 Switch Features Feature Descriptions Chassis Six horizontal slots. Slots are numbered from 1 (top) to 6 (bottom). Power supplies • Supports one or two power supplies. The following power supplies are supported: –...
Page 33: Catalyst 6506 Switch
Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6506 Switch Table 1-7 Catalyst 6506 Switch Features (continued) Feature Descriptions Supervisor engines Supports Supervisor Engine 2, Supervisor Engine 32, Supervisor • Engine 32 PISA, Supervisor Engine 720, and Supervisor Engine 720-10GE. –...
Page 34 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6506 Switch Table 1-7 Catalyst 6506 Switch Features (continued) Feature Descriptions Modules Chassis supports up to five Catalyst 6500 series modules. • WS-C6500-SFM and WS-X6500-SFM2 Switch Fabric Modules must be • installed in slot 5 or slot 6.
Page 35 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6506 Switch Table 1-8 Catalyst 6506 Switch Specifications Item Specification Environmental Temperature, operating Certified for operation: 32° to 104°F (0° to 40°C) Designed and tested for operation: 32° to 130°F (0° to 55°C) The Catalyst 6500 series switches are equipped with internal air Note temperature sensors that are triggered at 104°F (40°C) generating a...
Page 36: Catalyst 6506-E Switch
Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6506-E Switch Catalyst 6506-E Switch The Catalyst 6506-E switch is a 6-slot horizontal chassis. Figure 1-8 shows a front view of the chassis. Table 1-9 provides a description of the major switch features. Table 1-10 lists the specifications of the Catalyst 6506-E switch chassis.
Page 37 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6506-E Switch Table 1-9 Catalyst 6506-E Switch Features Feature Descriptions Chassis Six horizontal slots. Slots are numbered from 1 (top) to 6 (bottom). Power supplies • Supports one or two power supplies. The following power supplies are supported: –...
Page 38 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6506-E Switch Table 1-9 Catalyst 6506-E Switch Features (continued) Feature Descriptions Supervisor engines Supports Supervisor Engine 2, Supervisor Engine 32, Supervisor • Engine 32 PISA, Supervisor Engine 720, and Supervisor Engine 720-10GE. –...
Page 39 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6506-E Switch Table 1-9 Catalyst 6506-E Switch Features (continued) Feature Descriptions Modules Chassis supports up to five Catalyst 6500 series modules. • WS-C6500-SFM and WS-X6500-SFM2 Switch Fabric Modules must be • installed in slot 5 or slot 6.
Page 40 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6506-E Switch Table 1-10 Catalyst 6506-E Switch Specifications Item Specification Environmental Temperature, operating Certified for operation: 32° to 104°F (0° to 40°C) Designed and tested for operation: 32° to 130°F (0° to 55°C) The Catalyst 6500 series switches are equipped with internal air Note temperature sensors that are triggered at 104°F (40°C) generating a...
Page 41: Catalyst 6509 Switch
Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6509 Switch Catalyst 6509 Switch The Catalyst 6509 switch is a 9-slot horizontal chassis. Figure 1-9 shows a front view of the chassis. Table 1-11 provides a description of the major switch features. Table 1-12 lists the specifications of the Catalyst 6509 switch chassis.
Page 42 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6509 Switch Table 1-11 Catalyst 6509 Switch Features Feature Description Chassis Nine horizontal slots. Slots are numbered from 1 (top) to 9 (bottom). Power supplies • Supports one or two power supplies. The following power supplies are supported: –...
Page 43: Catalyst 6509 Switch
Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6509 Switch Table 1-11 Catalyst 6509 Switch Features (continued) Feature Description Supervisor engines Supports Supervisor Engine 2, Supervisor Engine 32, Supervisor • Engine 32 PISA, Supervisor Engine 720, and Supervisor Engine 720-10GE. –...
Page 44 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6509 Switch Table 1-11 Catalyst 6509 Switch Features (continued) Feature Description Modules Chassis supports up to eight Catalyst 6500 series modules. • WS-C6500-SFM and WS-X6500-SFM2 Switch Fabric Modules must be • installed in slot 5 or slot 6.
Page 45 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6509 Switch Table 1-12 Catalyst 6509 Switch Specifications Item Specification Environmental Temperature, operating Certified for operation: 32° to 104°F (0° to 40°C) Designed and tested for operation: 32° to 130°F (0° to 55°C) The Catalyst 6500 series switches are equipped with internal air Note temperature sensors that are triggered at 104°F (40°C) generating a...
Page 46: Catalyst 6509-E Switch
Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6509-E Switch Catalyst 6509-E Switch The Catalyst 6509-E switch is a 9-slot horizontal chassis. Figure 1-10 shows a front view of the chassis. Table 1-13 provides a description of the major switch features. Table 1-14 lists the specifications of the Catalyst 6509-E switch chassis.
Page 47 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6509-E Switch Table 1-13 Catalyst 6509-E Switch Features Feature Description Chassis Nine horizontal slots. Slots are numbered from (1) top to (9) bottom. Power supplies • Supports one or two power supplies. The following power supplies are supported: –...
Page 48 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6509-E Switch Table 1-13 Catalyst 6509-E Switch Features (continued) Feature Description Supervisor engines Supports Supervisor Engine 2, Supervisor Engine 32, Supervisor • Engine 32 PISA, Supervisor Engine 720, and Supervisor Engine 720-10GE. –...
Page 49 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6509-E Switch Table 1-13 Catalyst 6509-E Switch Features (continued) Feature Description Modules Chassis supports up to eight Catalyst 6500 series modules. • WS-C6500-SFM and WS-X6500-SFM2 Switch Fabric Modules must be • installed in slot 5 or slot 6.
Page 50 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6509-E Switch Table 1-14 Catalyst 6509-E Switch Specifications Item Specification Environmental Temperature, operating Certified for operation: 32° to 104°F (0° to 40°C) Designed and tested for operation: 32° to 130°F (0° to 55°C) The Catalyst 6500 series switches are equipped with internal air Note temperature sensors that are triggered at 104°F (40°C) generating a...
Page 51: Catalyst 6509-Neb Switch
Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6509-NEB Switch Catalyst 6509-NEB Switch The Catalyst 6509-NEB switch is a 9-slot vertical chassis. Figure 1-11 shows a front view of the chassis. Table 1-15 provides a description of the major switch features. Table 1-16 lists the specifications of the Catalyst 6509-NEB switch chassis.
Page 52 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6509-NEB Switch Table 1-15 Catalyst 6509-NEB Switch Features Feature Features Chassis Nine vertical slots. Slots are numbered from 1 (right) to 9 (left). Power supplies • Supports one or two power supplies. The following power supplies are supported: –...
Page 53 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6509-NEB Switch Table 1-15 Catalyst 6509-NEB Switch Features (continued) Feature Features Supervisor engines Supports Supervisor Engine 2, Supervisor Engine 32, Supervisor • Engine 32 PISA, Supervisor Engine 720, and Supervisor Engine 720-10GE. –...
Page 54 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6509-NEB Switch Table 1-15 Catalyst 6509-NEB Switch Features (continued) Feature Features Modules Chassis supports up to eight Catalyst 6500 series modules. • WS-C6500-SFM and WS-X6500-SFM2 Switch Fabric Modules must be • installed in slot 5 or slot 6.
Page 55 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6509-NEB Switch Table 1-16 Catalyst 6509-NEB Switch Specifications Item Specification Environmental Temperature, operating Certified for operation: 32° to 104°F (0° to 40°C) Designed and tested for operation: 32° to 130°F (0° to 55°C) The Catalyst 6500 series switches are equipped with internal air Note temperature sensors that are triggered at 104°F (40°C) generating a...
Page 56: Catalyst 6509-Neb-A Switch
Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6509-NEB-A Switch Catalyst 6509-NEB-A Switch The Catalyst 6509-NEB-A switch is a 9-slot vertical chassis. Figure 1-12 shows a front view of the chassis. Table 1-17 provides a description of the major switch features. Table 1-18 lists the specifications of the Catalyst 6509-NEB-A switch chassis.
Page 57 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6509-NEB-A Switch Table 1-17 Catalyst 6509-NEB-A Switch Features Feature Description Chassis Nine vertical slots. Slots are numbered from 1 (right) to 9 (left). Power supplies • Supports one or two power supplies. The following power supplies are supported: –...
Page 58 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6509-NEB-A Switch Table 1-17 Catalyst 6509-NEB-A Switch Features (continued) Feature Description Supervisor engines Supports Supervisor Engine 2, Supervisor Engine 32, Supervisor • Engine 32 PISA, Supervisor Engine 720, and Supervisor Engine 720-10GE. –...
Page 59 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6509-NEB-A Switch Table 1-17 Catalyst 6509-NEB-A Switch Features (continued) Feature Description Modules Chassis supports up to eight Catalyst 6500 series modules. • WS-C6500-SFM and WS-X6500-SFM2 Switch Fabric Modules must be • installed in slot 5 or slot 6.
Page 60 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6509-NEB-A Switch Table 1-18 Catalyst 6509-NEB-A Switch Specifications Item Specification Environmental Temperature, operating Certified for operation: 32° to 104°F (0° to 40°C) Designed and tested for operation: 32° to 130°F (0° to 55°C) The Catalyst 6500 series switches are equipped with internal air Note temperature sensors that are triggered at 104°F (40°C) generating a...
Page 61: Catalyst 6509-V-E Switch
Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6509-V-E Switch Catalyst 6509-V-E Switch The Catalyst 6509-V-E switch is a 9-slot vertical chassis. Figure 1-13 shows a front view of the chassis. Table 1-19 provides a description of the major switch features. Table 1-20 lists the specifications of the Catalyst 6509-V-E switch chassis.
Page 62 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6509-V-E Switch Table 1-19 Catalyst 6509-V-E Switch Features Feature Description Chassis Nine vertical slots. Slots are numbered from 1 (right) to 9 (left). ‘ • Supports one or two power supplies. The following power supplies are supported: –...
Page 63 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6509-V-E Switch Table 1-19 Catalyst 6509-V-E Switch Features (continued) Feature Description Supervisor engines Supports Supervisor Engine 32, Supervisor Engine 32 PISA, Supervisor • Engine 720, and Supervisor Engine 720-10GE. Supervisor Engine 32, Supervisor Engine 32 PISA, Supervisor –...
Page 64 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6509-V-E Switch Table 1-20 Catalyst 6509-V-E Switch Specifications Item Specification Environmental Temperature, operating Certified for operation: 32° to 104°F (0° to 40°C) Designed and tested for operation: 32° to 130°F (0° to 55°C) The Catalyst 6500 series switches are equipped with internal air Note temperature sensors that are triggered at 104°F (40°C) generating a...
Page 65: Catalyst 6513 Switch
Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6513 Switch Catalyst 6513 Switch The Catalyst 6513 switch is a 13-slot horizontal chassis. Figure 1-14 shows a front view of the chassis. Table 1-21 provides a description of the major switch features. Table 1-22 lists the specifications of the Catalyst 6513 switch chassis.
Page 66 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6513 Switch Table 1-21 Catalyst 6513 Switch Features Feature Description Chassis Thirteen horizontal slots. Slots are numbered from (1) top to (13) bottom. Power supplies • Supports one or two power supplies. The following power supplies are supported: –...
Page 67 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6513 Switch Table 1-21 Catalyst 6513 Switch Features (continued) Feature Description Supervisor engines Supports Supervisor Engine 2, Supervisor Engine 32, Supervisor • Engine 32 PISA, Supervisor Engine 720, and Supervisor Engine 720-10GE. –...
Page 68 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6513 Switch Table 1-21 Catalyst 6513 Switch Features (continued) Feature Description Modules Chassis supports up to 12 Catalyst 6500 series modules. • WS-C6500-SFM and WS-X6500-SFM2 Switch Fabric Modules must be • installed in slot 7 or slot 8.
Page 69 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6513 Switch Table 1-22 Catalyst 6513 Switch Specifications Item Specification Environmental Temperature, operating Certified for operation: 32° to 104°F (0° to 40°C) Designed and tested for operation: 32° to 130°F (0° to 55°C) The Catalyst 6500 series switches are equipped with internal air Note temperature sensors that are triggered at 104°F (40°C) generating a...
Page 70: Catalyst 6513-E Switch
Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6513-E Switch Catalyst 6513-E Switch The Catalyst 6513-E switch is a 13-slot horizontal chassis. Figure 1-15 shows a front view of the chassis. Table 1-23 provides a description of the major switch features. Table 1-24 lists the specifications of the Catalyst 6513-E switch chassis.
Page 71 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6513-E Switch Table 1-23 Catalyst 6513-E Switch Features Feature Description Chassis Thirteen horizontal slots. Slots are numbered from (1) top to (13) bottom. Power supplies • Supports one or two power supplies. The following power supplies are supported: –...
Page 72 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6513-E Switch Table 1-23 Catalyst 6513-E Switch Features (continued) Feature Description Supervisor engines Supports Supervisor Engine 32, Supervisor Engine 720, and Supervisor • Engine 720-10GE. Supervisor Engine 32, Supervisor Engine 720, and Supervisor –...
Page 73 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6513-E Switch Table 1-23 Catalyst 6513-E Switch Features (continued) Feature Description Modules Chassis supports up to 12 Catalyst 6500 series modules. • WS-X6748-SFP, WS-X6748-GE-TX, and WS-X6704-10GE modules • are not supported in slots 2–8; they are supported in slots 9–13. Slots 1–8 support a single fabric channel;...
Page 74 Chapter 1 Catalyst 6500 Series Switch Chassis Overview Catalyst 6513-E Switch Table 1-24 Catalyst 6513-E Switch Specifications Item Specification Environmental Temperature, operating Certified for operation: 32° to 104°F (0° to 40°C) Designed and tested for operation: 32° to 130°F (0° to 55°C) The Catalyst 6500 series switches are equipped with internal air Note temperature sensors that are triggered at 104°F (40°C) generating a...
Page 75 C H A P T E R Ethernet Switching Modules This chapter describes the 10BASE, 10/100BASE, 10/100/1000BASE, 1-Gigabit, and the 10-Gigabit Ethernet modules and contains these sections: 10 and 10/100 Fiber-Based Ethernet Modules, page 2-1 • 10/100 and 10/100/1000 Ethernet Modules, page 2-13 •...
Page 76: Chapter 2 Ethernet Switching Module
Chapter 2 Ethernet Switching Modules 10 and 10/100 Fiber-Based Ethernet Modules WS-X6024-10FL-MT Ethernet Module The WS-X6024-10FL-MT Ethernet module (Figure 2-1) provides 24 10-Mbps full- or half-duplex ports. Table 2-1 lists the module features, and Table 2-2 lists the module physical and environmental specifications.
Page 77: Ws-X6024-10Fl-Mt Ethernet Module
Chapter 2 Ethernet Switching Modules 10 and 10/100 Fiber-Based Ethernet Modules Table 2-1 WS-X6024-10FL-MT Ethernet Module Features (continued) Feature Description Bus connection Single connection into the 32-Gbps shared bus Module upgrades available PoE support Not available. Distributed forwarding Not available. support Pluggable transceivers Not supported.
Page 78: Ws-X6148-Fe-Sfp Ethernet Module
Chapter 2 Ethernet Switching Modules 10 and 10/100 Fiber-Based Ethernet Modules Table 2-2 WS-X6024-10FL-MT Ethernet Module Physical and Environmental Specifications Item Specification Dimensions (H x W x D) 1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm). Occupies one slot in the chassis. Weight 7.0 lb (3.18 kg) Power and heat numbers...
Page 79 Chapter 2 Ethernet Switching Modules 10 and 10/100 Fiber-Based Ethernet Modules Table 2-3 WS-X6148-FE-SFP Features (continued) Feature Description Cabling distance Depends on the 100BASE-X Fast Ethernet SFP transceiver installed in the module port. Refer to Appendix B for descriptions of the Fast Ethernet SFP transceiver types and supported cabling distances.
Page 80 Chapter 2 Ethernet Switching Modules 10 and 10/100 Fiber-Based Ethernet Modules Table 2-3 WS-X6148-FE-SFP Features (continued) Feature Description Digital Optical Monitoring Not supported (DOM) support Module front panel LEDs STATUS Green—All diagnostics pass; the module is operational. • Orange—The module is booting or running diagnostics; an •...
Page 81 Chapter 2 Ethernet Switching Modules 10 and 10/100 Fiber-Based Ethernet Modules WS-X6324-100FX-MM and WS-X6324-100FX-SM Ethernet Modules The WS-X6324-100FX-MM and the WS-X6324-100FX-SM Ethernet modules (Figure 2-3) provide 24 100-Mbps full- or half-duplex ports. The WS-X6324-100FX-MM Ethernet module operates over multimode fiber-optic (MMF) cable and the WS-X6324-100FX-SM Ethernet module operates over G.652 single-mode fiber-optic (SMF) cable.
Page 82: Ws-X6324-100Fx-Mm And Ws-X6324-100Fx-Sm Ethernet Modules
Chapter 2 Ethernet Switching Modules 10 and 10/100 Fiber-Based Ethernet Modules Table 2-5 WS-X6324-100FX-MM and WS-X6324-100FX-SM Ethernet Module Features (continued) Feature Description Software support With Supervisor Engine 2—12.1(2)E • With Supervisor Engine 32—12.2(18)SXF • With Supervisor Engine 32 PISA—12.2(18)ZY • With Supervisor Engine 720—12.2(14)SX •...
Page 83 Chapter 2 Ethernet Switching Modules 10 and 10/100 Fiber-Based Ethernet Modules Table 2-6 WS-X6324-100FX-MM and WS-X6324-100FX-SM Ethernet Modules Physical and Environmental Specifications Item Specification Dimensions (H x W x D) 1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm). Occupies one slot in the chassis. Weight 7.0 lb (3.18 kg) Power and heat numbers...
Page 84: Ws-X6524-100Fx-Mm Ethernet Module
Chapter 2 Ethernet Switching Modules 10 and 10/100 Fiber-Based Ethernet Modules WS-X6524-100FX-MM Ethernet Module The WS-X6524-100FX-MM Ethernet module (Figure 2-4) provides 24 100-Mbps full- or half-duplex ports. Table 2-7 lists the module features, and Table 2-8 lists the module physical and environmental specifications.
Page 85 Chapter 2 Ethernet Switching Modules 10 and 10/100 Fiber-Based Ethernet Modules Table 2-7 WS-X6524-100FX-MM Features (continued) Feature Description Queues per port Tx—1p3q1t • Rx—1p1q0t • Chassis/slot restrictions No chassis or slot restrictions; the module can occupy any slot in any Catalyst 6500 or Catalyst 6500-E chassis.
Page 86 Chapter 2 Ethernet Switching Modules 10 and 10/100 Fiber-Based Ethernet Modules Table 2-8 WS-X6524-100FX-MM Physical and Environmental Specifications Item Specification Dimensions 1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm). Occupies one slot in the chassis. Weight Base module—7.0 lb (3.18 kg) Power and heat numbers Base module:...
Page 87 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-8 WS-X6524-100FX-MM Physical and Environmental Specifications (continued) Item Specification Power and heat numbers Base module + DFC3B daughter card: • (continued) Module current—3.57 A – Module power—149.94 W – AC-input power—187.43 W –...
Page 88: And 10/100/1000 Ethernet Modules
Base module without daughter cards installed. WS-X6148-GE-45AF Base module equipped with a factory-installed IEEE 802.3af PoE daughter card (WS-F6K-GE48-AF). WS-X6148V-GE-TX Base module equipped with a factory-installed Cisco prestandard PoE daughter card (WS-F6K-VPWR-GE). WS-X6148A-GE-TX Base module (with enhanced port buffer size) without daughter cards installed.
Page 89 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-10 WS-X6148-GE-TX and WS-X6148A-GE-TX Features Feature Description Ports per module • 48 ports (all variants). Ports are numbered (left to right): – Top row, odd numbered ports 1–47. – Bottom row, even numbered ports 2–48.
Page 90 Both the WS-X6148-GE-TX and the WS-X6148A-GE-TX are field • upgradeable with the WS-F6K-GE48-AF= daughter card that supports both the Cisco prestandard and the IEEE 802.3af standard. Refer to the Catalyst 6500 Series Power over Ethernet Daughter Cards Field-Upgrade Installation Note for field upgrade procedures.
Page 91 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-10 WS-X6148-GE-TX and WS-X6148A-GE-TX Features (continued) Feature Description Module front panel LEDs STATUS Green—All diagnostics pass; the module is operational. • Orange—The module is booting or running diagnostics; an •...
Page 92 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-11 WS-X6148-GE-TX and Variants Physical and Environmental Specifications (continued) Item Specification Power and heat numbers Base module (WS-X6148-GE-TX): • Module current—2.47 A – Module power—104.00 W – AC-input power— 130.00W –...
Page 93 Base module without daughter cards installed. WS-X6148-21AF Base module equipped with a factory-installed IEEE 802.3af PoE daughter card (WS-F6K-GE48-AF). WS-X6148-RJ21V Base module equipped with a factory-installed Cisco prestandard PoE daughter card (WS-F6K-VPWR-GE). Figure 2-6 WS-X6148-RJ-21 Ethernet Module Front Panel WS-X6148-RJ-21...
Page 94: Ws-X6148-Rj21 Ethernet Modules
Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-13 WS-X6148-RJ-21 Ethernet Modules Features (continued) Feature Description Cabling distance 328 ft (100 m) over Category 5, 5e, and 6 UTP/STP cable (all variants) Buffer size 128 KB per port (all variants) •...
Page 95 WS-X6148-RJ-21—Field upgradeable to Cisco Prestandard only by installing the WS-F6K-VPWR= daughter card. Refer to the Cisco Catalyst 6500 Series Power over Ethernet Daughter Cards Field-Upgrade Installation Note for field upgrade procedures. An IEEE 802.3af standard PoE daughter card is available Note through factory advance replacement only;...
Page 96 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-14 WS-X6148-RJ-21 Physical and Environmental Specifications Item Specification Dimensions (H x W x D) 1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm). Occupies one slot in the chassis. Weight •...
Page 97 Base module without daughter cards installed. WS-X6148-45AF Base module equipped with a factory-installed IEEE 802.3af PoE daughter card (WS-F6K-GE48-AF). WS-X6148-RJ45V Base module equipped with a factory-installed Cisco prestandard PoE daughter card (WS-F6K-VPWR-GE). WS-X6148A-RJ-45 Base module (with enhanced port buffer size) without daughter cards installed.
Page 98: Cabling Distance
Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-16 WS-X6148-RJ-45 and WS-X6148A-RJ-45 Ethernet Modules Features Feature Description Ports per module • 48 ports (all variants). Ports are numbered (left to right): – Top row, odd numbered ports 1–47. –...
Page 99: Software Support
PoE support WS-X6148-RJ-45—Field upgradeable to the Cisco prestandard • only with the WS-F6K-VPWR-GE= daughter card or both the Cisco prestandard and the IEEE 802.3af standard by installing the WS-F6K-GE48-AF= daughter card. WS-X6148A-RJ-45—Field upgradeable to the Cisco prestandard • and the IEEE 802.3af standard by installing the WS-F6K-GE48-AF= daughter card.
Page 100 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-16 WS-X6148-RJ-45 and WS-X6148A-RJ-45 Ethernet Modules Features (continued) Feature Description Pluggable transceivers Not supported. support TDR support Module front panel LEDs STATUS Green—All diagnostics pass; the module is operational. •...
Page 101 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-17 WS-X6148-RJ-45 Ethernet Modules Physical and Environmental Specifications Item Specification Dimensions (H x W x D) 1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm). Occupies one slot in the chassis. Weight •...
Page 102 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-17 WS-X6148-RJ-45 Ethernet Modules Physical and Environmental Specifications (continued) Item Specification Power and heat numbers WS-X6148A-RJ-45: • (continued) Module current—1.00 A – Module power—42.00 W – AC-input power—52.50 W –...
Page 103 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules WS-X6148X2-RJ-45 and WS-X6148X2-45AF Ethernet Modules The WS-X6148X2-RJ-45 and the WS-X6148X2-45AF Ethernet modules, listed in Table 2-18, provide 96 10/100-Mbps full- or half-duplex ports. The WS-X6148X2-RJ-45 and the WS-X6148X2-RJ-45AF modules, see Figure 2-8, are shipped with a 96-port splitter panel (WS-F6K-48X2-SPLTR).
Page 104: Ws-X6148X2-Rj-45 And Ws-X6148X2-45Af Ethernet Modules
Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-19 WS-X6148X2-RJ-45 and WS-X6148X2-45AF Ethernet Modules Features Feature Description Ports per module 48 ports, but scalable to 96 ports with the use of the supplied splitter panel (both modules) •...
Page 105 96 Class 2 (7 W) devices per module when operating as a 96-port module. See the Cisco Catalyst 6500 Series Power over Ethernet Daughter Cards Field-Upgrade Installation Note for field upgrade procedures. See Appendix A for further information on the PoE daughter cards.
Page 106 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-19 WS-X6148X2-RJ-45 and WS-X6148X2-45AF Ethernet Modules Features (continued) Feature Description TDR support Not supported Module front panel LEDs STATUS Green—All diagnostics pass; the module is operational. • Orange—The module is booting or running diagnostics. •...
Page 107 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-20 WS-X6148X2-RJ-45 Physical and Environmental Specifications Item Specification Dimensions (H x W x D) Module—1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm). Occupies one slot in the chassis.
Page 108 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules WS-X6196-RJ-21 and WS-X6196-21AF Ethernet Modules The WS-X6196-RJ-21 and the WS-X6196-21AF Ethernet modules, listed in Table 2-21, provide 96 10/100-Mbps full- or half-duplex ports. Figure 2-10 shows the module front panel. Table 2-21 WS-X6196-RJ-21 Modules Module...
Page 109: Ws-X6196-Rj-21 And Ws-X6196-21Af Ethernet Modules
(15.4 W) devices per module. WS-X6196-21AF—Shipped with a WS-F6K-FE48X2-AF PoE daughter card installed. See the Cisco Catalyst 6500 Series Power over Ethernet Daughter Cards Field-Upgrade Installation Note for field upgrade procedures. See Appendix A for further information on the PoE daughter cards.
Page 110 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-22 WS-X6196-RJ-21 and WS-X6196-21AF Ethernet Modules Features (continued) Feature Description Pluggable transceivers Not supported. support TDR support Not supported. Module front panel LEDs STATUS Green—All diagnostics pass; the module is operational. •...
Page 111 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-23 WS-X6196-RJ-21 and WS-X6196-21AF Ethernet Modules Physical and Environmental Specifications Item Specification Dimensions (H x W x D) 1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm). Occupies one slot in the chassis. Weight WS-X6196-RJ-21—7.8 lb (3.54 kg) WS-X6196-21AF—11.2 lb (5.08 kg)
Page 112: Ws-X6348-Rj21V Ethernet Module
Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules WS-X6348-RJ21V Ethernet Module The WS-X6348-RJ21V Ethernet module (Figure 2-11) provides 48 10/100-Mbps full- or half-duplex ports. Table 2-24 lists the features and description for the module, and Table 2-25 lists the physical and environmental specifications for the module.
Page 113 Catalyst 6500 or Catalyst 6500-E chassis. Bus connection 32-Gbps shared bus Module upgrades available PoE support Cisco prestandard only. The WS-F6K-VPWR= PoE daughter card is factory installed on the module. No PoE field upgrades are available. Distributed forwarding Not supported. support Pluggable transceivers Not supported.
Page 114: Ws-X6348-Rj45 And Ws-X6348-Rj45V Ethernet Modules
Table 2-26 WS-X6348-RJ45 Modules Module Description WS-X6348-RJ45 Base module without daughter cards installed. WS-X6348-RJ45V Base module equipped with a factory-installed Cisco prestandard PoE daughter card (WS-F6K-VPWR-GE). Figure 2-12 WS-X6348-RJ45 and WS-X6348-RJ45V Ethernet Modules Front Panel WS-X6348-RJ-45 STATUS 48 PORT ETHERNET SWITCHING...
Page 115 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-27 WS-X6348-RJ45 and WS-X6348-RJ45V Ethernet Modules Features Feature Description Ports per module • 48 ports (both modules). Ports are numbered (left to right): – Top row, odd numbered ports 1 through 47. –...
Page 116 WS-F6K-VPWR= PoE daughter card. WS-X6348-RJ-45V—Comes equipped with the WS-F6K-VPWR • daughter card. See the Cisco Catalyst 6500 Series Power over Ethernet Daughter Cards Field-Upgrade Installation Note for field upgrade procedures. See Appendix A for further information on the PoE daughter cards. Distributed forwarding Not supported.
Page 117 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-28 WS-X6348-RJ45 and WS-X6348-RJ45V Physical and Environmental Specifications Item Specification Dimensions (H x W x D) 1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm). Occupies one slot in the chassis.
Page 118: Ws-X6516-Ge-Tx Ethernet Module
Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules WS-X6516-GE-TX Ethernet Module The WS-X6516-GE-TX Ethernet module (Figure 2-13) provides 16 10/100/1000-Mbps full- or half-duplex ports. Table 2-29 lists the features and description for the module, and Table 2-30 lists the physical and environmental specifications for the module.
Page 119 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-29 WS-X6516-GE-TX Ethernet Module Features (continued) Feature Description Chassis/slot restrictions No chassis or slot restrictions; the module can occupy any slot in any Catalyst 6500 or Catalyst 6500-E chassis. Bus connection 32-Gbps shared bus Module upgrades available...
Page 120 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-30 WS-X6516-GE-TX Ethernet Module Physical and Environmental Specifications Item Specification Dimensions (H x W x D) 1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm). Occupies one slot in the chassis.
Page 121: Ws-X6548-Ge-Tx, Ws-X6548-Ge-45Af, And Ws-X6548V-Ge-Tx Ethernet Modules
Base module without daughter cards installed. WS-X6548-GE-45AF Base module equipped with a factory-installed IEEE 802.3af PoE daughter card (WS-F6K-GE48-AF). WS-X6548V-GE-TX Base module equipped with a factory-installed Cisco prestandard PoE daughter card (WS-F6K-VPWR-GE). Figure 2-14 WS-X6548-GE-TX Ethernet Module Front Panel WS-X6548-GE-TX...
Page 122 WS-X6548-GE-TX—Field-upgradeable to Cisco prestandard only by installing the WS-F6K-VPWR-GE= daughter card or both Cisco prestandard and IEEE 802.3af by installing the WS-F6K-GE48-AF= daughter card. Refer to the Cisco Catalyst 6500 Series Power over Ethernet Note Daughter Cards Field-Upgrade Installation Note for field upgrade procedures.
Page 123 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-32 WS-X6548-GE-TX Modules Features (continued) Feature Description TDR support All module variants support TDR. Module front panel LEDs STATUS Green—All diagnostics pass; the module is operational. • Orange—The module is booting or running diagnostics. •...
Page 124 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-33 WS-X6548-GE-TX and Variants Physical and Environmental Specifications Item Specification Dimensions (H x W x D) 1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm). Occupies one slot in the chassis.
Page 125: Ws-X6548-Rj-21 Ethernet Module
Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules WS-X6548-RJ-21 Ethernet Module The WS-X6548-RJ-21 Ethernet module (Figure 2-15) provides 48 10/100-Mbps full- or half-duplex ports. Table 2-34 lists the features and description of the module, and Table 2-35 lists the physical and environmental specifications for the module.
Page 126 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-34 WS-X6548-RJ-21 Ethernet Module Features (continued) Feature Description Queues per port Tx—1p3q1t • Rx—1p1q0t • Chassis/slot restrictions No chassis or slot restrictions; the module can occupy any slot in any Catalyst 6500 or Catalyst 6500-E chassis.
Page 127 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-35 WS-X6548-RJ-21 Physical and Environmental Specifications Item Specification Dimensions (H x W x D) 1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm). Occupies one slot in the chassis.
Page 128: Ws-X6548-Rj-45 Ethernet Module
Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-35 WS-X6548-RJ-21 Physical and Environmental Specifications (continued) Item Specification Environment Operating temperature Certified for operation: 32° to 104°F (0° to 40°C) • Designed and tested for operation: 32° to 130°F (0° to 55°C) •...
Page 129 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-36 WS-X6548-RJ-45 Features (continued) Feature Description Supervisor engine support Supported on the following supervisor engines: Supervisor Engine 2 • Supervisor Engine 32 • Supervisor Engine 32 PISA • Supervisor Engine 720 •...
Page 130 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-36 WS-X6548-RJ-45 Features (continued) Feature Description TDR support Not supported. Module front panel LEDs STATUS Green—All diagnostics pass; the module is operational. • Orange—The module is booting or running diagnostics. •...
Page 131 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-37 WS-X6548-RJ-45 Physical and Environmental Specifications (continued) Item Specification Power and heat numbers Base module: • Module current—2.90 A – Module power—121.80 W – AC-input power—152.25 W – AC heat dissipation—519.93 BTU/hour –...
Page 132: Ws-X6748-Ge-Tx Ethernet Module
Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules WS-X6748-GE-TX Ethernet Module The WS-X6748-GE-TX Ethernet module (Figure 2-17) provides 48 10/100/1000-Mbps full- or half-duplex ports. Table 2-38 lists the module features, and Table 2-39 lists the module physical and environmental specifications.
Page 133 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-38 WS-X6748-GE-TX Ethernet Module Features (continued) Feature Description Chassis/slot restrictions The module is not supported in the Catalyst 6503 switch chassis. The module can occupy any slot in any other Catalyst 6500 or Catalyst 6500-E chassis except the Catalyst 6513 chassis where the module must be installed in slots 9–13.
Page 134 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-38 WS-X6748-GE-TX Ethernet Module Features (continued) Feature Description TDR support Supported. Module front panel LEDs STATUS Green—All diagnostics pass; the module is operational. • Orange—The module is booting or running diagnostics. •...
Page 135 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-39 WS-X6748-GE-TX Physical and Environmental Specifications Item Specification Dimensions (H x W x D) 1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm). Occupies one slot in the chassis. Weight Base module + CFC daughter card (WS-F6700-CFC)—10.2 lb (4.63 kg) Power and heat numbers...
Page 136 Chapter 2 Ethernet Switching Modules 10/100 and 10/100/1000 Ethernet Modules Table 2-39 WS-X6748-GE-TX Physical and Environmental Specifications (continued) Item Specification Power and heat numbers Base module + WS-F6700-DFC3BXL daughter card • (continued) Module current—10.30 A – Module power—363.30 W – AC-input power—454.13 W –...
Page 137: 1-Gigabit Ethernet Modules
Chapter 2 Ethernet Switching Modules 1-Gigabit Ethernet Modules 1-Gigabit Ethernet Modules This section describes the following 1-Gigabit Ethernet modules: WS-X6408A-GBIC, page 2-63 • WS-X6416-GBIC, page 2-66 • WS-X6516-GBIC and WS-X6516A-GBIC, page 2-69 • WS-X6724-SFP, page 2-74 • WS-X6748-SFP, page 2-78 •...
Page 138 Chapter 2 Ethernet Switching Modules 1-Gigabit Ethernet Modules Table 2-40 WS-X6408A-GBIC Ethernet Module Features (continued) Feature Description Maximum frame size Up to 9216 bytes per frame Module oversubscription rate N/A Supervisor engine support Supported on the following supervisor engines: Supervisor Engine 2 •...
Page 139 Chapter 2 Ethernet Switching Modules 1-Gigabit Ethernet Modules Table 2-40 WS-X6408A-GBIC Ethernet Module Features (continued) Feature Description TDR support Not supported. Module front panel LEDs STATUS Green—All diagnostics pass; the module is operational. • Orange—The module is booting or running diagnostics; an •...
Page 140: Ws-X6416-Gbic
Chapter 2 Ethernet Switching Modules 1-Gigabit Ethernet Modules Table 2-41 WS-X6408A-GBIC Physical and Environmental Specifications Item Specification Dimensions (H x W x D) 1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm). Occupies one slot in the chassis. Weight 6.4 lb (2.9 kg) Power and heat numbers...
Page 141 No chassis or slot restrictions; the module can occupy any slot in any Catalyst 6500 or Catalyst 6500-E chassis. Bus connection 32-Gbps shared bus Forwarding architecture Cisco Express Forwarding (CEF) Module upgrades available PoE support Not supported. Distributed forwarding Not supported.
Page 142 Chapter 2 Ethernet Switching Modules 1-Gigabit Ethernet Modules Table 2-42 WS-X6416-GBIC Features (continued) Feature Description Digital Optical Monitoring Supported on some GBIC transceivers (DOM) support Refer to your software release notes for specific information on Note which GBIC transceivers support DOM and the software release required for support.
Page 143: Ws-X6516-Gbic And Ws-X6516A-Gbic
Chapter 2 Ethernet Switching Modules 1-Gigabit Ethernet Modules WS-X6516-GBIC and WS-X6516A-GBIC The WS-X6516-GBIC and the WS-X6516A-GBIC Ethernet modules (Figure 2-20) provide 16 1-Gbps full- or half-duplex ports. Table 2-44 lists the module features, and Table 2-45 lists the module physical and environmental specifications.
Page 144 Chapter 2 Ethernet Switching Modules 1-Gigabit Ethernet Modules Table 2-44 WS-X6516-GBIC and WS-X6516A-GBIC Features (continued) Feature Description Software support With Supervisor Engine 2—12.1(18a)E, WS-X6516-GBIC; • 12.1(19)E1, WS-X6516A-GBIC With Supervisor Engine 32—12.2(18)SXF • With Supervisor Engine 32 PISA—12.2(18)ZY • With Supervisor Engine 720—12.2(14)SX •...
Page 145 Chapter 2 Ethernet Switching Modules 1-Gigabit Ethernet Modules Table 2-44 WS-X6516-GBIC and WS-X6516A-GBIC Features (continued) Feature Description Digital Optical Monitoring Supported on some GBIC transceivers. (DOM) support Refer to your software release notes for specific information on Note which GBIC transceivers support DOM and the software release required for support.
Page 146 Chapter 2 Ethernet Switching Modules 1-Gigabit Ethernet Modules Table 2-45 WS-X6516-GBIC and WS-X6516A-GBIC Physical and Environmental Specifications (continued) Item Specification Power and heat numbers WS-X6516-GBIC (base module): • Module current—3.40 A – Module power—142.80 W – AC-input power—178.50 W – AC heat dissipation—609.58 BTU/hour –...
Page 147 Chapter 2 Ethernet Switching Modules 1-Gigabit Ethernet Modules Table 2-45 WS-X6516-GBIC and WS-X6516A-GBIC Physical and Environmental Specifications (continued) Item Specification Power and heat numbers WS-X6516A-GBIC (enhanced base module): • (continued) Module current—3.62 A – Module power—152.04 W – AC-input power—190.05 W –...
Page 148: Ws-X6724-Sfp
Chapter 2 Ethernet Switching Modules 1-Gigabit Ethernet Modules WS-X6724-SFP The WS-X6724-SFP Ethernet module (Figure 2-21) provides 24 1-Gbps full- or half-duplex ports. Table 2-46 lists the module features, and Table 2-47 lists the module physical and environmental specifications. Figure 2-21 WS-X6724-SFP Ethernet Module Front Panel WS-X6724-SFP 24 PORT GIGABIT ETHERNET-SFP...
Page 149 Chapter 2 Ethernet Switching Modules 1-Gigabit Ethernet Modules Table 2-46 WS-X6724-SFP Ethernet Module Features (continued) Feature Description Queues per port With CFC daughter card: • Tx—1p3q8t – Rx—1q8t – With DFC daughter card: • Tx—1p3q8t – Rx—2q8t – Chassis/slot restrictions The module is not supported in the Catalyst 6503 chassis.
Page 150 Chapter 2 Ethernet Switching Modules 1-Gigabit Ethernet Modules Table 2-47 WS-X6724-SFP Ethernet Module Physical and Environmental Specifications Item Specification Dimensions (H x W x D) 1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm). Occupies one slot in the chassis. Weight Base module—8.8 lb (4.0 kg) Base module + DFC daughter card—9.4 lb (4.3 kg)
Page 151 Chapter 2 Ethernet Switching Modules 1-Gigabit Ethernet Modules Table 2-47 WS-X6724-SFP Ethernet Module Physical and Environmental Specifications (continued) Item Specification Power and heat numbers Base module + DFC3BXL daughter card (WS-F6700-DFC3BXL) • (continued) Module current—5.53 A – Module power—232.26 W –...
Page 152: Ws-X6748-Sfp
Chapter 2 Ethernet Switching Modules 1-Gigabit Ethernet Modules WS-X6748-SFP The WS-X6748-SFP Ethernet module (Figure 2-22) provides 48 1-Gbps full- or half-duplex ports. Table 2-48 lists the module features, and Table 2-48 lists the module physical and environmental specifications. Figure 2-22 WS-X6748-SFP Switching Module Front Panel WS-X6748-SFP 48 PORT GIGABIT ETHERNET-SFP...
Page 153 Chapter 2 Ethernet Switching Modules 1-Gigabit Ethernet Modules Table 2-48 WS-X6748-SFP Features (continued) Feature Description Software support With Supervisor Engine 720—12.2(17d)SXB • With Supervisor Engine 720 and DFC3C or • DFC3CXL—12.2(33)SXH With Supervisor Engine 720-10GE—12.2(33)SXH • Queues per port With CFC daughter card: •...
Page 154 Chapter 2 Ethernet Switching Modules 1-Gigabit Ethernet Modules Table 2-48 WS-X6748-SFP Features (continued) Feature Description Digital Optical Monitoring Not supported. (DOM) support Module front panel LEDs STATUS Green—All diagnostics pass; the module is operational. • Orange—The module is booting or running diagnostics; an •...
Page 155 Chapter 2 Ethernet Switching Modules 1-Gigabit Ethernet Modules Table 2-49 WS-X6748-SFP Physical and Environmental Specifications Item Specification Dimensions (H x W x D) 1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm). Occupies one slot in the chassis. Weight Base module with CFC daughter card (WS-F6700-CFC) installed—9.0 lb (4.1 kg) Base module with DFC daughter card WS-F6700-DFC installed—10.8 lb (4.5 kg)
Page 156 Chapter 2 Ethernet Switching Modules 1-Gigabit Ethernet Modules Table 2-49 WS-X6748-SFP Physical and Environmental Specifications (continued) Item Specification Power and heat numbers Base module + DFC3BXL daughter card (WS-F6700-DFC3BXL) • (continued) Module current—8.62 A – Module power—362.04 W – AC-input power—452.55 W –...
Page 157: Ws-X6816-Gbic
Chapter 2 Ethernet Switching Modules 1-Gigabit Ethernet Modules WS-X6816-GBIC The WS-X6816-GBIC Ethernet module (Figure 2-23) provides 16 1-Gbps full- or half-duplex ports. Table 2-50 lists the module features, and Table 2-51 lists the module physical and environmental specifications. Figure 2-23 WS-X6816-GBIC Switching Module Front Panel WS-X6816-GBIC 16 PORT GIGABIT ETHERNET...
Page 158 Chapter 2 Ethernet Switching Modules 1-Gigabit Ethernet Modules Table 2-50 WS-X6816-GBIC Ethernet Module Features (continued) Feature Description Software support With Supervisor Engine 720-10GE—12.2(33)SXH • With Supervisor Engine 720—12.2(14)SX • With Supervisor Engine 2—12.2(17d)SXB • With Supervisor Engine 2—12.1(8a)E • With CWDM GBIC and WS-G5483 GBIC Note support—12.1(13)E.
Page 159 Chapter 2 Ethernet Switching Modules 1-Gigabit Ethernet Modules Table 2-50 WS-X6816-GBIC Ethernet Module Features (continued) Feature Description Digital Optical Monitoring Supported on some GBIC transceivers. (DOM) support Refer to your software release notes for specific information on Note which GBIC transceivers support DOM and the software release required for support.
Page 160 Chapter 2 Ethernet Switching Modules 1-Gigabit Ethernet Modules Table 2-51 WS-X6816-GBIC Physical and Environmental Specifications Item Specification Dimensions (H x W x D) 1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm). Occupies one slot in the chassis. Weight Base module—9.2 lb (4.2 kg) Power and heat numbers...
Page 161: 10-Gigabit Ethernet Modules
Chapter 2 Ethernet Switching Modules 10-Gigabit Ethernet Modules 10-Gigabit Ethernet Modules This section describes the following 10-Gigabit Ethernet modules: WS-X6704-10GE Ethernet Module, page 2-87 • WS-X6708-10G-3C and WS-X6708-10G-3CXL Ethernet Modules, page 2-92 • WS-X6716-10G-3C and WS-X6716-10G-3CXL Ethernet Modules, page 2-96 •...
Page 162 Chapter 2 Ethernet Switching Modules 10-Gigabit Ethernet Modules Table 2-52 WS-X6704-10GE Ethernet Module Features (continued) Feature Description Supervisor engine support Supported on the following supervisor engines: Supervisor Engine 720 • Supervisor Engine 720-10GE • Software support With Supervisor Engine 720—12.2(17a)SX •...
Page 163 Chapter 2 Ethernet Switching Modules 10-Gigabit Ethernet Modules Table 2-52 WS-X6704-10GE Ethernet Module Features (continued) Feature Description Digital Optical Monitoring Supported on some XENPAK transceivers. (DOM) support Refer to your software release notes for specific information on Note which XENPAK transceivers support DOM and the software release required for support.
Page 164 Chapter 2 Ethernet Switching Modules 10-Gigabit Ethernet Modules Table 2-53 WS-X6704-10GE Ethernet Module Physical and Environmental Specifications Item Specification Dimensions 1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm). Occupies one slot in the chassis. Weight Base module + CFC daughter card (WS-F6700-CFC)—9.0 lb (4.08 kg) Power and heat numbers WS-X6704-10GE (base module + CFC daughter card): •...
Page 165 Chapter 2 Ethernet Switching Modules 10-Gigabit Ethernet Modules Table 2-53 WS-X6704-10GE Ethernet Module Physical and Environmental Specifications (continued) Item Specification Power and heat numbers WS-X6704-10GE (base module + DFC3C daughter card): • (continued) Module current—7.93 A – Module power—333.06 W –...
Page 166: Ws-X6708-10G-3C And Ws-X6708-10G-3Cxl Ethernet Modules
Chapter 2 Ethernet Switching Modules 10-Gigabit Ethernet Modules WS-X6708-10G-3C and WS-X6708-10G-3CXL Ethernet Modules The WS-X6708-10G-3C and WS-X6708-10G-3CXL Ethernet module (Figure 2-25) provides 8 10-Gbps full- or half-duplex ports. Table 2-52 lists the module features, and Table 2-53 lists the module physical and environmental specifications.
Page 167 X2 transceivers. Note The WS-6708-10GE does not support X2 transceivers shipped prior to the release of the WS-X6708-10GE with Cisco IOS Release 12.2(18)SXF5. The unsupported X2 transceivers are labeled with a number that ends with -01. This restriction does not apply to the X2-10GB-LRM transceiver.
Page 168 Chapter 2 Ethernet Switching Modules 10-Gigabit Ethernet Modules Table 2-54 WS-X6708-10G-3C and WS-X6708-10G-3CXL Ethernet Module Features (continued) Feature Description Digital Optical Monitoring Supported on some X2 transceivers. (DOM) support Refer to your software release notes for specific information on Note which X2 transceivers support DOM and the software release required for support.
Page 169 Chapter 2 Ethernet Switching Modules 10-Gigabit Ethernet Modules Table 2-55 WS-X6708-10G-3C and WS-X6708-10G-3CXL Ethernet Module Physical and Environmental Specifications Item Specification Dimensions 1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm). Occupies one slot in the chassis. Weight 16.0 lb (7.26 kg) Power and heat numbers...
Page 170: Ws-X6716-10G-3C And Ws-X6716-10G-3Cxl Ethernet Modules
Chapter 2 Ethernet Switching Modules 10-Gigabit Ethernet Modules WS-X6716-10G-3C and WS-X6716-10G-3CXL Ethernet Modules The WS-X6716-10G-3C and WS-X6716-10G-3CXL Ethernet modules (Figure 2-26) provide 16 10-Gbps full- or half-duplex ports. Table 2-56 lists the module features, and Table 2-57 lists the module physical and environmental specifications.
Page 171 Chapter 2 Ethernet Switching Modules 10-Gigabit Ethernet Modules Table 2-56 WS-X6716-10G-3C and WS-X6716-10G-3CXL Ethernet Module Features (continued) Feature Description Supervisor engine support Supported on the following supervisor engines: Supervisor Engine 720 • Supervisor Engine 720-10GE • Software support With Supervisor Engine 720—12.2(33)SXH2 •...
Page 172 X2 transceivers. WS-6716-10GE does not support X2 transceivers shipped prior Note to the release of the WS-X6708-10GE with Cisco IOS Release 12.2(18)SXF5. The unsupported X2 transceivers are labeled with a number that ends with -01. This restriction does not apply to the X2-10GB-LRM transceiver.
Page 173 Chapter 2 Ethernet Switching Modules 10-Gigabit Ethernet Modules Table 2-57 WS-X6716-10G-3C and WS-X6716-10G-3CXL Ethernet Module Physical and Environmental Specifications Item Specification Dimensions 1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm). Occupies one slot in the chassis. Weight 13.0 lb ( kg) (Excludes weight of X2 transceivers) Power and heat numbers...
Page 174: Ws-X6716-10T-3C And Ws-X6716-10T-3Cxl Ethernet Modules
Chapter 2 Ethernet Switching Modules 10-Gigabit Ethernet Modules WS-X6716-10T-3C and WS-X6716-10T-3CXL Ethernet Modules The WS-X6716-10T-3C and WS-X6716-10T-3CXL Ethernet modules (Figure 2-27) provide 16 10-Gbps full- or half-duplex copper ports. Table 2-58 lists the module features, and Table 2-59 lists the module physical and environmental specifications.
Page 175 Chapter 2 Ethernet Switching Modules 10-Gigabit Ethernet Modules Table 2-58 WS-X6716-10T-3C and WS-X6716-10T-3CXL Ethernet Module Features (continued) Feature Description Buffer size Oversubscription mode—90 MB per port group • Performance mode—200 MB per port • Number of egress queues: 8 • Number of ingress queues: 8 •...
Page 176 Chapter 2 Ethernet Switching Modules 10-Gigabit Ethernet Modules Table 2-58 WS-X6716-10T-3C and WS-X6716-10T-3CXL Ethernet Module Features (continued) Feature Description Module upgrades available PoE support Not supported. Distributed forwarding • WS-X6716-10T-3C comes factory-equipped with a DFC3C support daughter card. WS-X6716-10T-3CXL comes factory-equipped with a DFC3CXL •...
Page 177 Chapter 2 Ethernet Switching Modules 10-Gigabit Ethernet Modules Table 2-59 WS-X6716-10T-3C and WS-X6716-10T-3CXL Ethernet Module Physical and Environmental Specifications Item Specification Dimensions 1.2 x 14.4 x 16 in. (3.0 x 35.6 x 40.6 cm). Occupies one slot in the chassis. Weight 17.71 lb (8.03 kg) Power and heat numbers...
Page 178 Chapter 2 Ethernet Switching Modules 10-Gigabit Ethernet Modules Catalyst 6500 Series Ethernet Modules Installation Guide 2-104 OL-6265-03...
Page 179: Safety
C H A P T E R Installing Ethernet Switching Modules This chapter describes how to safely install, remove, and verify the operation of the Ethernet switching modules in the Catalyst 6500 series switches, and it contains these sections: Safety, page 3-1 •...
Page 180: C H A P T E R 3 Installing Ethernet Switching Modules
Chapter 3 Installing Ethernet Switching Modules Installing an Ethernet Switching Module During this procedure, wear grounding wrist straps to avoid ESD damage to the card. Do not directly Warning touch the backplane with your hand or any metal tool, or you could shock yourself. Statement 93 Invisible laser radiation may be emitted from disconnected fibers or connectors.
Page 181 Chapter 3 Installing Ethernet Switching Modules Installing an Ethernet Switching Module Step 3 Verify that there is enough clearance to accommodate any interface equipment, such as pluggable transceivers, that you will install directly to the module ports. If possible, install modules between empty slots that contain only module filler plates.
Page 182 Chapter 3 Installing Ethernet Switching Modules Installing an Ethernet Switching Module Figure 3-1 Positioning the Module in a Horizontal Slot Chassis Insert module between slot guides EMI gasket WS-X6K-SUP2-2 GE Switch Load 100% CONSOLE PORT PORT 1 PORT 2 MODE CONSOLE SUPERVISOR2 PCMCIA...
Page 183 Chapter 3 Installing Ethernet Switching Modules Installing an Ethernet Switching Module Using the thumb and forefinger of each hand, grasp the two ejector levers and gently press down to create a small 0.040 inch (1 mm) gap between the module’s EMI gasket and the module or cover plate above it.
Page 184 For more information about the orange or red STATUS LED states, see the LED table for your specific module in Chapter 2. Note You should install switching-module filler plates (Cisco part number 800-00292-01) in any empty slots to maintain consistent airflow through the switch chassis. Figure 3-3...
Page 185 Chapter 3 Installing Ethernet Switching Modules Installing an Ethernet Switching Module Figure 3-4 Positioning the Module in a Vertical Slot Chassis Ejector lever fully extended STATUS gasket gasket INPUT OUTPUT FAIL INPUT OUTPUT FAIL Insert module between slot guides Catalyst 6500 Series Ethernet Modules Installation Guide OL-6265-03...
Page 186 Chapter 3 Installing Ethernet Switching Modules Installing an Ethernet Switching Module Figure 3-5 Clearing the EMI Gasket in a Vertical Slot Chassis Gap between the module EMI gasket and the module above it 1 mm STATUS Press left Press left INPUT OUTPUT FAIL...
Page 187 For more information about the orange or red STATUS LED states, see the LED table for your specific module in Chapter 2. You should install switching-module filler plates (Cisco part number 800-00292-01) in any empty slots Note to maintain consistent airflow through the switch chassis.
Page 188: Removing An Ethernet Switching Module
Chapter 3 Installing Ethernet Switching Modules Removing an Ethernet Switching Module Removing an Ethernet Switching Module This section describes how to remove an Ethernet switching module from the Catalyst 6500 series switch chassis. During this procedure, wear grounding wrist straps to avoid ESD damage to the module. Caution Warning Invisible laser radiation may be emitted from disconnected fibers or connectors.
Page 189: Installing Pluggable Transceivers
Chapter 3 Installing Ethernet Switching Modules Installing Pluggable Transceivers Step 6 Place the removed module on an antistatic mat or in an antistatic bag, or immediately reinstall it in another slot. Step 7 If the slot is to remain empty, install a module filler plate to keep dust out of the chassis and to maintain proper airflow through the chassis.
Page 190 Fiber-optic end-face cleaning tools and inspection equipment. For information on inspecting and • cleaning fiber-optic interfaces, see the document at this URL: tap://www.cisco.com/en/US/tech/tk482/tk607/technologies_white_paper09186a0080254eba.shtml During this procedure, wear an ESD grounding strap to avoid ESD damage to the module. Caution Warning Invisible laser radiation may be emitted from disconnected fibers or connectors.
Page 191 Chapter 3 Installing Ethernet Switching Modules Installing Pluggable Transceivers Figure 3-7 Installing an Optical GBIC Transceiver (Plug Shown Removed for Clarity) GBIC Squeeze in clips and slide GBIC into slot Plug Figure 3-8 Installing a Copper (1000BASE-T) GBIC Transceiver Squeeze in clips and slide GBIC into slot GBIC...
Page 192: Installing Sfp Transceivers
Chapter 3 Installing Ethernet Switching Modules Installing Pluggable Transceivers Figure 3-9 GBIC Transceiver Body Alignment Grooves Alignment groove Alignment groove Installing SFP Transceivers SFP transceivers provide an interface between an optical or copper network and the switching module. There are different types of SFP transceivers, but all share the same form factor. For additional information on SFP transceiver types, including recommended cabling distances, see Appendix B.
Page 193 Antistatic mat or an antistatic bag to set the unpackaged SFP transceiver on. • • Fiber-optic end-face cleaning tools and inspection equipment. For information on inspecting and cleaning fiber-optic interfaces, see the document at this URL: http://www.cisco.com/en/US/tech/tk482/tk607/technologies_white_paper09186a0080254eba.shtml Catalyst 6500 Series Ethernet Modules Installation Guide 3-15 OL-6265-03...
Page 194 SFP transceiver connector (transmit direction or TX) and toward the connector (receive direction or RX). Different Cisco modules have different SFP module socket configurations. Your module could Note have either a latch-up or a latch-down orientation. Ensure that you are installing the SFP transceiver in the correct orientation for your Cisco device.
Page 195 Chapter 3 Installing Ethernet Switching Modules Installing Pluggable Transceivers Step 3 Insert the SFP transceiver into the socket and slide it in until you feel the SFP transceiver connector snap into place in the socket connector. (See Figure 3-13.) On SFP transceivers equipped with bale clasps, you must remove the dust plugs from the optical bores in order to pivot the bale clasp down (unlocked position).
Page 196: Installing 10Gbase Xenpak Transceivers
Fiber-optic end-face cleaning tools and inspection equipment. For complete information on • inspecting and cleaning fiber-optic connections, refer to the document at this URL: http://www.cisco.com/en/US/tech/tk482/tk607/technologies_white_paper09186a0080254eba.shtml Caution During this procedure, wear grounding wrist straps to avoid ESD damage to the module.
Page 197: Installing 10Gbase X2 Transceivers
• Fiber-optic end-face cleaning tools and inspection equipment. For complete information on inspecting and cleaning fiber-optic connections, see the document at this URL: http://www.cisco.com/en/US/tech/tk482/tk607/technologies_white_paper09186a0080254eba.shtml During this procedure, wear grounding wrist straps to avoid ESD damage to the module. Caution Invisible laser radiation may be emitted from disconnected fibers or connectors. Do not stare into Warning beams or view directly with optical instruments.
Page 198 X2 transceivers. Refer to the module descriptions in Chapter 2 for details. Figure 3-15 for the location of the part number label on the X2 transceiver body. Figure 3-15 X2 Transceiver Part Number Label X2-10GB-XX Cisco part number 10-XXXX-XX Class 1 Laser 21 CFR 1040.10 LN#50 07/2001 Made In COUNTRY...
Page 199 Chapter 3 Installing Ethernet Switching Modules Installing Pluggable Transceivers Step 4 Insert the X2 transceiver into the transceiver socket on the system module front panel. (See Figure 3-16, top view.) Continue sliding the X2 transceiver into the socket until the X2 transceiver EMI gasket is flush against the system module faceplate.
Page 200: Attaching The Network Interface Cables
Step 2 For complete information on inspecting and cleaning fiber-optic connections, see the document at this URL: http://www.cisco.com/en/US/tech/tk482/tk607/technologies_white_paper09186a0080254eba.shtml Remove the dust plugs from the transceiver optical bores. Step 3 If you are using the LX/LH GBIC with MMF, you need to install a patch cord between the GBIC Note and the MMF cable.
Page 201: Mode-Conditioning Patch Cord
Chapter 3 Installing Ethernet Switching Modules Attaching the Network Interface Cables Mode-Conditioning Patch Cord A mode-conditioning patch cord is recommended for use with an LX/LH GBIC or an LX/LH SFP transceiver and MMF to allow reliable laser transmission. When an unconditioned laser source designed for operation on single-mode optical fiber is directly coupled to a multimode optical fiber cable, an effect known as differential mode delay (DMD) might result in a degradation of the modal bandwidth of the optical fiber cable.
Page 202 Chapter 3 Installing Ethernet Switching Modules Attaching the Network Interface Cables Figure 3-18 Mode Conditioning Patch Cord with LC (SFP Transceiver) Connector Offset Gray color identifier To gigabit Ethernet interface Blue color identifier Multimode fiber Single-mode fiber Offset junction Beige color identifier To cable plant The mode-conditioning patch cord assembly is composed of duplex optical fibers, including a single-mode-to-multimode offset launch fiber connected to the transmitter, and a second conventional...
Page 203: Connecting Transceivers To A Copper Network
Verifying the Installation This section describes how to verify the installation of a supervisor engine or switching module. To verify the installation of a Catalyst 6500 series switch running Cisco IOS software, see the Catalyst 6500 Series Switch IOS Software Configuration Guide.
Page 204: Verifying Newly Installed Modules
Chapter 3 Installing Ethernet Switching Modules Verifying the Installation Verifying Newly Installed Modules Enter the show module or show port [mod_num/port_num] command to verify that the system acknowledges the new modules and has brought them online. This example shows the output of the show module command: Console>...
Page 205: Checking Connectivity
For complete information on configuring the modules, see the Catalyst 6500 Series Switch Software Configuration Guide or the Catalyst 6500 Series Switch Cisco IOS Software Configuration Guide. For information on all Catalyst 6500 series switch commands, see the Catalyst 6500 Series Switch Command Reference or the Catalyst 6500 Series Switch Cisco IOS Command Reference publications.
Page 206 Chapter 3 Installing Ethernet Switching Modules What To Do After Installing Modules and Verifying Connectivity Catalyst 6500 Series Ethernet Modules Installation Guide 3-28 OL-6265-03...
Page 207: Appendix
PoE Daughter Card Description Supported on Ethernet Maximum Module Power per Port (Watts) WS-F6K-VPWR= Cisco prestandard PoE daughter card for 10/100 WS-X6148-RJ-21 • and 10/100/1000 Ethernet modules. Provides WS-X6148-RJ-21V • 48 VDC over Category 5, Category 5e, or WS-X6148-RJ-45 •...
Page 208 Appendix A Ethernet Module Daughter Cards PoE Daughter Cards Table A-1 PoE Daughter Card Support (continued) PoE Daughter Card Description Supported on Ethernet Maximum Module Power per Port (Watts) WS-F6K-GE48-AF= IEEE 802.3af-compliant PoE daughter card for • WS-X6148-GE-TX 15.4 10/100 and 10/100/1000 Ethernet modules. •...
Page 209: Centralized And Distributed Forwarding Daughter Cards
Appendix A Ethernet Module Daughter Cards Centralized and Distributed Forwarding Daughter Cards Centralized and Distributed Forwarding Daughter Cards The centralized forwarding card (CFC) and the distributed forwarding cards (DFC) can be installed on select Ethernet switching modules in the field to upgrade the modules to support local switching. There is one CFC and six DFC daughter cards available for installation on Catalyst 6500 series modules.
Page 210 • • WS-X6716-10G-3C Ethernet modules. It is an option for all other CEF720 WS-X6716-10T-3C 1 GB • • linecards beginning with Cisco IOS • WS-X6724-SFP • 512 MB Release 12.2(33)SXH. This daughter card is supported only by the Supervisor •...
Page 211 Appendix A Ethernet Module Daughter Cards Centralized and Distributed Forwarding Daughter Cards Table A-3 lists the supported combinations of WS-F6K-DFC3 daughter cards with the Supervisor Engine 720 models and the corresponding functionality levels. Table A-3 WS-F6K-DFC Daughter Card Functionality Levels Supervisor Engine 720 WS-F6K-DFC3A WS-F6K-DFC3B...
Page 212 Appendix A Ethernet Module Daughter Cards Centralized and Distributed Forwarding Daughter Cards Catalyst 6500 Series Ethernet Modules Installation Guide OL-6265-03...
Page 213: Appendix
A P P E N D I X Pluggable Transceiver Modules This appendix provides descriptions and specifications for the pluggable transceiver modules that are supported on the Catalyst 6500 series Ethernet switching modules. The appendix is divided into these topics: 100-MB Transceivers, page B-1 •...
Page 214 Appendix B Pluggable Transceiver Modules 100-MB Transceivers Table B-1 100-MB SFP Transceiver Cabling Specifications 100-MB SFP Description Interface Nominal Network Fiber Core Cable Transceiver Product Connector Wavelength Cable Type Size Distance Number (nm) (micron) GLC-FE-100FX 100BASE-FX SFP for Dual LC 1310 50/62.5 1.24 miles...
Page 215: 1-Gb Transceivers
Appendix B Pluggable Transceiver Modules 1-GB Transceivers Table B-2 Fiber Loss Budgets for the 100-MB SFP Transceivers (continued) 100-MB SFP Transceiver Transmit (dBm) Receive (dBm) Product Number GLC-FE-100EX 0 (maximum) –8 (maximum) –5 (minimum) –28 (minimum) GLC-FE-100ZX 2 (maximum) –8 (maximum) –3 (minimum) –30 (minimum) Table B-3...
Page 216: 1-Gb Gbic Transceivers
Appendix B Pluggable Transceiver Modules 1-GB Transceivers 1-GB GBIC Transceivers Figure B-2 shows a 1000BASE-T (copper) GBIC transceiver. Figure B-3 shows a 1000BASE-X (optical) GBIC transceiver. Table B-5 lists the cabling specifications for the GBIC transceivers. Figure B-2 1000BASE-T GBIC Transceiver (WS-G5483) RJ-45 Plastic tab connector...
Page 217 Appendix B Pluggable Transceiver Modules 1-GB Transceivers Table B-5 GBIC Transceiver Module Cabling Specifications (continued) GBIC Transceiver Interface Nominal Network Fiber Core Modal Bandwidth Cable Distance Model and Product Connector Wavelength Cable Type Size (MHz km) Number (nm) (micron) 1000BASE-LX/LH SC duplex 1310 62.5...
Page 218: 1-Gb Sfp Transceivers
Appendix B Pluggable Transceiver Modules 1-GB Transceivers Table B-7 lists the physical and environmental specifications for the GBIC transceivers. Table B-7 1-GB GBIC Transceiver Physical and Environmental Specifications Item Specification Dimensions (H x W x D) 0.75 x 1.54 x 3.50 in. (19.0 x 39.1 x 88.9 mm) Operating temperature 32°...
Page 219 Appendix B Pluggable Transceiver Modules 1-GB Transceivers Table B-8 SFP Transceiver Cabling Specifications SFP Transceiver Interface Nominal Network Fiber Core Modal Cable Distance Module and Product Connector Wavelength Cable Type Size Bandwidth Number (nm) (micron) (MHz/km) 1000BASE-T RJ-45 — Category 5, —...
Page 220: 10-Gb Transceivers
Storage temperature –40° to 185°F (–40° to 85°C) You can use any combination of SFP modules that your Cisco device supports. The only restrictions are Note that each SFP port must match the wavelength specifications on the other end of the cable and that the cable must not exceed the stipulated cable length for reliable communications.
Page 221 Appendix B Pluggable Transceiver Modules 10-GB Transceivers XENPAK Transceivers XENPAK transceivers are supported in the WS-X6704-10GE 10-Gigabit Ethernet module. Figure B-6 shows the form-factor of the XENPAK transceiver. Table B-12 lists the optical and the cabling distance specifications for the XENPAK transceivers. Note The dual SC connector on the X2 transceivers support network interface cables with either Physical Contact (PC) or Ultra-Physical Contact (UPC) polished face types.
Page 222 6. The XENPAK-10GB-LW (WAN PHY) supports a link length of 6.2 miles (10 km) on standard SMF (G.652). 7. Requires a 5 db 1550 nm fixed loss attenuator for cable distances less than 12.43 miles (20 km). The attenuator is available from Cisco Systems...
Page 223 Appendix B Pluggable Transceiver Modules 10-GB Transceivers Table B-13 lists the fiber loss budgets for the 10-GB XENPAK transceivers. Table B-13 Fiber Loss Budgets for the 10-GB XENPAK Transceivers 10-GB XENPAK Transceiver Transmit (dBm) Receive (dBm) Product Number XENPAK-10GB-SR –1.2 (maximum) –1 (maximum) –7.3 (minimum)
Page 224: X2 Transceivers
X2-10GB-SR—10GBASE-SR serial 850-nm short-reach multimode fiber (MMF). No restrictions • for use. Figure B-7 X2 Transceiver Serial Number Label Locator X2-10GB-XX Cisco part number 10-XXXX-XX Class 1 Laser 21 CFR 1040.10 LN#50 07/2001 Made In COUNTRY SN: LLLYYWWSSSS XXXXXXXXXX...
Page 225 Appendix B Pluggable Transceiver Modules 10-GB Transceivers Figure B-8 shows the X2 transceivers with the major features identified. Table B-15 lists the cabling specifications for the X2 transceivers. Figure B-8 10-GB X2 Transceiver Latching sleeve retracted; latch extended Latching sleeve extended; latch retracted Transmit optical bore Module connector...
Page 226 CAB-MCP50-SC= (mode conditioning patch cable 50 microns, dual SC connectors). No mode conditioning patch cord is required for applications using OM3. 5. Requires a 5 db 1550 nm fixed loss attenuator for cable distances less than 12.43 miles (20 km). The attenuator is available from Cisco Systems (p/n WS-X6K-5DB-ATT=)
Page 227: Wdm Transceivers
Appendix B Pluggable Transceiver Modules WDM Transceivers Table B-16 lists the fiber loss budgets for the 10-GB X2 transceivers. Table B-16 X2 Transceiver Optical Transmit and Receive Specifications X2 Transceiver Product Transmit Power (dBm) Receive Power (dBm) Number X2-10GB-LRM 0.5 (max) 0.5 (max) –6.5 (min) –8.4 (min) (In average)
Page 228 • transmitter in the GBIC. The receiver WS-X6816-GBIC • can be used for all wavelengths supported by Cisco CWDM and DWDM transceivers and can be used interchangeably with 1000BASE-SX, 1000BASE-LX/LH, and 1000BASE-ZX transceivers on a port-by-port basis. The W/O WDM receiver has a single SC connector.
Page 229 DWDM transport network; there is no transmitter in the XENPAK. The receiver can be used for all wavelengths supported by Cisco DWDM XENPAK transceivers. The W/O WDM receiver has a single SC connector. 1. Not all WDM transceivers may be supported on the modules. Refer to your software release notes for specific information on which WDM transceivers are supported and the software release level necessary to support them.
Page 230 Appendix B Pluggable Transceiver Modules WDM Transceivers Figure B-9 CWDM GBIC Transceiver Color arrow on label Optical bore dust plug Alignment groove Receive optical bore Spring clip Color dot Transmit optical bore Table B-19 CWDM GBIC Transceivers Wavelengths Model Number Color Code CWDM GBIC Wavelength CWDM-GBIC-1470=...
Page 231 Appendix B Pluggable Transceiver Modules WDM Transceivers Table B-20 DWDM GBIC Transceiver Product Numbers and ITU Channel Numbers DWDM GBIC Description ITU Channel Product Number DWDM-GBIC-60.61 1000BASE-DWDM 1560.61 nm GBIC DWDM-GBIC-59.79 1000BASE-DWDM 1559.79 nm GBIC DWDM-GBIC-58.98 1000BASE-DWDM 1558.98 nm GBIC DWDM-GBIC-58.17 1000BASE-DWDM 1558.17 nm GBIC DWDM-GBIC-56.55...
Page 232 Appendix B Pluggable Transceiver Modules WDM Transceivers Table B-21 CWDM SFP Transceivers Model Number Color Code CWDM GBIC Wavelength CWDM-SFP-1470= Gray 1470 nm laser, single-mode CWDM-SFP-1490= Violet 1490 nm laser, single-mode CWDM-SFP-1510= Blue 1510 nm laser, single-mode CWDM-SFP-1530= Green 1530 nm laser, single-mode CWDM-SFP-1550= Yellow 1550 nm laser, single-mode...
Page 233 Appendix B Pluggable Transceiver Modules WDM Transceivers Table B-22 DWDM XENPAK Transceiver Module Product Numbers and ITU Channel Numbers (continued) DWDM XENPAK Description ITU Channel Product Number DWDM-XENPAK-54.13 1000BASE-DWDM 1554.13 nm XENPAK DWDM-XENPAK-52.52 1000BASE-DWDM 1552.52 nm XENPAK DWDM-XENPAK-51.72 1000BASE-DWDM 1551.72 nm XENPAK DWDM-XENPAK-50.92 1000BASE-DWDM 1550.92 nm...
Page 234 Appendix B Pluggable Transceiver Modules WDM Transceivers Table B-22 DWDM XENPAK Transceiver Module Product Numbers and ITU Channel Numbers (continued) DWDM XENPAK Description ITU Channel Product Number DWDM-XENPAK-34.25 1000BASE-DWDM 1534.25 nm XENPAK DWDM-XENPAK-32.68 1000BASE-DWDM 1532.68 nm XENPAK DWDM-XENPAK-31.90 1000BASE-DWDM 1531.90 nm XENPAK DWDM-XENPAK-31.12 1000BASE-DWDM 1531.12 nm...
Page 235: Appendix
A P P E N D I X ESD Precautions This appendix provides information on preventing ESD when removing and installing modules in a chassis. Attaching Your ESD Grounding Strap Electrostatic discharge (ESD) damage, which can occur when modules or other FRUs are improperly handled, results in intermittent or complete failures.
Page 236 Appendix C ESD Precautions Attaching Your ESD Grounding Strap After you install the system ground lug, follow these steps to correctly attach the ESD wrist strap: Attach the ESD wrist strap to bare skin as follows: Step 1 If you are using the ESD wrist strap supplied with the FRUs, open the wrist strap package and unwrap the ESD wrist strap.
Page 237 Appendix C ESD Precautions Attaching Your ESD Grounding Strap Figure C-1 Attaching the ESD Wrist Strap Clip to the System Ground Lug Screw Clip ESD ground Grounding lug strap Screw Side view of Slide clip grounding lug behind screw Clip installed System ground behind screw connector...
Page 238 Appendix C ESD Precautions Attaching Your ESD Grounding Strap Catalyst 6500 Series Ethernet Modules Installation Guide OL-6265-03...
Page 239: I N D E X
I N D E X modules supported on Numerics optical transmit and receive specifications B-15 10/100 and 10/100/1000BASE modules physical and environmental specifications table B-15 WS-X6148A-GE-TX 2-14 to 2-19 XENPAK transceivers B-8 to B-11 WS-X6148-GE-TX 2-14 to 2-19 modules supported on WS-X6148-RJ21 2-19 to 2-22 physical form (figure)
Page 240 Index altitude, operating 1-10 form factor, front view (figure) 1-11 chassis, dimensions form factor, rear view (figure) 1-10 1-11 environmental specifications humidity, operating 1-10 1-14 fantrays supported physical characteristics 1-10 1-14 features table port densities supported 1-13 form factor, front view (figure) slot numbering 1-12 form factor, rear view (figure)
Page 241 Index supervisor engines supported 1-17 fan trays supported 1-39 temperature, operating features table 1-19 1-35 weight form factor (figure) 1-19 1-35 Catalyst 6509-E switches humidity, operating 1-39 airflow 1-34 physical characteristics 1-39 altitude, operating port densities supported 1-34 1-38 chassis dimensions slot numbering 1-34 1-36...
Page 242 Index supervisor engines supported 1-47 show port 3-26 temperature, operating connectivity 1-48 weight checking 1-48 3-27 Catalyst 6513-E switches conventions, documentation 1-vi airflow 1-58 CWDM GBIC transceivers altitude, operating description 1-58 B-16 chassis dimensions modules supported on 1-58 B-16 environmental specifications physical form (figure) 1-58 B-18...
Page 243 Index product numbers and ITU channel numbers B-19 WS-X6324-100FX-SM DWDM XENPAK transceivers WS-X6348-RJ21V 2-38 description WS-X6348-RJ45 B-17 2-41 modules supported on WS-X6408A-GBIC B-17 2-63 physical form (figure) B-22 WS-X6416-GBIC 2-66 product numbers and ITU channel numbers WS-X6516A-GBIC B-20 2-69 WS-X6516-GBIC 2-69 WS-X6516-GE-TX 2-44...
Page 244 Index WS-X6548-RJ-45 2-56 WS-X6704-10GE 2-90 modules WS-X6708-10G-3C 2-95 blank module carriers 3-6, 3-9 WS-X6708-10G-3CXL 2-95, 2-99 WS-X6716-10G-3C 2-99 WS-X6716-10T-3C 2-103 WS-X6716-10T-3CXL 2-103 WS-X6724-SFP organization, document 2-76 WS-X6748-GE-TX 2-61 WS-X6748-SFP 2-81 WS-X6816-GBIC 2-86 physical characteristics physical and enviromental specifications tables Catalyst 6503-E switches 1-10 transceivers Catalyst 6503 switches...
Page 245 Index transceivers 1-GB transceivers B-3 to B-8 SFP transceivers Also see specific transceiver type 100-MB SFP transceivers B-1 to B-3 cabling specifications (table) description physical and environmental specifications verifying installation 3-26 table physical form (figure) 1-GB SFP transceivers B-3 to B-8 cabling specifications (table) warnings modules supported on...
Page 246 Index R/O WDM XENPAK transceivers See WS-X6148-RJ-45 description WS-X6148A-GE-45AF B-17 modules supported on See WS-X6148A-GE-TX B-17 weight WS-X6148A-GE-TX 2-14 to 2-19 Catalyst 6503-E switches 1-10 altitude, operating 2-19 Catalyst 6503 switches dimensions 2-17 Catalyst 6504-E switches features table 1-14 2-15 Catalyst 6506-E switches front panel (figure) 2-14...
Page 247 Index WS-X6148-GE-45AF altitude, operating 2-28 See WS-X6148-GE-TX dimensions 2-27 WS-X6148-GE-TX features table 2-14 to 2-19 2-24 altitude, operating front panel (figure) 2-19 2-23 dimensions 2-17 humidity, operating 2-28 features table LEDs 2-15 2-26 front panel (figure) module variants 2-14 2-23 humidity, operating network connector type 2-19...
Page 248 Index temperature, operating 2-33 upgrades available transceivers supported weight 2-31 upgrades available WS-X6324-100FX-SM 2-31 2-7 to 2-9 weight, module altitiude, operating 2-33 weight, splitter panel 2-33 dimensions WS-X6196-21AF features table See WS-X6196-RJ-21 front panel (figure) WS-X6196-RJ-21 humidity, operating 2-34 to 2-37 altitude, operating 2-37 LEDs...
Page 249 Index features table 2-41 network connector type 2-66 front panel (figure) physical and environmental specifications table 2-40 2-68 humidity, operating ports 2-43 2-66 LEDs power requirement 2-42 2-68 network connector type 2-41 supervisor engine support 2-67 physical and environmental specifications table temperature, operating 2-43 2-68...
Page 250 Index temperature, operating 2-73 See WS-X6548-GE-TX transceivers supported WS-X6548-GE-TX 2-70 2-47 to 2-50 upgrades available altitude, operating 2-70 2-50 weight dimensions 2-71 2-50 WS-X6516-GE-TX 2-44 to 2-46 environmental specifications table 2-50 altitude, operating features table 2-46 2-47 dimensions front panel (figure) 2-46 2-47 environmental specifications table...
Page 251 Index front panel (figure) 2-54 network connector type 2-92 humidity, operating physical and environmental specifications table 2-57 2-95 LEDs ports 2-56 2-92 network connector type power requirement 2-54 2-95 physical and environmental specifications table 2-56 restrictions, slot and chassis 2-93 ports supervisor engines supported 2-54...
Page 252 Index supervisor engines supported 2-97 WS-X6716-10T-3CXL 2-100 to 2-103 temperature, operating altitude, operating 2-99 2-103 transceivers supported dimensions 2-98 2-103 upgrades available features table 2-97 2-100 weight 2-99 front panel (figure) 2-100 WS-X6716-10G-3CXL humidity, operating 2-96 to 2-99 2-103 altitude, operating LEDs 2-99 2-102...
Page 253 Index humidity, operating 2-62 power requirement 2-86 LEDs restrictions, slot and chassis 2-60 2-84 network connector type supervisor engine support 2-58 2-83 physical and environmental specifications table temperature, operating 2-61 2-86 ports 2-58 transceivers supported 2-84 power requirement upgrades available 2-61 2-84 restrictions, slot and chassis...
Page 254 Index Catalyst 6500 Series Ethernet Modules Installation Guide IN-16 OL-6265-03...

Cisco 6513 - Catalyst Switch Installation Manual

Table of Contents

CHAPTER 1 Catalyst 6500 Series Switch Chassis Overview

Chapter 2 Ethernet Switching Module

Ws-X6148-Rj21 Ethernet Modules

CHAPTER 3 Installing Ethernet Switching Modules

Appendix

Appendix

Appendix

Quick Links

Chapters

Related Manuals for Cisco 6513 - Catalyst Switch

Summary of Contents for Cisco 6513 - Catalyst Switch

Table of Contents
