11.7 Key Pad

KEY 1
R001 3K 1/10W
KEY 2
R002 3K 1/10W
R003 2K OHM 1% 1/10W
R004 2K OHM 1% 1/10W
CN001
6 KEY 2
5 KEY 1
4 POWER
3 BLUE
2 Y ELLOW
1
GND
CONN
GND
ViewSonic Corporation
UP
DOWN
POWER
Y ELLOW
BLUE
SW001 SW002
KEY1
KEY2
T P V ( Top Victory Electronics Co . ,
G2970-A-X-X-2-071229
絬 隔 瓜 絪 腹
Key Component 1. Key board
Thursday , January 03, 2008
Date
- 76 –
Confidential - Do Not Cop
SW3
LED001
POWER
GND
Ltd. ) OEM MODEL
VX2262wm
TPV MODEL
K E P C8 JC5
PCB NAME 715G2970-A
Sheet 2 of 2
SW004 SW005
SW SW
DOWN UP
Size A
Rev C
<称爹>
称爹
VX2262wm/wmp
