EAW SB250zP Specifications

S B 2 5 0 z P S p e c i f i c a t i o n s
DESCRIPTION
The SB products are EAW's premium subwoofers designed for
the most demanding professional applications. A broad range of
capabilities and sizes provide the designer with selections that
can be specifically matched to their application. Top quality
drivers, engineered by EAW, provide the highest output and best
sonic performance possible for a given form factor. All SB
models are direct radiating, with optimally tuned, vented
enclosures. SB subwoofers are the choice where the best sonic
performance, highest reliability, and most robust physical
construction are required.
The SB250zP is a high output, mid-size subwoofer system. This
versatile, all-purpose subwoofer is designed for permanent
installation where the solid-sounding output of dual 15 inch
drivers is desired. The SB250zP works well with most full-range
loudspeakers in a variety of applications including: small houses
of worship, small auditoriums/theaters, A/V systems, hotel
ballrooms, meeting rooms, classrooms, exhibit areas, f/x
reinforcement, cruise ships, cinemas, and small dance clubs.
The SB250zP is designed to be used with today's sophisticated
digital signal processing to optimize the LF response. EAW's MX
Series processors are recommended for the required crossover
and equalization.
Six Year Warranty.
1 To achieve specified performance, the listed external signal processing with EAW-provided settings is required.
2 For recommendations to select power amplifier size refer to : "HOW MUCH AMPLIFIER POWER DO I NEED?" on the EAW web site.
EAW products are continually improved. All specifications are therefore subject to change without notice.
Eastern Acoustic Works One Main Street Whitinsville, MA 01588 tel 800 992 5013 / 508 234 6158 fax 508 234 8251 www.eaw.com
DUAL 15 INCH SUBWOOFER
See NOTES TABULAR DATA for details, half space = floor-mounted
CONFIGURATION
Subsystem
Transducer
SUB 2x 15 in cone
Operating Mode
Amplifier Channels
Single-amp LF1/LF2
Dual-amp LF1, LF2
1
PERFORMANCE
Operating Range 36 Hz to 150 Hz
Nominal Beamwidth
Horz 360°
Vert 360°
Axial Sensitivity (SPL)
LF1/LF2 (whole space) 96 dB
(half space) 102 dB
Input Impedance (ohms)
Nominal
LF1/LF2 4
LF1, LF2 8 (each)
High Pass Filter
High Pass =>30 Hz, 12 dB/octave Butterworth
2
Accelerated Life Test
System LF1/LF2 65 V
LF1, LF2 65 V (each)
Transducer (AES) 700 W (each)
Calculated Axial Output Limit (SPL)
Average
LF1/LF2 (whole space) 127 dB
(half space) 133 dB
ORDERING DATA
Description
SB250zP Dual 15 inch Subwoofer Black
SB250zP Dual 15 inch Subwoofer White
SB250zP Dual 15 inch Subwoofer Black WP
Optional Accessories
3/8-16 Forged Shoulder Eyebolt
group · I
Loading
Vented
External Signal Processing
DSP w/1-way filter
DSP w/1-way filter
36 Hz to 150 Hz
36 Hz to 150 Hz
Minimum
3.7 @ 150 Hz
7.3 @ 150 Hz (each)
1050 W @ 4 ohm
525 W @ 8 ohm (each)
Peak
133 dB
139 dB
Part Number
0008964
0011318
0009050
104001
Part Number: RD0310 (A) SB250zP April 2005
