EAW LA212 Specifications

DESCRIPTION
A 2-way full range system (passive LF/HF crossover) in a
vented dual purpose (main/stage monitor) enclosure. In-
cludes a 12-in woofer and a 2-in exit/3-in voice coil com-
pression driver on a Wave Guide Plate™.
APPLICATIONS
The LA212 integrates with other LA Series loudspeakers to
build an expandable total system. Includes rubber feet and a
stand mount cup for use as a small main and rubber footpads
for use as a stage monitor. Integrated handles and mount-
ing/suspension points. Six Year Warranty.
Applications include:
Ballroom Events
Corporate Events
Band PA
PERFORMANCE
Frequency Response (Hz)
3 db 60Hz to 18kHz
-10 dB 50Hz
Axial Sensitivity (dB SPL/1 Watt/1m)
97
Impedance (Ohms)
8
Power Handling, AES Standard (Watts)
500
Calculated Maximum Output (dB SPL, @ 1m)
Peak 130.0
Long Term 124.0
Nominal Coverage Angle / -6 dB points (degrees)
Conical 90
Recommended Complementary Systems
Sub LA118
EASTERN ACOUSTIC WORKS
One Main Street, Whitinsville, MA 01588 • (508) 234 - 6158 • FAX (508) 234 - 8251 • Email info@eaw.com • Web http://www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. • PUB# LA212-888065 (A)/2 pp/2/1/99 • Printed In USA
SPECIFICATIONS LA212
PHYSICAL
Part Number 999267
Product Group G
LF Subsystem & Loading 1x 12-in, vented
HF Subsystem & Loading 1x 2-in exit/3-in voice coil
compression driver
on Wave Guide Plate™
System Configuration 2-way, full range
Powering Configuration(s) Passive LF/HF crossover
Recommended High-Pass
Frequency (24 dB/Octave) 50 Hz
Cabinet Type (shape) Irregular pentagon (floor monitor)
Enclosure Materials Baltic birch plywood
Finish Black catalyzed polyurethane
Connectors 2x Neutrik NL4 connectors
Suspension Hardware (3) 3/8"-16 threaded mounting/
suspension points (1 top, 2 back),
rubber feet one side and one end,
stand mount cup (bottom)
Grille Vinyl coated perforated steel
Options 179001 flyclip with hook
179002 flyclip with ring
Dimensions inches
Height 24
Width 14.75
Depth 14.75
Minimum Stage Height 14.94
Floor Angle(s) 50 degrees
Weights pounds kilograms
Net Weight 52.0
Shipping Weight 60.0
millimeters
610
375
375
379
23.7
27.3
