Specifications - Sony DSLR-A700K - alpha; Digital Single Lens Reflex Camera Specifications

DSLR-A700K

Specifications

General
Megapixel: 12.24 MP
Imaging Device: 12.24 (effective) APS Exmor™
Sensor; 23.5 x 15.6 mm; RGB primary color filter
Convenience
White Balance: Auto plus 6 Modes (Daylight,
Shade, Cloudy, Tungsten, Fluorescent, Flash);
+/- 3-step adjustable Kelvin temperature control
(2500-9900k w/19-step Magenta/Green
compensation).
Self Timer: Yes (10 seconds, 2 seconds, Off)
Memory Stick PRO™ Media Compatibility: Tested
to support up to 16GB media capacity; does
not support Access Control security function
Red-Eye Reduction: On/Off (all modes)
Burst Mode: Selectable Hi (5FPS) Lo (3FPS); JPEG
Standard/Fine: Unlimited to capacity of
media; JPEG Extra Fine: 8; cRAW (compressed):
24; cRAW+JPEG: 12; RAW: 17; RAW+JPEG: 11.
Color Mode(s): Standard, Vivid, Neutral, Adobe
RGB, Clear, Deep, Light, Portrait, Landscape,
Sunset, Night view, Autumn, B/W, Sepia (Except
for Adobe RGB, all other color modes use the
sRGB color space)
Scene Mode(s): Portrait, Landscape, Macro,
Sports, Sunset, Night view/portrait
Convenience Features
Histogram Display: Yes; RGB display; Playback
only
AF Illuminator Light: Yes, On/Off Select
Multi-Pattern Measuring: 40 segment honeycomb
pattern; Multi-segment, Center Weighted, Spot
Clear RAW NR: N/A
Movie Mode(s): N/A
Inputs and Outputs
USB Port(s): Yes, Supports USB 2.0 Hi-speed
Output(s): Video: Yes, NTSC/PAL Selectable
HD Output: Yes (w/ optional HDMI cable)
Hardware
LCD: 3.0" TFT Xtra Fine™ (921k pixels) LCD
Viewfinder: Optical: TTL, 0.9x magnification with
50mm lens at infinity; 95% coverage
Microphone: N/A
Operating Conditions
Flash Effective Range: Manual popup; Approx.
GN 12 (in meters at ISO 100); Coverage of up
to 16 mm (in focal length); Approx. 3 sec.
recycling time; Flash-ready indicator.
Flash Mode(s): Manual Pop-up: Auto, Fill-flash,
Rear flash sync, Wireless off camera flash (with
Flash HVL-F56AM, F36AM)
Optics/Lens
Focus: Auto Focus: TTL Phase Detection, Multi-
point: 11 Area, 11 Line, 5 center twin-cross lines,
Auto Focus Mode: Yes, Wide focus area (Auto,
11 areas), Spot focus area, Local focus area
(11 local areas selectable), Visual Focus
Confirm: Direct via VF Matte Screen, Manual
Focus: Yes
Shutter Speed: 30 < 1/8000 sec 55 step, Bulb
EV Compensation: ±3.0 EV, 0.3 EV / 0.5 EV steps
selectable
Exposure: Manual Exposure: Yes, w/EV indicator,
Manual Exposure: Yes; Aperture/Shutter Priority,
Manual, Program Shift: Yes, Command Dial
Lens Type: Interchangeable A-mount
Power
Battery Type: NP-FM500H Lithium-ion rechargeable
battery
Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Battery Capacity: 7.2V, CIPA standard: approx.
3
650 pictures
Software
Supplied Software: Image Data Converter SR
ver.2.0, Image Data Lightbox SR ver.1.0,
Remote Camera Control ver.1.0 (all Windows
& Macintosh), Picture Motion Browser Ver.2.1.02
(Windows only)
Operating System Compatibility: Microsoft®
Windows® 2000 Professional, XP Home and
Professional, Vista; Macintosh® OS X (v 10.1.3
or later). OS must be installed at the factory.
Processor
BIONZ™ Engine: Yes w/ Dynamic Range
Optimizer. DRO Modes include Off, Standard,
Advanced Auto, Advanced Manual, Advanced
3-frame bracketing. Advanced Manual include
5 adjustable levels.
Control
ISO: Auto/160/200/400/800/1600/3200/
4000/5000/6400
Dimensions
Weight: 1 lb. 8 oz. (690g) body, not including
battery, lens and media
Measurements: (WHD) 5 5/8" x 4 1/4" x 3
1/4" (141.7 x 104.8 x 79.7 mm) (excl.
protrusions)
Service and Warranty Information
Limited Warranty Term: 1 Year Parts & Labor
Supplied Accessories
DT 18-70mm f3.5 zoom lens (27 - 105 35mm eq)
(SAL-1870)
M-series Lithium-Ion Battery (NP-FM500H)
Battery Charger w/cord (BC-VM10)
Wireless Remote Commander (RMT-DSLR1)
Video Cable
USB Cable
Shoulder strap with eyepiece cap and Remote
Commander clip
Body cap
Accessory shoe cap
Software/USB Driver CD-ROM
NOTE: No Memory Stick media is included.
Color: Black
UPC Code: 027242720992
1: Viewable area, measured diagonally.
2: HD Output requires a Sony® HDMI connector cable; HDTV sold
separately.
3: Actual results may vary based on product settings, usage patterns
and environmental conditions.
© 2008 Sony Electronics, Inc. All rights reserved.
Sony, the Sony logo, Alpha, " α ;", BIONZ, Cyber-shot, Exmor, InfoLithium,
Memory Stick Duo, Memory Stick PRO Duo, Stamina, SteadyShot, and
XtraFine are trademarks of Sony. All other trademarks are trademarks of
their respective owners.
Digital Single Lens Reflex Camera (18-70mm kit)
Please visit the Dealer Network for more
information at www.sony.com/dn
Last Updated: 07/16/2009
