Other Supported Configurations; Unsupported Configurations - Compaq dc5750 - Microtower PC User Manual

Table 5 HP Backup and Recovery
CD Part Number Software Part Number
408640-B22 415500-B2B
408640-B23 415500-B2C
408640-B24 415500-B2D
To order a Recovery Disc Set, go to the following Web site, select your region, and click the Technical
support after you buy link under the Call HP heading to obtain the support center telephone number for
your region. You will need the computer model and serial number of your system before calling.
http://welcome.hp.com/country/us/en/wwcontact_us.html

Other supported configurations

The HP Compaq dc5750 Business PC products support two other RAID configurations:
•
Two hard drive configuration.
• Two equal size/type SATA hard drive RAID configurations in RAID 0 or RAID 1.
• Maximum of two SATA optical drives.
•
Three hard drive configuration (only on HP Compaq dc5750 Microtower).
• Three equal size/type SATA hard drive RAID configurations in RAID 0.
• Maximum of one SATA optical drive.

Unsupported configurations

The HP Compaq dc5750 Business Desktop PC products only support the best user experience and highest
possible reliability. As a result, HP does not support the following combinations of RAID hard drives:
•
Different sizes.
•
Different speeds (5400 rpm, 7200 rpm, etc.).
•
Old and new technologies (SATA 1.5 GB and SATA 3.0 GB).
•
NCQ hard drives and non-NCQ drives.
•
Different cache size.
•
RAID combinations of hard drives with any operating system other than Microsoft XP Pro (SP2) using
Microsoft's IDE driver stack based on ATAPI.SYS and ATI drivers.
HPBR version
2.3i rev B
2.3i rev C
2.3i rev D
9
