Dell Vostro 3360

Setup And Features Information

About Warnings

WARNING: A WARNING indicates a potential for property damage, personal injury, or death.

Front And Back View

Figure 1. Front View

1. microphone (2)

2. camera

3. camera status light

4. display

5. Windows Mobility Center

6. Dell Support Center

7. Dell Instant Launch Manager

8. network connector

9. Secure Digital (SD) 8– in–1 media card reader

10. USB 3.0 connector

11. audio connector

12. fingerprint reader

13. speakers (2)

14. touchpad

15. touchpad buttons (2)

16. wireless status light

17. battery status light

18. hard disk status light

19. power status light

20. touchpad status light

21. keyboard

22. power button

Regulatory Model: P32G

Regulatory Type: P32G001

2012 - 01

Table of Contents

Page 1 5. Windows Mobility Center 17. battery status light 6. Dell Support Center 18. hard disk status light 7. Dell Instant Launch Manager 19. power status light 8. network connector 20. touchpad status light 9. Secure Digital (SD) 8– in–1 media card reader 21.
Page 2: Quick Setup
WARNING: Before you begin any of the procedures in this section, read the safety information that shipped with your computer. For additional best practices information, see www.dell.com/regulatory_compliance. WARNING: The AC adapter works with electrical outlets worldwide. However, power connectors and power strips vary among countries.
Page 3: Specifications
Figure 4. Network Connector Connect USB devices, such as a mouse or keyboard (optional). Figure 5. USB Connector Open the computer display and press the power button to turn on the computer. Figure 6. Power Button NOTE: It is recommended that you turn on and shut down your computer at least once before you install any cards or connect the computer to a docking device or other external device, such as a printer.
Page 4: Finding More Information And Resources
Information in this publication is subject to change without notice. © 2012 Dell Inc. All rights reserved. Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden. Trademarks used in this text: Dell...
