Dell Latitude E6220
Setup And Features Information
About Warnings
WARNING: A WARNING indicates a potential for property damage, personal injury,
or death.
Front And Back View
Figure 1. Front View
1. microphone
2. camera (optional)
3. camera status light (optional)
4. microphone (optional)
5. display
6. power button
7. HDMI connector
8. USB 2.0 connectors (2)
9. wireless switch
10. ExpressCard slot
Regulatory Model Regulatory Model: P15S
2011 – 03

Advertisement

loading

Related Manuals for Dell Latitude E6220

Summary of Contents for Dell Latitude E6220

  • Page 1 Dell Latitude E6220 Setup And Features Information About Warnings WARNING: A WARNING indicates a potential for property damage, personal injury, or death. Front And Back View Figure 1. Front View 1. microphone 6. power button 2. camera (optional) 7. HDMI connector 3.
  • Page 2 WARNING: Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your Dell computer in a low-airflow environment, such as a closed briefcase, while it is running. Restricting the airflow can damage the computer or cause a fire.

  • Page 3: Quick Setup

    WARNING: Before you begin any of the procedures in this section, read the safety information that shipped with your computer. For additional best practices information, see www.dell.com/regulatory_compliance. WARNING: The AC adapter works with electrical outlets worldwide. However, power connectors and power strips vary among countries. Using an incompatible cable or improperly connecting the cable to the power strip or electrical outlet may cause fire or equipment damage.

  • Page 4: Specifications

    Figure 5. USB Connector 4. Open the computer display and press the power button to turn on the computer. Figure 6. Power Button NOTE: It is recommended that you turn on and shut down your computer at least once before you install any cards or connect the computer to a docking device or other external device, such as a printer.
  • Page 5 Video Video controller GT2 Intel HD Graphics 3000 Data bus integrated video Video memory 512 MB Memory Memory connector two SODIMM slots Memory capacity 1 GB, 2 GB, 4 GB, or 8 GB Memory type DDR3 SDRAM (1333 MHz) Minimum memory 1 GB Maximum memory 8 GB...
  • Page 6 Battery Temperature range: Operating 0 °C to 35 °C (32 °F to 95 °F) Non-Operating –40 °C to 65 °C (–40 °F to 149 °F) Coin-cell battery 3 V CR2032 lithium coin cell AC Adapter Type 65 W and 90 W Input voltage 100 VAC to 240 VAC Input current (maximum)

  • Page 7: Finding More Information And Resources

    G1 or lower as defined by ISA- S71.04–1985 Finding More Information and Resources See the safety and regulatory documents that shipped with your computer and the regulatory compliance website at www.dell.com/ regulatory_compliance for more information on: • Safety best practices •...
  • Page 8 Other trademarks and trade names may be used in this publication to refer to either the entities claiming the marks and names or their products, Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.
